Sharx Security

HTNC Series PoE IP Camera

API Reference Manual

2018 Version

Table of Contents

Need help?

Do you have a question about the HTNC Series and is the answer not in the manual?

Questions and answers

Summary of Contents for SHARX SECURITY HTNC Series

Page 1 Sharx Security HTNC Series PoE IP Camera API Reference Manual 2018 Version...
Page 2 Some commands also return detailed status information from the camera. To use this reference guide you’d need to have administrator login access to an HTNC series camera that is already set up for your network (or accessible to you remotely). It is also assumed that you know the basics of writing a program or a script to send commands via HTTP.
Page 3: Stream Path Summary
Stream path summary Quite often the most important piece of information that a programmer is looking for is the spelling of the camera’s stream paths, so we summarized it up front. /1/stream1 Primary H264 RTSP stream: /1/stream2 MJPEG RTSP stream: /1/stream3 Third stream (H264 RTSP): /snapshot/1/snapshot.jpg...
Page 4: Table Of Contents
Table of Contents Stream path summary ........................3 Table of Contents ..........................4 Audio ..............................27 Revision History ......................... 27 Introduction ..........................27 Audio URI ..........................27 Back Channel Audio URI ......................27 Audio Parameter ......................... 27 Back Channel Audio Parameter....................28 Examples ............................
Page 5 4) Home Function Type setup ......................38 5) Home Function number setup ......................38 6) Home Function number set setup ..................38 Caution............................38 Dome – Motor Setup: ........................40 Revision History ......................... 40 Introduction ..........................40 Motor Setup URI ........................40 Motor Setup Parameter .......................
Page 6 6) Dome Answer setup........................48 Caution ..............................48 Dome – System Menu: ......................... 49 Revision History ......................... 49 Introduction ..........................49 System Menu URI ........................49 System Menu Parameter ......................49 Examples ............................ 50 1) Get the current PTZ Camera information and settings ............50 2) Check current Origin Check function status ...............
Page 7 2) AIHM setup ............................ 59 3) AIHM record status check setup..................... 59 4) AIHM format event setup ....................59 5) AIHM server setup ......................59 6) AIHM dwell time setup ...................... 60 Caution............................60 Event – Alarm In: ......................... 61 Revision History .........................
Page 8 Revision History ..........................67 Introduction ............................67 Boost URI ........................... 67 Boost Parameter .......................... 67 Examples ............................ 67 1) get the current setting ......................67 2) Boost setup ......................... 67 3) Boost stream setup ......................67 4) Boost stream1 Normal Condition setup................67 5) Boost stream2 Normal Condition setup................
Page 9 4) Event Push Pre-event setup ......................78 5) Event Push Post-event setup ......................78 6) Event Push URL setup......................78 7) Event Push Port setup ......................78 8) Event Push User name setup ....................78 9) Event Push Password setup ....................78 Caution............................
Page 10 3) Light brightness setup ........................85 4) Light mode & Light time setup ...................... 85 5) Operates only at night mode setup ..................86 6) Inactivate setup ........................86 Caution............................86 Event – Manual Trigger: ......................87 Revision History ......................... 87 Introduction ..........................
Page 11 3) Notification Server Type setup ....................... 97 4) Notification Server Method setup ....................98 5) Notification Server URL setup ................... 98 6) Notification Server Port setup .................... 98 7) Notification Server user setup .................... 98 8) Notification Server password setup ..................98 7) Notification Server Test .....................
Page 12 7) record audio setup ......................... 104 8) record schedule setup ........................104 9) record device type setup ....................105 10) record address setup ....................... 105 11) record remote directory setup ..................105 12) record capacity setup ...................... 105 13) record ID setup ....................... 105 13) record password setup ....................
Page 13 2) Time Trigger usage setup ......................112 3) Time Trigger # usage setup ......................112 4) Time Trigger # Specific Time usage setup ............... 112 5) Time Trigger # Day usage setup ..................112 6) Time Trigger # Day Of Week usage setup ............... 112 7) Time Trigger # Month usage setup...................
Page 14 Event Stream ........................... 121 Revision History ..........................121 Introduction ..........................121 Event Stream URI ........................121 Event Stream Format ........................ 121 1) HTTP GET REQUEST ....................121 2) HTTP POST REQUEST ....................121 3) HTTP CONTINUES RESPONSE ................... 122 Event Stream Request Parameter ....................122 Table 1.
Page 15 Introduction ............................134 Smart Focus URI ..........................134 Smart Focus Parameter ......................134 Example ............................ 134 Caution............................134 Live – Light Control: ......................... 135 Revision History ........................135 Introduction ..........................135 Light Control URI ........................135 Light Control Parameter ......................135 Examples ..........................
Page 16 Caution .............................. 139 Live – X1 Dome Configuration – Position: ..................140 Revision History ........................140 Introduction ..........................140 PTZ Position URI ........................140 PTZ Position Parameter ......................140 Examples ..........................140 1) Get the current setting ...................... 140 2) PTZ Position setup ......................140 3) PTZ Position setup (Degree) ....................
Page 17 13) Backward Quadruple Speed Play ....................150 14) Backward play stop ........................150 15) Clipcopy ......................... 151 16) Only I Frame with interval 1 Sec(record time line) ............151 Caution............................151 Snapshot ............................152 Revision History ........................152 Introduction ..........................152 Snapshot URI ..........................
Page 18 System – DDNS: ..........................160 Revision History ..........................160 Introduction ..........................160 DDNS URI ..........................160 DDNS Parameter ........................160 Examples ..........................160 1) get the current setting ....................... 160 2) DDNS setup ........................160 3) DDNS server URL setup ....................160 4) DDNS Host name setup....................
Page 19 IP Filtering Parameter ........................166 Examples ............................166 1) get the current setting ....................... 166 2) IP Filtering setup ......................166 3) IP Filtering Priority 1......................166 4) IP Filtering Priority 2......................167 5) IP Filtering Priority 3......................167 6) IP Filtering Priority 4......................167 7) IP Filtering Priority 5......................
Page 20 3) Default ............................174 4) Upgrade ............................174 5) VCA Upgrade ........................174 6) Backup ..........................174 7) Restore ..........................174 8) Calibrate ........................... 174 Examples ..........................174 1) Restart ..........................174 2) Reset ..........................174 3) Default ..........................175 4) Upgrade ..........................
Page 21 5) fixed Gateway Address setup ....................... 181 6) IPv6 setup ............................. 181 7) DNS Address assign method setup ................... 181 8) fixed DNS Server Domain Name setup ................181 9) fixed Primary DNS Server Address setup ................ 181 10) fixed Secondary DNS Server Address setup ..............181 11) Host Name setup ......................
Page 22 2) DSCP Setting ..........................188 3) Automatic Traffic Control ......................188 System – RTP: ..........................190 Revision History ........................190 Introduction ..........................190 RTP Parameter .......................... 190 Example ............................ 190 1) get the current setting ....................... 190 2) RTP Port Range ........................ 191 3) Multicast (Stream 1) ......................
Page 23 3) add Server ............................. 199 4) modify Server ..........................199 5) remove Server ........................199 Caution............................199 System – Network – Wireless: ....................200 Revision History ........................200 Introduction ..........................200 Wireless URI ..........................200 1) Wireless Network URI ..................... 200 2) Wireless Setup NRI ......................
Page 24 9) Noise Reduction setup ........................209 10) Noise Reduction Level setup ...................... 209 11) WDR setup ........................209 12) WDR Level setup ......................209 13) Defog setup ........................209 14) Defog Strength setup ...................... 210 15) IRIS setup ........................210 16) Backlight Compensation setup ..................
Page 25 60) Dark Buster setup ........................214 61) Dark Buster Level setup ......................214 Caution............................214 Video & Image – OSD: ......................216 Revision History ........................216 Introduction ..........................216 OSD URI ..........................216 OSD Parameter ......................... 216 Example ............................ 217 1) get the current setting .......................
Page 26 7) Bitrate setup ..........................227 8) Quality setup ..........................227 9) GOP (Group of Picture) setup ..................228 Caution............................228 -26-...
Page 27: Audio
Audio Version: 1.02 Date: 2016. 12. 13 Revision History Version Date Comment 1.00 2014-10-01 Initial version 1.01 2015-05-22 Added changes related to Xarina Entry 1.01e 2015-05-22 English Translation 1.02 2016-01-28 Add Xarina Entry Audio Codec AAC Introduction This Chapter defines the detailed setup procedure for the Audio and Back Channel Audio. Audio URI http://”camera ipaddress”/audio/audio.php Back Channel Audio URI...
Page 28: Back Channel Audio Parameter
Back Channel Audio Parameter Parameter Type Value snd#_back_channel_audio_statu integer 0 : Free, 1 : Occupied * ‘#’ : Audio Channel number Examples 1) get the current setting get the Audio setting • http://”camera ipaddress”/audio/audio.php?app=get get the Back Channel Audio setting •...
Page 29: Audio Input Mute Setup
http://”camera ipaddress”/audio/audio.php?app=set&snd1_in_gain=12.0 http://”camera ipaddress”/audio/audio.php?app=set&snd1_in_gain=-12 b. Input Value setup http://”camera ipaddress”/audio/audio.php?app=set&snd1_in_gain=10 http://”camera ipaddress”/audio/audio.php?app=set&snd1_in_gain=1 * Please refer to Caution. 8) Audio Input Mute setup http://”camera ipaddress”/audio/audio.php?app=set&snd1_in_mute=0 http://”camera ipaddress”/audio/audio.php?app=set&snd1_in_mute=1 9) Back Channel Audio Enable setup http://”camera ipaddress”/audio/audio.php?app=set&snd1_2way=0 http://”camera ipaddress”/audio/audio.php?app=set&snd1_2way=1 10) Back Channel Audio Volume setup a.
Page 30 OUTPUT_GAIN_VAL • snd#_out_gain can be set Output Value G711U, G711A • snd#_codec can be set G711 Audio Codec • snd#_codec can be set AAC Audio Codec • snd#_enable, snd#_codec, snd#_bitrate, snd#_samplerate, snd#_in, snd#_in_gain, snd#_in_mute items can be checked and set. •...
Page 31: Config.txt
1) Parameters Parameter Type Value integer Config.txt file version Camera series series string X2 : Sharx Security HTNC44xx series camera X4 : Sharx Security HTNC45xx series camera name string Host name ipv4 string Camera IP ver. 4 address ipv6 string Camera IP ver.
Page 32  ntsc : NTSC  pal : PAL total_ch integer Number of video channels total_strm integer Number of video streams ch#_strm#_uri string RTSP stream URI RTSP video stream codec name  H264BP : H.264 Baseline Profile  H264MP : H.264 Main Profile ...
Page 33: Motorized Options
RS-485 support description, ptz_option string Description types are in 3) RS-485 option function support description of PTZ camera, builtin_ptz_option string Description types are in 4) PTZ option VCA function support description, vca_option string Description types are in 5) VCA option vca_sw_ver string VCA software version...
Page 34: Vca Options
RS485_OUT RS485 Output support PRESET_GO preset go support PRESET_SAVE preset save support PRESET_CTRL preset control support TOUR_GO tour go support TOUR_CTRL tour modify support AUTO_SCAN_GO auto scan go support AUTO_SCAN_CTRL auto scan modify support PATTERN_GO pattern go support PATTERN_CTRL pattern modify support PTZ_POSITION PTZ position Get/Set support 5) VCA options...
Page 35 DEFOG Defog support Video motion detection support PTZ control support via RS485 BUILTIN_PTZ PTZ control support for Built-in PTZ camera OSD_CTRL on screen display control support at Video out OSD_DISPLAY_CTRL on screen display control support in Video stream FTP&JPEG support at Event In SMTP SMTP support at Event In MULTI_STREAM...
Page 36: Example
TAMPERING tampering support at Event in LIGHT light support at Event out PIR support at Event in WIRELESS Wireless network support LIVE_PUSH Live push support EVENT_PUSH Event push support VSAAS VSAAS support EVENT_NOTI XML notification support at Event out BOOST Boost support at Event out NOTIFY_SERVER Notification server support at Event out...
Page 37: Dome Configuration
Dome Configuration Dome – Home Function: Version : 1.00 Date : 2014. 09. 26 Revision History Version Date Comment 1.00 2014-09-26 Initial version Introduction This Chapter defines the detailed setup procedure for the Home Function. Home Function URI http://”camera ipaddress”/ptz/home_function.php Home Function Parameter Parameter Type...
Page 38: Examples
Examples 1) get the current setting http://”camera ipaddress”/ptz/home_function.php?app=get http://”camera ipaddress”/ptz/home_function.php?app=get&method=get_list 2) Home Function setup http://”camera ipaddress”/ptz/home_function.php?app=set&home_function_use=0 http://”camera ipaddress”/ptz/home_function.php?app=set&home_function_use=1 3) Home Function Waiting Time setup http://”camera ipaddress”/ptz/home_function.php?app=set&home_waiting_time=10 http://”camera ipaddress”/ptz/home_function.php?app=set&home_waiting_time=60 4) Home Function Type setup http://”camera ipaddress”/ptz/home_function.php?app=set&home_function=0 http://”camera ipaddress”/ptz/home_function.php?app=set&home_function=1 http://”camera ipaddress”/ptz/home_function.php?app=set&home_function=2 5) Home Function number setup “home_function”...
Page 39 -39-...
Page 40: Dome – Motor Setup
Dome – Motor Setup: Version : 1.00 Date : 2014. 09. 29 Revision History Version Date Comment 1.00 2014-09-29 Initial version Introduction This Chapter defines the detailed setup procedure for the Motor Setup Motor Setup URI http://”camera ipaddress”/ptz/motor.php Motor Setup Parameter Parameter Type Value...
Page 41: Motor Setup Max Tilt Speed Setup
4) Motor Setup Max Tilt Speed setup http://”camera ipaddress”/ptz/motor.php?app=set&max_tilt_speed=10 Caution You must check the following values in the response to http://”camera ipaddress”/config.txt Item Value Explanation option BUILTIN_PTZ Motor Setup available -41-...
Page 42: Dome – Preset
Dome – Preset: Version : 1.00 Date : 2014. 09. 18 Revision History Version Date Comment 1.00 2014-09-18 Initial version Introduction This Chapter defines the detailed setup procedure for the Preset. Preset URI http://”camera ipaddress”/ptz/preset.php Preset Parameter Parameter Type Value get_num : check setting value create : Preset creation and modification method...
Page 43: Examples
Examples 1) get configurable Preset value http://”camera ipaddress”/ptz/preset.php?app=get http://”camera ipaddress”/ptz/preset.php?app=get&method=get_num 2) get the current setting http://”camera ipaddress”/ptz/preset.php?app=get&preset_number=1 http://”camera ipaddress”/ptz/preset.php?app=get&method=get_num&preset_number=1 3) Preset creation create a Preset by using the “method=create” parameter http://”camera ipaddress”/ptz/preset.php?app=set&method=create • preset_number is configurable minimum number, preset_title “PRESET ‘preset_number’”, preset_af_mode is 0 (Auto : default), preset_speed is 4 (default) create a Preset by assigning a specific Preset Number...
Page 44: Preset Movement
** the “preset_number” parameter should be included when modifying a preset, pre-configured value also should be included . 6) Preset movement http://”camera ipaddress”/ptz/preset.php?app=set&method=preset_go&preset_number=3 http://”camera ipaddress”/ptz/preset.php?app=set&method=preset_go&preset_number=4 * the “preset_number” parameter should be included when deleting a preset Caution You must check the following values in the response to http://”camera ipaddress”/config.txt item Value Explanation...
Page 45: Dome – Privacy Zone
Dome – Privacy Zone: Version : 1.00 Date : 2014. 10. 06 Revision History Version Date Comment 1.00 2014-10-06 Initial version Introduction This Chapter defines the detailed setup procedure for the Privacy Zone. Privacy Zone URI http://”camera ipaddress”/ptz/privacy_zone.php Privacy Zone Parameter Parameter Type Value...
