FireMagic Echelon Diamond Quick Start Manual

MUST
YOU
I
ORIENTATION
Familiarize yourself with the thermometer, master switch, meat probe, and default screen.
Menu
button
Light
button
MASTER SWITCH & MEAT PROBE DETAIL
Meat probe plug
1. Master switch must be turned ON for all electrical components on your grill to operate. Turning Master switch off will shut down all electrical components.
2. Pressing any button will turn on the thermometer. Thermometer will automatically shut off after 5 minutes if no temperature change is detected.
3. You must turn thermometer on to turn interior and knob lights on. Automatic thermometer shutdown will not shut off these lights; they must be manually
shut off (via the light button) as instructed in this guide.
II
INTERIOR AND KNOB LIGHTS
MENU
Press ON
1. Turn thermometer On. Press light button to turn
both interior and knob lights On.
III
SET A ZONE AND/OR MEAT PROBE TEMP.
SET ACT
PROBE
05:00
TEMP 170 080
°F ZONE 1 ZONE 2 ZONE
MENU
350 350
SET
078 078
ACT
Select
as desired
(fl ashing)
1. Turn thermometer On. Press down arrow to
desired zone/meat probe area (flashing).
Press SET.
REV 1 - 1601290945
READ THE ORIENTATION SECTION PRIOR TO DIGITAL THERMOMETER OPERATION.
Timer
button
MENU
Meat probe handle
MEAT PROBE
MASTER SWITCH
(must be ON to operate
electrical components)
SET
Press OFF (progressively)
2. Press light button once to turn interior lights off,
and a second time to turn knob lights off.
Current area
3
SET
350
075
Set this
temp. as desired
2. Press up/down arrow to set desired temp.
Then press SET. Screen will return to default screen.
ECHELON DIAMOND THERMOMETER

QUICK START GUIDE

This guide serves as a
information found in your grill main instructions. Read all
instructions completely and carefully prior to product use.
THERMOMETER
This is the
display screen
Meat probe
temp. info
MENU
Cooking zones
temp. info
MENU SET
Use arrows to
ZONE 1
SET TEMP: 350
SET
MENU
ACTUAL: 078
supplement to the thermometer
SET
button for
SET
selecting &
confi rming
DEFAULT SCREEN DETAIL
SET ACT
PROBE
05:00
TEMP
170 080
°F 1 2
ZONE ZONE ZONE
350 350 350
SET
078
078 075
ACT
SET = Desired Cooking Temp.
ACT = Actual Temp. Reading
set temp
PROBE
TEMP 170
°F ZONE
MENU
350
SET
078
ACT
3. Repeat as necessary for all other areas. [Alarm will
sound (if set to do so) when an area's actual temp
reaches its set temp. Press any button to silence.]
Arrows
for adjusting/scrolling
Time set
via Timer
3
SET
SET ACT
05:00
080
1 ZONE 2 ZONE 3
SET
350 350
078 075
L-C2-369
