  • Page 1 PTZ Network Camera User Manual V2.08...
  • Page 2 Thank you for purchasing our product. If there is any questions or requests, please do not hesitate to contact your dealer. This manual is applicable to the Milesight H.265 Network Camera, series as follows, are shown except where otherwise indicated. Milesight H.265 PTZ Network Camera Type Megapixel...
  • Page 3 Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measures are divided into “Warnings” and “Cautions” Warnings: Serious injury or death may be caused if any of these warnings is neglected. Cautions: Injury or equipment damage may be caused if any of these cautions are neglected.
  • Page 4 EU Conformity Statement 2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points.

  • Page 5: Table Of Contents

    Table of Contents Chapter ..............................1 1.1 Product Overview........................1 1.2 Key Features..........................1 1.3 Hardware Overview.........................2 1.4 How to Connect to Alarm Interface..................4 1.5 How to Connect the Water-proof Connector................4 1.6 System Requirements......................5 Chapter II Network Connection......................6 2.1 Setting the Camera over the LAN.................... 6 2.1.1 Connect the Camera to the PC Directly.................6 2.1.2 Connect via a Switch or a Router...................6 2.2 Dynamic IP Connection......................6...

  • Page 6: Product Overview

    Chapter I Product Description 1.1 Product Overview Milesight provides a consistent range of cost-effective and reliable network cameras to fully meet your requirements. Based on embedded Linux operating system, Milesight network cameras could be easily accessed and managed either locally or remotely with great reliability. With built-in high-performance DSP video processing modules, the cameras pride on low power consumption and high stability.

  • Page 7: Hardware Overview

    1.3 Hardware Overview (PoE) Speed Dome Network Camera Figure 1-3-1 (PoE) Speed Dome Network Camera Note: 1) AC 24V and PoE are available for power supply. 2) Built-in SD card slot can be seen after removing the 4 screws and open the front panel.
  • Page 8 12x Mini PoE PTZ Bullet Network Camera Wall Mount: Pedestal Mount: Mini PTZ Bullet: Mini PoE PTZ Bullet: Figure 1-3-2 12x Mini PoE PTZ Bullet Network Camera Note: 1) Reset Button: Press “Reset” button for 5 seconds, then the device will be restored to factory default.

  • Page 9: How To Connect To Alarm Interface

    1.4 How to Connect to Alarm Interface External interface of camera is as the following, you can refer to the picture to install the external alarm device:(Example for PTZ BULLET) PIN1: Alarm Output NC/NO 24V DC 1A PIN2: Alarm Output NC/NO 24V DC 1A PIN3: Alarm Input NC/NO ≤12V PIN4: Alarm Input NC/NO ≤12V 1.5 How to Connect the Water-proof Connector...

  • Page 10: System Requirements

    1.6 System Requirements Operating System: Windows XP/Vista/7/8/10/Server 2000/Server 2008 CPU: 1.66GHz or higher RAM: 1G or higher Graphic memory: 128MB or more Internet protocol: TCP/IP (IPv4/IPv6) Web Browsers: Internet Explorer 8.0 and above version, Mozilla Firefox, Google Chrome and Safari.

  • Page 11: Chapter Ii Network Connection

    Chapter II Network Connection 2.1 Setting the Camera over the LAN Connecting the camera to a switch or a router is the most common connection method. The camera must be assigned an IP address that is compatible with its LAN. 2.1.1 Connect the Camera to the PC Directly In this method, only when the computer connected to a camera, it will be able to view the camera.
  • Page 12 assistance with port forwarding; Step4: Apply a domain name from a domain name provider; Step5: Configure the DDNS settings in the setting interface of the router; Step6: Visit the camera via the domain name. Figure 2-2 Connect the network camera via a router using dynamic IP...

