Wulfsberg C-5000 Installation Manual

Communication management controller
Hide thumbs Also See for C-5000:

Advertisement

Quick Links

Download this manual See also: Installation Manual
C-5000 COMMUNICATION MANAGEMENT CONTROLLER
INSTALLATION MANUAL
Remove this page.
Page 4-54
Publication No. 150-041118
Section 4 – Electrical Installation
Rev C
May 2006

Advertisement

loading
Need help?

Need help?

Do you have a question about the C-5000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wulfsberg C-5000

Summary of Contents for Wulfsberg C-5000

  • Page 1 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page. Page 4-54 Publication No. 150-041118 Section 4 – Electrical Installation Rev C May 2006...
  • Page 2 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page and insert 152-140131 Sheet 8 of 17 (Figure 4-11h) Publication No. 150-041118 Page 4-55 Rev C Section 4 –Electrical Installation May 2006...
  • Page 3 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page. Page 4-56 Publication No. 150-041118 Section 4 – Electrical Installation Rev C May 2006...
  • Page 4 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page and insert 152-140131 Sheet 9 of 17 (Figure 4-11i) Publication No. 150-041118 Page 4-57 Rev C Section 4 –Electrical Installation May 2006...
  • Page 5 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page. Page 4-58 Publication No. 150-041118 Section 4 – Electrical Installation Rev C May 2006...
  • Page 6 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page and insert 152-140131 Sheet 10 of 17 (Figure 4-11j) Publication No. 150-041118 Page 4-59 Rev C Section 4 –Electrical Installation May 2006...
  • Page 7 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page. Page 4-60 Publication No. 150-041118 Section 4 – Electrical Installation Rev C May 2006...
  • Page 8 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page and insert 152-140131 Sheet 11 of 17 (Figure 4-11k) Publication No. 150-041118 Page 4-61 Rev C Section 4 –Electrical Installation May 2006...
  • Page 9 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page. Page 4-62 Publication No. 150-041118 Section 4 – Electrical Installation Rev C May 2006...
  • Page 10 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page and insert 152-140131 Sheet 12 of 17 (Figure 4-11l) Publication No. 150-041118 Page 4-63 Rev C Section 4 –Electrical Installation May 2006...
  • Page 11 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page. Page 4-64 Publication No. 150-041118 Section 4 – Electrical Installation Rev C May 2006...
  • Page 12 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page and insert 152-140131 Sheet 13 of 17 (Figure 4-11m) Publication No. 150-041118 Page 4-65 Rev C Section 4 –Electrical Installation May 2006...
  • Page 13 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page. Page 4-66 Publication No. 150-041118 Section 4 – Electrical Installation Rev C May 2006...
  • Page 14 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page and insert 152-140131 Sheet 14 of 17 (Figure 4-11n) Publication No. 150-041118 Page 4-67 Rev C Section 4 –Electrical Installation May 2006...
  • Page 15 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page. Page 4-68 Publication No. 150-041118 Section 4 – Electrical Installation Rev C May 2006...
  • Page 16 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page and insert 152-140131 Sheet 15 of 17 (Figure 4-11o) Publication No. 150-041118 Page 4-69 Rev C Section 4 –Electrical Installation May 2006...
  • Page 17 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page. Page 4-70 Publication No. 150-041118 Section 4 – Electrical Installation Rev C May 2006...
  • Page 18 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page and insert 152-140131 Sheet 16 of 17 (Figure 4-11p) Publication No. 150-041118 Page 4-71 Rev C Section 4 –Electrical Installation May 2006...
  • Page 19 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page. Page 4-72 Publication No. 150-041118 Section 4 – Electrical Installation Rev C May 2006...
  • Page 20 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page and insert 152-140131 Sheet 17 of 17 (Figure 4-11q) Publication No. 150-041118 Page 4-73 Rev C Section 4 –Electrical Installation May 2006...
  • Page 21 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page. Page 4-74 Publication No. 150-041118 Section 4 – Electrical Installation Rev C May 2006...
  • Page 22 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL F. C-5000 Communication Management Controller Installation Wiring Considerations (1) C-5000 Transceiver (FLEXCOMM I) Connector P501 or P502. Figure 4-12. C-5000 Transceiver (FLEXCOMM I) Connector P501 or P502 Publication No. 150-041118 Page 4-75 Rev C Section 4 –Electrical Installation...

