- Page 1 Innovation in soft start technology agility REMOTE KEYPAD USER GUIDE MAN-AGY-005. Version 01 MAN-AGY-005. Version 01 (01/11/2017)
- Page 2 Enquiries about copyright of Fairford Electronics deliverables should be made to Fairford Electronics Ltd. If, by permission of the copyright owner, any part of this document is quoted, then a statement specifying the original document shall be added to the quotation.
- Page 3 Connection and Operation The remote keypad (AGY-010) can be used to control, monitor and program up to 32 agility soft starters. The unit is powered from the host agility requires an Ethernet cable for communication (Modbus RTU). As the remote keypad acts as the Modbus master, no additional master units must be placed within the network.
- Page 4 MAN-AGY-001 and MAN-AGY-002 (both may be downloaded from www.fairford.co.uk). However, specific steps must be taken to connect the Remote Keypad to one or more agility host units.
- Page 5 Connection and Operation (continued) If any of the Modbus communication parameters are dissimilar on the host unit or remote keypad, communication will not be established. The keypad will display the following screen: Only Right key is active May show: Local, Remote or Modbus By pressing the Right key, the user will be taken directly to the Modbus address selection menu: Use UP / DOWN...
- Page 6 Connection and Operation (continued) Procedure: Modbus address of connected unit 1. Press the ‘Right’ key 2. Address selection screen will be shown 3. Press the ‘Centre’ key. Display will change mode 4. Use ‘Up’ or ‘Down’ keys to change address to the desired number (agility address).
- Page 7 Do not install other equipment that generates significant heat close to the keypad. Firmware Update 1. Download the latest firmware version from www.fairford.co.uk and copy the files to a USB flash drive. 2. Power down the Remote Keypad and insert the USB flash.
- Page 8 MAN-AGY-005. Version 01 (01/11/2017)
