Page 1 NeoGSM-IP Control panel with GSM / IP communication. Installation Guide (DTR). Ropam Elektronik Tel. +48 12 272 39 71 Polanka 301 www.ropam.com.pl Document version : 1.0 32-400 Myślenice, Polska Faks +48 12 379 34 10 biuro@ropam.com.pl 2018-04-01...
Page 2 - according to the application. The device is a source of electromagnetic waves, so in specific configurations it can interfere with other radio devices). The Ropam Elektronik company is not responsible for the malfunctioning of the GSM network and the consequences of possible technical problems. WEEE LABELING Waste electrical and electronic equipment must not be disposed of with normal household waste.
Page 3: Table Of Contents
Local TCP / IP configuration (GPRS)..................23 Remote configuration TCP / IP / GPRS..................24 Firmware upgrade........................26 Update methods........................26 Additional modules and extensions................... 30 EXP-LAN ........................... 30 Connection of the EXP-LAN module..................30 © 2018 Ropam Elektronik...
Page 4 Send the USSD code to the GSM network..............44 Send a test SMS......................44 Timers 1-4........................44 Internet module....................... 45 Show network status....................46 SSID: ........................... 46 WPA: ........................... 46 Module restart......................46 QR-code ........................47 © 2018 Ropam Elektronik...
Page 5 EXP-O8T-RN ..........................64 General description........................ 64 Properties........................... 64 Destiny..........................64 Warnings..........................64 Module description......................... 65 Module version........................65 Construction and description..................... 65 Optical signaling of the state....................66 © 2018 Ropam Elektronik...
Page 6 Construction and description..................... 73 Assembly and installation...................... 73 Basic requirements......................73 Installing the controller....................... 74 Configuration......................... 74 Configuration: NeoGSMIPManager................... 74 NeoGSMIPManager: AP-Aero..................74 Technical parameters......................77 Keyfob-Aero ..........................78 © 2018 Ropam Elektronik...
Page 7 Description and operation of IO-Aero module..............86 Installation and programming of the IO module..............87 Reset procedure for lips factory..................88 Configuration......................... 88 Configuration: NeoGSMIPManager................... 88 NeoGSMIPManager: AP-Aero..................88 System maintenance......................90 Technical parameters......................90 © 2018 Ropam Elektronik...
Page 8 Requirements, installation....................100 Basic requirements......................100 Installation..........................100 Preparing the system for work..................100 Connecting the module to the control panel..............101 List of devices cooperating with the module..............101 © 2018 Ropam Elektronik...
Page 9 Tab: Modules, touch panels....................123 TPR touch panel......................124 Other settings ....................... 125 Expander EXP-I8......................125 APx-Aero.......................... 126 RF-4..........................127 PSR-ECO-xx........................128 EXP-I8-RN........................129 EXP-O8x-RN (EXP-O8R-RN lub EXP-O8T-RN)............. 129 © 2018 Ropam Elektronik...
Page 10 Starting values......................... 174 Preview of the script......................175 Simulator.......................... 176 Application notes......................176 Tab: Event memory......................176 Tab: Online preview......................177 System maintenance....................... 180 Technical parameters......................181 Version history......................... 183 © 2018 Ropam Elektronik...
Page 11: General Description
- a version in the housing for the DIN rail is also available. Appliance. The alarm system built on the basis of NeoGSM-IP series alarm panels, TPR-xx touch panel and other additional devices is an ideal solution for residential buildings and small commercial facilities.
Page 12: Warnings
• intelligent lighting, Warnings. Ropam Elektronik devices are part of a full alarm system, whose effectiveness depends on the quality and technical condition of all devices (detectors, signaling devices), cabling, etc. included in the system. The user is obliged to periodically test the operation of the alarm system. It is necessary to check whether the control panel reacts to the violation of individual detectors (PIR, reed switches, etc.) or signaling...
Page 13: Requirements For Sms, Dtmf Control
To control the DTMF phone, the smartphone must be able to generate DTMF tones during a phone call. A single DTMF code (pressing the sign) should last for a minimum of 0.5s. © 2018 Ropam Elektronik...
Page 14: System Description
Alarm control panel with GSM communication and building automation functions: SMS / VOICE / CLIP / GPRS / WIFI / E-MAIL, 12VDC *, PSR-ECO x1, TELx8, BIx8-32, BOx8-24, AI, TEMPx2, Aero x16, PCB, housing DIN 9M GPRS monitoring, ThermostatGSM, KeyGSM, LoggerTemp. LogicProcessor. © 2018 Ropam Elektronik...
Page 15: Description Of Connectors And Components
System description. Str. 05 Description of connectors and components. View: NeoGSM-IP-PS PCB. View: NeoGSM-IP PCB. © 2018 Ropam Elektronik...
Page 16 Connector / element Description / Function connector for connecting the PSR-ECO-5012-RS power supply; power power terminal NeoGSM-IP-PS = 16 ÷ 20V / AC or 20 ÷ 30V / DC * controlled transistor outputs, high-current 12V / 1A, O1÷O2 second load terminal: GND, (control of the continuity of the circuit, connection of the signaling device) controlled transistor outputs, OpenCollector (OC, GND / 0.1A)
Page 17: Optical Signalling Of The State
• blinking alternately SEND NOTIFICATION by SMS -1 flash = sending SMS to NUMBER 1, ... and INCOM = restoring 8 flashes = sending SMS to NUMBER 8, copies of settings from AUDIT NOTIFICATION EEPROM (configuration error checksum) © 2018 Ropam Elektronik...
Page 18 23 - FLASH memory error (serial) 24 - RTC clock chip error 25 - failure of the motherboard inputs 26 - internal error of the MCU microcontroller 27 - blocking of SMS / CALL / E-MAIL, exceeding 24h counter © 2018 Ropam Elektronik...
Page 19 Blue • shines = AP access mode, • blinks = client mode, • shines = there is internet, INTERN Yellow • no light = no internet, • blinks = sending data on the RopamNET Green bus, © 2018 Ropam Elektronik...
Page 20: Installation And Commissioning
3. Installation and commissioning. Basic requirements. The system built on the basis of the NeoGSM-IP control panel, touch panels and other required elements are intended for assembly by a qualified installer, holding appropriate (required and necessary for a given country) permits and licenses to connect (interfere) 230V / AC installations and low-voltage installations.
Page 21: Connection Of The Ropamnet Bus
1 pair will lead the bus to the device and the other will go out to the next one. Devices with RopamNET bus: Control panel Expander NeoGSM-IP TPR-4 RF-4x APx-Aero PSR-ECO-5012-xx EXP-I8-RN-xx EXP-O8R-RN-xx © 2018 Ropam Elektronik...
