  • Page 1 SOFTLUX Cool Lights soFtlUX Cool Lights Instruction Manual Lighting Technologies Manual - page 1 I s s u e 0 0 3 Lighting Technologies 1106.04.103 ME 4103...
  • Page 2 SOFTLUX Cool Lights Manual - page 2 I s s u e 0 0 3 Lighting Technologies...

  • Page 3: Table Of Contents

    SOFTLUX Cool Lights Table of Contents Advice before Use General Remarks 1 Setting Up Before Use (All Types) Power Cable Fitting Lamps 2 Accessories (All Types) Barndoors Honeycomb Focus Mesh Polycarbonate Lamp Guard and Colour Frame Pole Operated Yoke 3 Lamp Replacement...

  • Page 4: Advice Before Use

    The luminaire can under no circumstances be modified. ADB will not assume any responsibility in case of damage resulting from modications made to the luminaire. This luminaire is a piece of professional equipment designed for easy and simple use. Nevertheless, always refer to qualified personnel for any installation or repair work.

  • Page 5: Setting Up Before Use (All Types)

    SOFTLUX Cool Lights 1. set Up Before Use 1.1 electrical Connection The luminaire is suitable for operation on standard 50 Hz, 230 V to 250 V star type electrical supplies with Phase, Neutral and Earth connections. It is delivered with a cable HO7-RNF 3 x 1.5 mm...

  • Page 6: Accessories (All Types)

    2.3 polycarbonate lamp Guard and Colour Frame This unit screws into the front face of the Softlux and provides a clear plastic protective cover for the fluorescent tubes. This unit is recommended in studios where pole operated units are in use as poles sometimes slip and could go straight into the tubes.

  • Page 7: Lamp Replacement

    SOFTLUX Cool Lights 3. lamp Replacement iMpoRtAnt A LWAY S I S O L AT E F R O M T H E M A I N S S U P P LY B E F O R E C O M M E N C I N G L A M P R E P L A C E M E N T.

  • Page 8: Specifications

    This loop-through includes continuity of the second data link (pins 4 and 5). Each DMX input to a Softlux unit is optically isolated. The XLR connections are listed below : Pin 1 Cable Drain wire.

  • Page 9: Further Information

    • United States Institute of Theatre Technology DMX512/1990 Lighting Control Protocol. The SOFTLUX range comprises of 2, 4 or 6 tube units in 55 watt versions (other versions on special request). A comprehensive catalogue of further products is available together with a range of accessories and carrying cases for Studio and ENG applications.

  • Page 10: The Full Range

    1075.01.105 soFtlUX linear space lights with 4-leaf black barndoor, 2 m cable, without lamps SOFTLUX 2 x 110W in line - 4 x 55W - 230V DMX/Local Control SLW220/DMX/LC 1075.02.090 SOFTLUX 4 x 110W in line - 8 x 55W - 230V DMX/Local Control SLW440/DMX/LC 1075.02.105...

  • Page 11: Recommended Spare Parts

    SOFTLUX Cool Lights 8. Recommended spare parts description Reference AdB Code 4-leaf reflector barndoor for SL110 SL110/BR 1075.00.180 4-leaf reflector barndoor for SL220 SL220/BR 1075.00.190 4-leaf reflector barndoor for SL330 SL330/BR 1075.00.200 4-leaf reflector barndoor for SL440 SL440/BR 1075.00.400 4-leaf black barndoor for SLW220 SLW220/BR 1075.02.190...

  • Page 12: Photometric Data (Typical Values)

    SOFTLUX Cool Lights 9. photometric data (typical values) sl 110/dMX/lC distance horizontal vertical stUdioline dUlUX/930 84° Beam 42° Beam 3200K • fitted with 2 fluorescent lamps PL55W 5600 5280 Dimensions (A x B x C) 645 x 230 x 605 mm...
  • Page 13 SOFTLUX Cool Lights Notes Manual - page 13 I s s u e 0 0 3 Lighting Technologies...

  • Page 14: Ec Declaration Of Conformity

    SOFTLUX Cool Lights 10. eC declaration of conformity Manual - page 14 I s s u e 0 0 3 Lighting Technologies...
  • Page 15 SOFTLUX Cool Lights Manual - page 15 I s s u e 0 0 3 Lighting Technologies...