Page 46: Privacy Zone Creation
2) Privacy Zone creation http://”camera ipaddress”/ptz/privacy_zone.php?app=set&method=create&masking_number=1 * the parameter for the creation of Privacy Zone are only “method” and “masking_number” . * if Privacy Zone has been created, “masking_title”, “masking_enable”, “masking_set” parameter values will be automatically set and you will see a response like the one below res=200&masking_number=1&masking_title=MASK-1&masking_enable=1&masking_set=1 3) Privacy Zone modification http://”camera...
Page 47: Dome – Rs485
Dome – RS485: Version : 1.00 Date : 2014. 10. 01 Revision History Version Date Comment 1.00 2014-10-01 Initial version Introduction This Chapter defines the detailed setup of the RS485. RS485 URI http://”camera ipaddress”/ptz/comm.php RS485 Parameter Parameter Type Value min_comm_id integer (ro) max_comm_id integer (ro)
Page 48: Parity Setup
http://”camera ipaddress”/ptz/comm.php?app=set&comm_baud=1 http://”camera ipaddress”/ptz/comm.php?app=set&comm_baud=2 http://”camera ipaddress”/ptz/comm.php?app=set&comm_baud=3 http://”camera ipaddress”/ptz/comm.php?app=set&comm_baud=4 5) Parity setup http://”camera ipaddress”/ptz/comm.php?app=set&comm_parity=0 http://”camera ipaddress”/ptz/comm.php?app=set&comm_parity=1 http://”camera ipaddress”/ptz/comm.php?app=set&comm_parity=2 6) Dome Answer setup http://”camera ipaddress”/ptz/comm.php?app=set&comm_dome_answer=0 http://”camera ipaddress”/ptz/comm.php?app=set&comm_dome_answer=1 Caution You must check the following values in the response to http://”camera ipaddress”/config.txt item Value Explanation option BUILTIN_PTZ, PTZ...
Page 49: Dome – System Menu
Dome – System Menu: Version: 1.01e Date: 2015. 07. 24 Revision History Version Date Comment 1.00 2014-10-02 Initial version 1.01 2015-07-22 Add Schedule Origin Check 1.01e 2015-07-24 English Translation Introduction This Chapter defines the detailed setup procedure for the System Menu. System Menu URI http://”camera ipaddress”/ptz/system_menu.php System Menu Parameter...
Page 50: Examples
sys_weekly_dayofwee Weekly day of week ( 0 ~ 6 ) integer 0 : Sun, 1 : Mon, 2 : Tue, 3 : Wed, 4 : Thu, 5 : Fri, 6 : Sat sys_monthly_time string Monthly time ( HH:MM:SS ) sys_weekly_time string Weekly time ( HH:MM:SS )
Page 51: Fa Module F/W Upgrade
http://”camera ipaddress”/ptz/system_menu.php?app=set&sys_enable_weekly=1 d. Enable Daily setup http://”camera ipaddress”/ptz/system_menu.php?app=set&sys_enable_daily=0 http://”camera ipaddress”/ptz/system_menu.php?app=set&sys_enable_daily=1 e. Monthly Day setup http://”camera ipaddress”/ptz/system_menu.php?app=set&sys_monthly_day=20 f. Weekly Day of week setup http://”camera ipaddress”/ptz/system_menu.php?app=set&sys_weekly_dayofweek=3 g. Monthly Time setup http://”camera ipaddress”/ptz/system_menu.php?app=set&sys_monthly_time=23:50:00 h. Weekly Time setup http://”camera ipaddress”/ptz/system_menu.php?app=set&sys_weekly_time=01:20:00 i. Daily Time setup http://”camera ipaddress”/ptz/system_menu.php?app=set&sys_daily_time=05:31:00 7) FA Module F/W Upgrade http://”camera...
Page 52: Caution
c. For further information about multipart/form-data, please refer to the following URL’s. multipart/form-data : <http://www.w3.org/TR/html401/interact/forms.html> multipart/form-data RFC : <http://www.ietf.org/rfc/rfc2045.txt> Caution You can check current settings by referring to the following values in the response to http://”camera ipaddress”/config.txt. Item Value Description BUILTIN_PTZ System Menu setup available options...
Page 53: Dome – Tour
Dome – Tour: Version : 1.00 Date : 2014. 09. 25 Revision History Version Date Comment 1.00 2014-09-25 Initial version Introduction This Chapter defines the detailed setup procedure for the Tour Tour URI http://”camera ipaddress”/ptz/tour.php Tour Parameter Parameter Type Value get_num : check configured value get_preset : Preset creation and modification get_tour : deletion of configured Preset...
Page 54: Examples
dwell_min integer (ro) 0 : configurable minimum Dwell Time dwell_max integer (ro) 99 : configurable maximum Dwell Time Default Pan/Tilt speed def_pt_speed integer (ro) 5 : Xarina2 FASTRAX5 8 : Xarina2 PTZ Camera(FASTRAX5 ) pt_speed_min integer (ro) 1 : configurable minimum Pan/Tilt speed pt_speed_max integer (ro) 8 : configurable maximum Pan/Tilt speed...
Page 55 Tour creation by assigning specific Tour Title http://”camera ipaddress”/ptz/tour.php?app=set&method=create&tour_number=1&tour_title=BASIC_TOUR • tour_repeat_time is 0 (Continuous : default), tour_sequence is 0 (Forward : default) tour_tourlist should be configured separately * “tour_number” parameter should be stated when creating the Tour Tour creation by assigning specific tour_repeat_time http://”camera ipaddress”/ptz/tour.php?app=set&method=create&tour_number=3&tour_repeat_time=5 •...
Page 56: Tour Deletion
tour_repeat_time is 0 (Continuous : default), tour_sequence is (Forward : default) * Preset position should be pre-configured to check proper tour functionality * “tour_number” parameter should be stated when creating the Tour. 6) Tour deletion http://”camera ipaddress”/ptz/tour.php?app=set&method=delete&tour_number=1 * the “tour_number” parameter should be included when deleting the Tour. 7) Tour modification http://”camera ipaddress”/ptz/tour.php?app=set&method=create&tour_number=1&tour_title=MODIFY_TOU...
Page 57: Dome – View Angle
Dome – View Angle: Version : 1.00 Date : 2014. 10. 02 Revision History Version Date Comment 1.00 2014-10-02 Initial version Introduction This Chapter defines the detailed setup procedure for the View Angle. View Angle URI http://”camera ipaddress”/ptz/view_angle.php View Angle Parameter Parameter Type Value...
Page 58: Examples
MINITRAX3 : "Off,Auto,90,100,110,120" Examples 1) get the current setting http://”camera ipaddress”/ptz/view_angle.php?app=get 2) Tilt Angle Limit setup http://”camera ipaddress”/ptz/view_angle.php?app=set&tiltoverangle=10 http://”camera ipaddress”/ptz/view_angle.php?app=set&tiltoverangle=-10 3) Flip setup http://”camera ipaddress”/ptz/view_angle.php?app=set&ptz_flip=0 http://”camera ipaddress”/ptz/view_angle.php?app=set&ptz_flip=1 http://”camera ipaddress”/ptz/view_angle.php?app=set&ptz_flip=2 * In case of FASTRAX5, only 0 or 1 value is allowed for “ptz_flip” parameter Caution You must check the following values in the response to http://”camera ipaddress”/config.txt Item...
Page 59: Event
Event Event – AIHM: Version: 1.01e Date: 2016. 12. 16 Revision History Version Date Comment 1.00 2015-09-06 Initial version 1.00e 2015-09-06 English Translation 1.01 2016-12-16 Added Dwell Time, AIHM Server API Introduction This Chapter defines the detailed setup procedure for the AIHM. AIHM URI http://”camera ipaddress”/event/aihm.php AIHM Parameter...
Page 60: Aihm Dwell Time Setup
6) AIHM dwell time setup http://”camera ipaddress”/event/aihm.php?app=set&aihm_time=1 http://”camera ipaddress”/event/aihm.php?app=set&aihm_time=180 Caution You must check the following values in the response to http://”camera ipaddress”/config.txt Item Value Explanation AIHM function available options AIHM...
Page 61: Event – Alarm In
Event – Alarm In: Version: 1.00e Date: 2014. 03. 03 Revision History Version Date Comment 1.00 2014-01-23 Initial version 1.00e 2014-03-03 English Translation Introduction This Chapter defines the detailed setup procedure for the Alarm In. Alarm In URI http://”camera ipaddress”/event/alarm_in.php Alarm In Parameter Parameter Type...
Page 62: Event – Alarm Out
Event – Alarm Out: Version: 1.00e Date: 2014. 03. 03 Revision History Version Date Comment 1.00 2014-01-24 Initial version 1.00e 2014-03-03 English Translation Introduction This Chapter defines the detailed setup procedure for the Alarm Out. Alarm Out URI http://”camera ipaddress”/event/alarm_out.php Alarm Out Parameter Parameter Type...
Page 63: Event – Audio Alert
Event – Audio Alert: Version: 1.00e Date: 2014. 03. 17 Revision History Version Date Comment 1.00 2014-02-13 Initial version 1.00e 2014-03-17 English Translation Introduction This Chapter defines the detailed setup procedure for the Audio Alert. Audio Alert URI http://”camera ipaddress”/event/audio_alert.php Audio Alert Parameter Parameter Type...
Page 64: Reminder For The Audio Alert File Upload
options AUD_ALERT Audio Alert function available * In order to use Audio Alert, both “Audio” and “bidirectional Audio” should be enabled. 1) Reminder for the Audio Alert file upload a. File upload uses multipart/form-data of MIME protocol HTML tag. A prior knowledge of the file name is needed for uploading.
Page 65: Event – Audio Detection
Event – Audio detection: Version: 1.00e Date: 2014. 03. 17 Revision History Version Date Comment 1.00 2014-01-23 Initial version 1.00e 2014-03-17 English Translation Introduction This Chapter defines the detailed setup procedure for the Audio detection. Audio detection URI http://”camera ipaddress”/event/audio_detection.php Audio detection Parameter Parameter Type...
Page 66 Item Value Explanation AUD_DETECTIO Audio Detection function available options -66-...
Page 67: Event – Boost
Event – Boost: Version: 1.00e Date: 2014. 03. 17 Revision History Version Date Comment 1.00 2014-02-26 Initial version 1.00e 2014-03-17 English Translation Introduction This Chapter defines the detailed setup procedure for the Boost. Boost URI http://”camera ipaddress”/event/boost.php Boost Parameter Parameter Type Value boost_enable...
Page 68: Boost Stream2 Normal Condition Setup
* If URI includes boost_stream, the value of boost_stream must match the number at the end of “ch1_strm” for proper operation. http://”camera ipaddress”/event/boost.php?app=set&boost_enable=1&ch1_strm1_fps=5 * If URI does not include boost_stream, the current stream number must match the number at the end of “ch1_strm”...
Page 69: Boost Condition Setup
http://”camera ipaddress”/event/boost.php?app=set&boost_enable=1&boost_stream=3&ch1_strm3_fps=25 * If URI includes boost_stream, the value of boost_stream must match the number at the end of “ch1_strm” for proper operation. http://”camera ipaddress”/event/boost.php?app=set&boost_enable=1&ch1_strm3_fps=5 * If URI does not include boost_stream, the current stream number must match the number at the end of “ch1_strm”...
Page 70: Explanation On "Ch#¹_Strm#²_
* ch#¹_strm#²_maxfps is explained below current bitrate setting ch#¹_strm#²_bitrate 1 ~ ch#¹_strm#²_maxbr * ch#¹_strm#²_maxbr is explained below current bitrate control setting ch#¹_strm#²_ratecontrol cbr or vbr current Quality setting ch#¹_strm#²_quality 1 ~ 100 2) Explanation on “ch#¹_strm#²_○○○” in Parameter column of table in “3. Boost Parameter” a.
Page 71: Event – Map
Event – Map: Version: 1.02e Date: 2015. 07. 20 Revision History Version Date Comment 1.00 2013-12-11 Initial version 1.00e 2014-03-18 English Translation 1.01e 2015-05-21 Event Map Renewal 1.02e 2015-07-20 AIHM, Time Trigger Update Introduction This Chapter defines the detailed setup procedure for the Event Map. Event Map setup is divided into List retrieve, List add, List remove, and List modify.
Page 72 event_out_http_msg string Message String for HTTP Notification event_out_audio boolean 0(Disable), 1(Enable) event_out_audio_file integer 1 ~ 3 event_out_preset boolean 0(Disable), 1(Enable) event_out_preset_num integer 1 ~ 255 event_out_preset_home boolean 0(false), 1(true) event_out_record boolean 0(false), 1(true) event_out_event_push boolean 0(false), 1(true) event_out_light boolean 0(false), 1(true) event_out_event_noti boolean 0(false), 1(true)
Page 73: Examples
Audio Detection AIHM Time Trigger Time Trigger 1 Time Trigger 2 Time Trigger 3 Time Trigger 4 Examples 1) get the current setting http://”camera ipaddress”/event/map.php?app=get 2) Method setup add : http://”camera ipaddress”/event/event_pop.php?app=set&method=add&event_in_id=1000&event_name=test &event_out_alarm=1 modify : http://”camera ipaddress”/event/event_pop.php?app=set&method=modify&event_in_id=1000&event_name=t est2 remove : http://”camera ipaddress”/event/event_pop.php?app=set&method=remove&event_in_id=1000 3) Event name setup http://”camera...
Page 74: Event Out Ftp Setup
6) Event out FTP setup http://”camera ipaddress”/event/event_pop.php?app=set&method=add&event_in_id=0500&event_name=test &event_out_ftp=1 http://”camera ipaddress”/event/event_pop.php?app=set&method=modify&event_in_id=0500&event_name=t est&event_out_ftp=1 * If event_out_ftp is 1 and the camera is T-series, only event_out_ftp is set instead of event_out_ftp_server1. 7) Event out FTP Server setup http://”camera ipaddress”/event/event_pop.php?app=set&method=add&event_in_id=0500&event_name=test &event_out_ftp_server1=1 http://”camera ipaddress”/event/event_pop.php?app=set&method=modify&event_in_id=0500&event_name=t est&event_out_ftp_server1=1 http://”camera ipaddress”/event/event_pop.php?app=set&method=add&event_in_id=0500&event_name=test &event_out_ftp_server2=1...
Page 75: Event Out Preset Setup
10) Event out preset setup http://”camera ipaddress”/event/event_pop.php?app=set&method=add&event_in_id=0500&event_name=test &event_out_preset=1&event_out_preset_num=10&event_out_preset_home=1 http://”camera ipaddress”/event/event_pop.php?app=set&method=modify&event_in_id=0500&event_name=t est&event_out_preset=1&event_out_preset_num=20&event_out_preset_home=0 11) Event out record setup http://”camera ipaddress”/event/event_pop.php?app=set&method=add&event_in_id=0500&event_name=test &event_out_record=1 http://”camera ipaddress”/event/event_pop.php?app=set&method=modify&event_in_id=0500&event_name=t est&event_out_record=1 12) Event out event push setup http://”camera ipaddress”/event/event_pop.php?app=set&method=add&event_in_id=0500&event_name=test &event_out_event_push=1 http://”camera ipaddress”/event/event_pop.php?app=set&method=modify&event_in_id=0500&event_name=t est&event_out_event_push=1 13) Event out light setup http://”camera ipaddress”/event/event_pop.php?app=set&method=add&event_in_id=0500&event_name=test &event_out_light=1 http://”camera...
Page 76: Caution
http://”camera ipaddress”/event/event_pop.php?app=set&method=add&event_in_id=0500&event_name=test& event_out_smtp=1&event_out_smtp_en1=1&event_out_smtp_title=test&event_out_smtp_msg= testmsg&event_out_alarm=1&event_out_ftp=1&event_out_http=1&event_out_http_msg=test& event_out_audio=1&event_out_audio_file=1&event_out_preset=1&event_out_preset_num=10 &event_out_preset_home=1&event_out_record=1&event_out_event_push=1&event_out_light= 1&event_out_event_noti=1&event_out_boost=1 http://”camera ipaddress”/event/event_pop.php?app=set&method=modify&event_in_id=0500&event_name=te st&event_out_smtp=1&event_out_smtp_en1=1&event_out_smtp_title=test&event_out_smtp_m sg=testmsg&event_out_alarm=1&event_out_ftp=1&event_out_http=1&event_out_http_msg=tes t&event_out_audio=1&event_out_audio_file=1&event_out_preset=1&event_out_preset_num=1 0&event_out_preset_home=1&event_out_record=1&event_out_event_push=1&event_out_light =1&event_out_event_noti=1&event_out_boost=1 Caution You must check the following values in the response to http://”camera ipaddress”/config.txt Item Value Explanation alarm_in integer Number of Event In Alarm alarm_out interger Number of Event Out Alarm Event In Motion available ALARM_IN Event In Alarm In available...
