Whittier Wood 1127GACg Assembly Instructions Manual

Whittier Wood 1127GACg Assembly Instructions Manual

11-drawer mckenzie chest; 12-drawer mckenzie dresser; 9-drawer mckenzie dresser; 10-drawer mckenzie dresser

Advertisement

McKenzie Chest &
Dressers
GAC = Glazed Antique Cherry finish
CAF = Caffè finish
Model #
1127GACg;
1127CAFg
9-Drawer
McKenzie Dresser
1181GACg;
1181CAFg
11-Drawer
McKenzie Chest
Thank you for allowing us to help you furnish your
home. We are certain you will be delighted with
your new furniture for many years to come.
If you ever have questions about your furniture, please do not hesitate to contact us. In the unlikely event you need a
replacement part; we can make those parts available through an authorized Whittier Wood Furniture dealer. If you
cannot order replacement parts through your dealer, please contact our customer service department.
Customer Service: 800-653-3336 • Outside the U.S.: 541-687-0213
1128GACg;
1128CAFg
10-Drawer
McKenzie Dresser
1182GACg;
1182CAFg
12-Drawer
McKenzie Dresser
CUSTOMER SERVICE
Hours: Our friendly customer service staff can be reached:
Monday-Friday 8:00 a.m. to 5:00 p.m. (Pacific Time).
You may leave a message 24 hours a day, seven days a week.
Fax: 541-687-2060• Email: info@whittierwood.com
P.O. Box 2827
Eugene, OR 97402 USA

IMPORTANT NOTES:

• For normal household use only. Not recommended for commercial use.
• Do not climb, sit or stand on this piece of furniture.
• Do not overload the drawers.
• Unload items before you move this unit.
• This assembly requires two people.
Serious or fatal crushing injuries can occur from furniture tip-over. Use of
tip-over restraints may only reduce but not eliminate the risk of tip-over.
To help prevent tip-over:
Place heaviest items in the bottom drawers.
Unless specifically designed to accommodate, do not set TVs or other
heavy objects on top of this product.
Never allow children to climb or hang on drawers, doors or shelves.
Never open more than one drawer at a time.
Do not defeat or remove the drawer interlock system.
Warning: At least one tipping restraint kit was included with your piece of
Whittier Wood Furniture. When you receive your furniture, be sure to find
and properly install the tipping restraint(s). If you cannot locate the
restraint(s), please contact us immediately for replacement.
Drilling, sawing, sanding or machining wood products can expose you to
wood dust, a substance known to the state of California to cause cancer.
Avoid inhaling wood dust or use a dust mask or other safeguards for
personal protection.
For more information go to: www.p65warnings.ca.gov/wood
This product can expose you to chemicals, including formaldehyde,
which are known to the State of California to cause cancer.
For more information go to: www.p65warnings.ca.gov/furniture
DESIGN SUBJECT TO CHANGE WITHOUT NOTICE.
Production Code:
VN
WARNING
10/16
