Stafford Instruments ST610B User Handbook

Specification

Temperature
Temperature measurement ranges
R Type: -40°C to 1450ºC
S Type: -40°C to 1450ºC
K Type: -40°C to 1325ºC
N Type: -40°C to 1275ºC
Accuracy
±0.25% FSD ± 1 digit
(does not include thermocouple error)
Readings per second: 4
Cold Junction Compensation
Precision thermistor (calibrated)
Environmental
Operating temperature range: -20°C to 50°C
Storage temperature range: -20°C to 60°C
Enclosure
Material: ABS Size: 170x85x45mm
(L x W x H)
IP53
Sealing:
Error Handling
Thermocouple failure detection
This instrument
complies with
Council Directive
89/336/EEC (electromagnetic
compatibility) & Council Directive
73/23/EEC (low voltage safety)
Further copies of this handbook may be found at http://www.stafford-inst.co.uk/docs/st610b/user610b.pdf
Page 4
Electrical
Power supply
Replaceable standard alkaline
9V (PP3) dry battery types:
IEC 6F22, NEDA 1604 etc.
Battery Life: > 100 hours
Auto power-off: 15 mins.
Connector
Standard "miniature"
thermocouple connector
(7.9mm between pin centres)
Overload withstand
60VDC 24VAC
ST610B User Handbook
S D
TAFFOR
INSTRUMENTS
User Handbook
ST610B Digital Pyrometer
Stafford Instruments Ltd.
www.stafford-inst.co.uk
Tel: +44(0)1785 255588 email: support@stafford-inst.co.uk
Fax: +44(0)1785 255589
© Copyright 2006 Stafford Instruments Ltd.
ST610B User Handbook
ST610B
Issue: 1.000
Page 1
Date: 26 June 2006