Page 77: Event – Event Push
Event – Event Push: Version: 1.00e Date: 2014. 03. 18 Revision History Version Date Comment 1.00 2014-01-27 Initial version 1.00e 2014-03-18 English Translation Introduction This Chapter defines the detailed setup procedure for the Event Push. Event Push URI http://”camera ipaddress”/event/event_push.php Event Push Parameter Parameter Type...
Page 78: Event Push Pre-Event Setup
4) Event Push Pre-event setup http://”camera ipaddress”/event/event_push.php?app=set&event_push_pre_time=3 http://”camera ipaddress”/event/event_push.php?app=set&event_push_pre_time=11 * If the event_push_pre_time is assigned to a value bigger than 10, the value is set to the maximum value (10). * If the event_push_pre_time is assigned to a value less than 0, the value is set to the minimum value (0).
Page 79: Event – Face Detector
Event – Face Detector: Version : 1.00e Date : 2015. 01. 29 Revision History Version Date Comment 1.00 2015-01-28 Initial version 1.00e 2015-01-29 English Translation Introduction This Chapter defines the setup procedure for the Face Detector. Face Detector URI http://”ipaddress”/event/face_detector.php Face Detector Parameter Parameter Type...
Page 80: Event – Ftp & Jpeg
Event – FTP & JPEG: Version: 1.01e Date: 2015. 05. 21 Revision History Version Date Comment 1.00 2014-02-11 Initial version 1.00e 2014-03-18 English Translation 1.01e 2015-05-21 FTP&JPEG renewal Introduction This Chapter defines the detailed setup procedure for the FTP & JPEG. FTP &...
Page 81: Examples
ftp#_mode boolean 0 : Active Mode, 1 : Passive Mode ftp#_user string User name ftp#_pass string Password ftp#_anonymous boolean 0 : Identified, 1 : Anonymous ftp#_path string Directory for uploading JPEG images ftp#_enable_time_folde boolean 0 : Off, 1 : On ftp#_time_folder_type integer 1: Day, 2: Hour, 3: Minute...
Page 82: Ftp & Jpeg Port Setup
http://”camera ipaddress”/event/ftp.php?app=set&ftp4_server=10.0.2.15 5) FTP & JPEG Port setup http://”camera ipaddress”/event/ftp.php?app=set&ftp_port=8079 http://”camera ipaddress”/event/ftp.php?app=set&ftp1_port=8080 http://”camera ipaddress”/event/ftp.php?app=set&ftp2_port=8081 http://”camera ipaddress”/event/ftp.php?app=set&ftp3_port=8082 http://”camera ipaddress”/event/ftp.php?app=set&ftp4_port=8083 6) FTP & JPEG Passive mode setup http://”camera ipaddress”/event/ftp.php?app=set&ftp_mode=0 http://”camera ipaddress”/event/ftp.php?app=set&ftp_mode=1 http://”camera ipaddress”/event/ftp.php?app=set&ftp1_mode=0 http://”camera ipaddress”/event/ftp.php?app=set&ftp1_mode=1 http://”camera ipaddress”/event/ftp.php?app=set&ftp2_mode=0 http://”camera ipaddress”/event/ftp.php?app=set&ftp2_mode=1 http://”camera ipaddress”/event/ftp.php?app=set&ftp3_mode=0 http://”camera ipaddress”/event/ftp.php?app=set&ftp3_mode=1 http://”camera ipaddress”/event/ftp.php?app=set&ftp4_mode=0 http://”camera ipaddress”/event/ftp.php?app=set&ftp4_mode=1 7) FTP &...
Page 83: Ftp & Jpeg Time Folder Setup
http://”camera ipaddress”/event/ftp.php?app=set&ftp3_path=/home3 http://”camera ipaddress”/event/ftp.php?app=set&ftp4_path=/home4 11) FTP & JPEG Time folder setup http://”camera ipaddress”/event/ftp.php?app=set&ftp1_enable_time_folder=0 http://”camera ipaddress”/event/ftp.php?app=set&ftp1_enable_time_folder=1 http://”camera ipaddress”/event/ftp.php?app=set&ftp2_enable_time_folder=0 http://”camera ipaddress”/event/ftp.php?app=set&ftp2_enable_time_folder=1 http://”camera ipaddress”/event/ftp.php?app=set&ftp3_enable_time_folder=0 http://”camera ipaddress”/event/ftp.php?app=set&ftp3_enable_time_folder=1 http://”camera ipaddress”/event/ftp.php?app=set&ftp4_enable_time_folder=0 http://”camera ipaddress”/event/ftp.php?app=set&ftp4_enable_time_folder=1 12) FTP & JPEG JPEG Time folder type setup http://”camera ipaddress”/event/ftp.php?app=set&ftp1_time_folder_type=0 http://”camera ipaddress”/event/ftp.php?app=set&ftp1_time_folder_type=1 http://”camera ipaddress”/event/ftp.php?app=set&ftp1_time_folder_type=2 http://”camera ipaddress”/event/ftp.php?app=set&ftp2_time_folder_type=0 http://”camera ipaddress”/event/ftp.php?app=set&ftp2_time_folder_type=1...
Page 84: Ftp & Jpeg Jpeg Post-Event Time Setup
http://”camera ipaddress”/event/ftp.php?app=set&jpg3_event_fps=1 http://”camera ipaddress”/event/ftp.php?app=set&jpg3_event_fps=2 http://”camera ipaddress”/event/ftp.php?app=set&jpg4_event_fps=1 http://”camera ipaddress”/event/ftp.php?app=set&jpg4_event_fps=2 16) FTP & JPEG JPEG Post-event time setup http://”camera ipaddress”/event/ftp.php?app=set&jpg_pst_timeout=5 http://”camera ipaddress”/event/ftp.php?app=set&jpg1_post_timeout=5 http://”camera ipaddress”/event/ftp.php?app=set&jpg2_post_timeout=5 http://”camera ipaddress”/event/ftp.php?app=set&jpg3_post_timeout=5 http://”camera ipaddress”/event/ftp.php?app=set&jpg4_post_timeout=5 17) FTP & JPEG JPEG Post-event FPS setup http://”camera ipaddress”/event/ftp.php?app=set&jpg_pst_fps=1 http://”camera ipaddress”/event/ftp.php?app=set&jpg_pst_fps=2 http://”camera ipaddress”/event/ftp.php?app=set&jpg1_post_fps=1 http://”camera ipaddress”/event/ftp.php?app=set&jpg1_post_fps=2 http://”camera ipaddress”/event/ftp.php?app=set&jpg2_post_fps=1 http://”camera ipaddress”/event/ftp.php?app=set&jpg2_post_fps=2...
Page 85: Event – Light
Event – Light: Version: 1.00e Date: 2014. 03. 17 Revision History Version Date Comment 1.00 2014-01-27 Initial version 1.00e 2014-03-17 English Translation Introduction This Chapter defines the detailed setup procedure for the Light. Light URI http://”camera ipaddress”/event/light.php Light Parameter Parameter Type Value light_enable...
Page 86: Operates Only At Night Mode Setup
* light_time_select sets the time unit and light_time sets the time duration. * For example, light_time=60 and light_time_select=second means 60seconds. * If light_time and light_time_select are not determined but light_mode=2, the previous setting values are used. * For light_mode=1, light_time, light_time_select, and light_night_enable are restored but not used. * Light mode setup example http://”camera ipaddress”/event/light.php?app=set&light_mode=1 * For light_mode=2, light_time and light_time_select a setup example is as follows.
Page 87: Event – Manual Trigger
Event – Manual Trigger: Version: 1.00e Date: 2014. 03. 18 Revision History Version Date Comment 1.00 2014-02-11 Initial version 1.00e 2014-03-18 English Translation Introduction This Chapter defines the detailed setup procedure and operation for the Manual Trigger. Manual Trigger Setup & Operation URI http://”camera ipaddress”/event/trigger.php Manual Trigger Setup Parameter Parameter...
Page 88 total_manual_trigger 4 total manual triggers available MANUAL_TRIGG options Manual Trigger setup and operation available -88-...
Page 89: Event – Motion
Event – Motion: Version: 1.01e Date: 2014. 03. 18 Revision History Version Date Comment 1.00 2013-12-11 Initial version 1.01 2014-01-13 Detail menu set-up update 1.01e 2014-03-18 English Translation Introduction This Chapter defines the detailed setup procedure for the Motion. Event – Motion URI http://”camera ipaddress”/event/motion.php Event –...
Page 90: Examples (Latest F/W)
string md_rgn_name Region Name integer md_rgn_type 1(Include), 2(Exclude) md_rgn_thre integer 1 ~ 100 md_rgn_sen integer( 1 ~ 100 md_rgn_time integer 1 ~ 180 md_rgn_rgntype string roi(Pixel Type), grid(Grid Type) md_rgn_left integer Left Pixel Position or Grid Number md_rgn_top integer Top Pixel Position or Grid Number md_rgn_right integer Right Pixel Position or Grid Number...
Page 91: Motion Region Parameter Modify
* Detail setting examples are as follows. They can be set individually as in the following example or can be set in combination as in the above. a. Region Name setup while Motion Region Create http://”camera ipaddress”/event/motion.php?app=set&method=create&md_rgn_name=test b. Region Type setup while Motion Region Create http://”camera ipaddress”/event/motion.php?app=set&method=create&md_rgn_type=1 http://”camera ipaddress”/event/motion.php?app=set&method=create&md_rgn_type=2 * md_rgn_type 1 means include region of Motion Event, and 2 means exclude region.
Page 92 http://”camera ipaddress”/event/motion.php?app=set&method=modify&md_rgn_id=1&md_rgn_thre=25 http://”camera ipaddress”/event/motion.php?app=set&method=modify&md_rgn_id=3&md_rgn_thre=100 c. Region Sensitivity setup for single region modify http://”camera ipaddress”/event/motion.php?app=set&method=modify&md_rgn_id=1&md_rgn_sen=25 http://”camera ipaddress”/event/motion.php?app=set&method=modify&md_rgn_id=3&md_rgn_sen=100 d. Region Dwell time setup for single region modify http://”camera ipaddress”/event/motion.php?app=set&method=modify&md_rgn_id=1&md_rgn_time=60 http://”camera ipaddress”/event/motion.php?app=set&method=modify&md_rgn_id=4&md_rgn_time=150 e. Region Night Threshold setup for single region modify http://”camera ipaddress”/event/motion.php?app=set&method=modify&md_rgn_id=1&md_rgn_night_thre http://”camera ipaddress”/event/motion.php?app=set&method=modify&md_rgn_id=2&md_rgn_night_thre =100...
Page 93: Motion Region Remove
http://”camera ipaddress”/event/motion.php?app=set&method=modify&md_rgn1_name=second&md_rgn4_n ame=first b. Region Threshold setup for multiple region modify http://”camera ipaddress”/event/motion.php?app=set&method=modify&md_rgn3_thre=25&md_rgn4_thre=5 http://”camera ipaddress”/event/motion.php?app=set&method=modify&md_rgn2_thre=100&md_rgn3_thre= c. Region Sensitivity setup for multiple region modify http://”camera ipaddress”/event/motion.php?app=set&method=modify&md_rgn3_sen=25&md_rgn1_sen=5 http://”camera ipaddress”/event/motion.php?app=set&method=modify&md_rgn4_sen=100&md_rgn1_sen= d. Region Dwell Time setup for multiple region modify http://”camera ipaddress”/event/motion.php?app=set&method=modify&md_rgn2_time=60&md_rgn1_time= http://”camera ipaddress”/event/motion.php?app=set&method=modify&md_rgn1_time=150&md_rgn2_time e.
Page 94: Examples (Old F/W)
Examples (old F/W) 1) get the current setting http://”camera ipaddress”/event/motion.php?app=get 2) Motion setup http://”camera ipaddress”/event/motion.php?app=set&method=save&md_enable=1 http://”camera ipaddress”/event/motion.php?app=set&method=save&md_enable=0 3) Motion Day & Night setup http://”camera ipaddress”/event/motion.php?app=set&method=save&md_day_night_enable=1 http://”camera ipaddress”/event/motion.php?app=set&method=save&md_day_night_enable=0 4) Motion Region create http://”camera ipaddress”/event/motion.php?app=set&method=create&md_rgn_name=New&md_rgn_type= 1&md_rgn_left=1&md_rgn_top=1&md_rgn_right=5&md_rgn_bottom=4 5) Motion Region modify http://”camera ipaddress”/event/motion.php?app=set&method=modify&md_rgn_id=4&md_rgn_thre=50&m d_rgn_sen=20&md_rgn_time=30 * Each region is assigned a unique id when created.
Page 95 rgn3_name=New&md_rgn3_type=1&md_rgn3_thre=50&md_rgn3_sen=20&md_rgn3_time= 30&md_rgn3_rgntype=grid&md_rgn3_left=1&md_rgn3_top=1&md_rgn3_right=4&md_rgn 3_bottom=4& Response : res=200&ch=1&md_enable=0&md_rgn_count=3&md_rgn1_id=2&md_rgn1_name=New(1) &md_rgn1_type=1&md_rgn1_thre=2&md_rgn1_sen=44&md_rgn1_time=3&md_rgn1_rgnty pe=grid&md_rgn1_left=1&md_rgn1_top=3&md_rgn1_right=3&md_rgn1_bottom=6&md_rg n2_id=3&md_rgn2_name=New(2)&md_rgn2_type=1&md_rgn2_thre=2&md_rgn2_sen=55& md_rgn2_time=3&md_rgn2_rgntype=grid&md_rgn2_left=7&md_rgn2_top=4&md_rgn2_rig ht=9&md_rgn2_bottom=6&md_rgn3_id=4&md_rgn3_name=New&md_rgn3_type=1&md_r gn3_thre=50&md_rgn3_sen=20&md_rgn3_time=30&md_rgn3_rgntype=grid&md_rgn3_left =1&md_rgn3_top=1&md_rgn3_right=4&md_rgn3_bottom=4& * As for the above, method=save means app=get and then set with response. * In the save operation, you must send current information as a whole, otherwise the parameter not transmitted will be deleted.
Page 96: Event – Network Loss
Event – Network Loss: Version: 1.00e Date: 2014. 03. 17 Revision History Version Date Comment 1.00 2014-01-29 Initial version 1.00e 2014-03-17 English Translation Introduction This Chapter defines the detailed setup procedure for the Network Loss. Network Loss URI http://”camera ipaddress”/event/netloss.php Network Loss Parameter Parameter Type...
Page 97: Event –Notification Server
Event –Notification Server: Version : 1.01e Date : 2015. 08. 25 Revision History Version Date Comment 1.00 2014-08-28 Initial version 1.00e 2015-02-06 English Translation 1.01e 2015-08-24 Method field add Introduction This Chapter defines the detailed setup procedure for the Notification Server. Notification Server URI http://”camera ipaddress”/event/notification_server.php Notification Server Parameter...
Page 98: Notification Server Method Setup
4) Notification Server Method setup http://”camera ipaddress”/event/http_server.php?app=set&noti_srv_method=GET http://”camera ipaddress”/event/http_server.php?app=set&noti_srv_method=POST 5) Notification Server URL setup http://”camera ipaddress”/event/http_server.php?app=set&noti_srv_server=192.168.xxx.xxx http://”camera ipaddress”/event/http_server.php?app=set&noti_srv_server=www.xxx.com http://”camera ipaddress”/event/http_server.php?app=set&noti_srv_server=http://192.168.xxx.xxx/ event.php 6) Notification Server Port setup http://”camera ipaddress”/event/notification_server.php?app=set&noti_srv_port=80 * If event_noti_port is set to bigger number than 65535, (Error: 400) is returned. * If event_noti_port is set to smaller number than 1, (Error: 400) is returned.
