- Page 1 Innovation in soft start technology synergy REMOTE KEYPAD (SGY-010) INSTALLATION GUIDE MAN-AGY-010. Version 02...
- Page 2 Enquiries about copyright of Fairford Electronics deliverables should be made to Fairford Electronics Ltd. If, by permission of the copyright owner, any part of this document is quoted, then a statement specifying the original document shall be added to the quotation.
-
Page 3: Installation
Remote Keypad Setup – SGY-010 Introduction The remote keypad (SGY-010) can be used to control, monitor and program up to 32 synergy soft starters. The remote unit is powered from the host synergy and requires only an Ethernet cable for communication. - Page 4 CABLE15 [ (or CAT5 cable to suit length required) CBL-014 A RJ45 to RJ12 adaptor cable is available from Fairford (part number CBL-014). The use of this adaptor is recommended to ease network installation and reduce the possibility of incorrect wiring.
- Page 5 Remote Keypad Operation Ensure starter’s Modbus Network Settings are: Even parity and 19200 baud rate. If connecting to multiple starters, set the Address to a unique number for each synergy starter. If remote touchscreen start/stop control is desired, set the Control Method to Modbus Control. If the remote touchscreen will only be used for monitoring or configuration (digital input or local touchscreen start/stop control will be used), select the appropriate setting (Local Touchscreen, User Programmable, 2-wire control, or 3-wire control).
