WHEN REPLACEMENT PARTS ARE REQUIRED, BE SURE TO USE REPLACEMENT PARTS SPECIFIED BY THE MANUFACTURER. Proper service and repair is important to the safe, reliable operation of all Hisense Electric Co., Ltd Equipment. The service procedures recommended by Hisense and described in this Service Guide are effective methods of performing service operations.
Hisense, must first satisfy himself thoroughly that neither his safety nor the safe of the equipment will be jeopardized by the service method selected. Hereafter throughout this manual, Hisense Electric Co., Ltd will be referred to as Hisense. 1.1 Warning 1.1.1...
Page 5
that you are connected with the same potential as the mass of the set by a wristband with resistance. Keep components and tools also at this same potential. 1. Never replace modules or other components while the unit is switched on. 2.
Page 6
touch EMI ground part and Heat Sink of Film Filter. (2) Do not supply a voltage higher than that specified to this product. This may damage the product and may cause a fire. (3) Do not use this product in locations where the humidity is extremely high, where it may be splashed with water, or where flammable materials surround it.
otherwise, this can lead to fire or electric shock. (10) If the power connector or the connector of the power cable becomes dirty or dusty, wipe it with a dry cloth. Otherwise, this can lead to fire. (11) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus.
Page 8
equipment and the high voltage power supply block, it can result in electric shock or activation of the leakage-detection circuit breaker. • When installing the LCD module in, and removing it from the packing carton, be sure to have at least two persons perform the work. •...
Page 9
that they are not damaged and their materials do not deteriorate over long periods of time. Therefore, route the cables and fix the cables to the original position and states using the wire clamps. • Perform a safety check when servicing is completed. Verify that the peripherals of the serviced points have not undergone any deterioration during servicing.
2.2 Main Board 5165 (LHD24K26AMN、LHD24K300AMN) - 14 -...
Page 15
Main Board: 5253 (LHD24N10AMN ) Australia MSD1309BT Chassis Series includes model: Model Panel Mode LVDS(Main-Panel) Main board(PCB) V236BJ1-LE1\JK\ROH FFC-30-450-P\ROH 2RSAG7.820.5165\VER.C\ROH LHD24K26AMN LHD24K300AMN V236BJ1-LE1(C2)\ROH FFC-30-450-P\ROH 2RSAG7.820.5165\VER.C\ROH - 15 -...
V236BJ1-LE1(C2/C3) LHD24N10AMN HX2-2×20KLB400-BOE\ROH RSAG2.908.5253\ROH \JK\ROH 3. Factory/Service OSD Menu and Adjustment 3.1 To enter the Factory OSD Menu a. With factory RC (remote control) 1. Press button “M” and enter factory mode.(Note1) 2. Press button “Menu” and enter factory OSD menu. 3.
Page 17
Function Factory Menu TOFAC : M or U White Balance Power Mode Save Auto Calibrate Software Update Function LOGO: Hisense Init OSD language: English Test Pattern PVR RECORD ALL WDT: UART Debug : None White Balance RDRV: GDRV: BDRV RCUT:...
4. Software Upgrading 4.1 Upgrading with the ISP_TOOL 4.1.1 Hardware connecting You can update the software through a special tool (as following) Connect the Debug board to the TV use VGA interface or the RS232 (4 pin), the other USB port to the compute.
Page 19
3、Double click the ISP_TOOL4.5.0.4 icon, and then a dialog window will show as below. 4、Click the” Config “button. And then a dialog window will show as below. Draw on the front of “Use USB” Port Type setting is USB Base Addr setting is 0x38C ISP Slave Address choose 0x92 Serial Debug Slave Address choose 0xB2,...
Page 20
5、Click the “Connect”button,if appear the following figure, It indicates that the ISP_TOOL has connected.(According to the tv set,”Device Type” maybe different.) If appear the following figure,It indicates that the ISP_TOOL has not connected. Please click the“DisCon”button and “Connect”button to connect.. 6、Click the“Read ”button,Choose the correct update file。...
8、Click the “Run” button and wait update end. If show any error message ,then do “Dis Con” >> “Connect”,and click the “Run” button again,till show the following dialog window。 4.2 Upgrading with the USB Software can update with USB device: 1.
5.2 Troubleshooting 5.2.1 Troubleshooting for Remote Control Remote control does not work Try new batteries Replace battery Replace RC Replace remote control Check IR receiver Change Led & IR board Replace Led & IR BD Change Led & IR cable Replace Led &...
Page 24
5.2.2 Troubleshooting for Function Key Buttons does not work Check solder connections and Check switches see if any switches are stuck. Replace Key BD Check key board Check Key BD cable Change Key BD Replace main board - 24 -...
Page 25
BD or Keypad one works Try Power on by RC and Button Check signal Panel Bright Source Neither Both works Work Replace Main Replace Main BD Power on Replace Panel (to contact Hisense tech support.) Replace Power BD - 25 -...
Page 26
5.2.4 Troubleshooting for Audio No sound Reconnect Check connecter Replace speaker wire Check speaker wire Replace speaker set Check speaker set Replace main board Power Supply Board - 26 -...
Page 27
5.2.5 Troubleshooting for TV/VGA/HDMI input No picture on the screen Check Signal Source Make sure signal source is available Reconnect Check connect Replace cable Check cable Replace main board - 27 -...
Page 28
5.2.6 Troubleshooting for YPbPr input No picture on the screen Check Source work or not Check Source Device Reconnect Check connect Check Wires (Green Blue, Red) Replace wires Replace main board - 28 -...
Page 29
5.2.7 Troubleshooting for Video input No picture on the screen Check Source work or not Check Signal Source Reconnect Check connect Replace Cable/Wires Check Cable/ Wires Replace main board - 29 -...