Page 99: Event – On Boot
Event – On Boot: Version: 1.00e Date: 2014. 03. 18 Revision History Version Date Comment 1.00 2014-01-23 Initial version 1.00e 2014-03-18 English Translation Introduction This Chapter defines the detailed setup procedure for the On boot. On Boot URI http://”camera ipaddress”/event/onboot.php On Boot Parameter Parameter Type...
Page 100: Event – Pir
Event – PIR: Version: 1.00e Date: 2014. 03. 17 Revision History Version Date Comment 1.00 2014-02-05 Initial version 1.00e 2014-03-17 English Translation Introduction This Chapter defines the detailed setup procedure for the PIR. PIR URI http://”camera ipaddress”/event/pir.php PIR Parameter Parameter Type Value pir_enable...
Page 101: Event – Ptz Preset
Event – PTZ Preset: Version: 1.00e Dat : 2014. 03. 18 Revision History Version Date Comment 1.00 2014-01-28 Initial version 1.00e 2014-03-18 English Translation Introduction This Chapter defines detailed the setup procedure for the PTZ Preset. PTZ Preset URI http://”camera ipaddress”/event/ptz_preset.php PTZ Preset Parameter Parameter Type...
Page 102: Event – Record
Event – Record: Version : 1.00 Date : 2014. 09. 26 Revision History Version Date Comment 1.00 2014-09-26 Initial version Introduction This chapter specifies how to set up the Record in detail. Record URI http://”ipaddress”/event/record.php Record Parameter Parameter Type Value record_enable integer 0 : disable, 1 : enable...
Page 103: Examples
record_device_remove_cifs integer (ro) 1 : available remove, 0 : not available remove record_device_remove_nfs integer (ro) 1 : available remove, 0 : not available remove record_device_total integer (ro) Total storage ( GB ) record_device_used integer (ro) Used ( MB ) record_device_available integer (ro) Available ( GB ) record_device_percent...
Page 104: Record Stream Setup
4) record stream setup http://”ipaddress”/event/record.php?app=set&record_stream=1 http://”ipaddress”/event/record.php?app=set&record_stream=2 http://”ipaddress”/event/record.php?app=set&record_stream=3 5) record pre time setup http://”ipaddress”/event/record.php?app=set&record_pre_time=0 http://”ipaddress”/event/record.php?app=set&record_pre_time=5 http://”ipaddress”/event/record.php?app=set&record_pre_time=10 6) record post time setup http://”ipaddress”/event/record.php?app=set&record_post_time=0 http://”ipaddress”/event/record.php?app=set&record_post_time=30 http://”ipaddress”/event/record.php?app=set&record_post_time=60 7) record audio setup http://”ipaddress”/event/record.php?app=set&record_audio=0 ( disable ) http://”ipaddress”/event/record.php?app=set&record_audio=1 ( enable ) 8) record schedule setup * The record schedule setting can be set by the day of the week. (Sunday, Monday, Tuesday, Wednesday, Thursday, Friday, and Saturday) Figure 1.
Page 105: Record Device Type Setup
* continuous recording http://”ipaddress”/event/record.php?app=set&record_schedule_value=11111111111111111111 11111111111111111111111111111111111111111111111111111111111111111111111111 11111111111111111111111111111111111111111111111111111111111111111111111111 9) record device type setup http://”ipaddress”/event/record.php?app=set&record_device_type=0 ( SD ) http://”ipaddress”/event/record.php?app=set&record_device_type=1 ( CIFS ) http://”ipaddress”/event/record.php?app=set&record_device_type=1 ( NFS ) 10) record address setup http://”ipaddress”/event/record.php?app=set&record_address=192.168.1.1 http://”ipaddress”/event/record.php?app=set&record_address=192.168.1.1:1000 11) record remote directory setup http://”ipaddress”/event/record.php?app=set&record_path=/volume1/test 12) record capacity setup http://”ipaddress”/event/record.php?app=set&record_size=5 (GB) 13) record ID setup http://”ipaddress”/event/record.php?app=set&record_id=test 13) record password setup...
Page 106: Event – Smtp
Event – SMTP: Version: 1.01e Date: 2015. 08. 25 Revision History Version Date Comment 1.00 2014-02-13 Initial version 1.00e 2014-03-17 English Translation 1.01e 2015-08-24 “smtp_image_attachment” parameter add “smtp_auth_enable” parameter contents delete “5. Caution” modify Introduction This Chapter defines the detailed setup procedure for the SMTP. SMTP URI http://”camera ipaddress”/event/smtp.php SMTP Parameter...
Page 107: Examples
smtp_receiver string Receiver’s e-mail address : For use SMTP Test only method string “test” : For use SMTP Test only * smtp_receiver_list# : # is a number in the range of 1~8. Examples 1) Get the current setting http://”camera ipaddress”/event/smtp.php?app=get 2) SMTP setup http://”camera ipaddress”/event/smtp.php?app=set&smtp_enable=1 http://”camera ipaddress”/event/smtp.php?app=set&smtp_enable=0...
Page 108: Receiver Address Setup
14) Receiver address setup http://”camera ipaddress”/event/smtp.php?app=set&smtp_receiver_list1=”e-mail address” 15) SMTP Test method a. Mail server is not used http://”camera ipaddress”/event/smtp.php?app=set&method=test&smtp_enable=1&smtp_sender=”e-mail address”&smtp_receiver=”e-mail address” &smtp_image_attachment=1 * If you set method=test in URI, you must include smtp_enable, smtp_sender, and smtp_receiver. * In the case method=test, smtp_enable must be 1. * If smtp_image_attachment=1, an image is attached on mail transmission.
Page 109: Event – Tampering
Event – Tampering: Version : 1.02e Date : 2016. 12. 16 Revision History Version Date Comment 1.00 2014-09-26 Initial version tampering_threshold deletion 1.01 2015-01-28 tampering_event_time deletion 1.01e 2015-01-29 English Translation 1.02e 2016-12-16 Added area rate function Introduction This Chapter defines the setup procedure for the Tampering. Tampering URI http://”ipaddress”/event/tempering.php Tampering Parameter...
Page 110: Area Rate Setup
4) Area rate setup http://”ipaddress”/event/tampering.php?app=set&tampering_area_rate=10 http://”ipaddress”/event/tampering.php?app=set&tampering_area_rate=50 http://”ipaddress”/event/tampering.php?app=set&tampering_area_rate=100 5) Setup tampering at once http://”ipaddress”/event/tampering.php?app=set&tampering_enable=1&tampering_time=50&tam pering_area_rate=50 -110-...
Page 111: Event – Time Trigger
Event – Time Trigger: Version: 1.00e Date: 2015. 7. 20 Revision History Version Date Comment 1.00 2015-06-30 Initial version 1.00e 2015-07-20 English Translation Introduction This Chapter defines the detailed setup procedure for the Time Trigger. Time Trigger URI http://”camera ipaddress”/event/time_trigger.php Time Trigger Parameter Parameter Type...
Page 112: Examples
6 : Friday 7 : Saturday HH:MM timetrigger#_day_of_week_time string 24 hour format ex) 14:23 timetrigger#_month_date integer 1~31 HH:MM timetrigger#_month_time string 24 hour format ex) 14:23 Examples 1) get the current setting http://”camera ipaddress”/event/time_trigger.php?app=get 2) Time Trigger usage setup http://”camera ipaddress”/event/time_trigger.php?app=set&timetrigger_enable=0 http://”camera ipaddress”/event/time_trigger.php?app=set&timetrigger_enable=1 3) Time Trigger # usage setup http://”camera ipaddress”/event/time_trigger.php?app=set&timetrigger1_enable=0...
Page 113: Setup Time In Time Trigger # Specific Time
http://”camera ipaddress”/event/time_trigger.php?app=set&timetrigger1_specific_time_date=2015-06-30 9) setup Time in Time Trigger # Specific Time http://”camera ipaddress”/event/time_trigger.php?app=set&timetrigger1_specific_time_time=14:02 10) setup Time in Time Trigger # Day http://”camera ipaddress”/event/time_trigger.php?app=set&timetrigger1_day_time=14:02 11) setup Day in Time Trigger # Day Of Week http://”camera ipaddress”/event/time_trigger.php?app=set&timetrigger1_day_of_week_day=1 http://”camera ipaddress”/event/time_trigger.php?app=set&timetrigger1_day_of_week_day=2 http://”camera ipaddress”/event/time_trigger.php?app=set&timetrigger1_day_of_week_day=3 http://”camera ipaddress”/event/time_trigger.php?app=set&timetrigger1_day_of_week_day=4 http://”camera ipaddress”/event/time_trigger.php?app=set&timetrigger1_day_of_week_day=5 http://”camera ipaddress”/event/time_trigger.php?app=set&timetrigger1_day_of_week_day=6 http://”camera ipaddress”/event/time_trigger.php?app=set&timetrigger1_day_of_week_day=7...
Page 114: Event – Vca
Event – VCA: Version: 1.01e Date: 2015. 03. 26 Revision History Version Date Comment 1.00 2015-01-28 Initial version 1.00e 2015-01-29 English Translation linedetector_reset API revision & sample project 1.01 2015-03-23 update 1.01e 2015-03-26 English vesion update Introduction This Chapter defines the setup procedure for the VCA. VCA URI http://”ipaddress”/event/vca.php VCA Parameter...
Page 115: Examples
va_#_#_linedetector_point_x# integer 0~1919 (x coordinate) va_#_#_linedetector_point_y# integer 0~1079 (y coordinate) advance VCA only va_#_#_linedetector_reset_time integer 1~86400 (second) 1~3 (rule index of the counter to be reset) va_#_linedetector_reset integer advance VCA doesn’t support va_#_#_linedetector_event_tracking_enable boolean 0 : disable, 1 : enable 1: enter 2: exit (currently not supported) va_#_#_fielddetector_mode...
Page 116: Set Fixed Camera Rule Number 1 To Line Detector
http://”ipaddress”/event/vca.php?app=get&va_preset_name=PRESET-1 Response: res=200&va_enable=1&va_PRESET-1_obj_min_width=2&va_PRESET- 1_obj_min_height=3&va_PRESET-1_obj_max_width=40&va_PRESET- 1_obj_max_height=50&va_PRESET-1_obj_sensitivity=75&va_PRESET- 1_2_name=AnalyticRule22&va_PRESET-1_2_rule=0&va_PRESET- 1_3_name=AnalyticRule23&va_PRESET-1_3_rule=0&va_PRESET- 1_4_name=AnalyticRule24&va_PRESET-1_4_rule=0&va_PRESET- 1_1_exclusive_enable=0&va_ PRESET-1_2_exclusive_enable=0&va_PRESET- 1_3_exclusive_enable=0&va_PRESET-1_4_exclusive_enable=0 3) set Fixed camera rule number 1 to line detector Request: http://”ipaddress”/event/vca.php?app=set&va_1_rule=1&va_1_name=LineDetector&va__1_lin edetector_direction=3&va_1_linedetector_counter=2&va_1_linedetector_base=3&va_1_linede tector_point_x1=1&va_1_linedetector_point_y1=1&va_1_linedetector_point_x2=1919&va_1_ linedetector_point_y2=1079&va_1_linedetector_reset_time=3600 Response: res=200 4) set PTZ camera “PRESET-1” rule number 1 to line detector Request: http://”ipaddress”/event/vca.php?app=set&va_PRESET-1_1_rule=1&va_PRESET- 1_1_name=LineDetector&va_PRESET-1_1_linedetector_direction=3&va_PRESET- 1_1_linedetector_counter=2&va_PRESET-1_1_linedetector_base=3&va_PRESET-...
Page 117: Set Fixed Camera Rule Number 3 To Absent
1_2_fielddetector_point_y2=1&va_PRESET-1_2_fielddetector_point_x3=1919&va_PRESET- 1_2_fielddetector_point_y3=1079&va_PRESET-1_2_fielddetector_point_x4=1&va_PRESET- 1_2_fielddetector_point_y4=1079& Response: res=200 7) set Fixed camera rule number 3 to absent Request: http://”ipaddress”/event/vca.php?app=set&va_3_rule=3&va_3_name=Absent&va_3_absent_ev ent_time=5&va_3_absent_dwell_time=5&va_3_absent_point_x1=1&va_3_absent_point_y1=1 &va_3_absent_point_x2=1919&va_3_absent_point_y2=1&va_3_absent_point_x3=1919&va_ 3_absent_point_y3=1079&va_3_absent_point_x4=1&va_3_absent_point_y4=1079& Response: res=200 8) set PTZ camera “PRESET-1” rule number 3 to absent Request: http://”ipaddress”/event/vca.php?app=set&va_PRESET-1_3_rule=3&va_PRESET- 1_3_name=Absent&va_PRESET-1_3_absent_event_time=5&va_PRESET- 1_3_absent_dwell_time=5&va_PRESET-1_3_absent_point_x1=1&va_PRESET- 1_3_absent_point_y1=1&va_PRESET-1_3_absent_point_x2=1919&va_PRESET- 1_3_absent_point_y2=1&va_PRESET-1_3_absent_point_x3=1919&va_PRESET- 1_3_absent_point_y3=1079&va_PRESET-1_3_absent_point_x4=1&va_PRESET- 1_3_absent_point_y4=1079& Response: res=200 9) reset counter of line detector rule number 1 Request:...
Page 118 vca_option LINE_DETECTOR line detector support FIELD_DETECTOR field detector support ABSENT absent support -118-...
Page 119: Event – Video Loss
Event – Video Loss: Version: 1.00e Date: 2014. 03. 17 Revision History Version Date Comment 1.00 2014-02-06 Initial version 1.00e 2014-03-17 English Translation Introduction This Chapter defines the detailed setup procedure for the Video Loss. Video Loss URI http://”camera ipaddress”/event/loss.php Video Loss Parameters Parameter Type...
Page 120: Event – Xml Notification
Event – XML Notification: Version: 1.00e Date: 2014. 03. 18 Revision History Version Date Comment 1.00 2014-01-28 Initial version 1.00e 2014-03-18 English Translation Introduction This Chapter defines the detailed setup procedure for the XML Notification. XML Notification URI http://”camera ipaddress”/event/notification.php XML Notification Parameter Parameter Type...
Page 121: Event Stream
Event Stream Version : 1.01e Date : 2015. 01. 29 Revision History Version Date Comment 1.00 2014-12-02 Initial version Deleted parameter - Request Filter(vca_event, vca_rule, vca_object) - VCA Reaponse(object_timestamp) 1.01 2015-01-28 2. Add parameter – Request Filter(vca, face_detect) 1.01e 2015-01-29 English Translation Introduction This API document describes the method to receive event information from a camera through...
Page 122: Http Continues Response
Contents-Length: 20 fulltext=1&trigger=1 3) HTTP CONTINUES RESPONSE HTTP/1.1 200 OK MIME-Version: 1.0 Content-Type: multipart/mixed; boundary="1234567890" --1234567890 Content-Type: application/ht-event; charset="UTF-8" Content-Length: 91 event_time=2014-12-02 20:03:47 trigger=0 trigger1=0 trigger2=0 trigger3=0 trigger4=0 --1234567890 Content-Type: application/ht-event; charset="UTF-8" Content-Length: 91 event_time=2014-12-02 20:03:47 trigger=0 trigger1=0 trigger2=0 trigger3=0 trigger4=0 * Event Stream Server transmits Event information via HTTP response, and uses multipart Content-Type boundary to differentiate Event Groups occurred at the same time.
Page 123: Event Stream Response Parameter
motion boolean Transmit Motion event 1 : enable, 0 : disable tampering boolean Transmit Tampering event 1 : enable, 0 : disable vloss boolean Transmit Video Loss event 1 : enable, 0 : disable record boolean Transmit Record event 1 : enable, 0 : disable boolean Transmit VCA information 1 : enable, 0 : disable...