  • Page 13: Chapter Iii Accessing The Network Camera

    Chapter III Accessing the Network Camera The camera must be assigned an IP address to be accessible. 3.1 Assigning An IP Address The Network Camera must be assigned an IP address to be accessible. The default IP address of Milesight Network Camera is 192.168.5.190. The default user name is “admin”, and password is “ms1234”.
  • Page 14 Step3: Select a camera or multiple cameras according to the MAC addresses; Figure 3-1-2 Select single camera Figure 3-1-3 Select multiple cameras...
  • Page 15 Step4: Type the User Name and Password (admin/ms1234 for default, please change your password for your device security); Figure 3-1-4 Type the User Name and Password Step5: Change the IP address or other network values, and then click “Modify” button; Figure 3-1-5 Modify...
  • Page 16 Step6: Change the IP address successfully; Figure 3-1-6 Change IP address successfully Step7: By double clicking the selected camera or the browser of interested camera, you can access the camera via web browser directly. The Internet Explorer window will pop up. Figure 3-1-7 Login interface More usage of Smart Tools, please refer to the Smart Tools User Manual.

  • Page 17: Assign An Ip Address Via Browser

    3.1.2 Assign An IP Address via Browser If the network segment of the computer and that of the camera are different, please follow the steps to change the IP address: Step1: Change the IP address of computer to 192.168.5.0 segment, here are two ways as below: Start...
  • Page 18 Figure 3-1-9 Setting IP Address of Computer Step2: Start the browser. In the address bar, enter the default IP address of the camera: http://192.168.5.190; Step3: Enter the user name and password when the LOGIN page appears; Default user name: admin Default password: ms1234 Figure 3-1-10 Login...

  • Page 19: Accessing From The Web Browser

    3.2 Accessing from the Web Browser The camera can be used with the most standard operating systems and browsers. The recommended browsers are Internet Explorer, Firefox, Chrome, Safari. Access over IE Browser Before using the browser to get access to your camera, you need to install the MsActiveX firstly. You can refer the steps as follows: Step1: Launch the IE browser and enter the IP address of the camera;...
  • Page 20 Figure 3-2-3 To add the permission Step2: Select “Security” to “Trusted”; Figure 3-2-4 To trust the control Step3: Enter the IP address of the camera in the blank and click “Add”; Figure 3-2-5 Add the website to the zone...

  • Page 21: Accessing From Milesight Vms (Video Management Software)

    Step4: Enter the IP address. After logging on network camera’s web GUI successfully, user is allowed to view live video as follows. Figure 3-2-6 Live View Interface 3.3 Accessing from Milesight VMS (Video Management Software) Milesight VMS(ONVIF compatible) is a handy and reliable application designed to work with network cameras in order to provide video surveillance, recording settings and event management functions.

  • Page 22: Chapter Iv System Operation Guide

    Chapter IV System Operation Guide 4.1 Live Video After logging in the network camera web GUI successfully, you are allowed to view live video as follows. Figure 4-1-1 Live view interface 4.1.1 Operations on Live View Page Table 4-1-1 Description of the buttons Parameter Description Navigation key is used to control the direction.
  • Page 23 Click to zoom in and zoom out Click to focus near or far of the lens. Lens Initialization, Auxiliary Focus and Auto Iris Click to open/ close the White LED for Lighting For 30s: lighting 30s. 3D Positioning: Click to enable/ disable 3D positioning. Click to carry out the patrol.
  • Page 24 acceptable delay; Best Fluency: The most fluent mode in the three modes. Click to display images at a window size. Window size Click to display images at a real size. Real size Click to display images at full-screen. Full Screen When recording, the icon will turn red.

  • Page 25: Positioning

    4.1.2 3D Positioning 3D Positioning allows user to use mouse clicking and dragging to control the PTZ. Steps: 1.Click on the toolbar of Live View interface. 2.Operate the 3D positioning function  Left click a position of the Live View, the corresponding position will be moved to the center of the Live View.
  • Page 26 Calling a preset: Select a defined preset form the preset list and click to call the preset. Figure 4-1-3 call a Preset Note: The following presets are predefined with special commands. You can only call them but can’t configure them. For example, preset 037 is the “Self Check”. If you call the preset number 037, the PTZ camera will start self check function at once.
  • Page 27 Set / Call a patrol A patrol is a memorized series of preset function. It can be configured and called on the patrol setting list. You can customize up to 8 patrols and it can be configured with 48 presets. Before configuring the patrol, you should make sure that the presets you want to add to the patrol have been defined.
  • Page 28 Figure 4-1-6 Call a Patrol Note: The three buttons behind the Patrol list means: Play, Set and Delete. Set / Call a pattern A pattern is a memorized series of pan, tilt, zoom and preset functions. It can be called on the pattern settings interface.

