VIA Technologies EMIO-3450 Quick Manual

EMIO- - - - 3450 EMIO EMIO EMIO 3450 3450 3450
Quick Quick Quick Guide Quick Guide Guide Guide

Key Features:

Key Features: Key Features: Key Features:
Compatible with Em-ITX form factor
•
Optional support for WiFi, GPS,
•
Bluetooth, and HSPA/WCDMA/
EDGE/GPRS using miniPCIe module.
Support one SIM slot
•
Integrated 6W stereo audio power
•
amplifier
P/N: 99G51-013064-10
Installing the WLAN Installing the WLAN Installing the WLAN Installing the WLAN
1
module module module module
The WLAN kit should include the WLAN module, two screws, one
board-to-board cable, one mini coaxial cable, one washer, one nut,
and one external antenna.
Step 1 Step 1 Step 1 Step 1
Locate the mounting holes for the WLAN module. The mounting
holes have two standoffs pre-mounted. Then align the two
mounting holes on the WLAN module with the mounting holes
on the standoffs.
Step 2 Step 2
Step 2 Step 2
Secure the WLAN module in place with the two screws provided
with the WLAN kit.
The EMIO-3450 Em-IO card is specially designed for Em-ITX form factor
mainboard. The combinations of both EMIO-3450 card and Em-ITX
mainboard is ideally suited for traffic, delivery, KIOSK, wireless, in-vehicle
system and fleet management applications.
The EMIO-3450 card can support one SIM card slot and four optional
wireless connectivity protocols for proper communication through
expansion modules. The four wireless protocols provide supports for
802.11b/g Wireless LAN, Bluetooth, GPS receiver and mobile network
such as HSPA/WCDMA/EDGE/GPRS. In addition, the EMIO-3450
offers HD Audio quality via a built-in 6W stereo audio power amplifier.

Specifications:

Specifications: Specifications: Specifications:
Bridge: Bridge: Bridge: Bridge:
•
PLX PEX8112 PCIe-to-PCI Bridge
Mini PCIe Interface Mini PCIe Interface Mini PCIe Interface Mini PCIe Interface
•
2 x Mini-PCIe slots
•
SIM slot SIM slot SIM slot SIM slot
•
1 x SIM slot
•
USB USB USB USB
•
2 x USB 2.0 ports connector
•
UART UART UART UART
•
1 x D-sub 9-pin UART port
•
Digital I/O Digital I/O Digital I/O Digital I/O
•
1 x D-sup 9 pin DIO port
•
Digital I/O 5V Output: Digital I/O 5V Output:
Digital I/O 5V Output: Digital I/O 5V Output:
•
1 x 2-Pole Phoenix connector (DC output for exter-
•
nal GPIO device)
Audio: Audio: Audio: Audio:
•
Onboard TI TPA1517, 6W stereo audio power
amplifier
3 x 3.5mm TRS jacks: Line-in, Speak-out, Mic-in
•
Step 3 Step 3
Step 3 Step 3
Insert the one end of the WLAN signal cable into the connector on
the WLAN module. Be sure to have the metal contacts facing
down before inserting.
Step 4 Step 4 Step 4 Step 4
Insert the other end of the WLAN signal cable into the connector
labeled JWLAN1 on the upper board. Be sure to have the metal
contacts facing down before inserting.
Step 5 Step 5 Step 5 Step 5
Secure the WLAN antenna jack to the chassis with the toothed
washer and nut, then attach the antenna Connect the WLAN
antenna cable to the micro RF connector labeled MAIN on the
WLAN module.
WLAN (option): WLAN (option): WLAN (option): WLAN (option):
•
Reserved socket for EMIO-1530 WLAN module.
Supports IEEE802.11b/g
•
Bluetooth (option): Bluetooth (option): Bluetooth (option): Bluetooth (option):
•
Reserved socket for EMIO-1531 Bluetooth module.
Bluetooth core specification version 2.1 compliant
•
+EDR supported module
GPS (option): GPS (option): GPS (option): GPS (option):
•
Reserved socket for EMIO-1532 GPS receiver
module
SirFStarII base of 20-channel GPS receiver
•
Support external antenna
•
3G Mobile Broadband (option): 3G Mobile Broadband (option): 3G Mobile Broadband (option): 3G Mobile Broadband (option):
•
Reserved MiniPCIe slots for mobile broadband
modules that supports HSPA/WCDMA/EDGE/GPRS.
EMIO-1534, Ericsson Mobile Broadband Module
•
F3307, data rate up to 7.2Mbps downlink and
2Mbps uplink.
EMIO-1538, Motorola Mobile Broadband Module
•
HTM1000, data rate up to 10.1Mbps downlink and
5.56Mbps uplink.
Dimensions: Dimensions:
Dimensions: Dimensions:
•
170 mm (W) x 120 mm (L)
•
Operating Temperature: Operating Temperature: Operating Temperature: Operating Temperature:
•
-20°C ~ 70°C
•
With EMIO-1532 module: -20°C ~ 60°C;
•
With EMIO-1530 module: -20°C ~ 60°C
•
Humidity: Humidity: Humidity: Humidity:
•
0% ~ 90% relative humidity, non-condensing
•
Installing the Bluetooth Installing the Bluetooth Installing the Bluetooth Installing the Bluetooth
2
module module module module
The Bluetooth kit should include the Bluetooth module, one screw,
and one board-to-board cable.
The optional Bluetooth module includes a printed antenna and
uses the QCM-QBT400UB Bluetooth controller. The Bluetooth
module is classified as a Class 2 device with an effective range of 10
meters. It supports multi-point operation and a full 7-slave piconet.
Step 1 Step 1 Step 1 Step 1
Locate the mounting hole for the Bluetooth module. The
mounting hole (labeled U31) is located next to the edge of the
upper board near the audio jacks.
Step 2 Step 2 Step 2 Step 2
Align the mounting holes and secure the Bluetooth module to the
EMIO-3450.