Page 124: Table 5. Video Loss Fulltext Response Parameter
ch#_strm#_motion integer Motion Any Region 1 : active, 0 : inactive Grid Count of Frame ch#_strm#_motion_width integer Width Grid Count of Frame ch#_strm#_motion_height integer Height Motion Detection of the 1 : active, 0 : inactive ch#_strm#_motion_rgn# integer Region Left Grid Number of the ch#_strm#_motion_rgn#_left integer Region...
Page 125: Table 8. Vca Object Fulltext Response Parameter
4 : DISAPPEAR The ‘vca_object’’ Event Stream has independent ‘Event Group,’ and transmitted with ‘vca_rule’ in case ofObject detect. Table 8. VCA OBJECT FULLTEXT RESPONSE PARAMETER Parameter Type Description Value Total number of object_total_count integer detected Objects object_id_# integer object id Number of apexes of default : 4 object_point_size_#...
Page 126: Examples
* ‘#’ means rule index, and uses the same value as VCA Setup API. Examples 1) BASIC EVENT STREAM REQUEST http://”camera ipaddress”/stream/event_stream.php 2) BASIC EVENT STREAM RESPONSE --1234567890 Content-Type: application/ht-event; charset="UTF-8" Content-Length: 208 event_time=2014-12-03 17:01:52 onboot=0 alarm=0 alarmout=0 trigger=0 netloss=0 analytics=0 pir=0 audiodetect=0...
Page 127: Basic Event Stream Request With Alarmin Filter
tour=0 vca_event=0 record=0 face_detect=0 ….abbreviated… 3) BASIC EVENT STREAM REQUEST WITH ALARMIN FILTER http://”camera ipaddress”/stream/event_stream.php?alarm=1 4). BASIC EVENT STREAM RESPONSE WITH ALARMIN FILTER --1234567890 Content-Type: application/ht-event; charset="UTF-8" Content-Length: 41 event_time=2014-12-02 16:39:09 alarm=1 --1234567890 Content-Type: application/ht-event; charset="UTF-8" Content-Length: 41 event_time=2014-12-02 16:39:10 alarm=0 ….abbreviated…...
Page 128: Event Stream Request With Vca Filter
ch1_strm1_rgn2_right=9 ch1_strm1_rgn2_bottom=7 ch1_strm1_rgn2_sen=55 ch1_strm1_rgn2_thre=2 ch1_strm1_rgn2_act=1 --1234567890 Content-Type: application/ht-event; charset="UTF-8" Content-Length: 476 event_time=2014-12-03 17:09:11 motion=1 ch1_strm1_motion=1 ch1_strm1_motion_width=10 ch1_strm1_motion_height=8 ch1_strm1_rgn1=0 ch1_strm1_rgn1_left=2 ch1_strm1_rgn1_top=2 ch1_strm1_rgn1_right=5 ch1_strm1_rgn1_bottom=5 ch1_strm1_rgn1_sen=55 ch1_strm1_rgn1_thre=2 ch1_strm1_rgn1_act=0 ch1_strm1_rgn2=1 ch1_strm1_rgn2_left=6 ch1_strm1_rgn2_top=3 ch1_strm1_rgn2_right=9 ch1_strm1_rgn2_bottom=7 ch1_strm1_rgn2_sen=55 ch1_strm1_rgn2_thre=2 ch1_strm1_rgn2_act=2 ….abbreviated… 7) EVENT STREAM REQUEST WITH VCA FILTER http://”camera ipaddress”/stream/event_stream.php?vca=1 8) EVENT STREAM RESPONSE WITH VCA FILTER * The following example is a Field Detect Event of object_id 1 set to Rule Index 2.
Page 129 object_point_4_1=516,803 object_classify_1=3 object_timestamp_1=2000-01-14T07:10:57.582Z object_event_type_1=0,2,0,0 vca_rule=1 rule_total_count=8 rule_type_1=1 rule_mode_1=1 rule_name_1=AnalyticRule0 rule_point_size_1=2 rule_point_1_1=983,1 rule_point_2_1=1002,1054 rule_type_2=2 rule_mode_2=1 rule_name_2=AnalyticRule2 rule_point_size_2=4 rule_point_1_2=207,557 rule_point_2_2=847,557 rule_point_3_2=847,917 rule_point_4_2=207,917 rule_type_3=0 rule_type_4=0 rule_type_5=6 rule_mode_5=1 rule_name_5=ExclusiveAreaRule4 rule_point_size_5=4 rule_point_1_5=192,108 rule_point_2_5=832,108 rule_point_3_5=832,468 rule_point_4_5=192,468 rule_type_6=0 rule_type_7=0 rule_type_8=0 --1234567890 Content-Type: application/ht-event; charset="UTF-8" Content-Length: 738 event_time=2000-01-14 07:10:57 vca_event=1 event_total_count=1 event_rule_type_1=2...
Page 130 rule_point_1_1=983,1 rule_point_2_1=1002,1054 rule_type_2=2 rule_mode_2=1 rule_name_2=AnalyticRule2 rule_point_size_2=4 rule_point_1_2=207,557 rule_point_2_2=847,557 rule_point_3_2=847,917 rule_point_4_2=207,917 rule_type_3=0 rule_type_4=0 rule_type_5=6 rule_mode_5=1 rule_name_5=ExclusiveAreaRule4 rule_point_size_5=4 rule_point_1_5=192,108 rule_point_2_5=832,108 rule_point_3_5=832,468 rule_point_4_5=192,468 rule_type_6=0 rule_type_7=0 rule_type_8=0 ….abbreviated…...
Page 131: Jpeg Push
JPEG Push Version : 1.00 Date : 2014. 05. 30 Revision History Version Date Comment 1.00 2014-05-30 Initial version Introduction This Chapter defines the detailed setup procedure for the JPEG Push. JPEG Push URI http://”camera ipaddress”/jpeg/”ch”/jpeg.php * “ch” will be described in JPEG Push Parameter. JPEG Push Parameter Parameter Type...
Page 132: Live
Live Live – Motor, Smart Focus Control API Version: 1.00e Date: 2014. 02. 16 Revision History Version Date Comment 1.00 2013-12-11 Initial version 1.00e 2014-02-16 English Translation Motor Control: Introduction This Chapter defines the Motor Control Method for Cameras which supports MPTZ Option. Motor Control URI http://”camera ipaddress”/mptz/control.php Motor Control Parameter...
Page 133 ZOOM zoom control available FOCUS focus control available m_ptz_option left, right move available TILT up, down move available * You need to maintain the Session after an HTTP Request for correct operation * Once the Session is disconnected, it is recognized as a stop command and the operation is terminated -133-...
Page 134: Live – Smart Focus
Live – Smart Focus: Version: 1.00e Date: 2014. 02. 16 Revision History Version Date Comment 1.00 2013-12-11 Initial version 1.00e 2014-02-16 English Translation Introduction This Chapter defines the Smart Focus Method for Cameras which supports SMART_FOCUS Option. Smart Focus URI http://”camera ipaddress”/live/live_control.php Smart Focus Parameter Parameter...
Page 135: Live – Light Control
Live – Light Control: Version : 1.00 Date : 2014. 05. 30 Revision History Version Date Comment 1.00 2014-05-30 Initial version Introduction This Chapter defines the detailed setup procedure for the Light Control.. Light Control URI http://”camera ipaddress”/live/light_control.php Light Control Parameter Parameter Type Value...
Page 136: Live – Ptz Control
Live – PTZ Control: Version : 1.00 Date : 2014. 09. 17 Revision History Version Date Comment 1.00 2014-09-17 Initial version Introduction This Chapter defines the detailed setup procedure for the PTZ Control. PTZ Control URI 1) PTZ Control UI Open http://”camera ipaddress”/live/ptz_control.php 2) PTZ Control API URL http://”camera ipaddress”/ptz/control.php...
Page 137: Example
camera, preset, ascan, tour, pattern, esc, stop, up, down, left, menu string right, enter ctrl integer 1 : ctrl on, 0 : ctrl off shortcut_on integer 0 ~ 255 shortcut_off integer 0 ~ 255 * ‘pspd’, ‘tspd’, ‘zspd’ Parameters indicates the speed of continuous move and, ‘pan_speed’, ‘tilt_speed’, ‘zoom_speed’...
Page 138: Preset Save
8) Preset Save http://”camera ipaddress”/ptz/control.php?app=set&presetsave=0 http://”camera ipaddress”/ptz/control.php?app=set&presetsave=10 http://”camera ipaddress”/ptz/control.php?app=set&presetsave=240 9) Preset Control http://”camera ipaddress”/ptz/control.php?app=set&preset=0 http://”camera ipaddress”/ptz/control.php?app=set&preset=10 http://”camera ipaddress”/ptz/control.php?app=set&preset=240 10) Tour Control http://”camera ipaddress”/ptz/control.php?app=set&tour=10 http://”camera ipaddress”/ptz/control.php?app=set&tour=240 11) Pattern Control http://”camera ipaddress”/ptz/control.php?app=set&pattern=10 http://”camera ipaddress”/ptz/control.php?app=set&pattern=240 12) Position Control http://”cameraipaddress”/ptz/control.php?app=set&app=set&position=set&pan_pos=- 0.1&tilt_pos=-0.1&zoom_pos=-0.1 http://”cameraipaddress”/ptz/control.php?app=set&app=set&position=set&pan_pos=- 0.5&tilt_pos=-0.5&zoom_pos=-0.5 http://”cameraipaddress”/ptz/control.php?app=set&app=set&position=set&pan_pos=0.5&tilt_pos =0.5&zoom_pos=0.5 http://”cameraipaddress”/ptz/control.php?app=set&app=set&position=set&pan_pos=1&tilt_pos=1 &zoom_pos=1...
Page 139: Esc Menu
19) Esc menu http://”camera ipaddress”/ptz/control.php?app=set&menu=esc 20) Stop menu http://”camera ipaddress”/ptz/control.php?app=set&menu=stop 21) Up menu http://”camera ipaddress”/ptz/control.php?app=set&menu=up 22) Down menu http://”camera ipaddress”/ptz/control.php?app=set&menu=down 23) Left menu http://”camera ipaddress”/ptz/control.php?app=set&menu=left 24) Right menu http://”camera ipaddress”/ptz/control.php?app=set&menu=right 25) Enter menu http://”camera ipaddress”/ptz/control.php?app=set&menu=enter 26) Ctrl control http://”camera ipaddress”/ptz/control.php?app=set&ctrl=1 http://”camera ipaddress”/ptz/control.php?app=set&ctrl=0 27) shortcut on control http://”camera ipaddress”/ptz/control.php?app=set&shortcut_on=10...
Page 140: Live – X1 Dome Configuration – Position
Live – X1 Dome Configuration – Position: Version: 1.05e Date: 2016. 12. 14 Revision History Version Date Comment 1.00 2014-04-02 Initial version 1.00e 2014-04-10 English Translation Modify Get Position API 1.01e 2014-06-30 Add PTZ Speed Modify PTZ Position setting Add Get Preset Position Status 1.04e 2015-04-17 (version number match for Korean version)
Page 141: Ptz Position Setup (Degree)
http://”camera ipaddress“/ptz/control.php?position=set&pan_pos=0.15515&tilt_pos=0.5&zoom_pos=0&pan_ speed=0.5&tilt_speed=0.81&zoom_speed=0.015 • PTZ POSITION coordinate range is -1.0000000 ~ 1.0000000. • PAN initial coordinate is 0 • TILT initial coordinate is 0 • ZOOM initial coordinate is -1 (x1) • When you setup Position, pan, tilt, and zoom information should be set at once.. •...
Page 142: Live View
Live View Version : 1.00 Date : 2014. 06. 13 Revision History Version Date Comment 1.00 2014-06-13 Initial version Introduction This Chapter defines the detailed setup procedure for the Live View.. Live View URI http://”camera ipaddress”/liveview/source.php LIVE View Parameter Parameter Type Value video_mode...
Page 143: Playback
Playback Version : 1.00 Date : 2014. 09. 26 Revision History Version Date Comment 1.00 2014-09-26 Initial version Introduction This Chapter defines the detailed setup procedure of the Playback. Playback URI http://”ipaddress”/playback/search.php Playback Parameter Parameter Type Value get_calendar, get_month, get_day, get_hour, method string get_minute, gotofirst, gotolast, get_event, get_index,...
Page 144 integer (ro) video frame count max_client integer (ro) current_client integer (ro) current client count * ‘method’ Parameter is as following Parameter Value Explanation get_calendar entire calendar info get_month Month’s recording data get_day day’s recording data get_hour hour’s recording data get_minute minute’s recording data gotofirst the first information of recording data...
Page 145: Examples
FIELDDETECT ABSENT TAMPERING * ‘clipcopy_size’ Parameter is limited to a max. of 1Gbyte * 'Codec', 'width', 'height', 'fps' parameters indicate the video data information. * ‘max_client’ Parameter indicates the maximum number of clients that can have access to the Camera * ‘current_client”...
Page 146: Get Minute Information
0,0,0,0,0,0,0,0&minute_list=0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,1,1,1,1,0,0,0,0,0,0,0,0,0,0,0, 0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0 5) get minute information http://”ipaddress”/playback/search.php?method=get_minute&year=2013&month=1&day=1&hour =14&minute=10 http://”ipaddress”/playback/search.php?method=get_minute&year=2013&month=1&day=1&hour =14&minute=50 * Response of minute value res=200&method=get_minute&year=2013&month=1&day=1&hour=1&minute=1&day_list=0,0 ,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,1,0&hour_list=0,0,1,2,3,1,2,3,0,0,0,0,0,0,0 ,0,0,0,0,0,0,0,0,0&minute_list=0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,1,1,1,1,0,0,0,0,0,0,0,0,0,0 ,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0 6) get the first information of recording data http://”ipaddress”/playback/search.php?method=gotofirst 7) get the last information of recording data http://”ipaddress”/playback/search.php?method=gotolast 8) get event list http://”ipaddress”/playback/search.php?method=get_event&event_type=0&start_date=2014-09- 17&end_date=2014-09-19 (entire event list) http://”ipaddress”/playback/search.php?method=get_event&event_type=3&start_date=2014-09-...
Page 147: Forward Step Play
clock=‘yyyymmdd’T’hhmmss’-‘yyyymmdd’T’hhmmss’ default yes Rate-Control string yes : real time using standard RTP mechanisms no : as fast as possible Scale float default 1.0 default all all : all frame Frames string intra : intra frame intra/<ms> : intra frame with minimum interval of <ms> default 1 Refresh boolean...
Page 148: Forward Double Speed Play
Session: 931380111 User-agent: eon-client Authorization: Basic aGl0cm9uOmhpdHJvbjEyMzQ= Connection: Keep-Alive Content-Length: 0 Require: onvif-replay Range: clock=YYYYMMSSTHHMMSS- Rate-Control: yes Frames: all Scale: 1.0 4) Forward Double Speed Play PLAY rtsp://<ip address>/<channel>/<date>/<time>/<time index>/to/recording RTSP/1.0 CSeq: 8 Session: 931380111 User-agent: eon-client Authorization: Basic aGl0cm9uOmhpdHJvbjEyMzQ= Connection: Keep-Alive Content-Length: 0 Require: onvif-replay...
Page 149: Forward Play Stop
Scale: 4.0 7) Forward play stop PLAY rtsp://<ip address>/<channel>/<date>/<time>/<time index>/to/recording RTSP/1.0 CSeq: 5 Session: 63845242 User-agent: eon-client Authorization: Basic aGl0cm9uOmhpdHJvbjEyMzQ= Connection: Keep-Alive Content-Length: 0 Require: onvif-replay Range: clock=YYYYMMSSTHHMMSS- Rate-Control: no 8) Backward Step Play PLAY rtsp://<ip address>/<channel>/<date>/<time>/<time index>/to/recording RTSP/1.0 CSeq: 15 Session: 931380111 User-agent: eon-client Authorization: Basic aGl0cm9uOmhpdHJvbjEyMzQ=...
