Summary of Contents for STIGO Stigobike

  • Page 3: Table Of Contents

    4. BEFORE YOU BEGIN 5. OPENING THE BOX 6. MIRROR INSTALLATION (NOT APPLICABLE TO ALL MODELS) 7. STIGO SCOOTER DETAILS 8. STIGO SCOOTER DISPLAY DETAILS 9. HOW TO UNFOLD version1 HOW TO UNFOLD version2 10. HOW TO FOLD 11. STARTING A STIGO 12.

  • Page 4: Box Contents

    Stigo Ltd is limited to the cost of repairing or replacing the failed product or component at the discretion of Stigo Ltd and does not extend to any loss or damage which may be caused as a consequence of misuse or failure of the product.

  • Page 5: Before You Begin

    Stigo scooter for the first time, you will know how to get the most from your Stigo. It is also important that your first ride on a Stigo scooter is taken in a controlled environment, away from traffic and obstacles.

  • Page 6: Mirror Installation (Not Applicable To All Models)

    6. MIRROR INSTALLATION (NOT APPLICABLE TO ALL MODELS) Required tool for mirror mounting (included in the accessory box):4mm Allen key. Remove the endcap from the left side end of the handlebar. Insert the mirror into the handlebar. Fasten the bolt inside the mirror with the supplied Allen key until the mirror is firmly...

  • Page 7: Stigo Scooter Details

    7. STIGO SCOOTER DETAILS Rear lock opening lever Front brake lever Front lock opening lever Light Throttle Horn Frame number. ON/OFF switch Starts with V6G Horn switch Kickstand Mirror Motor Rear brake lever Transportation wheels...

  • Page 8: Stigo Scooter Display Details

    8. STIGO SCOOTER DISPLAY DETAILS Status indicator - white = power on / red = charging / green = fully charged Odometer Speed reading Speed unit Battery level...

  • Page 9: How To Unfold Version1

    9. HOW TO UNFOLD version 1 Hold the Stigo in an upright position. Grabbing the center of the handlebar with your left hand, slightly tilt the Stigo forward and locate the front lock opening lever. Using the other hand, pull the front lock opening lever with your thumb.

  • Page 10: How To Unfold Version2

    CLICK, that locks the mechanism. HOW TO UNFOLD version 2 Hold the Stigo in an upright position. Grabbing the center of the handlebar with your left hand, slightly tilt the Stigo forward and locate the front lock opening lever.
  • Page 11 Using the other hand, pull the front lock opening lever with your thumb. Tilt the Stigo further down and bring the handlebar upwards until your hear the CLICK, that locks the mechanism. Place your right hand on the handle behind the seat.

  • Page 12: How To Fold

    10. HOW TO FOLD Grab the rear lock opening lever. Pull up the lever and at the same time, push down the seat. Keep pushing down the seat until you hear the CLICK, that locks the mechanism.

  • Page 13: Starting A Stigo

    fingers and place your thumb on the front lock opening lever and pull the lever. While lifting the Stigo upwards from the carrying handle, use the other hand to grab the center of the handlebar and bring the fork closer to the frame until you hear the CLICK, that locks the mechanism.
  • Page 14 The bike is unlocked when the display lights up. The Stigo scooter has a twist throttle that is located on the right hand grip. To start moving, twist the throttle backwards, towards you. You control the throttle by twisting it towards yourself. The further you twist, the more power is applied.

  • Page 15: Charging

    To turn off the Stigo scooter, press and hold down the ON/OFF button for 2 seconds until the display switches off. Always keep the RFID key with you in order to prevent unauthor- ized usage. 12. CHARGING Remove the rubber cap from the charging plug and plug in the charger.
  • Page 16 Put back the protective rubber cap. If the Stigo is switched ON while charging, the display will show the battery charging level. There are a total of 8 LEDs indicating the battery level and the...

  • Page 17: Pre-Ride Instructions

    Check that the lights are operating properly. Pull the brakes to see if the brake light is working. Please do not use the Stigo if you believe that it is not functioning properly or it might be damaged in any way.

  • Page 18: Important Components

    In the event that an emergency stop is required, apply both brakes in a safe and controlled way until you have brought the Stigo to a complete stop. Do not release the brakes until it is safe to do so.

  • Page 19: Kickstand

    Using the kickstand – fold it out of its resting position all the way; then support the bike on it and make sure it stands safely. Once you lift the Stigo scooter to a vertical position, the kickstand will automatically fold. Please note that it is a safety feature! The kickstand might not prevent the Stigo electric scooter from falling.

  • Page 20: Frame And Frame Number

    (off-road use, jumping, stunt riding, skidding, etc.). As a result, sudden and/ or premature failure of some components may occur without warning and there may be a risk of injury. If the Stigo has been damaged (besides light cosmetic scratches), dented, bent, cracked or damaged in any other way, do not use the Stigo until it has been checked by an authorized service center.

  • Page 21: Batteries

    Read carefully the information about the battery for safe usage. It is not permitted to use the batteries supplied with the Stigo in any other product. They have been designed for the use of the Stigo only. Do not remove the battery from the Stigo.

  • Page 22: Tires

    Always use proper tires with your Stigo scooter. The correct dimensions are 12 1/2 x 1.75. Make sure that the tires are inflated to the correct pressure shown on the sidewall of the tire. All tires used on the Stigo have to corre- spond to type approval for mopeds.
  • Page 23 Stigo are not designed for slippery conditions. It is not recommended to use the product in rain or wet conditions. If the Stigo gets wet, dry it with a soft microfiber towel or compressed air as soon as you stop riding.
  • Page 24 Do not let your mobile phone, headphones or anything else distract you from paying full attention to your operation of your Stigo scooter. Your insur- ance policies may not provide cover for accidents involving the use of a Stigo scooter/electric ride-on product. To determine if coverage is provided, you should contact your insurance company or agent.

  • Page 25: Warranty

    Do not exceed the weight limit of 100 kg (220 lbs). Rider weight does not necessarily pertain to a person’s size being appropriate for maintaining control of the Stigo electric scooter. The weight limit includes clothing and all luggage. Luggage weight should not exceed 10% of total weight. Exceeding the limit will void warranty and may result in the premature failure.

  • Page 26: Service

    Improper disposal of lithium-ion batteries may result in the battery heating up, rupturing, or igniting which may cause serious injury or fires. The recommended disposal for any Stigo bike at its end-of-life is to dispose of the entire unit at an e-waste recycling center, program, or facility.
  • Page 27 Stigo is a product of Stigo Ltd. Stigo Ltd Müürivahe 22, Tallinn 10141 Estonia www.stigobike.com...
