ViewBladder 10 Quick Start Guide

INTRODUCTION TO VIEWBLADDER 10 CONTROLS

A short video can be viewed that describes the functions of each tab by selecting
a specific tab and then selecting Video Help under the Help pull down.
The Help pull down also includes a number of Help Topics to better understand
the capabilities of ViewBladder 10.
ViewBladder 10 Display
The ViewBladder 10 display is divided into three sections:
On the upper left is the Imaging Window. This window displays the ultrasound
scan, and includes measurement data from the scan.
Directly below the imaging window is the Status Window. The status window
displays the Patient information and information about the probe.
On the right side of the screen is the User Interface Section. There are five
tabs: Auto Scan, Adv. Scan, Patient, Settings, and Measure, to adjust the
displayed image, input patient and exam information, set preferences, and
perform measurements. Video Help is available for each tab by selecting a
specific tab and then selecting the Help pull down, Video Help.
Operators can perform all bladder scans and measurements from the Auto Scan
Tab – these functions are discussed here in this Quick Start Guide.
Detailed instructions and safety information are contained in the User Guide.
Note: The blue dot on the upper left side of the image window corresponds to
the blue image orientation/freeze-scan button on the probe.
The blue button on the probe is customarily pointed to the patient's right side for
viewing the bladder.