Page 150: Backward Double Speed Play
Content-Length: 0 Require: onvif-replay Range: clock=YYYYMMSSTHHMMSS- Rate-Control: yes Frames: intra Scale: -1.0 11) Backward Double Speed Play PLAY rtsp://<ip address>/<channel>/<date>/<time>/<time index>/to/recording RTSP/1.0 CSeq: 18 Session: 931380111 User-agent: eon-client Authorization: Basic aGl0cm9uOmhpdHJvbjEyMzQ= Connection: Keep-Alive Content-Length: 0 Require: onvif-replay Range: clock=YYYYMMSSTHHMMSS- Rate-Control: yes Frames: intra Scale: -2.0 12) Backward Triple Speed Play...
Page 151: Clipcopy
CSeq: 5 Session: 63845242 User-agent: eon-client Authorization: Basic aGl0cm9uOmhpdHJvbjEyMzQ= Connection: Keep-Alive Content-Length: 0 Require: onvif-replay Range: clock=YYYYMMSSTHHMMSS- Rate-Control: no 15) Clipcopy PLAY rtsp://<ip address>/<channel>/<date>/<time>/<time index>/to/recording RTSP/1.0 CSeq: 5 Session: 63845242 User-agent: eon-client Authorization: Basic aGl0cm9uOmhpdHJvbjEyMzQ= Connection: Keep-Alive Content-Length: 0 Require: onvif-replay Range: clock=YYYYMMSSTHHMMSS-YYYYMMSSTHHMMSS Rate-Control: no Frames: all...
Page 152: Snapshot
Snapshot Version : 1.00 Date : 2014. 05. 30 Revision History Version Date Comment 1.00 2014-05-30 Initial version Introduction This Chapter defines the detailed setup procedure for the Snapshot. Snapshot URI http://”camera ipaddress”/snapshot/”ch”/snapshot.jpg * “ch” will be described in Snapshot Parameter.
Page 153: System
System System – Bonjour: Version: 1.00e Date: 2014. 03. 17 Revision History Version Date Comment 1.00 2014-02-07 Initial version 1.00e 2014-03-17 English Translation Introduction This Chapter defines the detailed setup procedure for the Bonjour. Bonjour URI http://”camera ipaddress”/system/bonjour.php Bonjour Parameter Parameter Type Value...
Page 154: System – Date&Time
System – Date&Time: Version : 1.00 Date : 2014. 06. 27 Revision History Version Date Comment 1.00 2014-06-27 Initial version Introduction This Chapter defines the detailed setup procedure for the Date&Time. Date&Time URI http://”ipaddress”/system/time.php Date&Time Parameter Parameter Type Value string get, set integer tsyncmode...
Page 155: Example
Example 1) get the current setting http://”ipaddress”/system/time.php?app=get 2) datetime mode setup http://”ipaddress”/system/time.php?app=set&tsyncmode=0 (manual) http://”ipaddress”/system/time.php?app=set&tsyncmode=1 (computer) http://”ipaddress”/system/time.php?app=set&tsyncmode=2 (NTP) 3) timezone setup http://”ipaddress”/system/time.php?app=set&tzone=1 http://”ipaddress”/system/time.php?app=set&tzone=20 http://”ipaddress”/system/time.php?app=set&tzone=40 http://”ipaddress”/system/time.php?app=set&tzone=72 Refer to Time Zone Table 4) timezone daylight saving setup http://”ipaddress”/system/time.php?app=set&dst_enable=0 http://”ipaddress”/system/time.php?app=set&dst_enable=1 5) timezone daylight saving user setup http://”ipaddress”/system/time.php?app=set&dst_user_enable=0 http://”ipaddress”/system/time.php?app=set&dst_user_enable=1 6) timezone daylight saving start month setup...
Page 156: Timezone Daylight Saving End Week Setup
http://”ipaddress”/system/time.php?app=set&dst_emonth=12 11) timezone daylight saving end week setup http://”ipaddress”/system/time.php?app=set&dst_eweek=1 http://”ipaddress”/system/time.php?app=set&dst_eweek=3 http://”ipaddress”/system/time.php?app=set&dst_eweek=5 12) timezone daylight saving end dayofweek setup http://”ipaddress”/system/time.php?app=set&dst_edayofweek=0 (Sunday) http://”ipaddress”/system/time.php?app=set&dst_edayofweek=1 (Monday) http://”ipaddress”/system/time.php?app=set&dst_edayofweek=2 (Tuesday) http://”ipaddress”/system/time.php?app=set&dst_edayofweek=3 (Wednesday) http://”ipaddress”/system/time.php?app=set&dst_edayofweek=4 (Thursday) http://”ipaddress”/system/time.php?app=set&dst_edayofweek=5 (Friday) http://”ipaddress”/system/time.php?app=set&dst_edayofweek=6 (Saturday) 13) timezone daylight saving end time setup http://”ipaddress”/system/time.php?app=set&dst_etm=01:00 http://”ipaddress”/system/time.php?app=set&dst_etm=18:20 http://”ipaddress”/system/time.php?app=set&dst_etm=23:45 14) timezone daylight saving time gap setup...
Page 157: Caution
=1&dst_sdayofweek=0&dst_stm=23:00&dst_emonth=10&dst_eweek=1&dst_edayofweek=0& dst_etm=22:00&dst_tm=60&ntp_interval=720&time_format=1&date_format=1 Caution Refer to the table below ‘tzone’ Parameter for TimeZone setup. tzone Value (GMT-12:00) International Date Line West (GMT-11:00) Midway Island, Samoa (GMT-10:00) Hawaii (GMT-09:00) Alaska (GMT-08:00) Pacific Time(US & Canada), Tijuana (GMT-07:00) Arizona (GMT-07:00) Chihuahua, La Paz, Mazatlán (GMT-07:00) Mountain Time(US &...
Page 158 (GMT+01:00) Sarajevo, Skopje, Warsaw, Zagreb (GMT+01:00) West Central Africa (GMT+02:00) Athens, Beirut, Istanbul, Minsk (GMT+02:00) Bucharest (GMT+02:00) Cairo (GMT+02:00) Harare, Pretoria (GMT+02:00) Helsinki, Kyiv, Riga, Sofia, Tallinn, Vilnius (GMT+02:00) Jerusalem (GMT+03:00) Baghdad (GMT+03:00) Kuwait, Riyadh (GMT+03:00) Moscow, St. Petersburg, Volgograd (GMT+03:00) Nairobi (GMT+03:30) Tehran (GMT+04:00) Abu Dhabi, Muscat...
Page 159 (GMT+09:30) Adelaide (GMT+09:30) Darwin (GMT+10:00) Brisbane (GMT+10:00) Canberra, Melbourne, Sydney (GMT+10:00) Guam, Port Moresby (GMT+10:00) Hobart (GMT+10:00) Vladivostok (GMT+11:00) Magadan, Solomon Is., New Caledonia (GMT+12:00) Auckland, Wellington (GMT+12:00) Fiji, Kamchatka, Marshall Is. (GMT+13:00) Nuku’alofa [ Time Zone ] -159-...
Page 160: System – Ddns
System – DDNS: Version : 1.00 Date : 2014. 06. 27 Revision History Version Date Comment 1.00 2014-06-27 Initial version Introduction This Chapter defines the detailed setup procedure for the DDNS. DDNS URI http://”camera ipaddress”/system/ddns.php DDNS Parameter Parameter Type Value net_ddns boolean 0 : Off, 1 : On...
Page 161: Ddns Password Setup
6) DDNS Password setup http://”camera ipaddress”/system/ddns.php?app=set&ddns_pwd=admin 7) DDNS Confirm Password setup http://”camera ipaddress”/system/ddns.php?app=set&ddns_pwdconfirm=admin 8) DDNS Interval setup http://”camera ipaddress”/system/ddns.php?app=set&ddns_interval=1800 http://”camera ipaddress”/system/ddns.php?app=set&ddns_interval=3600 9) DDNS Local setup http://”camera ipaddress”/system/ddns.php?app=set&ddns_local=0 http://”camera ipaddress”/system/ddns.php?app=set&ddns_local=1 Caution You must check the following values in the response to http://”camera ipaddress”/config.txt Item data.
Page 162: System – H/W Check
System – H/W check: Version : 1.00 Date : 2014. 03. 03 Revision History Version Date Comment 1.00 2014-03-03 Initial version Introduction This Chapter defines the detailed setup procedure for the Hardware Check. Hardware Check URI http://”camera ipaddress”/system/check_hardware.php Hardware Check Parameter Parameter Type Value...
Page 163: System – Https
System – HTTPS: Version : 1.00 Date : 2014. 06. 27 Revision History Version Date Comment 1.00 2014-06-27 Initial version Introduction This Chapter defines the detailed setup procedure HTTPS. HTTPS URI http://”camera ipaddress”/system/https.php HTTPS Parameter Parameter Type Value Method string update, remove https_mode integer...
Page 164: Caution
http://”camera ipaddress”/system/https.php?app=set&https_mode=1 http://”camera ipaddress”/system/https.php?app=set&https_mode=2 Caution You must check the following values in the response to http://”camera ipaddress”/config.txt Item Value Explanation https_port Current https port value https_mode 0, 1, 2 Current https mode value...
Page 165: System – Information
System – Information: Version : 1.00 Date : 2014. 06. 27 Revision History Version Date Comment 1.00 2014-06-27 Initial version Introduction This Chapter defines the detailed setup procedure for the Information. Information URI http://”camera ipaddress”/system/information.php Information Parameter Parameter Type Value device_name string User defined device name...
Page 166: System – Ip Filtering
System – IP Filtering: Version : 1.00 Date : 2014. 05. 30 Revision History Version Date Comment 1.00 2014-05-30 Initial version Introduction This Chapter defines the detailed setup procedure IP Filtering. IP Filtering URI http://”camera ipaddress”/system/filtering.php IP Filtering Parameter Parameter Type Value ipfilter_enable...
Page 167: Ip Filtering Priority 2
http://”camera ipaddress”/system/filtering.php?app=set&ipfilter1_startip=10.0.2.10&ipfilter1_endip=10.0.2. 4) IP Filtering Priority 2 a. IP Filtering Priority 2 setup http://”camera ipaddress”/system/filtering.php?app=set&ipfilter2_enable=0 http://”camera ipaddress”/system/filtering.php?app=set&ipfilter2_enable=1 b. Policy setup http://”camera ipaddress”/system/filtering.php?app=set&ipfilter2_policy=0 http://”camera ipaddress”/system/filtering.php?app=set&ipfilter2_policy=1 c. Start & End IP setup http://”camera ipaddress”/system/filtering.php?app=set&ipfilter2_startip=10.0.2.30&ipfilter2_endip=10.0.2.4 5) IP Filtering Priority 3 a. IP Filtering Priority 3 setup http://”camera ipaddress”/system/filtering.php?app=set&ipfilter3_enable=0 http://”camera ipaddress”/system/filtering.php?app=set&ipfilter3_enable=1 b.
Page 168: Caution
http://”camera ipaddress”/system/filtering.php?app=set&ipfilter5_policy=0 http://”camera ipaddress”/system/filtering.php?app=set&ipfilter5_policy=1 c. Start & End IP setup http://”camera ipaddress”/system/filtering.php?app=set&ipfilter5_startip=10.0.2.70&ipfilter5_endip=10.0.2. Caution The ending IP address should have a larger value than starting IP adddress for all priority You must check the following values in the response to http://”camera ipaddress”/config.txt Item Value Explanation...
Page 169: System – Language
System – Language: Version: 1.00e Date: 2014. 03. 18 Revision History Version Date Comment 1.00 2014-01-23 Initial version 1.00e 2014-03-18 English Translation Introduction This Chapter defines the detailed setup procedure for the web page Language. Language URI http://”camera ipaddress”/system/language.php Language Parameter Parameter Type Value...
Page 170: System – Live Push
System – Live Push: Version : 1.00 Date : 2014. 02. 27 Revision History Version Date Comment 1.00 2014-02-27 Initial version Introduction This Chapter defines the detailed setup procedure for the Live Push.. Live Push URI http://”camera ipaddress”/system/live_push.php Live Push Parameter Parameter Type Value...
Page 171: Live Push
b. Live Push 2 URL setup http://”camera ipaddress”/system/live_push.php?app=set&live_push2_server=10.0.2.12 c. Live Push 2 Port setup http://”camera ipaddress”/system/live_push.php?app=set&live_push2_port=8080 d. Live Push 2 User name setup http://”camera ipaddress”/system/live_push.php?app=set&live_push2_user=admin e. Live Push 2 Password setup http://”camera ipaddress”/system/live_push.php?app=set&live_push2_pass=admin 4) Live Push 3 a. Live Push 3 setup http://”camera ipaddress”/system/live_push.php?app=set&live_push3_enable=1 http://”camera ipaddress”/system/live_push.php?app=set&live_push3_enable=0 b.
Page 172: System – Log
System – Log: Version: 1.00e Date: 2015. 07. 20 Revision History Version Date Comment 1.00 2015-07-01 Initial version 1.00e 2015-07-20 English Translation Introduction This chapter describest he camera Log request method via URI. Log URI http://"Camera IP Address"/system/log.txt Log Parameter Parameter Type Value...
Page 173: End Time
3) End time http://”camera ipaddress”/system/log.txt?etime=05:10:51 4) Start time, End time http://”camera ipaddress”/system/log.txt?stime=13:00:00&etime=13:07:00 5) Start date http://”camera ipaddress”/system/log.txt?sdate=2015-12-25 6) End date http://”camera ipaddress”/system/log.txt?edate=2015-12-31 7) Start date, End date http://”camera ipaddress”/system/log.txt?sdate=2015-12-25&edate=2015-12-31 8) Start date, Start time, End date, End time http://”camera ipaddress”/system/log.txt?sdate=2015-02-28&stime=10:42:11&edate=2015-09- 03&etime=18:23:45 9) Type, Start date, Start time, End date, End time http://”camera ipaddress”/system/log.txt?type=2&sdate=2015-02-...
Page 174: System – Maintenance
System – Maintenance: Version : 1.01 Date : 2014. 09. 17 Revision History Version Date Comment 1.01 2014-09-17 Initial version Introduction This Chapter defines the detailed setup procedure for the Maintenance. Maintenance URI 1) Restart Restart Camera system. http://”camera ipaddress”/system/restart.php 2) Reset Reset all parameter except the IP parameter.
Page 175: Default
3) Default http://”camera ipaddress”/system/default.php 4) Upgrade Refer to caution of File upload. 5) VCA Upgrade Refer to caution of VCA upload. 6) Backup http://”camera ipaddress”/system/backup.cgi 7) Restore Refer to caution of File upload .. 8) Calibrate Refer to detailed explanation of Move in Motor Position Control API.
Page 176 vca_option UPDATE VCA Update available You must check the following values in the response to http://”camera ipaddress”/config.txt for proper work of calibration Item Value Explanation Motor available Options M_PTZ Detailed support in m_ptz_option m_ptz_option ZOOM_TRACKING Motor Position Control available -176-...
Page 177: System – Media Check
System – Media check: Version : 1.00 Date : 2014. 03. 04 Revision History Version Date Comment 1.00 2014-03-04 Initial version Introduction This Chapter defines the detailed setup for the Media Check. Media Check URI http://”camera ipaddress”/system/check_media.php Media Check Parameter Parameter Type Value...
Page 178: System – Nat
System – NAT: Version : 1.00 Date : 2014. 05. 26 Revision History Version Date Comment 1.00 2014-05-26 Initial version Introduction his Chapter defines the detailed setup procedure for the NAT NAT URI http://”camera ipaddress”/system/nat.php NAT Parameter Parameter Type Value nat_enable_wire integer 0 : Disable, 1 : Enable...
Page 179: External Wireless Rtsp Port Setup
7) External wireless RTSP port setup http://”camera ipaddress”/system/nat.php?app=set&nat_wireless_rtsp_port=11234 If it is set to “0” ,it will be defined to available random port. 8) Response wire HTTP&RTSP URL nat_enable_wire, nat_wire_http_port, nat_wire_rtsp_port, port mapping HTTP URL and RTSP URL will be responded. Below is proper example of response.. res=200&nat_wire_http_address=115.95.240.151:11234&nat_wire_rtsp_address=115.95.240.151 :10001 9) Response wireless HTTP&RTSP URL...