  • Page 29: Playback

    Figure 4-1-8 Call a Pattern Note: The three button behind the Pattern list means: Play, Record and Delete. When configuring the pattern, pan and tilt are valid but the limit stops and auto flip will be invalid. Also, 3D Positioning operation is not supported. 4.2 Playback This section explains how to view the recorded video files stored in SD cards.
  • Page 30 Figure 4-2-2 Search Video Note: The date with bright red means current date; one with a dark red number and white background means weekend day; one with a dark red number and blue background means that the date is selected now. Step3: Click to play the video files found on this date.

  • Page 31: Local Settings

    Snapshot Zoom On/Off Full Screen Note: Drag the progress bar with the mouse to locate the exact playback point. You can also input the to locate the playback point in the Set Playback Time filed. You can also click time and click to zoom out/in the progress bar.
  • Page 32 Figure 4-4-1 Primary Stream Settings Secondary Stream Settings Figure 4-4-2 Secondary Stream Settings Tertiary Stream Settings Figure 4-4-3 Tertiary Stream Settings Table 4-4-1 Description of the buttons Parameters Function Introduction Video Codec H.265/H.264/MJPEG are available.

  • Page 33: Image

    Options include 5M(2560*1920)(only for 5MP Mini (PoE) PTZ Bullet and Speed Dome), 4M(2592*1520)(only for 5MP and 4MP Mini (PoE) PTZ Bullet and Speed Dome), 3M(2304*1296), 1080P(1920*1080), 1.3M(1280*960), 720P(1280*720), D1 (704*576). Frame Size For Secondary Stream, it includes 704*576, 640*480, 640*360, 352*288, 320*240, 320*192, 320*176.
  • Page 34 Display Figure 4-4-4 Display Settings Table 4-4-2 Description of the buttons Parameters Function Introduction Power Line Frequency 60HZ flicker for NTSC mode and 50HZ flicker for PAL mode There are several parameters such as Exposure Level, Maximum Exposure Time and IR-CUT Interval, etc, associated with this mode. Night Mode: Show in live view based on Night Mode settings Day Mode: Show in live view based on Day Mode settings Day/Night Mode...
  • Page 35 With the combination of the High Beam and Low Beam, The IR LEDs technology has been upgraded to provide better image clarity and quality regardless of the object distance. Also, the Low Beam and High Beam's brightness can be adjusted manually or automatically on the basis of the Zoom ratio.
  • Page 36 Table 4-4-3 Description of the buttons Parameters Function Introduction There is an option to turn On/Off the IR LED. IR Balance Mode IR Balance Mode would avoid the problem of overexposure or darkness, and the IR LED will change according to the actual illumination. To restore white objects and remove color distortion cause by the light of the environment Auto White Balance: This option will automatically enable the White Balance...
  • Page 37 This function which can capture and display both bright and dark areas in the same frame enables details of objects in both bright and dark areas to be visible. Wide Dynamic Range Off: Disable WDR function On: Enable the WDR, there are Low/High/Auto three levels Customize: Customize the schedule to enable/disable the WDR function and set the levels with Low/High/Auto Wide Dynamic Level...
  • Page 38 Figure 4-4-7 Exposure mode schedule settings 3) You can customize the schedule to enable/disable BLC/WDR/HLC mode. Figure 4-4-8 BLC/WDR/HLC mode schedule settings 4) WDR/HLC has higher priority than exposure settings at the same time frame. 5) Anti-fog Image. Figure 4-4-9 Anti-fog Image 6) HLC Image.
  • Page 39 Figure 4-4-10 HLC Image Day/Night Mode Figure 4-4-11 Day/Night Mode Settings Table 4-4-4 Description of the buttons Parameters Function Introduction Exposure Level Level 0~10 are available to meet your need. Minimum Shutter is the same as Maximum Exposure Time. Set the minimum Minimum Shutter Shutter to 1~1/100000s Maximum Shutter is the same as Minimum Exposure Time.
  • Page 40 Color Mode Select B/W or Color mode under Day/Night mode. By this you can customize your special demands for different time, then the Day Schedule Mode mode and Night mode will switch automatically according to your settings. OSD(On Screen Display) Figure 4-4-12 OSD Settings Table 4-4-5 Description of the buttons Parameters...