  • Page 23: Table Of Contents

    C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL (2) C-5000 Transceiver (FLEXCOMM I) Connector P501 or P502. SIGNAL NAME SIGNAL NAME TONE C LINE 4 MHZ CHN LINE TX PWR LITE MIC LO/PTT 0.08 MHZ CHN LINE 0.01 MHZ CHN LINE 120 MHZ CHN LINE 0.005 MHZ CHN LINE...

  • Page 24: On/Off

    C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Pin(s) - Signal Name 3, 4, 5, 9, 10, 26, 27, 28, 30, 31, 32, 34, 35, 37, 44, 49, 51, 52, 53, 55, 57 - CHANNEL LINES The channeling lines use BCD (Binary Coded Decimal) negative logic to control the Transceiver channel frequency.
  • Page 25 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Pin(s) - Signal Name 54 - GUARD RX AUDIO DISABLE Grounding this line disables guard audio, but does not affect Main Receiver or sidetone audio. The guard channel indicator continues to indicate guard channel activity.

  • Page 26: Audio Hi

    C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Pin(s) - Signal Name Some possible uses for these include: • Antenna switching • External encoder enable (disable). • External decoder enable (disable). • Any functional or equipment switching associated with a given channel.

  • Page 27: Unsquelched Guard Audio

    C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Pin(s) - Signal Name 21 - UNSQUELCHED MAIN AUDIO This line provides unsquelched audio from the Main Receiver. The frequency response is flat from 60 Hz to 5 kHz. A received signal of 1 kHz tone at ±3 kHz deviation will produce approximately 0.6 Vrms into a 20k Ohm load.
  • Page 28 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page and insert 147-014991 Sheet 1 of 5 (Figure 4-13a) Publication No. 150-041118 Page 4-81 Rev C Section 4 –Electrical Installation May 2006...
  • Page 29 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page. Page 4-82 Publication No. 150-041118 Section 4 – Electrical Installation Rev C May 2006...
  • Page 30 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page and insert 147-014991 Sheet 2 of 5 (Figure 4-13b) Publication No. 150-041118 Page 4-83 Rev C Section 4 –Electrical Installation May 2006...
  • Page 31 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page. Page 4-84 Publication No. 150-041118 Section 4 – Electrical Installation Rev C May 2006...
  • Page 32 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page and insert 147-014991 Sheet 3 of 5 (Figure 4-13c) Publication No. 150-041118 Page 4-85 Rev C Section 4 –Electrical Installation May 2006...
  • Page 33 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page. Page 4-86 Publication No. 150-041118 Section 4 – Electrical Installation Rev C May 2006...
  • Page 34 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page and insert 147-014991 Sheet 4 of 5 (Figure 4-13d) Publication No. 150-041118 Page 4-87 Rev C Section 4 –Electrical Installation May 2006...
  • Page 35 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page. Page 4-88 Publication No. 150-041118 Section 4 – Electrical Installation Rev C May 2006...
  • Page 36 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page and insert 147-014991 Sheet 5 of 5 (Figure 4-13e) Publication No. 150-041118 Page 4-89 Rev C Section 4 –Electrical Installation May 2006...
  • Page 37 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page Page 4-90 Publication No. 150-041118 Section 4 – Electrical Installation Rev C May 2006...
  • Page 38 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL C-5000 Transceiver Interface, RT-9600, RT-9600F, RT-7200 Transceivers (1) Connector P501/P502 Figure 4-14. Connector P501/P502 Publication No. 150-041118 Page 4-91 Rev C Section 4 –Electrical Installation May 2006...