Page 22 Installation and commissioning. Str. 12 1. Alarm panel + one device on the bus. Control panel Expander +12V JT= ON JT/Rt= ON 2. NeoGSM-IP control panel + three and more devices on the bus. Expander Control panel Expander Expander +12V +12V +12V...
Page 23: Connecting Devices To Inputs
- anti-tamper contacts: signaling devices, casings, etc. Device Number of inputs Max. quantity in the system NeoGSM-IP-xx EXP-I8 EXP-I8-RN-xx TPR-xx Input in configuration: NC Input in configuration: NO. Input in configuration: EOL (diagram with a tamper contact). © 2018 Ropam Elektronik...
Page 24: Connection Of Devices To Outputs
EXP-O8R-RN-D9M O1-O8: 230VAC / 8A electrical devices. O1- O2, outputs with full OCP short-circuit potential, transistor EXP-O8T-RN-xx protection, OLP overload O1-O8: OpenDrain GND type / 0.7A protection and overvoltage OVP. TPR-xx potential-free, relay30VDC/1A RF-4 potential-free, relay © 2018 Ropam Elektronik...
Page 25 O1-O2 output of NeoGSM-IP board: connection as power supply, eg signaling device. O1-O2 output of NeoGSM-IP board: connection of 12V DC relay. O3-O8 output of NeoGSM-IP board: connection of 12VDC / 100mA signaling siren max. (acoustic and / or optical).
Page 26: Connecting The Signal To The Ai Input
0-10. The input can be used to measure the DC voltage, e.g. via a voltage divider. The reference potential for the AI input is GND, the mass of the measuring system must be connected to the GND NeoGSM-IP terminal. The input has the option of scaling to a physical value (two-point). © 2018 Ropam Elektronik...
Page 27: Connection Of Temperature Sensors
AI input: connection of a 0-10V voltage signal relative to common GND ground (asymmetric). Connection of temperature sensors. The system supports 2 temperature sensors, wired. On the NeoGSM-IP board there are dedicated connectors for power supply and communication with sensors of the TSR-1 series.
Page 28: Connecting The Power Supply To The Control Panel
Installation and commissioning. Str. 18 Connecting the power supply to the control panel. The control panel is available in two power versions, NeoGSM-IP: - PSR-ECO-5012-RS power supply required or power supply PSR-ECO-2012 © 2018 Ropam Elektronik...
Page 29 NeoGSM-IP-PS = 16÷20V/AC or 20÷30V/DC In the alarm control panel application, a supervised power supply must be used, ie: NeoGSM-IP-PS or NeoGSM-IP + PSR-ECO-5012-RS / PSR-ECO-2012. The choice depends on the current balance of the system, temperature and working conditions, efficiency requirements.
Page 30: Installation And Start-Up Procedure
Connector / Description / Function element +/~ V -/~ NeoGSM-IP-PS = 16 ÷ 20V / AC or 20 ÷ 30V / DC (according to polarization). NeoGSM-IP: connector for connecting the PSR-ECO-5012-RS power supply; (power supply and RopamNET) (if the PSR-ECO-5012-RS is used, the + V- terminals should be left unused) Installation and start-up procedure.
Page 31: The Reset Procedure Of The Control Panel To The Factory Settings
RESET (jumper) Comments: After the reset, the control panel is restored to factory settings, no modules are stored in memory. TCP / IP encryption key after reset to factory settings = ID plate (character size is important). © 2018 Ropam Elektronik...
Page 32: System Configuration
6. Perform tests and trials, go to the "Online Preview" tab to check the system status, among others: failures, input operation, output control, GSM status, temperature measurement, etc. © 2018 Ropam Elektronik...
Page 33: Local Tcp / Ip Configuration (Gprs)
1. Start the NeoGSMIPManager program. 2. Make sure that the PC is in the same network as the NeoGSM-IP control panel. Default WiFi settings of control panel. 3. Select the connection mode "2. Local TCP / IP connection".
Page 34: Remote Configuration Tcp / Ip / Gprs
NeoGSM-IP panel). 8. Press the button 9. The NeoGSM IP Manager program searches for available NeoGSM-IP exchanges in the field of the IP network addresses of the computer, a window with the found IP address appears. (manual editing is possible).
Page 35 6. You can also open the settings file * .rpn which will load the ID and key automatically. 7. Press the button 8. The NeoGSMIPManager program searches the exchanges on the RopamBridge server. 9. Send an SMS to the control panel saying "connect service password" (eg "123B connect"). © 2018 Ropam Elektronik...
Page 36: Firmware Upgrade
The update takes place using a micro USB cable and is possible even in the absence of internet or online update failure (upgrade firmware required). Requirements: - connection of the computer with the control panel by means of a micro USB cable, - Ensuring continuous power supply to the control panel without interruption. © 2018 Ropam Elektronik...
Page 37 Save the firmware file to disk - saves the downloaded firmware file to the local disk. • Select ... - allows you to select the update file located on the local disk. • Update - starts the update process. 2. Online update using the NeoGSMIPManager program. © 2018 Ropam Elektronik...
Page 38 The update process takes about 5 minutes. 3. Update using the TPR4 panel. Requirements: - Connection of the control panel to the Wifi or Ethernet Internet network. - Ensuring continuous power supply to the control panel without interruption. © 2018 Ropam Elektronik...
Page 39 "Check new firmware" - checks the latest available version of the software on the Ropam server. After pressing "OK" a window appears: • Clicking the confirmation starts updating the control panel. The update process takes about 5 minutes. © 2018 Ropam Elektronik...
Page 40: Additional Modules And Extensions
System configuration. Str. 30 5. Additional modules and extensions. EXP-LAN Ethernet Expander for NeoGSM-IP - allows connection of the control panel to the local network via a wired connection. - Ethernet port: 10/100 BaseT, RJ45, - compatibility: NeoGSM-IP, - PCB local module, mounted on the board, - installing EXP-LAN disables WIFI communication in the control panel, Connection of the EXP-LAN module.
Page 41: General Description
/ home automation has never been as easy as with the TPR-4 series touch panels. The touch panel in connection with the series control panels: NeoGSM-IP allows you to build a fully functional alarm system / home automation.
Page 42: Description Of The Touch Panel
• esthetic and solid housing in white or black • tamper protection of the casing • detachable terminal strips • cooperation with the NeoGSM-IP control panel Construction of the TPR-4 touch panel. The TPR-4 touch panel in a surface-mounted housing consists of:...
Page 43: View And Dimensioning Of The Panel
On the back of the device there is a hole that can be used to feed power and signal wires to the panel. The aesthetic design, easy-to-install housing and ergonomic connections make the installation and operation of the device easy and uncomplicated operation. Dimensioning and panel view: © 2018 Ropam Elektronik...
Page 44: Installation And Commissioning
The remaining connections should be made in accordance with the device manufacturer's instructions, and if there are no such cables, the following cables can be used: • YTDY, YTLZ, • UTP, STP, FTP, • YTSKY, • other low-current, compliant with regulations and standards. © 2018 Ropam Elektronik...