Page 180: System – Network
System – Network: Version: 1.01e Date: 2017. 1. 10 Revision History Version Date Comment 1.00 2015-06-16 Initial version 1.00e 2015-06-26 English Translation 1.01e 2017-01-10 DHCP API error modify Introduction This Chapter defines the detailed setup procedure for the Network. System – Network URI http://”camera ipaddress”/system/network.php System –...
Page 181: Examples
Examples 1) get the current information http://”camera ipaddress”/system/network.php?app=get 2) IP address assign method setup http://”camera ipaddress”/system/network.php?app=set&net_dhcp=0 http://”camera ipaddress”/system/network.php?app=set&net_dhcp=1 3) fixed IP address setup http://”camera ipaddress”/system/network.php?app=set&net_ip=192.168.35.44 4) fixed Subnet Mask setup http://”camera ipaddress”/system/network.php?app=set&net_mask=255.255.255.0 5) fixed Gateway Address setup http://”camera ipaddress”/system/network.php?app=set&net_gateway=192.168.35.1 6) IPv6 setup http://”camera ipaddress”/system/network.php?app=set&net_ipv6=0 http://”camera ipaddress”/system/network.php?app=set&net_ipv6=1 7) DNS Address assign method setup...
Page 182: Link Speed Setup
16) Link Speed setup http://”camera ipaddress”/system/network.php?app=set&net_link_speed_control =1 http://”camera ipaddress”/system/network.php?app=set&net_link_speed_control =2 Caution You must check the following values in the response to http://”camera ipaddress”/config.txt Item Value Description name String Host Name ipv4 IP Address IPv4 Address ipv6 IP Address IPv6 Address http_port Integer HTTP Port Number...
Page 183: System – Network Check
System – Network check: Version : 1.00 Date : 2014. 03. 04 Revision History Version Date Comment 1.00 2014-03-04 Initial version Introduction This Chapter defines the detailed setup procedure for the Network Check. Network Check URI http://”camera ipaddress”/system/check_network.php Network Check Parameter Parameter Type Value...
Page 184 lpush_session boolean (ro) 0 : Disconnected, 1 : Connected epush_session boolean (ro) 0 : Disconnected, 1 : Connected -184-...
Page 185: Openvpn
OpenVPN: Version : 1.00 Date : 2014. 09. 26 Revision History Version Date Comment 1.00 2014-09-26 Initial version Introduction This Chapter defines the detailed setup procedure for the OpenVPN. OpenVPN URI http://”ipaddress”/system/openvpn.php OpenVPN Parameter Parameter Type Value openvpn_enable integer 0 : disable, 1 : enable openvpn_mode integer 0 : client mode, 1 : server mode...
Page 186: Example
authentication will be done by uploading client cert, client key which are provided by openvpn server. * the openvpn_user_authentication_id’, ‘openvpn_user_authentication_passwd’ parameter setup are available when ‘openvpn_user_authentication_mode’ Parameter is set to ‘User authentication’ * the Suffix ‘ipaddr’Parameter means openvpn server URL. * the openvpn_ip’...
Page 187: Openvpn_User_Authentication_Mode Setup
12) openvpn_user_authentication_mode setup http://”ipaddress”/system/openvpn.php?app=set&openvpn_user_authentication_mode=1 ( User Authentication ) http://”ipaddress”/system/openvpn.php?app=set&openvpn_user_authentication_mode=0 ( Machine Authentication ) 13) openvpn_user_authentication_id setup http://”ipaddress”/system/openvpn.php?app=set&openvpn_user_authentication_id=test 14) openvpn_user_authentication_passwd setup http://”ipaddress”/system/openvpn.php?app=set&openvpn_user_authentication_passwd=test 15) openvpn_server_ipaddr setup http://”ipaddress”/system/openvpn.php?app=set&openvpn_server_ipaddr=192.168.1.1 16) How to setup openvpn at once http://”ipaddress”/system/openvpn.php?app=set&openvpn_enable=1&openvpn_mode=1&openvp n_server_protocol=1&openvpn_server_port=1194&openvpn_server_lzo=1&openvpn_server_i paddr=192.168.1.1&openvpn_client_protocol=1&openvpn_client_port=1194&openvpn_client _lzo=1&openvpn_user_authentication_mode=0&openvpn_user_authentication_id=&openvpn_ user_authentication_passwd=&openvpn_server_reneg=3600&openvpn_client_reneg=3600 Caution * List of reference for ‘openvpn_server_reneg’, ‘openvpn_client_reneg’ Parameter setup 1.
Page 188: System – Qos
System – QoS: Version : 1.00 Date : 2014. 06. 27 Revision History Version Date Comment 1.00 2014-06-27 Initial version Introduction This Chapter defines the detailed setup procedure for the QoS. QoS URI http://”camera ipaddress”/system/qos.php QoS Parameter Parameter Type Value dscp_stream integer 0 ~ 63...
Page 189 b. Automatic traffic control mode setup http://”camera ipaddress”/system/qos.php?app=set&net_ctrl_mode=1 http://”camera ipaddress”/system/qos.php?app=set&net_ctrl_mode=2 c. net_ctrl_mode=1 , bandwidth setup http://”camera ipaddress”/system/qos.php?app=set&net_limit=1024 d. net_ctrl_mode=1, Priority setup http://”camera ipaddress”/system/qos.php?app=set&control_method=1 http://”camera ipaddress”/system/qos.php?app=set&control_method=2 http://”camera ipaddress”/system/qos.php?app=set&control_method=3...
Page 190: System – Rtp
System – RTP: Version : 1.00 Date : 2014. 05. 30 Revision History Version Date Comment 1.00 2014-05-30 Initial version Introduction This Chapter defines the detailed setup procedure for the RTP. RTP URI http://”camera ipaddress”/system/rtp.php RTP Parameter Parameter Type Value rtp_start_port integer 30000 ~ 39800...
Page 191: Rtp Port Range
2) RTP Port Range a. Start Port setup http://”camera ipaddress”/system/rtp.php?app=set&rtp_start_port=30500 3) Multicast (Stream 1) a. Multicast destination IP setup http://”camera ipaddress”/system/rtp.php?app=set&rtp_mcast1_ip=231.1.128.23 b. RTP Port setup http://”camera ipaddress”/system/rtp.php?app=set&rtp_mcast1_port=40000 c. RTP TTL setup http://”camera ipaddress”/system/rtp.php?app=set&rtp_mcast1_ttl=5 d. Always enable multicast setup - http://”camera ipaddress”/system/rtp.php?app=set&rtp_mcast1_always_enable=0 - http://”camera ipaddress”/system/rtp.php?app=set&rtp_mcast1_always_enable=1 4) Multicast (Stream 2) a.
Page 192: Multicast (Meta)
http://”camera ipaddress”/system/rtp.php?app=set&rtp_mcast_audio_port=40000 c. RTP TTL setup http://”camera ipaddress”/system/rtp.php?app=set&rtp_mcast_audio_ttl=5 d. Always enable multicast setup http://”camera ipaddress”/system/rtp.php?app=set&rtp_mcast_audio_always_enable=0 http://”camera ipaddress”/system/rtp.php?app=set&rtp_mcast_audio_always_enable=1 7) Multicast (Meta) a. Multicast destination IP setup http://”camera ipaddress”/system/rtp.php?app=set&rtp_mcast_meta_ip=231.1.128.27 b. RTP Port setup http://”camera ipaddress”/system/rtp.php?app=set&rtp_mcast_meta_port=40000 c. RTP TTL setup http://”camera ipaddress”/system/rtp.php?app=set&rtp_mcast_meta_ttl=5 d. Always enable multicast setup http://”camera ipaddress”/system/rtp.php?app=set&rtp_mcast_meta_always_enable=0 http://”camera ipaddress”/system/rtp.php?app=set&rtp_mcast_meta_always_enable=1 Caution...
Page 193: System – System Check
System – System check: Version : 1.00 Date : 2014. 03. 04 Revision History Version Date Comment 1.00 2014-03-04 Initial version Introduction This Chapter defines the detailed setup procedure for the System Check. System Check URI http://”camera ipaddress”/system/check_system.php System Check Parameter Parameter Type Value...
Page 194: System – Upnp
System – UpnP: Version: 1.00e Dat : 2014. 03. 17 Revision History Version Date Comment 1.00 2014-02-07 Initial version 1.00e 2014-03-17 English Translation Introduction This Chapter defines the detailed setup procedure for the UPnP. UPnP URI http://”camera ipaddress”/system/upnp.php UPnP Parameter Parameter Type Value...
Page 195: System – Users
System – Users: Version: 1.00e Date: 2014. 03. 17 Revision History Version Date Comment 1.00 2014-02-21 Initial version 1.00e 2014-03-17 English Translation Introduction This Chapter defines the detailed setup procedure for the Users. Users URI http://”camera ipaddress”/system/user.php Users Parameter Parameter Type Value method...
Page 196: Example
• list[3] * format : list[0] | list[1] | list[2] (‘|’ : differentiator) list[0] = user list string (ro) list[1] = level list[2] = 0 : Motor & PTZ not support list[2] = 1 : PTZ support list[2] = 2 : Motor support Example 1) get the current setting http://”camera ipaddress”/system/user.php?app=get...
Page 197: Modify User
3) modify User a. Password change http://”camera ipaddress”/system/user.php?app=set&method=modify&user=myadmin1&pass=myadmin1 b. level change http://”camera ipaddress”/system/user.php?app=set&method=modify&user=myadmin2&pass=1234&level= c. PTZ control change http://”camera ipaddress”/system/user.php?app=set&method=modify&user=myadmin2&pass=1234&ptz_en able=0 http://”camera ipaddress”/system/user.php?app=set&method=modify&user=myadmin2&pass=1234&ptz_en able=1 d. Motor control change http://”camera ipaddress”/system/user.php?app=set&method=modify&user=myadmin2&pass=1234&motor_ enable=0 http://”camera ipaddress”/system/user.php?app=set&method=modify&user=myadmin2&pass=1234&motor_ enable=1 * In the case method=modify, you must include user and pass. 4) delete User http://”camera ipaddress”/system/user.php?app=set&method=remove&remove_user=myadmin1 * the remove_user value must match one of the registered user ID’s.
Page 198: Security – Vpm
Security – VPM: Version: 1.01e Date: 2015. 07. 20 Revision History Version Date Comment 1.00 2015-05-20 Initial version 1.01 2015-07-02 Modify the server add API 1.01e 2015-07-20 English Translation Introduction This Chapter defines the detailed setup procedure for the VPM. VPM URI http://”camera ipaddress”/system/vpm.php VPM Parameter...
Page 199: Example
Example 1) get the current setting http://”camera ipaddress”/system/vpm.php?app=get * Response : res=200&vpm_enable=0&vpm_count=6&list=4|server3|13.12.132.122|162\n5|server123|153.1 2.132.122|162\n6|server4|153.112.132.122|162\n7|server5|153.120.132.122|162\n8|server6|153. 120.131.177|162\n9|server7|153.121.31.1|162 2) VPM setup http://”camera ipaddress”/system/vpm.php?app=set&vpm_enable=1 http://”camera ipaddress”/system/vpm.php?app=set&vpm_enable=0 * Response : res=200 3) add Server http://”camera ipaddress”/system/vpm.php?app=set&method=add&title=server_title&addr=1.0.0.1&port=162 * Response : res=200&id=1&title=server_title&addr=1.0.0.1&port=162 * For Server addition, you must input addr. * In Server addition, id is assigned and returned.
Page 200: System – Network – Wireless
System – Network – Wireless: Version : 1.00 Date : 2014. 05. 22 Revision History Version Date Comment 1.00 2014-05-22 Initial version Introduction This Chapter defines the detailed setup procedure for the Wireless Wireless URI 1) Wireless Network URI http://”camera ipaddress”/system/wireless.php 2) Wireless Setup NRI http://”camera ipaddress”/system/wireless_setup.php Wireless Parameter...
Page 201: Example
BSSID String AP Mac Address method String connect, disconnect, delete wireless_ssid String AP Name wireless_bssid String AP Mac Address wireless_password String AP Password Example 1) get the current Wireless Network value http://”camera ipaddress”/system/wireless.php?app=get 2) get the current Wireless AP value http://”camera ipaddress”/system/ wireless_setup?app=get 3) Wireless Network setup http://”camera ipaddress”/system/ wireless.php?app=set&wireless_dhcp=1...
Page 202: Wireless Ap Delete Setup
11) Wireless AP Delete setup http://”camera ipaddress”/system/ wireless_setup?app=set&method=delete&wireless_ssid=IPTIME&wireless_bssid=00:26:66:cc: 09:bc...
Page 203: System – Zeroconf
System – Zeroconf: Version: 1.00e Date: 2014. 03. 17 Revision History Version Date Comment 1.00 2014-02-06 Initial version 1.00e 2014-03-17 English Translation Introduction This Chapter defines the detailed setup procedure for the Zeroconf. Zeroconf URI http://”camera ipaddress”/system/zeroconf.php Zeroconf Parameter Parameter Type Value zeroconf_enable...
Page 204: Video & Image
Video & Image Video & Image – Camera Setup: Version : 1.03e Date : 2016. 06. 21 Revision History Version Date Comment 1.00 2014-09-18 Initial version 1.01 2015-02-03 AIP update 1.01e 2015-02-04 English Translation 1.02 2015-02-12 Manual White Blance Control update, 1.02e 2015-02-15 English version updatea...
Page 205 integer(ro) max_saturation Max. Saturation Value integer(ro) min_hue Min. Hue Value integer(ro) max_hue Max. Hue Value integer(ro) min_sharpness Min. Sharpness Value integer(ro) max_sharpness Max. Sharpness Value integer(ro) def_brightness Default brightness integer(ro) def_contrast Default contrast integer(ro) def_saturation Default saturation integer(ro) def_hue Default hue integer(ro) def_sharpness Default sharpness...
Page 206 def_wb_cb_gain integer(ro) Default White Balance Blue Gain Value def_wb_cr_gain integer(ro) Default White Balance Red Gain Value wb_cb_gain integer min_wb_cb_gain ~ max_ wb_cb_gain wb_cr_gain integer min_wb_cr_gain ~ max_ wb_cr_gain dnn_mode integer(ro) 0(Low), 3(Middle), 4(High) T series, X2 Fixed : 1(Low), 0(High) dnn_thres integer(ro) X2 PTZ : 0(Low), 1(Middle), 2(High)
Page 207 camera_f60_auto_shutter_list for Exposure Mode “Flicker-free 50Hz” and Shutter “Automatic” camera_manual_fixed_shutter_list for Exposure Mode “Manual” and Shutter “Automatic” camera_iris_mode integer 1(Automatic), 2(Fixed) string(ro) List for Exposure Mode “Automatic” and Iris camera_auto_fixed_iris_list “Fixed” string(ro) List for Exposure Mode “Manual” and Iris camera_manual_fixed_iris_list “Fixed”...
Page 208: Example
moving_ir_bright integer min_moving_ir_bright ~ max_moving_ir_bright fixed_ir_level integer min_fixed_ir_level ~ max_fixed_ir_level moving_ir_level integer min_moving_ir_level ~ max_moving_ir_level delay_time integer min_delay_time ~ max_delay_time moving_ir_mode integer 1(Low), 2(Middle), 3(High) enable_long_exposure boolean 0(false), 1(true) max_shutter_value integer 0(1/15), 1(1/8), 2(1/4) flicker_free boolean 0(false), 1(true) flicker_mode integer 0(50Hz), 1(50Hz) agc_db integer...
Page 209: Brightness Setup
2) Brightness setup http://”camera ipaddress”/video/image.php?app=set&brightness=10 http://”camera ipaddress”/video/image.php?app=set&brightness=1 3) Contrast setup http://”camera ipaddress”/video/image.php?app=set&contrast=10 http://”camera ipaddress”/video/image.php?app=set&contrast=1 4) Saturation setup http://”camera ipaddress”/video/image.php?app=set&saturation=10 http://”camera ipaddress”/video/image.php?app=set&saturation=1 5) Hue setup http://”camera ipaddress”/video/image.php?app=set&hue=10 http://”camera ipaddress”/video/image.php?app=set&hue=1 6) Sharpness setup http://”camera ipaddress”/video/image.php?app=set&sharpness=10 http://”camera ipaddress”/video/image.php?app=set&sharpness=1 7) Flip setup http://”camera ipaddress”/video/image.php?app=set&flip=0 http://”camera ipaddress”/video/image.php?app=set&flip=1 8) Mirror setup http://”camera ipaddress”/video/image.php?app=set&mirror=0...