  • Page 41: Audio

    Region of interest(often abbreviate ROI), is a selected subset of samples within a dataset identified for a particular purpose. Users can select up to 3 key regions of a scene to transmit through separate streams for targeted preview and recording. By using Milesight ROI technology, more than 50% of bit rate can be saved and therefore less bandwidth demanded and the storage usage reduced.
  • Page 42 Figure 4-4-14 Audio Settings Table 4-4-7 Description of the buttons Parameters Function Introduction Enable Audio Check on the checkbox to enable audio feature. Denoise: Set it as On/Off. When you set the function on, the noise detected can be filtered. Encoding: G711-ULaw, G711-ALaw and AAC LC are available;...

  • Page 43: Network

    Figure 4-4-15 Audio File Note: Only support ‘.wav’ audio files with codec type PCM/PCMU/PCMA, 64kbps or 128 kbps and no more than 500k. 4.4.4 Network TCP/IP Figure 4-4-16 TCP/IP Settings Table 4-4-8 Description of the buttons Parameters Function Introduction Get IPv4 Address Get an IP address from the DHCP server automatically.
  • Page 44 address; IPv6 Mode: Choose different mode for IPv6: Manual/Route Advertisement/ DHCPv6; IPv6 Address: It is used to identify a network camera on the network; IPv6 Prefix: Define the prefix length of IPv6 address; IPv6 Default Gateway: The default router IPv6 address. Note: The Test button is used to test if the IP is conflicting.
  • Page 45 Stream Main Stream http://username:password@IP:port/ipcam/mjpeg.cgi Secondary Stream http://username:password@IP:port/ipcam/mjpegcif.cgi Tertiary Stream http://username:password@IP:port/mjpegthird.cgi RTSP Figure 4-4-18 RTSP Settings Table 4-4-10 Description of the buttons Parameters Function Introduction RTSP Port The port of RTSP, the default is 554. Playback Port The port of playback, the default is 555. There are Better Compatibility and Better Performance two options.
  • Page 46 1) Get the format of RTSP URL by clicking “ ”on the right side of RTSP Port. 2) Get the playback tip by clicking “ ”on the right side of Playback Port. 3) DSCP refers to the Differentiated Service Code Point; and the DSCP value is used in the IP header to indicate the priority of the data.
  • Page 47 DDNS DDNS allows you to access the camera via domain names instead of IP address. It manages to change IP address and update your domain information dynamically. You need to register an account from a provider. Figure 4-4-20 DDNS Settings You can choose “ddns.milesight.com”...
  • Page 48 Email Alarm video files can be sent to specific mail account through SMTP server. You must configure the email settings correctly before using it. Figure 4-4-21 SMTP Settings Table 4-4-13 Description of the buttons Parameters Function Introduction User Name The sender's name. It is usually the same as the account name Sender Email Address Email address to send video files attached emails Password...
  • Page 49 Alarm video files can be sent to specific FTP server. You must configure the FTP settings correctly before using it. Figure 4-4-22 FTP Settings Table 4-4-14 Description of the buttons Parameters Function Introduction Server Address FTP server address Server Port The port of the FTP server.
  • Page 50 If you choose to customize the alarm action file name, YYYY-MM-DD/ Video File Name MM-DD-YYYY/ DD-MM-YYYY/ Add prefix are available. If you choose to customize the alarm action file name, YYYY-MM-DD/ Image File Name MM-DD-YYYY/ DD-MM-YYYY/ Add prefix are available. Timing Snapshot File Default(YYYY-MM-DD) /MM-DD-YYYY/ DD-MM-YYYY/ Add prefix/ Overwrite with Name...
  • Page 51 Note: 1) The obtained IP address is dynamically assigned via PPPoE, so the IP address always changes after rebooting the camera. To solve the inconvenience of the dynamic IP, you need to get a domain name from the DDNS provider (e.g. DynDns.com). 2) The user name and password should be assigned by your ISP.
  • Page 52 Trap Port Set the trap port, the default is 162 Trap Community Name Input the trap community name Read Security Name Input the name of Read Security Community Level of Security There are three levels available: (auth, priv), (auth, no priv) and (no auth, no priv) Write Security Name Input the name of Write Security Community Level of Security...

