VIA Technologies EMIO-3430 Quick Manual

EMIO- - - - 3430 EMIO EMIO EMIO 3430 3430 3430
Quick Guide Quick Guide
Quick Quick Guide Guide
Key Features: Key Features: Key Features: Key Features:
Supports PCMCIA and Card-
•
Bus expansion cards
• Integrated 6W stereo audio
power amplifier
Compatible with EITX-3000
•
Optional support for WiFi,
•
GPS, and Bluetooth
P/N: 99G51-012974-10
Step 3 Step 3 Step 3 Step 3
Align the Em-IO connector on the bottom side of the EMIO-3430 with
the Em-IO connector on the EITX-3000.
Step 4 Step 4 Step 4 Step 4
Connect the module to the board and make sure that nothing
obstructs the mounting holes on the top side of the hex spacers.
The EMIO-3430 Em-IO card supports one PC card slot and three optional
wireless modules. The PC card slot supports PCMCIA or CardBus expan-
sion cards. The three optional wireless modules provide support for
802.11b/g Wireless LAN, GPS, and Bluetooth.
In addition, the EMIO-3430 offers HD Audio quality via a built-in 6W ste-
reo audio power amplifier. The EMIO-3430 is an ideal solution for traffic,
delivery and fleet management, as well as KIOSK and wireless POI applica-
tions.

Specifications:

Specifications:
Specifications: Specifications:
I/O Controllers: I/O Controllers: I/O Controllers: I/O Controllers:
•
VT1211 LPC UART controller
VT6212L PCI USB 2.0 controller
Bridge: Bridge: Bridge: Bridge:
•
Tundra Tsi382 PCIe-to-PCI Bridge
PC Card Interface: PC Card Interface: PC Card Interface: PC Card Interface:
•
Rich R5C803 PC card controller
•
Supports One PC card slot
•
Supports CardBus (32-bit)
•
Supports PCMCIA 2.1 / JEIDA 4.2 (16-bit)
•
• Supports +5V, +3.3V, and +12V @ 120 mA
Audio: Audio:
• Audio: Audio:
TI TPA1517 6W stereo audio power
•
amplifier
3 x 3.5mm TRS jacks: Line-in, Speak-out,
•
Mic-in
Dimensions: Dimensions: Dimensions: 170 mm (W) x 120 mm (L) Dimensions:
•
Operating Temperature: 0°C ~ 60°C Operating Temperature: Operating Temperature: Operating Temperature:
•
Humidity: Humidity: Humidity: Humidity:
•
0% ~ 90% relative humidity, non-condensing
Step 5 Step 5 Step 5 Step 5
Secure the module with the six screws from the EITX-3000.

Packing List:

Packing List: Packing List: Packing List:
EMIO- - - - 3430 EMIO EMIO EMIO 3430 3430- - - - 00A1 3430 00A1 00A1 00A1
1 x EMIO-3430 Em-IO card
•
1 x board-to-board audio cable (P/N: 99G33-190546)
•
• 1 x hex spacer kit (P/N: 99G44-020192)
— 6 x M3*5.5*19mm
1 x quick guide (P/N: 99G51-012974-10)
•
EMIO EMIO EMIO- - - - 3430 EMIO 3430- - - - 01A1 3430 3430 01A1 01A1 01A1
All of the above plus:
• 1 x EMIO-1531 Bluetooth module kit
1 x EMIO-1532 GPS module kit
•
1 x EMIO-1530 WLAN module kit (US version)
•
1 x Software driver and utility CD (P/N: 99G64-021261-100)
•
EMIO EMIO EMIO- - - - 3430 EMIO 3430- - - - 02A1 3430 3430 02A1 02A1 02A1
Same as above except the WLAN module kit is the EU version.

Note:

Note: Note: Note:
Please ensure that all items in the packing list are present
before using this product. If any of the items are missing or
damaged, contact your distributor or sales representative
immediately.
Installing the
2 2 2 2
GPS module
The GPS kit should include the GPS module, two screws, one board-to-
board cable, one mini coaxial cable, one washer, one nut, and one
external antenna.
The optional GPS module includes a Leadtek LR9102 20-channel GPS
receiver.
Installing the
1 1 1 1
EMIO-3430
Step 1 Step 1 Step 1 Step 1
Remove the six screws from the EITX-3000 as indicated in the picture.
Step 2 Step 2 Step 2 Step 2
Replace the screws with the six hex spacers.
Step 1 Step 1 Step 1 Step 1
Align the mounting holes and secure the GPS module to the EMIO-
3430.
Step 2 Step 2 Step 2 Step 2
Then insert the board-to-board cable with the contacts facing down,
as shown in the picture.