  • Page 39: Tx Pwr Select

    C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL (2) C-5000 Transceiver (RT-9600(F)/7200) Connector P50X (P501, P502, or P503) SIGNAL NAME SIGNAL NAME TONE SELECT C 4 MHZ TX POWER ANNUNCIATE 0.08 MHZ 0.01 MHZ 20 MHZ 0.005 MHZ 80 MHZ GUARD TONE ENABLE TONE E RT7200: 40 MHZ, RT9600(F): .0025...

  • Page 40: Unsquelched Main Audio

    C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Pin(s) - Signal Name 13, 14, 15, 16 - AUDIO AND SIDETONE HI AND LO These wires are provided separately for those systems that have separate transmitter sidetone circuits. They should be paralleled when driving a speaker directly.

  • Page 41: Section 4 – Electrical Installation May

    C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Pin(s) - Signal Name 25 - EXTERNAL GUARD AUDIO INHIBIT When grounded, will mute audio outputs for the guard receiver. 18 - EXTERNAL CTCSS TONE IN Provision for modulating the transmitter with audio outside the normal audio frequency range of 300 to 3000 Hz.
  • Page 42 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page and insert 147-014992 Sheet 1 of 3 (Figure 4-15a) Publication No. 150-041118 Page 4-95 Rev C Section 4 –Electrical Installation May 2006...
  • Page 43 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page. Page 4-96 Publication No. 150-041118 Section 4 – Electrical Installation Rev C May 2006...
  • Page 44 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page and insert 147-014992 Sheet 2 of 3 (Figure 4-15b) Publication No. 150-041118 Page 4-97 Rev C Section 4 –Electrical Installation May 2006...
  • Page 45 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page. Page 4-98 Publication No. 150-041118 Section 4 – Electrical Installation Rev C May 2006...
  • Page 46 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page and insert 147-014992 Sheet 3 of 3 (Figure 4-15c) Publication No. 150-041118 Page 4-99 Rev C Section 4 –Electrical Installation May 2006...
  • Page 47 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page. Page 4-100 Publication No. 150-041118 Section 4 – Electrical Installation Rev C May 2006...
  • Page 48 In addition, Pin 17 from each P501 connector must go to a switch that grounds one or the other Pin 17. When the C-5000 sees a ground on Pin 17 of its P501 connector, it gives up control of the RT-5000 to the other C-5000. The display of the control head without control will indicate "NO CONTROL"...
  • Page 49 If an operator wants to control RT-5000 #1 with C-5000 #1, they put the Take_Control switch for radio #1 in the position that grounds pin 17 of P501 on C-5000 #2. At this point, C-5000 #2 gives up control of RT-5000 #1 and displays "NO CONTROL" on the top line of its display.
  • Page 50 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL All the above boils down to the following: To use RT-5000 #1, put the "Take_Control" switch in the position so the operators control head shows the status of RT-5000 #1. To transmit, put the audio panel on FM1. Do the same for transceiver #2 except use Take_Control switch for RT-5000 #2 and then select FM2 on the audio panel.
  • Page 51 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Figure 4-16 Dual C-5000/RT-5000 with Take_Control Block Diagram Page 4-104 Publication No. 150-041118 Section 4 – Electrical Installation Rev C May 2006...
  • Page 52 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page and insert 124-015911 Sheet 1 of 2 (Figure 4-17a) Publication No. 150-041118 Page 4-105 Rev C Section 4 –Electrical Installation May 2006...
  • Page 53 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page. Page 4-106 Publication No. 150-041118 Section 4 – Electrical Installation Rev C May 2006...
  • Page 54 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page and insert 124-015911 Sheet 2 of 2 (Figure 4-17b) Publication No. 150-041118 Page 4-107 Rev C Section 4 –Electrical Installation May 2006...