  • Page 53: Date&Time

    4.4.5 Date&Time Figure 4-4-27 Date&Time Settings Current System Time Current date&time of the system Set the System Time Table 4-4-16 Description of the buttons Parameters Function Introduction Time Zone Choose a time zone for your location. Daylight Saving time Enable the daylight saving time. NTP Sync Regularly update your time according to the interval time.

  • Page 54: Advanced Settings

    4.5 Advanced Settings 4.5.1 Alarm Motion Detection Step1: Check the checkbox to enable the motion detection; Step2: Set motion region; Figure 4-5-1 Motion Region Settings Table 4-5-1 Description of the buttons Parameters Function Introduction Enable Motion Check the checkbox to enable Motion Detection function. Detection Normal and Compatible are available for the option.
  • Page 55 Step3: Set motion detection schedule; Figure 4-5-2 Schedule Settings Step4: Set alarm action; Figure 4-5-3 Alarm Action Table 4-5-2 Description of the buttons Parameters Function Introduction Save Into SD Card Save alarm recording files into SD Card. Save Into NAS Save alarm recording files into NAS.
  • Page 56 Alarm to SIP Phone Support to call the SIP phone after enable the SIP function. HTTP Notification Support to pop up the alarm news to specified HTTP URL. When the alarm triggered, White LED will turn on to warning the detected White LED objects (Only for Mini (PoE) PTZ Bullet).
  • Page 57 Example: http://192.168.8.75:8601/Interface/Cameras/MotionDetection/Notify?Camera=annie, this url format is exactly supported by Digifort VMS, so we can set as above to our cameras and get it work well. Step3: Choose use motion detection by external notification; Step4: If successful, you can see the device icon turn yellow in the Surveillance when the camera is under Motion Detection Alarm;...
  • Page 58 Figure 4-5-4 Alarm Settings Table 4-5-3 Description of the buttons Parameters Function Introduction Record Video Sections Six different periods are available(5, 10, 15, 20, 25, 30 sec). Pre-record Reserve the record time before alarm, 0~10 sec. Snapshot The number of snapshot, from 1 to 5. Snapshot Interval It cannot be edited unless you choose more than 1 to Snapshot.
  • Page 59 Note: 1) Recovery time should not be less than flash time. 2) You can customize the schedule of Audio Action. Figure 4-5-5 Audio Action schedule settings Audio Alarm Enable the Audio before using Audio Alarm function. Figure 4-5-6 Schedule Settings...
  • Page 60 Figure 4-5-7 Alarm Settings Please refer to table 4-5-2 and 4-5-3 to get the meaning of items. External Input Figure 4-5-8 Schedule Settings...
  • Page 61 Figure 4-5-9 Alarm Settings The meaning of items please refer to table 4-5-2 and 4-5-3, here will not repeat again. Other Alarm Figure 4-5-10 Other Alarm...
  • Page 62 Table 4-5-4 Description of the buttons Parameters Function Introduction Network Lost, Tampering and IP Address Conflicted are available Alarm Type Check the checkbox to enable the alarm type you selected Save Into SD Card: Save alarm recording files into SD Card External Output: If the camera equips with External Output, you can enable the action after configuring the trigger duration Play Audio: If the camera equips with Speaker, you can enable the action after...

