All rights reserved. Use of this product and this manual is subject to license. Information in this document is subject to change without notice. Trademarks Barracuda NG Firewall is a trademark of Barracuda Networks. All other brand and product names mentioned in this document are registered trademarks or trademarks of their respective holders.
Migrating from phion netfence to Barracuda NG Firewall 5.0.3 ......20 Default Management IP Address and Default Password ..... 20 Issues and Restrictions when Updating from phion netfence .
GPL Compliance Statement This product is in part Linux based and contains both Barracuda Networks proprietary software components and open source components in modified and unmodified form. A certain number of the included open source components underlie the GPL or LGPL or other similar license conditions that require the respective modified or unmodified source code to be made freely available to the general public, this source code is available on http://source.barracuda.com.
Minimum System Requirements If you are going to upgrade standard hardware or phion netfence hardware to Barracuda NG Firewall 5.0.3, please ensure that at least 2 GB of free storage space is available on the root partition. If this minimum amount of space is not available, Barracuda Networks highly recommends to re-install the system with a larger root partition instead of upgrading.
Known Issues Advice about known issues is available at www.barracuda.com or through the Barracuda Networks support. If you are using standard hardware and / or updating from phion netfence, please pay also attention to the Barracuda NG Firewall 5.0 Migration Instructions and the Barracuda NG Firewall 5.2 Migration Instructions...
Updates with Firmware 5.0 Minor Release 3 Update Matrix Table 1–4 Update matrix – supported and not supported update cases 4.2.10 and earlier 4.2.11 4.2.13 4.2.14 4.2.15 4.2.16 5.0.1 5.0.2 If you are going to update from a firmware release version below 5.0, then please see the 5.0 Migration Instructions http://barracuda.com/doc before executing the update.
Software Modules and Components Affected by Minor Release 5.0.3 Table 1–5 Affected Software Modules and Components Firewall VPN Service Access Control Service HTTP Proxy Secure Web Proxy URL Filter Mail Gateway Spam Filter Virus Scanner DHCP Service DHCP Relay FW Audit Log Service FTP Gateway OSPF/RIP Service SNMP Service...
Big amounts of global firewall objects were, even if they were not referenced in a ruleset, leading to high Firewall memory consumption. This issue was fixed. 10 Release and Migration Notes - Bugfixes Included with Barracuda NG Firewall 5.0.3 Description button was erroneously disabled within the...
Page 11
Access Control Service connections on certain ports. This issue was fixed. The VPN Service occasionally crashed with certificates that contained long subject names. This issue was VPN Service fixed. 11 Release and Migration Notes - Bugfixes Included with Barracuda NG Firewall 5.0.3 Description...
Page 12
12 Release and Migration Notes - Bugfixes Included with Barracuda NG Firewall 5.0.3...
Determine Your Update Scenario If you are going to update firmware version 4.2 to Barracuda NG Firewall 5.0.3, Barracuda Networks strongly recommends to study the instructions given in this chapter, as, under certain circumstances, no countermanding is possible once the updating process was initiated.
Page 14
Before beginning the updating process, you should clarify which types of hardware and administrative configuration you have. Barracuda NG Firewall 5.0.3 and its predecessors allow different administrative configurations. Please follow those update instructions that apply to your configuration Table 2–9...
Updating Unmanaged Units or NG Control Centers Updating Units or NG Control Centers Using SSH For speed reasons, Barracuda Networks recommends using this method of updating for all appliances in general, especially for those based on a flash drive or slower hardware.
For Firewall and Configuration HA synchronizing, the primary and the HA unit must both run at least firmware release versions between 4.2.11 and 5.0.3. Barracuda Networks strongly recommends to follow the procedure for updating HA systems exactly as described below in order to minimize any operational drop outs.
Page 17
Proceed after having assured that the HA unit is fully functional. • Unblock the (standby) servers on the HA unit by clicking Control > Servers • Log-in to the primary unit using Barracuda NG Admin. • Switch all servers from the primary to the HA unit and verify for correct operability.
Updating NG Control Center Managed Units To make use of the multi-release capabilities of Barracuda NG Control Center, all units within one cluster must run under the same software major release version. Migration of the NG CC configuration is only available for all units, servers and services of a cluster simultaneously. Step 1: Import the Update Package into the NG Control Center •...
Page 19
No more interaction with the unit is necessary. Wait until the update is finished. Depending on the hardware, it will need from 15 minutes on the fastest appliances up to 60 minutes on the flash appliances. Take a look into the box log file at In case of a not succeeded update please consult Box\Release\update_hotfix for a detailed log.
If you are migrating from phion netfence 4.2.x to Barracuda NG Firewall 5.0.3 on standard hardware, you need to apply hotfix 386 before migrating from 4.2.x to 5.0.3 in order to make use of the MAC-to-eth mapping feature that will help you to keep the port labeling as it is.
Updating Standard Hardware from 4.2.x to 5.0.3 General Due to a kernel version change between 4.2.x and 5.0.3 (Linux kernel 2.4 was changed to Linux kernel 2.6), the enumeration of NICs may on some hardware sort the ethX devices in a different order, resulting in a loss of management access.
Page 22
In this case you may disable MAC mapping. This will make the configuration hardware-independent, providing you with more flexibility in case hardware will be changed somewhen in the future. Further advice about updating standard hardware is available through the Barracuda Networks support. 22 Release and Migration Notes - Updating Standard Hardware from 4.2.x to 5.0.3...