  • Page 55 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page. Page 4-108 Publication No. 150-041118 Section 4 – Electrical Installation Rev C May 2006...
  • Page 56 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page and insert 124-015910 Sheet 1 of 1 (Figure 4-18) Publication No. 150-041118 Page 4-109 Rev C Section 4 –Electrical Installation May 2006...
  • Page 57 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page. Page 4-110 Publication No. 150-041118 Section 4 – Electrical Installation Rev C May 2006...
  • Page 58 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page and insert 152-241520 Sheet 1 of 1 (Figure 4-19) Publication No. 150-041118 Page 4-111 Rev C Section 4 –Electrical Installation May 2006...
  • Page 59 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Remove this page. Page 4-112 Publication No. 150-041118 Section 4 – Electrical Installation Rev C May 2006...
  • Page 60 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Item Designator Description Wulfsberg P/N Mil Spec P/N Radio & Control Supplies C-5000 System P500 D-Sub (62 Pin female, with backshell and two PN 129-215344-01 Interface male jackscrews) Connector Radio Option 1: P501 and/or...
  • Page 61 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Item Designator Description Wulfsberg P/N Mil Spec P/N Non RT-5000 Radio Install Supplies IN-210 Connector & Tray, Flexcomm™ I 149-0059-000 Connector IN-210-1 Kit Includes: Mil-Circ, 61 Pin female, 149-0059-001 Flexcomm™ I Tray MT-210 Kit Includes: Mounting Tray, Flexcomm™ I...
  • Page 62 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Item Designator Description Wulfsberg P/N Mil Spec P/N AT-550 / AT-560 / AT-5000 Hi-Split J401 TNC (Plug, straight) for use with RG-393 coax) 129-041397-01 Connector TNC (Plug, 90 degree) for use with RG-393 coax)
  • Page 63 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Item Designator Description Wulfsberg P/N Mil Spec P/N Flexcomm I System converting to Flexcomm II System Special Adapters Adapter Cable Harness/Transceiver/Antenna Tuner 153-041054 Adapter Cable C-5000 Parallel to Serial 153-041055 Adapter Cable FC-5000 to AT-560...
  • Page 64 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL SECTION 5 – CONFIGURATION AND PROGRAMMING Introduction Refer to the Operator’s Manual, P/N 150-041102, for more information. Publication No. 150-041118 Page 5-1 Rev. C Section 5 – Configuration and Programming May 2006...
  • Page 65 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL This page intentionally left blank. Page 5-2 Publication No. 150-041118 Section 5 – Configuration and Programming Rev. C May 2006...
  • Page 66 Perform Step 6 for all Transceivers in the system. This will verify that all radios are connected, powered up, and able to send audio to the control head. NOTE: If the C-5000 does not allow the input of the specific RT-5000 part number, use the table on the following page for alternative input options.
  • Page 67 Select Transceiver #1 using the audio panel and attempt to transmit to a known good receiver (Both the transmitter and the receiver must be using the same frequency). Press the aircraft PTT switch and verify that the C-5000 display shows a transmit condition and that the receiver detects a valid voice signal.
  • Page 68 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL RT-5000 Alternative Input Options (cont’d) Actual RT-5000 Alternate RT-5000 Part Number Part Number 1811 1911 2011 2111 2211 2311 2411 2511 2611 1011 2711 1211 2811 0611 2911 0611 3011 1211 3111 1311 3211...
  • Page 69 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL This page intentionally left blank. Page 6-4 Publication No. 150-041118 Section 6 – System Verification Procedure Rev C May 2006...
  • Page 70 SECTION 7 - SYSTEM CHECKOUT General This section contains a system checkout procedure to verify the operation of the C-5000 and transceiver installation. The following procedures are intended to provide sufficient exercising of the system configuration to assure that system parameter selection/control and transmit/receive functions are operating properly.