Page 210: Defog Strength Setup
14) Defog Strength setup http://”camera ipaddress”/video/image.php?app=set&defog_strength=0 http://”camera ipaddress”/video/image.php?app=set&defog_strength=1 http://”camera ipaddress”/video/image.php?app=set&defog_strength=2 15) IRIS setup http://”camera ipaddress”/video/image.php?app=set&enable_auto_iris=0 http://”camera ipaddress”/video/image.php?app=set&enable_auto_iris=1 16) Backlight Compensation setup http://”camera ipaddress”/video/image.php?app=set&blc_enable=0 http://”camera ipaddress”/video/image.php?app=set&blc_enable=1 17) IR setup http://”camera ipaddress”/video/image.php?app=set&enable_ir=0 http://”camera ipaddress”/video/image.php?app=set&enable_ir=1 18) Max Strength Value setup http://”camera ipaddress”/video/image.php?app=set&max_strength_value=1 http://”camera ipaddress”/video/image.php?app=set&max_strength_value=2 http://”camera ipaddress”/video/image.php?app=set&max_strength_value=3 http://”camera ipaddress”/video/image.php?app=set&max_strength_value=4 http://”camera ipaddress”/video/image.php?app=set&max_strength_value=5...
Page 211: Day & Night Mode Setup
http://”camera ipaddress”/video/image.php?app=set&wb_cr_gain=255 25) Day & Night Mode setup http://”camera ipaddress”/video/image.php?app=set&dnn_mode=0 http://”camera ipaddress”/video/image.php?app=set&dnn_mode=3 http://”camera ipaddress”/video/image.php?app=set&dnn_mode=4 26) Day & Night Threshold setup Day & Night Threshold input and output values depend on the contents of Config.txt. For X2 series, if BUILTIN_PTZ item exists in options, the following setup commands are applied.
Page 212: Camera Iris Value Setup
33) Camera Iris Value setup http://”camera ipaddress”/video/image.php?app=set&camera_iris_value=F14 http://”camera ipaddress”/video/image.php?app=set&camera_iris_value=F2.1 34) Camera Iris Value setup http://”camera ipaddress”/video/image.php?app=set&camera_iris_value=F14 http://”camera ipaddress”/video/image.php?app=set&camera_iris_value=F2.1 35) Camera Manual Gain setup http://”camera ipaddress”/video/image.php?app=set&camera_manual_gain=0db http://”camera ipaddress”/video/image.php?app=set&camera_manual_gain=42db 36) IR Mode setup http://”camera ipaddress”/video/image.php?app=set&ir_mode=1 http://”camera ipaddress”/video/image.php?app=set&ir_mode=2 http://”camera ipaddress”/video/image.php?app=set&ir_mode=3 37) IR On Level setup http://”camera ipaddress”/video/image.php?app=set&ir_on_level=1 http://”camera ipaddress”/video/image.php?app=set&ir_on_level=20 38) IR Off Level setup...
Page 213: Long Exposure Setup
45) Long Exposure setup http://”camera ipaddress”/video/image.php?app=set&enable_long_exposure=0 http://”camera ipaddress”/video/image.php?app=set&enable_long_exposure=1 46) Max Shutter Value setup http://”camera ipaddress”/video/image.php?app=set&max_shutter_value=0 http://”camera ipaddress”/video/image.php?app=set&max_shutter_value=1 http://”camera ipaddress”/video/image.php?app=set&max_shutter_value=2 47) Flicker Free setup http://”camera ipaddress”/video/image.php?app=set&flicker_free=0 http://”camera ipaddress”/video/image.php?app=set&flicker_free=1 48) Flicker Mode setup http://”camera ipaddress”/video/image.php?app=set&flicker_mode=0 http://”camera ipaddress”/video/image.php?app=set&flicker_mode=1 49) AGC DB setup http://”camera ipaddress”/video/image.php?app=set&agc_db=0 http://”camera ipaddress”/video/image.php?app=set&agc_db=1 http://”camera ipaddress”/video/image.php?app=set&agc_db=2 50) IRIS Type setup...
Page 214: High Light Compensation Level Setup
56) High Light Compensation Level setup http://”camera ipaddress”/video/setup_camera.php?app=set&hlc_level=1 http://”camera ipaddress”/video/setup_camera.php?app=set&hlc_level=2 http://”camera ipaddress”/video/setup_camera.php?app=set&hlc_level=3 57) ANPR Multi Shutter setup http://”camera ipaddress”/video/setup_camera.php?app=set&anpr_count=1 http://”camera ipaddress”/video/setup_camera.php?app=set&anpr_count=2 http://”camera ipaddress”/video/setup_camera.php?app=set&anpr_count=3 http://”camera ipaddress”/video/setup_camera.php?app=set&anpr_count=4 http://”camera ipaddress”/video/setup_camera.php?app=set&anpr_count=5 58) ANPR Multi Shutter Value setup http://”camera ipaddress”/video/setup_camera.php?app=set&anpr_count=1|2|1|4|3 http://”camera ipaddress”/video/setup_camera.php?app=set&anpr_count=2|4|3|1|5 59) High Light Compensation Level setup http://”camera ipaddress”/video/setup_camera.php?app=set&hlc_level=1 http://”camera ipaddress”/video/setup_camera.php?app=set&hlc_level=2 http://”camera ipaddress”/video/setup_camera.php?app=set&hlc_level=3...
Page 215 Aisle available AISLE Manual White Balance Control available -215-...
Page 216: Video & Image – Osd
Video & Image – OSD: Version: 1.02e Date: 2015. 11. 24 Revision History Version Date Comment 1.00 2015-03-18 Initial version 1.00e 2015-03-26 English translation Added osd_background, 1.01e 2015-06-26 Changed osd_title_text 1.02e 2015-11-24 Added osd_subtitle_text Introduction This Chapter defines detailed setup procedure of OSD. OSD URI http://”camera ipaddress”/video/osd.php OSD Parameter...
Page 217: Example
Example 1) get the current setting http://”camera ipaddress”/video/osd.php?app=get 2) OSD setup for each stream http://”camera ipaddress”/video/osd.php?app=set&osd_stream1_enable=0 http://”camera ipaddress”/video/osd.php?app=set&osd_stream1_enable=1 http://”camera ipaddress”/video/osd.php?app=set&osd_stream2_enable=0 http://”camera ipaddress”/video/osd.php?app=set&osd_stream2_enable=1 http://”camera ipaddress”/video/osd.php?app=set&osd_stream3_enable=0 http://”camera ipaddress”/video/osd.php?app=set&osd_stream3_enable=1 3) OSD transparency setup * check osd_min_transparency, osd_max_transparency before setup. http://”camera ipaddress”/video/osd.php?app=set&osd_transparency=3 4) OSD title setup http://”camera ipaddress”/video/osd.php?app=set&osd_title_enable=0 http://”camera ipaddress”/video/osd.php?app=set&osd_title_enable=1 5) OSD title text setup...
Page 218 OSD available options OSD_DISPLAY_CTRL URL Encoding All characters except 0~9, a~z, A~Z, ‘@’, ‘.’, ‘/’, ‘\’, ‘-‘, ‘_’, ‘:’ use %HH format. ‘HH’ means 1byte Hex value. ex) $ABC@ = %24ABC%40 -218-...
Page 219: Video & Image – Privacy Masking
Video & Image – Privacy Masking: Version: 1.01e Date: 2015. 06. 26 Revision History Version Date Comment 1.00 2014-07-08 Initial version 1.00e 2014-08-05 English Translation 1.01e 2015-06-26 Add API Introduction This Chapter defines the detailed setup procedure for the Privacy Masking. Video&Image –...
Page 220: Example (Latest F/W)
masking_right integer Right pixel position masking_bottom integer Bottom pixel position masking_type string Color, Mosaic, ColorMosaic masking_type_list string(ro) Color|Mosaic|ColorMosaic Example (Latest F/W) 1) get the current information http://”camera ipaddress”/video/masking.php?app=get 2) Privacy Masking setup http://”camera ipaddress”/video/masking.php?app=set&masking_enable=1 http://”camera ipaddress”/video/masking.php?app=set&masking_enable=0 3) Privacy Masking Region setup http://”camera ipaddress”/video/masking.php?app=set&method=create * If a Parameter is null, a Region is created as the whole area with Default setting.
Page 221: Privacy Masking Region Parameter Modify
4) Privacy Masking Region Parameter modify single region modify http://”camera_ipaddress”/video/masking.php?app=set&method=modify&masking_id=1&”modif y desired parameter” * You must send an assigned id to request a change in a parameter value. * If you change a coordinate, the value of left cannot exceed that of right, and the value of top cannot exceed that of bottom.
Page 222: Privacy Masking Region Remove
b. Region Left setup for Privacy Masking multiple Region Modify http://”camera ipaddress”/video/masking.php?app=set&method=modify&masking1_left=0&masking2_l eft=500 c. Region Top setup for Privacy Masking multiple Region Modify http://”camera ipaddress”/video/masking.php?app=set&method=modify&masking1_Top=0&masking2_T op=50 d. Region Right setup for Privacy Masking multiple Region Modify http://”camera ipaddress”/video/masking.php?app=set&method=modify&masking1_right=900&masking3 _right=100 e. Region Bottom setup for Privacy Masking multiple Region Modify http://”camera ipaddress”/video/masking.php?app=set&method=modify&masking1_bottom=500&maskin g3_bottom=100...
Page 223: Privacy Masking Region Remove
5) Privacy Masking Region remove http://”camera ipaddress”/video/masking.php?app=set&method=delete&masking_id=1 * If you want to delete, you must make the request using the assigned id.. 6) Privacy Masking all * For old F/W, the following method is recommended rather than the method=modify. Request : http://”ipaddress”/video/masking.php?app=get Response : res=200&masking_enable=1&masking_count=3&masking1_id=2&masking1_name=New(1)&...
Page 224: Video & Image – Basic
Video & Image – Basic: Version: 1.03e Date: 2015. 10. 08 Revision History Version Date Comment 1.00 2013-12-11 Initial version 1.00e 2014-03-17 English Translation 1.01e 2014-04-29 Add Capture Resolution List option Add Capture Resolution value Add Resolution List option Add supported Frame List Add supported maximum Bitrate Change Framerate value description Change Bitrate value description...
Page 225: Example
* “ch#_strm#_res_list”, “ch#_strm#_res” reference caution. Example 1) get the current setting http://”camera ipaddress”/video/video.php?app=get The followings are responses for each camera series. • Sharx Security HTNC44xx full HD 60 fps series (Sony Xarina / X2) res=200&input_mode=1920x1080&video_mode=NTSC&total_ch=1&total_strm=3& ch1_cap_res_list=1920x1080 Max. 60fps|1920x1080 Max. 30fps&ch1_cap_res=1080P& ch1_strm1_codec_list=H264HP|H264MP|H264BP&ch1_strm1_res_list=1080P|SXGA|QUADV GA|720P|XGA|576P|480P|VGA|VGAWIDE|QVGA&ch1_strm1_fps_list=30|25|20|15|12|10|6 |5|4|3|2|1&ch1_strm2_codec_list=MJPEG&ch1_strm2_res_list=1080P|SXGA|QUADVGA|72...
Page 226: Capture Resolution Setup
• Sharx Security HTNC45xx 5 MP camera series (Sony Xarina Pro / X4) res=200&input_mode=2592x1944&video_mode=NTSC&total_ch=1&total_strm=3&ch1_str m1_codec_list=H264HP|H264MP|H264BP&ch1_strm1_res_list=1944P|QXGA|1944FE|14 40FE|SXGA|QUADVGA|1024FE|XGA|720FE|576P|VGA|480FE&ch1_strm1_fps_list=15| 12|10|6|5|4|3|2|1&ch1_strm2_codec_list=MJPEG&ch1_strm2_res_list=1440FE|SXGA|QU ADVGA|1024FE|XGA|720FE|576P|VGA|480FE&ch1_strm2_fps_list=15|12|10|6|5|4|3|2|1 &ch1_strm3_codec_list=H264HP|H264MP|H264BP&ch1_strm3_res_list=1944P|QXGA|1 944FE|1440FE|SXGA|QUADVGA|1024FE|XGA|720FE|576P|VGA|480FE&ch1_strm3_fp s_list=15|12|10|6|5|4|3|2|1&ch1_strm1_enable=1&ch1_strm1_codec=H264BP&ch1_strm1 _res=1944P&ch1_strm1_fps=15&ch1_strm1_maxfps=15&ch1_strm1_bitrate=6000&ch1_ strm1_maxbr=12000&ch1_strm1_ratecontrol=cbr&ch1_strm1_gov=15&ch1_strm1_vbr_q uality=1&ch1_strm1_vbr_quality_min=1&ch1_strm1_vbr_quality_max=5&ch1_strm2_en able=1&ch1_strm2_codec=MJPEG&ch1_strm2_res=VGA&ch1_strm2_fps=15&ch1_strm 2_maxfps=15&ch1_strm2_quality=50&ch1_strm3_enable=1&ch1_strm3_codec=H264BP &ch1_strm3_res=480FE&ch1_strm3_fps=15&ch1_strm3_maxfps=15&ch1_strm3_bitrate =500&ch1_strm3_maxbr=12000&ch1_strm3_ratecontrol=cbr&ch1_strm3_gov=15&ch1_s trm3_vbr_quality=1&ch1_strm3_vbr_quality_min=1&ch1_strm3_vbr_quality_max=5& * The User can check the above response values via “Video & Image – Basic Parameter”.
Page 227: Frame Per Second Setup
http://”camera ipaddress”/video/video.php?app=set&ch1_strm#_res=QXGA http://”camera ipaddress”/video/video.php?app=set&ch1_strm#_res=1080P http://”camera ipaddress”/video/video.php?app=set&ch1_strm#_res=UXGA http://”camera ipaddress”/video/video.php?app=set&ch1_strm#_res=SXGA http://”camera ipaddress”/video/video.php?app=set&ch1_strm#_res=720P http://”camera ipaddress”/video/video.php?app=set&ch1_strm#_res=SVGA http://”camera ipaddress”/video/video.php?app=set&ch1_strm#_res=576P http://”camera ipaddress”/video/video.php?app=set&ch1_strm#_res=480P http://”camera ipaddress”/video/video.php?app=set&ch1_strm#_res=VGA http://”camera ipaddress”/video/video.php?app=set&ch1_strm#_res=CIFP http://”camera ipaddress”/video/video.php?app=set&ch1_strm#_res=CIFN http://”camera ipaddress”/video/video.php?app=set&ch1_strm#_res=QVGA http://”camera ipaddress”/video/video.php?app=set&ch1_strm#_res=4CIF http://”camera ipaddress”/video/video.php?app=set&ch1_strm#_res=2CIF http://”camera ipaddress”/video/video.php?app=set&ch1_strm#_res=CIF http://”camera ipaddress”/video/video.php?app=set&ch1_strm#_res=QCIF http://”camera ipaddress”/video/video.php?app=set&ch1_strm#_res=QQVGA * Supported Resolutions are listed in ch#_strm#_res_list. * Please refer Resolution Table for Resolution setting.
Page 228: Gop (Group Of Picture) Setup
9) GOP (Group of Picture) setup http://”camera ipaddress”/video/video.php?app=set&ch1_strm#_gov=1 http://”camera ipaddress”/video/video.php?app=set&ch1_strm#_gov=30 http://”camera ipaddress”/video/video.php?app=set&ch1_strm#_gov=60 * Stream 2 does not support GOP setup since the Codec is MJPEG. * GOP Size is confined to twice the current FPS setting. Caution If the response of http://”camera ipaddress”/config.txt is the same as described in the table below, the user can setup “ch#_cap_res”...