Page 45 TPR-4 connection. The minimum supply voltage at the terminals of a given TP can not be lower than 9V / DC (ie at a minimum battery voltage of 9.5V-10.0V, the drop on the power supply wires can not be greater than 0.5V). Signal To 150m. To 300m. 2x0,5 (1 pair) 2x0,5 (1 pair) © 2018 Ropam Elektronik...
Page 46: Panel Connection
6. Assemble the TPR-4 panel (e) in reverse order of point 2. 7. Perform the remaining actions and connections in the system (GSM control panel, detectors, signaling devices). 8. Turn on the system power supply (230V / AC). © 2018 Ropam Elektronik...
Page 47: Configuration Of Tpr-4 Touch Panels
• from the NeoGSM-IPManager program (locally or remotely - RopamBridge, Local server) Main menu of the TPR-4 touch panel (default setting of icons): TPR-4 configuration: user menu. User screen - NeoGSM-IP system Window view with user settings for the TPR-4 panel: © 2018 Ropam Elektronik...
Page 48: Set The Clock
Brightness of the screensaver. Adjust the brightness of the screen saver for the digital photo frame (when the current SD card with photos) or the brightness of the clock with a date stamp on the display screen. © 2018 Ropam Elektronik...
Page 49: Service Access
Temperature settings for individual thermostats - temperature sensors (2 independent in the NeoGSM- IP system). The upper temperature values are Tx (a) The lower temperatures are Tx (b) After selecting a window with the temperature settings of a given sensor, the temperature settings window opens: © 2018 Ropam Elektronik...
Page 50: Room Thermostats
Str. 40 Room thermostats. The function allows setting two independent thermostats based on temperature sensors connected to the NeoGSM-IP system. Room thermostats allow you to control the climate in rooms according to a set time and temperature schedule. This functionality also allows significant energy savings in the building (no space heating during absence of household members, switching on the heating before returning to the rooms, room ventilation function ensures access of fresh air to the building according to a specified schedule).
Page 51 Thermostat view from the TPR-4 panel: Explanation of the meaning of thermostat icons: Icon Explanation Entering the manual temperature control mode. It is also attached after sending an SMS saying "Heating" Heating mode - higher temperature Information: Heating mode included © 2018 Ropam Elektronik...
Page 52 Thermostat settings icon (temperature profiles, weekly program). Changing the settings changes the temperature and calendar parameters according to the settings and saves these settings in the control panel. © 2018 Ropam Elektronik...
Page 53: Ussd Codes, Test Sms
Thermostat settings from the TPR-4 panel: Menu for setting temperature profiles: Calendar settings menu for room thermostat: USSD codes, test SMS. Convenience allowing access to the system test functions from the touch panel level in NeoGSM- IPManager systems. © 2018 Ropam Elektronik...
Page 54: Introduction Of The Ussd Code
Sends an SMS entered using the keypad on the touch panel to the first user on the list of numbers in the system. The function gives the possibility to test the operation of SMS commands in the system. Timers 1-4. Available timer modes for the NeoGSM-IP system are: - constant - daily - weekly...
Page 55: Internet Module
If you try to edit such a timer using the TPR-4 panel, the following message will be displayed: Internet module. TCP / IP module configuration window. It allows you to read the module data: - network status - sending an SSID - sending a WPA encryption key - module restart - QR code © 2018 Ropam Elektronik...
Page 56: Show Network Status
SSID: The name of the WiFi network to which the Internet module is to login. WPA: Security key for WiFi networks. Module restart. Internet module restart option, required when the module does not respond too long. © 2018 Ropam Elektronik...
Page 57: Qr-Code
The service mode is indicated by the blinking of the red and yellow LEDs. For other windows / keyboards: Window type / Keyboard Confirmation of the function Exit the function Numerical ENTER Full Graphic Window view with service settings for the TPR-4 panel: © 2018 Ropam Elektronik...
Page 58: Settings
256 (8bit) or 16 mln. (24bit), in addition, the touch panel version information is displayed. TPR-4 configuration: NeoGSM-IPManager. The first installation or addition of TPR4 to the NeoGSM-IP system requires the identification of connected devices. "Identification of connected devices" (Modules tab, TPR panels)
Page 59 (i) individually from the level of the tab: touch panel. Main menu of touch panel settings: Menu for setting display options, controlling outputs and temperature visibility from individual sensors (1-4). © 2018 Ropam Elektronik...
Page 60: Tab: Touch Panel / Settings
• Relay control requires a code: the active option will require the user to enter the code at the entrance to the relay output control function in the given TP panel. © 2018 Ropam Elektronik...
Page 61: Tab: Touch Panel / Other Settings
• Show temperature from selected sensors: the option allows you to select temperature sensors connected to T1-T2 inputs in the NeoGSM-IP control panel and display temperatures on the top bar of the display and in the screensaver mode at the bottom of the screen.
Page 62 System configuration. Str. 52 Each of the icons on any screen may have an additional description, which will be visible on the touch panel in the same way as in the program: © 2018 Ropam Elektronik...
Page 63: Description And Functions Of Icons
Preview of the zone status (violation, tamper, OK). Building plan preview (requires a MicroSD card with files: plan1.bmp to plan4.bmp). Possibility to edit the layout of detectors on the set from the service menu level in the TPR-4 panel. © 2018 Ropam Elektronik...
Page 64 Possible (set in NeoGSMIPManager): - selecting the entry number - blocking the zone after pressing the icon (after disarming the entry system they are unblocked) - indication of the status from the PLC I / O module input © 2018 Ropam Elektronik...
Page 65 0 = dark bulb icon Controlling control panel output (1-32). e.g. roller blinds. Controlling control panel output (1-32). e.g. blinds down. Controlling control panel output (1-32). e.g. gate. Controlling control panel output (1-32). e.g. a garage door. © 2018 Ropam Elektronik...
Page 66 - display only temp., only% Rh or temp and% Rh Basic information about the system: Firmware of the control panel, Panel firmware, Power supply to the control panel and modem, The status of the internet module. Panic Fire © 2018 Ropam Elektronik...
Page 67 A description of the action Single output control - Fan Controlling a single output - Radiator Single output control - Power supply Single output control - Sprinkler Wicket Controlling a single exit Garden lights Single output control Plugin © 2018 Ropam Elektronik...
Page 68: Firmware Update
- turn off the system power - connect the USB cable to the computer and panel - put on a PR jumper - switch on the panel power supply (system) - select the file by double-clicking - click the "Update" button © 2018 Ropam Elektronik...
Page 69: Tpr-4 Panel Maintenance