Packing List:

Packing List: Packing List: Packing List:
EMIO- - - - 3450 EMIO EMIO EMIO 3450 3450- - - - 00A1 3450 00A1 00A1 00A1
1 x EMIO-3450 Em-IO card
•
1 x Board-to-board audio cable (P/N: 99G33-190376)
•
1 x Board-to-board 2 port USB cable for USB connector
•
(P/N: 99G33-191036)
1 x Board-to-board 1 port USB cable for USB interface WLAN
•
connector (P/N: 99G33-191026)
1 x Hex spacer kit (P/N: 99G44-020192)
•
— 6 x M3*5.5*19mm
1 x Quick guide (P/N: 99G51-013064-10)
•
EMIO EMIO- - - - 3450 EMIO EMIO 3450- - - - 01A1 3450 3450 01A1 01A1 01A1
All of the above plus:
1 x EMIO-1531 Bluetooth module kit
•
1 x EMIO-1532 GPS module kit
•
1 x EMIO-1530 WLAN module kit (US version)
•
1 x Software driver and utility CD (P/N: 99G64-021358-100)
•
EMIO- - - - 3450 EMIO EMIO EMIO 3450- - - - 02A1 3450 3450 02A1 02A1 02A1
Same with EMIO-3450-01A1 except the WLAN module kit is the EU
version.
Note: Note: Note: Note:
Please ensure that all items in the packing list are present
before using this product. If any of the items are missing
or damaged, contact your distributor or sales
representative immediately.
Step 3 Step 3 Step 3 Step 3
Insert one end of the Bluetooth signal cable into the connector on
the Bluetooth module. Be sure to have the metal contacts facing
down before inserting.
Step 4 Step 4 Step 4 Step 4
Insert the other end of the Bluetooth signal cable into the
connector labeled JBT1 on the upper board. Be sure to have the
metal contacts facing down before inserting.