  • Page 63: Storage

    Please set the Normal Status firstly, when the Current Status is different with Normal Status, it will lead to the alarm. 4.5.2 Storage Before you start: To configure record settings, please make sure that you have the network storage device within the network or the SD card inserted in your camera.
  • Page 64 Table 4-5-6 Description of the buttons Parameters Function Introduction Server Address IP address of NAS server File Path Input the NAS file path, e.g. “\path”. NFS and SMB/CIFS are available. And you can set the user name and password to Mounting Type guarantee the security if SMB/CIFS is selected.
  • Page 65 Table 4-5-6 Description of the buttons Parameters Function Introduction File Sizes: Set record file size, (10-256)M Record Frame Type: All/Key Record Settings (All: Record all the frame Key: Only record I-frame) Schedule Settings Click the Edit button to edit record schedule Note: SD Card or NAS are available.
  • Page 66 Snapshot Figure 4-5-16 Snapshot Table 4-5-7 Description of the buttons Parameters Function Introduction Enable Time Snapshot: Check the checkbox to enable the Timing Snapshot function; Interval: Set the snapshots interval, input the number and choose the unit(millisecond, second, minute, hour, day); Save Into SD Card: Save the snapshots into SD card, and choose the file name to add time suffix or overwrite the base file name;...

  • Page 67: Security

    4.5.3 Security User Figure 4-4-17 User Settings Table 4-5-8 Description of the buttons Parameters Function Introduction Allow anonymous viewing: Check the checkbox to enable visit from whom Manage Privilege doesn’t have account of the device. User Name: Input user name for creating an account; User Password: Input password for the account;...
  • Page 68 Access List Figure 4-5-18 Access List Table 4-5-9 Description of the buttons Parameters Function Introduction Maximum number of concurrent streaming: Select the maximum number of General Settings concurrent streaming. Options include Number Limit, 1~9. Rule: Single, Network and Range are available; IP access list IP address: Input the address to get the access to the device.

  • Page 69: Sip

    Secure Shell (SSH) has many functions: it can replace Telnet and also provides a SSH Settings secure channel for FTP, POP, even for PPP. 4.5.4 SIP The Session Initiation Protocol(SIP) is a signaling communications protocol, widely used for controlling multimedia communication sessions such as voice and video calls over Internet Protocol(IP) networks.
  • Page 70 Unregistered/ SIP registration status. Display “Unregistered” or “Registered” Registered Enable Start or stop using SIP Choose to use Enable mode or Disable mode. Enable mode means to use SIP with Register Mode register account. Disable mode refers to use SIP without register account, just use the IP address to call.

  • Page 71: Smart Event

    Table 4-5-12 Description of the buttons Parameters Function Introduction Phone Number(Call by phone number) & Direct IP Call(Check to accept peer to Phone Type peer IP call). To Phone Number/ Call by phone number or IP address. IP Address Remark Name Display name.
  • Page 72 Figure 4-5-23 Region Entrance Step1: Set detecting object size; Step2: Set entrance detection region; Figure 4-5-24 Set Entrance Detection Region Step3: Set detection schedule; Step4: Set alarm action; Step5: Set alarm settings. Note: The “Object Size” can be set to define whether an object is big enough for triggering the alarm when enter into the selected region.
  • Page 73 Figure 4-5-25 Set Region Exiting Step1: Set detecting object size; Step2: Set exiting detection region; Step3: Set detection schedule; Step4: Set alarm action; Step5: Set alarm settings. Advanced Motion Detection Different from traditional motion detection, Milesight advanced motion detection can filter out “noise”...
  • Page 74 Note: The sensitivity can be configured to detect various movement according to different requirements. When the level of sensitivity is low, slight movement won’t trigger the alarm. Tamper Detection Tamper Detection is used to detect possible tampering like the camera being unfocused, obstructed or moved.
  • Page 75 Figure 4-5-29 Set Line Direction Step2: Draw detection lines; Step3: Set detection schedule; Step4: Set alarm action; Step5: Set alarm settings. Note: Milesight allows to set up to four lines at a time. There are three direction modes to choose for triggering alarm.
  • Page 76 Step5: Set alarm action; Step6: Set alarm settings. Note: After setting minimum loitering time from 3s to 300s, any objects loitering in the selected area over the minimum loitering time will trigger the alarm. Also Milesight loitering allows to set “Object Size”.
  • Page 77 Step1: Set detection line; Step2: Set detection schedule; Step3: Set counting OSD; Figure 4-5-33 Set Counting OSD Step4: Set alarm trigger; Figure 4-5-34 Set Alarm Trigger Step5: Set alarm action; Step6: Set alarm settings. Note: 1) Enable people counting need to enable human detection first; 2) Crossing along the direction of the arrow will record as “In”, opposite is “Out”;...