- registration of temperature history from temperature sensors Housing IP20 (tamper protection: opening and detaching from the housing base) Working conditions environmental class: II T: -10 ° C ... + 55 ° C RH: 20% ... 90%, no condensation) © 2018 Ropam Elektronik...
Page 70: Exp-I8-Rn
• transmission from EXP-I8-RN inputs: SMS / VOICE / CLIP / IP. • disconnect terminal connectors. Destiny. The EXP-I8-RN is an input module that cooperates with the NeoGSM-IP and NeoGSM-IP-PS alarm control panels. The module increases the number of entries in the system by eight. Warnings.
Page 71: Construction And Description
LED: - FAIL red - failure, no communication with the control panel or modules connected to the NeoGSM-IP system - COMM green - communication with the control panel or modules connected to the NeoGSM-IP...
Page 72: Optical Signaling Of The State
1. Install the module in the appropriate place (switchgear, external surface-mounted housing) and connect in accordance with the description of the terminals, taking particular care while connecting the power cables. 2. Connect the RopamNET bus cables of the module to the NeoGSM-IP control panel according to drawing below Add the module to the control panel using the NeoGSMIPManager program.
Page 73: Technical Parameters
System configuration. Str. 63 Connection of the module: Line polarizations possible: Technical parameters. Parameter Value Power supply voltage U = 9 - 14VDC from the connector + KB, GND 20mA/40mA min/max Power consumption (Ix=2,5mA @12VDC) © 2018 Ropam Elektronik...
Page 74: Exp-O8T-Rn
• NO, NC configuration • module on the RopamNET bus, local or elevated work - bus length up to 200mb, • configuration, properties and types of reactions like NeoGSM-IP inputs, NeoGSM-IP-PS, • transmission from EXP-I8-RN inputs: SMS / VOICE / CLIP / IP.
Page 75: Module Description
RopamNET bus (only assumed if the module is located at the end of the communication bus). Diody LED: - FAIL red - failure, no communication with the control panel or modules connected to the NeoGSM-IP system © 2018 Ropam Elektronik...
Page 76: Optical Signaling Of The State
AUX|GND 12VDC power output terminals protected by a 100mA polymer fuse O1-O8 module outputs, parameterized in the same way as the NeoGSM-IP control panel inputs, 0.7A @ 24VDC, GND control Protection short-circuit OCP, overload OLP, thermal OHP, OVP overvoltage Tamper external tamper input for the module, status displayed and serviced from the NeoGSM-IP control panel.
Page 77: Requirements, Installation
1. Install the module in a suitable place (switchgear, external surface-mounted housing) and connect according to the description of the terminals with particular care when connecting the power cables. 2. Connect the RopamNET bus cables of the module to the NeoGSM-IP control panel according to drawing below.
Page 78: Technical Parameters
• assembly in a housing for a DIN rail (width 9 modules). Destiny. EXP-O8R-RN is an output module compatible with the NeoGSM-IP / NeoGSM-IP-PS alarm control panel. The module increases by eight the number of relay outputs (AC1: 16A / 250V, AC3: 750W 1-phase motor, contacts: C / NO / NC) in the system.
Page 79: Module Description
RopamNET bus (only assumed if the module is located at the end of the communication bus). LEDs: - FAIL red - failure, no communication with the control panel or modules connected to the NeoGSM-IP system- © 2018 Ropam Elektronik...
Page 80: Optical Signaling Of The State
Relay contact terminals, NO - normally open contact, C - common contact, NC - normally closed contact O1-O8 Module outputs, parameterized identically to the inputs of the NeoGSM-IP control panel, (AC1: 16A / 250V, AC3: 750W single-phase motor) Assembly DIN-TS35 DIN rail housing, 9 modules wide...
Page 81: Installation And Connection Of The Module
1. Install the module in the appropriate place (switchgear, external surface-mounted housing) and connect in accordance with the description of the terminals, taking particular care while connecting the power cables. 2. Connect the RopamNET bus cables of the module to the NeoGSM-IP control panel according to drawing below. Add the module to the control panel using the NeoGSMIPManager program.
Page 82: Apm-Aero
- power supply: 9V ÷ 14V / DC, - ABS surface-mounted housing white - dimensions: 80x80x25 [mm], - cooperation with systems: NeoGSM-IP, - in NeoGSM-IP systems, the Aero controller or the EXP-I8 local expander can be operated, - anti-sabotage protection, Destiny.
Page 83: Controller Description
- assembly optimally centrally in relation to the expected range (radius) of pilots work, - controller availability for third parties and sabotage attempts, - maintaining a safe distance from sources of possible interference (eg 230V / AC power buses - buildings, radio transmitters, etc.). © 2018 Ropam Elektronik...
Page 84: Installing The Controller
1. Install the controller housing in a suitable place and enter the appropriate wiring through the cable glands. 2. Connect the power wires to the terminals. In the case of NEO / NeoGSM-IP: + KB - 12V, GND - GND 3.
Page 85 Delete all detectors: the function removes all detectors from the controller (currently connected to the AP). Read the detector settings: the function gets settings from the detectors. Send sensor settings: the function sends settings to all detectors. © 2018 Ropam Elektronik...
Page 86 In system standby mode (supervision), the loss of Aero connectivity is a sabotage of the system. Module status window (AP STATUS): - Connected: connection status with the NeoGSM-IP control panel (yes / no) - Soft version: the firmware version in the APm Aero device - Usupp: supply voltage at the module power terminals...
Page 87: Technical Parameters
II temp.: -10 ° C ... + 55 ° C Working conditions RH: 20% ... 90%, no condensation Connectors AWG: 24-18, separable Dimensions, weight. 80x80x25 (WxHxD, mm), antenna built into the PCB surface-mounted ABS cabinet white with optical signaling, ~ 70g © 2018 Ropam Elektronik...
Page 88: Keyfob-Aero
- power supply: 3VDC, CR2032 - ABS housing white / black, Destiny. Remote control Keyfob-Aero is designed to work with Aero Ropam Elektronik wireless devices and, through them, to control the alarm system / building automation or control selected functions of the system.
Page 89: Construction And Description
- assembly optimally centrally in relation to the expected range (radius) of pilots work, - controller availability for third parties and sabotage attempts, - maintaining a safe distance from sources of possible interference (eg 230V / AC power buses - buildings, radio transmitters, etc.). © 2018 Ropam Elektronik...
Page 90: Configuration
Preparing the system for work. Depending on whether the remote control is programmed into the system or not - the procedure for configuring the remotes to operate with the selected Ropam Elektronik production system is presented below. © 2018 Ropam Elektronik...
Page 91: Configuration: Neogsmipmanager
AP). Delete all keyfobs: function deletes all keyfobs from controller (currently connected to the AP). Read settings from AP: function retrieves settings from AP. Transfer settings to AP: function sends settings to the AP. © 2018 Ropam Elektronik...
