PXD1000
1. Turn off your computer and unplug it.
2. Remove the computer's cover to access the PCI bus sockets.
3. Using anti-static precautions, locate an unused PCI socket on the motherboard and
remove its cover plate. (See Chapter 2 for anti-static precautions.)
4. Remove the PXD1000 from the anti-static bag.
E20.000
J2
5. Optional: If you plan to use the PXD1000 for setting triggers, switches, etc., attach the
I/O ribbon cable to the JP5 connector on the PXD1000 card (see diagram).
Note
It is essential that this cable be attached correctly. The red side of the ribbon
cable should face away from the back plane of the PXD1000 and should line up
with pin #1 (see diagram on previous page).
Quick Start Guide
JP5
1
F1
F2
1
J1