  • Page 78: Ptz

    Table 4-5-14 Description of the buttons Parameters Function Introduction Process FPS Five different periods are available(5, 10, 15, 20, 25, fps) for process fps Scenario Mode Select Indoor or Outdoor mode to meet your needs Select camera installation view, including Angle View, Horizontal View and Camera Installation Overhead View Analysis Type...
  • Page 79 Table 4-5-15 Description of the buttons Parameters Function Introduction Configure the OSD parameter, and you can set the Zoom status OSD with Close/ Zoom Status Always open/ 2s/ 5s/ 10s. Configure the OSD parameters, and you can set the Pan&Tilt status OSD with Pan&Tilt Status Close/ Always open/ 2s/ 5s/ 10s.
  • Page 80 Auto Home Figure 4-5-37 Auto Home Auto Home allows the PTZ camera to return to a predefined Home Position automatically after a period of latency time. Check the checkbox to enable the Auto Home mode. Table 4-5-16 Description of the buttons Parameters Function Introduction Latency Time...
  • Page 81 PTZ Limit The PTZ camera can be programmed to move within the configurable PTZ Limits(Left/Right). Figure 4-5-38 PTZ Limit Step1: Check the checkbox to enable the PTZ Limit function. Step2: Choose the limit mode as Manual limit or scanning limit. ...
  • Page 82 Table 4-5-17 Description of the buttons Parameters Function Introduction Click to set the current position as a Initial Position Clear Clear the Initial Position to default settings. Call Click to call the Initial Position. Note: This function is only for Mini (PoE) PTZ Bullet. Privacy Mask Privacy mask enables to cover certain areas on the live video to prevent certain spots in the surveillance area from being viewed and recorded.
  • Page 83 Select the color for the privacy areas, there are eight colors available: White, Type Black, Blue, Yellow, Green, Brown, Red, Violet Set the value of Active Zoom Ratio according to your need, and then the mask will Active Zoom Ratio only appear when the zoom ratio is greater than the predefined value Scheduled Tasks You can configure the PTZ camera to perform a certain action automatically in a user-defined time...

  • Page 84: Logs

    Config Clear Figure 4-5-42 Config Clear Here you can clear PTZ configurations, including all PTZ configurations, Presets, Patrols, Patterns, Auto Homes, PTZ Limits , Initial Position(Mini PTZ Bullet), Privacy Masks and Scheduled Tasks. RS485 Figure 4-5-43 RS485 Here you can clear configure RS485 serial port to control the PTZ of Speed Dome. Protocol, Baudrate, Data Bit, Stop Bit, Parity, Flow Control, PTZ Address should be exactly the same as those of the control device.

  • Page 85: System

    Figure 4-5-44 Logs Table 4-5-19 Description of the buttons Parameters Function Introduction There are five main log types: All Type, Event, Operation, Information, Main Type Exception. On the premise that main type has been selected, select the sub type to narrow Sub Type the range of logs.
  • Page 86 Figure 4-6-1 System Information Table 4-6-1 Description of the parameters Parameters Function Introduction Device Name The device name can be customized. It will be seen in file names of video files. Product Model The product model of the camera Hardware Version The hardware version of the camera Software Version The software version of the camera can be upgraded...

  • Page 87: Maintenance

    4.7 Maintenance 4.7.1 System Maintenance The software can be upgraded by the following steps: Step1: Browse and select the upgrading file; Step2: Click the “upgrade” button after it prompts upload file successfully. After the system reboots successfully, the update is done. Note: Do not disconnect the power of the device during the update.
  • Page 88 Reboot the device: Click “Reboot” button to restart the device immediately Reset settings: Click “Reset” button to reset the camera to factory default settings Maintenance Keep the IP Configuration: Select this option to keep the IP configuration when resetting the camera Export Config File: Click this button to export the configuration file Import Config File: Click this button to import the old configuration file 4.7.2 Auto Reboot...

  • Page 89: Chapter V Services

    Chapter V Services Milesight Technology Co., Ltd provides customers with timely and comprehensive technical support services. End-users can contact your local dealer to obtain technical support. Distributors and resellers can contact directly with Milesight for technical support. Technical Support Mailbox: support@milesight.com Web: http://www.milesight.com...