Page 92 - Send SMS to: control panel allows you to specify phone numbers to which SMS will be sent; - Remove controller no.: removes selected number o remote controller (1-16) from Aero system - Rem. all remote cntrlrs: removes all remote controllers programmed into Aero system.. © 2018 Ropam Elektronik...
Page 93: Flags For The Pilot In Logicprocessor
In the Logic Processor tab, you can select the flags corresponding to each of the remote control buttons and set the appropriate action for them as needed. Flags in LP for Keyfob-Aero: - kb1, - kb2, - kb3, - kb4, - kb5 © 2018 Ropam Elektronik...
Page 94: Technical Parameters
- cooperation with systems: NeoGSM-IP, - anti-sabotage protection, Destiny. The IO module of the Aero system is intended for the wireless integration of wired devices (detectors, reed switches, etc.) with Ropam Elektronik systems via the wireless Aero system. © 2018 Ropam Elektronik...
Page 95: It Allows You To Extend The Functionality Of The System With Wireless Devices In The Absence Of Wired Resources (Cabling)
System Aero module, wireless communication, surface-mounted ABS housing white - dimensions: 80x80x25 [mm]. Construction and description. View of the IO-Aero module Element Description, function (vice) DC power input: 9V ÷ 14 V / DC voltage terminal GND (0V) 'mass' power (GND) © 2018 Ropam Elektronik...
Page 96: Assembly And Installation
Signals and power supply should be carried out in one cable. Module checks the status: - I1 input on the module's board, - controls the OUT output according to the settings in the control panel, see table: © 2018 Ropam Elektronik...
Page 97: Installation And Programming Of The Io Module
4. Check the status of the modules in the controller (RSSi, LQI), save the settings to the AP. Comments: It is necessary to keep possible antistatic protection measures to protect electronic circuits on PCBs against electrostatic discharge ESD. © 2018 Ropam Elektronik...
Page 98: Reset Procedure For Lips Factory
Configuration: NeoGSMIPManager. The module during system operation is configured from the control panel level. Requirements: - cooperation with the system: NeoGSM-IP, NeoGSMIPManager: AP-Aero. NeoGSMIPManager program tab: Modules, TPR panels: APx-Aero. The controller configuration and the RSSI radio signal level are available.
Page 99 For maximum battery life, select the interval of 90 seconds. The control interval affects the time after which the AP command will be sent to the detector / module including: armed mode (supervision). All alarms, sabotages are sent without delay to the AP controller. © 2018 Ropam Elektronik...
Page 100: System Maintenance
/ module goes into the power saving state. Module status window (AP STATUS): - Connected: connection status with the NeoGSM-IP control panel (yes / no) - Soft version: firmware version in the APm Aero device - Usupp: supply voltage at the module power terminals...
Page 101: Rht-Aero
- anti-sabotage protection, Destiny. RHT-Aero module is designed for wireless temperature and humidity measurement. Thanks to it you can integrate measurements from multiple devices (up to 4 in the NeoGSM-IP system) and analyze changes in temperature and humidity parameters. Warnings.
Page 102: Module Description
System configuration. Str. 92 Module description. Module version. Code Description RHT - Aero Wireless module of Aero temperature and humidity sensor. © 2018 Ropam Elektronik...
Page 103: Construction And Description
J1 - normal operation - jumper removed, installed - see the installation and programming procedure (deleting the detector from the system). J2- temperature sensor selection: removed - internal module sensor, installed - external sensor TSR- xx series by Ropam Elektronik. Description of connectors: T1 - data from the TSR-xx digital temperature sensor...
Page 104: Assembly And Installation
3. Repeat point 2 for all modules, the RHT-Aero modules receive the system number according to the order of addition. 4. Check the status of modules in the controller (RSSi, LQI), save settings to RHT-Aero modules. Procedure of removing the module from the system: © 2018 Ropam Elektronik...
Page 105: Rht-Aero Flags In Logicprocessor
1, temperature test in the ranges of 25-30 degrees Celsius): int tw; int M1; int O1; main(){ gbenv(); M1=0 O1=geto(1); while(1){ gbenv(); tw=gettw(1); O1=geto(1); if(tw<25&&M1==0){ M1=1; PRINT("Zimno"); if(tw>30&&M1==1){ M1=0; PRINT("Temp. OK."); O1=tofd(1,M1,0,2); // hysteresis of switching the output on and off seto(1,O1); © 2018 Ropam Elektronik...
Page 106: Configuration
Connect the optional external temperature sensor TSR1-HT according to the polarity. Configuration: NeoGSMIPManager. The system operation module is configured from the control panel level. Requirements: - cooperation with the NeoGSM-IP system NeoGSMIPManager: Apx-Aero – sensor temp./hum. NeoGSMIPManager program tab: and then:...
Page 107: Value Display Settings On The Tpr-4 Panel
The device does not require any special maintenance. During periodic technical inspections, it is necessary to check the condition of screw joints, emergency power supply status, clean the PCB with compressed air. The system should be periodically tested for proper operation and communication. © 2018 Ropam Elektronik...
Page 108: Technical Parameters
- regulation of the sound level in the doorphone and mobile phone from the level of the device and / or the NeoGSMIPManager program, - the system does not limit other functions of the systems and increases their functionality, - functions of reducing costs and number of transfers. © 2018 Ropam Elektronik...
Page 109: Destiny
Destiny. The VAR-1U module is used to integrate doorphone / video intercom systems with alarm systems / building automation NeoGSM-IP. Thanks to its functions, the device raises the functionality of the alarm system with the possibility of remote identification and verification of persons.
Page 110: Module Versions
- CALL - signaling of establishing / ongoing voice call / doorphone call (shining) - COMM - blinking every 250ms - correct communication with the NeoGSM-IP control panel, correct receiving of data from the Kenwei doorphone: blink 2 x 250ms, redirection active - Vpp FAULT - Vpp output failure indication (lighting = failure) Module versions.
Page 111: Connecting The Module To The Control Panel
Add the module to the control panel using the NeoGSMIPManager program. 4. Perform the connection of the NeoGSM-IP + Var-1U system with the entry phone / video intercom system. 5. Connect the programming cable of the control panel to the USB socket.
Page 112: Connection Of Intercoms To Var-1U
Pro716A video intercom (10, 7, 8, ---) Vpp, Audio, GND, Data Pro 716A intercom (4, 1, 2, ---) Competition MT 300C (3,1,2,---), Vpp, Audio, GND, Data MT 337C (E4, E2, E3, ---) Eura 4,1,2,--- Vpp, Audio, GND, Data © 2018 Ropam Elektronik...
Page 113 System configuration. Str. 103 Connection diagrams for individual manufacturers acc. the table above: Vidos: Commax: Abaxo: Leelen: © 2018 Ropam Elektronik...
Page 115: Configuration
System configuration. Str. 105 Competition: Eura: Configuration. The system operation module is configured from the control panel level. Requirements: - control panel: NeoGSM-IP NeoGSMIPManager: VAR-1U. Identification of the module in the system: - NeoGSMIP program tab: © 2018 Ropam Elektronik...