  • Page 71 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL The C-5000 can control up to two radio systems composed of various Wulfsberg radios. It is the responsibility of the installer to understand the capabilities of the individual transceivers and associated antenna systems. The C-5000 must be programmed with configuration information BEFORE it will properly communicate with any transceivers.
  • Page 72 (a) On the C-5000, tune transceiver system #1 to the manual channel. Using the "EDIT" page on the C-5000 tune the manual channel for 30 MHz Rx and Tx frequency, set Tx Power to Hi, and the Bandwidth to "S", no subaudible tone.
  • Page 73 400 MHz use the "TNC" RF connector. Use the manual channel on the C-5000 to tune the transceiver. Verify RT #1 by varying the input signal until 12 dB sinad is measured. The signal level should be < .6μV for all FM Channels.
  • Page 74 C. Encryption Verification (1) If any of the ITM modules use encryption, verify loading encryption keys. See C-5000 Operator's manual for instructions on how to set up the RT-5000 to receive encryption keys (KVL Load). (2) If the ITM module is capable of performing an OTAR and the location the system checkout can access an OTARable station, test this function on all applicable ITM's.
  • Page 75 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Installation Checkout Data Tables and Checklist Date: _________________ Operator: ______________ Installation Number: ____________ C-5000 Part Number: _________________(31300-1X02-XXXX) Transceiver #1 Model #: ________________________________________ (RT-5000, RT-30, RT-138(F), RT-450, RT-406F, RT-9600, RT-7200) Transceiver #1 Part Number: _________________________________________...
  • Page 76 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Step 6 C-5000 Preset Channels Program Verification ___________ Preset Channels Programmed into C-5000 (yes/no) Step 7 Transceiver Communications and Receiver audio/indicator Tests ___________ RT #1 Main Receiver Squelch Test OK, Volume Adjustable ___________ RT #1 Guard Squelch Test OK...
  • Page 77 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Step 10 Antenna Forward/Reflected Power Tests (Record Data In Tables 7-XX) ________ RT #1 Antenna Forward vs. Reflected Power OK (Record Data in Tables 7-XX) ___________ RT #2 Antenna Forward vs. Reflected Power OK (yes/no, see data sheet)
  • Page 78 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Step 13 Internal Encryption Keyload Verification ___________ RT #1 VHFXXX ITM Encryption Keyload OK ___________ RT #1 VHFXXX ITM Encryption Keyload OK ___________ RT #2 VHFXXX ITM Encryption Keyload OK ___________ RT #2 VHFXXX ITM Encryption Keyload OK...
  • Page 79 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Transmitter Test Data Sheet Table 7-1. RT-30 Transceiver Test Frequencies Frequency(MHz) Power Out (Watts) Modulation (Hz) Forward Power Reflected Power 30.000 34.110 41.220 45.440 48.880 Table 7-2. RT-138(F) Transceiver Test Frequencies Frequency(MHz) Power Out (Watts)
  • Page 80 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Table 7-4. RT-450 Transceiver Test Frequencies Frequency(MHz) Power Out (Watts) Modulation (Hz) Forward Power Reflected Power 450.110 451.222 462.445 464.887 468.000 469.990 Table 7-5. RT-5000 Transceiver Lo Split (29.7 to 399.999 MHz) Test Frequencies...
  • Page 81 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL RECEIVER TEST DATA SHEET Table 7-7. RT-30 Transceiver Test Frequencies Frequency(MHz) Sensitivity (.6μV) 30.000 34.110 41.220 45.440 48.880 Table 7-8. RT-138(F) Transceiver Test Frequencies Frequency(MHz) Sensitivity (.6μV) 138.110 142.222 144.445 158.887 160.000 165.000 Table 7-9. RT-406F Transceiver Test Frequencies Frequency(MHz) Sensitivity (.6μV)
