3. Mounting

3.1 Mounting Without Rainy Cover

PA3*25

3.2 With Rainy Cover and 30 degree angle

PA4*25
Note:Both rainy cover and 30 degree angle accessories are supplied seperately.
1
1
PM3*12
TX20-4*10
2
TX20-4*10
-2-
2
3
3
4