Page 116 - after that a window will appear with modules found by the control panel. - save the configuration to the control panel by clicking: Then in the tab concerning the module VAR-1U module configuration are available options: © 2018 Ropam Elektronik...
Page 117: Changing The Parameters Of The Module
Custom settings. Custom settings allow you to adjust the parameters of the audio line to achieve the best possible sound quality. Factory settings are recommended for individual device models (they load automatically after selecting the device model). © 2018 Ropam Elektronik...
Page 118: Notifications From The Var-1U Module
The VAR-1U module enables remote opening of the bolt using the DTMF code during an ongoing voice connection between the user and the NeoGSM-IP system. Call forwarding after [s] - the function allows to play a message from the VSR-1 module installed in the VAR-1U door intercom (we recommend that the redirection time should not be shorter than the message duration in the VSR-1 module).
Page 119: System Maintance
II temp.:10°C ... + 55°C Working conditions RH: 20% ... 90%, no condensation Dimensions, weight. 67.5 x 87 x 17.53 (WxHxD, mm), ~ 30g without housing, 71 x 90.2 x 57.5 (WxHxD, mm), ~ 90g housing D4M, © 2018 Ropam Elektronik...
Page 120: System Operation
System operation. Str. 110 5. System operation. Applications that support the NeoGSM-IP system using SMS, DTMF or TCP / IP. Basic SMS commands ARMING: The control of armed mode by SMS consists in sending an SMS about the form, access to functions and zones, determining the authorization of the given code.
Page 121 X = 1 function enable x = 0 function disable ##### replysms x Remote activation / 5555 replysms 1 Configurati deactivation of confirmation return function for SMS changed commands X = 1 function enable x = 0 function disable © 2018 Ropam Elektronik...
Page 122: Basic Dtmf Commands
5555 # 1 - will arm all zones 1-4 CONTROL OF RYGLES (opening): The VAR-1U module enables remote opening of the bolt using the DTMF code during an ongoing voice connection between the user and the NeoGSM-IP system. © 2018 Ropam Elektronik...
Page 123: Ropamneo Application
A phone or tablet with Android, Apple iOS. System demo. The Ropam Elektronik company allows you to connect to the "Demo" object using the RopamNeo application, which allows you to easily find out about the possibilities of the system and check its functionality.
Page 124 System operation. Str. 114 The full installation and operation manual for the RopamNeo application is available at: www.ropam.com.pl. © 2018 Ropam Elektronik...
Page 125: Neogsmipmanager
Tab: SIM card settings. Options SIM card and GSM modem. SIM card settings. Object phone number This is the number of the SIM card in the module. The field is saved to the module's memory. © 2018 Ropam Elektronik...
Page 126: Voice Call Settings
The number should be entered in the international format. No SIMCARD The function disables the presence of the card. Comments: - The SIM card PIN is only required if the card has a PIN. Voice call settings. © 2018 Ropam Elektronik...
Page 127: Sms Settings
VSR-1, VSR-2, AMR-1 module. When inactive - no possibility to send CLIP and voice notifications from the NeoGSM-IP control panel. Confirming / disarming the alarm ends the notyfication Turning off the alarm during the notification will end the notification.
Page 128: Gsm Modem Options
You can also set up sending account status information to the first phone number from the list of numbers. The interval for sending account status information is 7 days. Time 7 days is counted from the last restart of the NeoGSM-IP. GPRS monitoring, e-mail configuration.
Page 129 Monitoring GPRS (Ropam RMS station, Kronos Net) Monitoring server settings Remote access to control panel through the RopamBridge server To set access to the module from the mobile application, you must configure the appropriate options in NeoGSMIPManager. © 2018 Ropam Elektronik...
Page 130 Remote access to the control panel through RopamBridge server This option allows you to operate the NeoGSM-IP control panel from the RopamNeo application. The NeoGSM-IP control panel can connect to RopamBridge via Wifi / Ethernet (Internet) or via a GPRS connection.
Page 131 It allows the user to edit the pictograms visible on the screen from the application level. (It does not allow you to change their appearance!) Description and operation of individual pictograms described in the RopamNEO manual, available at www.ropam.com.pl. © 2018 Ropam Elektronik...
Page 132 It is necessary for accounts configured in the system to be ACTIVE! That means: there should be standard traffic on them (receiving and sending messages), otherwise they will be deleted by the service provider (see regulations on the use of an e-mail account). © 2018 Ropam Elektronik...
Page 133: Wifi, Internet Settings
Tab: Modules, touch panels. The procedure for identifying new modules connected to the control panel. Addition of new modules to the NeoGSM-IP control panel: 1. Connect the module in accordance with the connection diagram. 2. Connect the control panel behind the NeoGSMIPManager.
Page 134: Tpr Touch Panel
Save log to an SD card: function activates log recording with temperature measurement on the SD card in the given panel (files YYMMDD.txt). Display messages from LogicProcessor: Displaying messages from the PRINT LogicProcessor function. Partition status. Displays the status of selected zones. Options - Show addres selection © 2018 Ropam Elektronik...
Page 135: Other Settings
Warning! After adding a new extension module, check the zone allocation. Expander EXP-I8. Local zone expander (8). Line configuration as in the NeoGSM-IP control panel. Warning! After adding a new extension module, check the zone allocation. © 2018 Ropam Elektronik...
Page 136: Apx-Aero
Low sensitivity values also reduce the real detection range. For applications in which animal resistance (PET) is to be used, use parameters 1 to 4. Pulses: signal analysis time parameter, SmartPIR algorithm. PULSE 1: najkrótszy czas zbierania próbek, analizy sygnału….. © 2018 Ropam Elektronik...
Page 137 (no supervision). The option allows selection: sabotage (loud alarm) or failure. Warning! After adding a new extension module, check the zone allocation. Signal level graph. A level histogram is available for each detector, distinguishing by color. RF-4. Configuration of channels (pilots). © 2018 Ropam Elektronik...
Page 138: Psr-Eco-Xx
Finish prog. RF-4: terminating the RF-4 programming mode and returning to the RF-4 configuration in the system. PSR-ECO-xx. System impulse power supply with RopamNET bus and monitoring of power supply and network operation status (loss of power) and battery (charging, charge status, voltage). © 2018 Ropam Elektronik...
Page 139: Exp-I8-Rn
Dystem may have two EXP-O8x-RN-xx output expanders. Address of the given EXP-O8x-RN is determined by the first switch DS1: 1: OFF = adress 1 1: ON = adress 2. Warning! After adding a new extension module, check the output allocation. VAR-1U © 2018 Ropam Elektronik...
Page 140 When the VSR-1 voice synthesizer is installed in the module - first the message saved in the VSR-1 module memory will be played and then the system user number saved in position 1 or 2 will be selected in the tab: © 2018 Ropam Elektronik...