  • Page 82 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Table 7-10. RT-450 Transceiver Test Frequencies Frequency(MHz) Sensitivity (.6μV) 450.110 451.222 462.445 464.887 468.000 469.990 Table 7-11. RT-5000 Transceiver Lo Split (29.7 to 399.999 MHz) Test Frequencies Frequency(MHz) Sensitivity (.6μV) 30.100 50.100 70.100 140.100 173.100...
  • Page 83 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL This page intentionally left blank. Page 7-14 Publication No. 150-041118 Section 7 – System Checkout Rev C May 2006...
  • Page 84 5000 control head, a RT-5000, RT-30, RT-138F, RT-450 and/or a RT-406 radio (control of non-current production units such as the RT-7200, RT-9600, and RT-9600F is possible with the C-5000 control head) and suitable antennas. The recommended maintenance cycle is one year.
  • Page 85 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL F. Set the Service Monitor to receive the transmit frequency of the selected channel. Connect the output of the radio under test to the Service Monitor RF input port with a cable less than three feet in length (refer to the Service Monitor User’s Manual).
  • Page 86 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL B. Place an AT-150 or similar broad band antenna 10 feet from the aircraft antenna. The antenna should be at the same elevation and have the same polarity as the antenna on the aircraft.
  • Page 87 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL This page intentionally left blank. Page A-4 Publication No. 150-041118 Appendix A Rev. C May 2006...
  • Page 88 VHF 138-174 (Federal Government), UHF 403-470 (Federal & State/Local), UHF 450-512 (State & Local), and 800 MHz band. However, the C-5000 that is used with this model of radio is limited to controlling two transceiver systems. This system is labeled "Configuration #2"...
  • Page 89 (6) Run the two new coax cables from the radio to the antenna. (7) Run the Antenna tuning cable from the FC-5000 to the AT-560. (8) Install Adapter Cable #2. (9) Configure and program the C-5000. (10) Verify system performance via test equipment and/or flight testing. Page B-2 Publication No.
  • Page 90 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Figure B-1. Current Configuration (Basic RT-5000) Publication No. 150-041118 Page B-3 Rev. C Appendix B May 2006...
  • Page 91 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Figure B-2. Configuration #1 (Basic RT-5000) Page B-4 Publication No. 150-041118 Appendix B Rev. C May 2006...
  • Page 92 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Figure B-3. Configuration #2 (VHF and/or UHF Digital RT-5000) Publication No. 150-041118 Page B-5 Rev. C Appendix B May 2006...
  • Page 93 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Figure B-4. Adapter Cables & Plates (Allows use of existing harness) Page B-6 Publication No. 150-041118 Appendix B Rev. C May 2006...
  • Page 94 Requires 1 ea of the following ten (10) items (see install instructions) PART NUMBER DESCRIPTION 153-041054-01 Adapter Cable, Harness/Transceiver/Antenna Tuner 153-041055-01 Adapter Cable, C-5000 Parallel to Serial 153-041056-01 Adapter Cable, FC-5000 to AT-560 153-041057-01 Adapter Cable, Coax Antenna Cable RG-142 153-041058-01...
  • Page 95 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Figure B-5. FLEXCOMM I / FLEXCOMM II Cable Adapter (Sheet 1 of 1) Dwg No. 153-041056, Rev C Page B-8 Publication No. 150-041118 Appendix B Rev. C May 2006...
  • Page 96 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Figure B-6. Installation Wiring Diagram FLEXCOMM I / FLEXCOMM II Cable Adapters (Sheet 1 of 1) Dwg No. 152-241316, Rev B Publication No. 150-041118 Page B-9 Rev. C Appendix B May 2006...
  • Page 97 C-5000 COMMUNICATION MANAGEMENT CONTROLLER INSTALLATION MANUAL Figure B-7. Cable Assembly FLEXCOMM I Single to Dual Cable Adapter (Sheet 1 of 1) Dwg No. 124-041326, Rev C Page B-10 Publication No. 150-041118 Appendix B Rev. C May 2006...