Page 141 Custom settings allow you to adjust the parameters of the audio line to achieve the best possible sound quality. Factory settings are recommended for individual device models (they load automatically after selecting the device model). Notifications from the VAR-1U module © 2018 Ropam Elektronik...
Page 142 The VAR-1U module enables remote opening of the bolt using the DTMF code during an ongoing voice connection between the user and the NeoGSM-IP system. Call forwarding after [s] - the function allows to play a message from the VSR-1 module installed in the VAR-1U door intercom (we recommend that the redirection time should not be shorter than the message duration in the VSR-1 module).
Page 143: Tab: Partitions, Phone Numbers, E-Mails
Exit time - time counted down after arming an alarm in which it is possible to violate delayed zones. Entry time – the time counted after the delayed zone violation, in which the alarm should be disarmed. Controlling the armed mode by timers – standby is controlled according to the timer. © 2018 Ropam Elektronik...
Page 144: Tab: Zones
- the telephone number should be entered in the international format, e.g. +48500111222. Tab: Zones. Zone settings Attribution – information on the physical allocation of input from available modules in the control panel. Name - name displayed in the system, TPR panels, RopamNeo application. Polarization – © 2018 Ropam Elektronik...
Page 145 3.Delayed - line triggers a loud alarm after the violation and after the entry delay time has elapsed in the absence of disarming the system (during this time). The time for entry is set in the Zones tab, © 2018 Ropam Elektronik...
Page 146 Allocation to partition – function allows for assigning an entrance to the zone or to zones in accordance with the set logic and enabling the entry of the night zone (the zones marked as night will be armed when the night watching is started). © 2018 Ropam Elektronik...
Page 147: Advanced
Max. time of non-infringement [min] – parameter specifies the maximum time after which zone will fail if it was not violated. Max. violation time [min] – parameter specifies the maximum violation time of the zone, followed by the entry failure. © 2018 Ropam Elektronik...
Page 148: Global Zones Options
Pulse line – By selecting the PULSED LINE option, the system is armed as a "button": the first violation activates the system, the second disarms, etc. Do not save events for INFO zones- It does not record 11. onfo line violations to the memory of events. Notyfication © 2018 Ropam Elektronik...
Page 149 (Wifi / Ethernet / GPRS), • an active connection to the RopamBridge server, • subscription to the RopamBridge service in the Google Play or AppStore store, • minimum three successful logins of the RopamNeo application by RopamBridge, © 2018 Ropam Elektronik...
Page 151: Analog Input
Delay [ms] - time delay in response to a change in the measured value. Add instantaneous value to the content of the sent message (L, H exceeded) – the option adds an instantaneous value to the notification content. © 2018 Ropam Elektronik...
Page 152: Allocation Of Inputs
The function is used for arbitrary deployment of inputs from available extension modules in the control panel. Warning! After adding a new extension module, check the allocation of inputs. Renumber - automatic arrangement of available inputs. Save changes – saves changes (necessary to send configuration to the control panel). © 2018 Ropam Elektronik...
Page 153: Tab: Outputs
The output in BI mode for triggering as an ALARM acts as a latch (latch) to reset the alarm. © 2018 Ropam Elektronik...
Page 154: Alarm Control
Full standby indicator – active output when the partition is full armed. Night watch indicator – active output with night standby. Confirm arm / disarm with pulses – the function generates pulses on the output when arming or disarming. © 2018 Ropam Elektronik...
Page 155: Remote Control
Ringtone clip – the option allows the output to be controlled by short connection to the module telephone number. In addition, it is possible to determine the response of the module to an incoming call, using the option INCOMING CALLS. © 2018 Ropam Elektronik...
Page 156: Local Control
Collective failure – switching on output when any failure occurs. No AC power – turning on the output when power is off. GSM signal interference – switching on output when signal interference is detected © 2018 Ropam Elektronik...
Page 157: Notyfication
(this is not dependent on the settings but results from restrictions introduced by the operators!). Include system status – appends the object's status to the notification content according to the setting in the Communication, tests, and counters tab. © 2018 Ropam Elektronik...
Page 158 (Wifi / Ethernet / GPRS), • an active connection to the RopamBridge server, • a subscription to the RopamBridge service in the Google Play or AppStore store, • a minimum of three successful logins of the RopamNeo application by RopamBridge, © 2018 Ropam Elektronik...
Page 159: Allocation Of Outputs
Save settings – saves changes (necessary to send configuration to the control panel). Tab: Timers. Settings of four independent timers to control the system arming, control of outputs, LogicProcessor functions. Each timer can have 20 independent entries on attachments. © 2018 Ropam Elektronik...
Page 160: Tab: Communication, Tests, Counters
NeoGSMIPManager Str. 150 Tab: Communication, tests, counters. Settings of parameters and methods of communication between the control panel and the user, the Internet network. Configuring notifications in the event of a system failure. © 2018 Ropam Elektronik...
Page 161 - TCP/IP encryption Key: key encrypting transmission between the module NeoGSM-IP and the RopamNeo mobile application. The key is generated automatically each time when running the NeoGSMIPManager program. Also used when encrypting the service connection with NeoGSMIPManager.
Page 162 Show in STATUS message – the function allows you to adjust the information contained in the text message. NOTIFICATIONS WHEN: • Panic alarm / help request Configuring notifications after calling a panic alarm. Loud alarm • Fire alarm © 2018 Ropam Elektronik...
Page 163: Tab: Temperature
- Dynamic battery test - selecting this option cycles the battery every 10 minutes. If the control panel detects a significant voltage drop at the battery terminals, there is an error or no error. Tab: Temperature Parameter settings for temperature sensors in the system (2). © 2018 Ropam Elektronik...
Page 164 NeoGSMIPManager Str. 154 Settings of temperature sensors The NeoGSM-IP module allows you to measure temperature using a digital temperature sensor TSR-xx. Temperature measurement takes place every 30s. The measurement accuracy is 0.5 ° C. Based on the temperature measurement, you can perform the LogicProcessor functions, send notifications about changes in temperature parameters and temperature sensor failures.
Page 165 - Save humidity to the memory every interval – writes the humidity value to the event memory every interval - Do not log events to memory – does not save alarms for exceeding thresholds and other events © 2018 Ropam Elektronik...
Page 166 The function allows to set an independent thermostat operating based on temperature sensors connected to the NeoGSM-IP system. The room thermostat allows you to control the climate in rooms according to a set time and temperature schedule. This functionality also allows significant energy...
Page 167: Tab: Logicprocessor
- up to 20 independent logic conditions, (If ... Then ... Else blocks), - 20 time relays for the implementation of time-logic functions, - logic wizard or script editor (scripting language C), simulator: setter and script preview, © 2018 Ropam Elektronik...
Page 168 Conditions If is a maximum of 8 conditions between two arguments, each line is bound to logic' and / or '(AND / OR) with the next. If the 'If' condition is met, the 'Then' block is executed, otherwise 'Else'. © 2018 Ropam Elektronik...
Page 169: Logic Functions
0 or 1 1 = temp sensor failure analog input value indicator AI for threshold L, 1 = (ail <L) assumes a binary value of 0 or 1 0 = [ail> (L + hysteresis)] © 2018 Ropam Elektronik...
Page 170 MSR-1 monitoring station "0" - no connection "1" - active connection tr1, tr2 thermostat activation indicator "0" - heating off, "1" - heating is included binary value 0, Binary Value type object binary value 1 Logic function (If) Symbol Description Name © 2018 Ropam Elektronik...
Page 171 (NOT AND): A1 ÷ A8 NAND it is a logic sum system that outputs '1' when this value has n-1 input signals. This means that '0' appears if and only if all signals are '1' © 2018 Ropam Elektronik...
Page 172 A1 ÷ A2 PRINT function displays a window with information on touch panels, as argument A1 you can specify info text and argument A2 another system argument, eg power, function will connect A1 and A2 © 2018 Ropam Elektronik...
Page 173 Name of the HINT function Function prints a given message on the bottom of the TPR panel. Displayed text is Destiny not remembered, the next HINT () call or other system message will overwrite the displayed message. © 2018 Ropam Elektronik...
Page 174 (value of the measured voltage at the AI input) will be added An example from the logic wizard One time sending a text message when the voltage value at the analog input AI Sample script exceeds 5V int aiv; int M1; main(){ while(1){ aiv=getai(1); © 2018 Ropam Elektronik...
Page 175 Function arms the set partition in full armed mode Destiny Syntax ARMF (x) x- the number of armed zone 1-2 An example from the logic wizard Automatic arming / disarming of partition 2 when zone 1 is armed Script example int as2; int as1; © 2018 Ropam Elektronik...
Page 176 DISARM (x) x- number of disarmed zone 1-4 An example from the logic wizard Script example Automatic disarming of zone 2 when zone 1 is armed int as1; int as2; main(){ while(1){ gbenv(); if(as1==1){ if(as2==0){ ARMF(2); } else { if(as2==1){ DISARM(2); © 2018 Ropam Elektronik...
Page 177 Activation of O1 output according to the Timer 1 state Script example int O1; int tk1; main(){ while(1){ gbenv(); O1=tk1; seto(1,O1); Comments In order to access the output it is necessary to enable the option in the exit tab for the controlled output © 2018 Ropam Elektronik...
Page 178 • x - the entry number of the state to be read 1-32 An example from the logic wizard Script example Rewriting the state of input I1 to output O1 (input tracking) int I1; int O1; main(){ while(1){ © 2018 Ropam Elektronik...
Page 179 The function returns only the total temperature in degrees Celsius If there is no sensor or failure, the function returns -999 Name of the getenv() function A function that retrieves the value of all system variables Destiny Syntax getenv() © 2018 Ropam Elektronik...
Page 180 HINT("It is frost T=",twv); } else { HINT("Positive temperature "); WAIT(30000); Comments The function returns only the total temperature in degrees Celsius When a read error is found, the function returns -999 © 2018 Ropam Elektronik...
Page 181: Time Relays
255. Time relays. Time-logic functions allow to perform programmed timers, triggers and resets of timers (blocks) identical to arguments in logic functions and results are written to outputs or markers. Symbol Parameter Description © 2018 Ropam Elektronik...
Page 182 NeoGSMIPManager Str. 172 Trigger triggering signal Time time of the timer, function Reset reset signal Output function output TIMER Timer type type of time / counter function TimeOnDelay DelayKeepOn © 2018 Ropam Elektronik...
Page 184: Starting Values
Str. 174 Blinker Starting values. In order to avoid transients during the start of the LP script, you can set start values for the script based on the resources of the system intended for the Logic Processor. © 2018 Ropam Elektronik...
Page 186: Simulator
The real-time clock used in the device allows recording in the memory of events of the module violation of inputs, functions, tests, etc. The memory contains 10,000 events that have occurred recently, the memory is overwritten and the oldest information is deleted in a chronological manner. © 2018 Ropam Elektronik...
Page 187: Tab: Online Preview
Reset access codes - restores the main code to 5555 and removes all created users. Emulator, control, SMS - It allows you to check the functions normally available via SMS. Notification test – allows you to check the communication of e-mail notifications, sms, call. © 2018 Ropam Elektronik...
Page 188 - all activities related to the change of the SIM card, jumper settings, connections of modules and interfaces should be made after disconnecting the module's power supply and maintaining all available static protection. MODEM RESET Restarts the GSM modem. RESTART WIFI/LAN Restarts WIFI / LAN © 2018 Ropam Elektronik...
Page 190: System Maintenance
Control panel does not require special maintenance. During periodic technical inspections, it is necessary to check the condition of screw joints, emergency power supply status, clean the PCB with compressed air. The system should be periodically tested for proper operation and communication. © 2018 Ropam Elektronik...
Page 191: Technical Parameters
U = 16V ÷ 20V / AC min / max @ 30VA min. Power supply voltage NeoGSM-IP-PS U = 20V ÷ 28V / DC min / max @ 0.7A min. The output voltage of the NeoGSM-IP- Un= 13,8V/DC (+/- 2%) PS power supply U=9,5V-13,8V/DC**.
Page 192 -10 ° C ... + 55 ° C RH: 20% ... 90%, no condensation Connectors AWG: 24-12, separable Dimensions: NeoGSM-IP / NeoGSM-IP-PS 156x 88 x 25 [-/+1] [mm] NeoGSM-IP-xx-D9M 159,5x 90 x 58 [-/+1] [mm] housing DIN 9M Waga:...
Page 193: Version History
2018.05.25 - added SMS update software update, The Ropam Elektronik company is the sole owner of copyrights to the materials contained in the documentation, catalog and website, in particular for photos, descriptions, translations, graphic form, presentation. Any copying of information or technical materials found in catalogs, on websites or otherwise provided by Ropam Elektronik requires written permission.

Ropam elektronik NeoGSM-IP Installation Manual

1 General Description

2 System Description

3 Installation and Commissioning

4 System Configuration

5 Additional Modules and Extensions

6 Neogsmipmanager

7 System Maintenance

8 Technical Parameters

9 Version History

Quick Links

Need help?

Questions and answers

Related Manuals for Ropam elektronik NeoGSM-IP

Summary of Contents for Ropam elektronik NeoGSM-IP

Table of Contents
