Summary of Contents for Simrad IS40 PRO

  • Page 1 IS40 PRO Operator Manual ENGLISH...
  • Page 3 Navico Holding AS and its subsidiaries, branches and affiliates reserve the right to make changes to specifications without notice. Compliance When IS40 PRO is installed in a network with RF25N or RF70N as Rudder Feedback unit, the system complies with the following regulations: •...
  • Page 4 The Wheelmark The IS40 PRO indicator system is produced and tested in accordance with the European Marine Equipment Directive 96/98. This means that the systems comply with the highest level of tests for nonmilitary marine electronic navigation equipment existing today.
  • Page 5: Table Of Contents

    Contents Basic Operation The IS40 PRO Display Turning the IS40 PRO on and off Display Lighting Missing or faulty data Setting up the Rudder Angle page Optional data pages Customizing a page Setup Sources Device list Remote Displays Calibration Time & Date...
  • Page 6: Basic Operation

    Basic Operation Simrad IS40 PRO is a networked instrument system showing Rudder Angle in the range ±45° or ±70° (setup alternative). The display can also be configured to show up to six additional pages for speed, depth, heading, position, navigational data etc when available on the network.
  • Page 7: Turning The Is40 Pro On And Off

    Turning the IS40 PRO on and off The IS40 PRO has no Power key, and it will be running as long as the power is connected. Display Lighting Press and hold the Enter key for 3 seconds to display the Display Setup dialog.
  • Page 8: Missing Or Faulty Data

    Digital page with missing missing data data out of scale. data Setting up the Rudder Angle page Factory default analog scale for Rudder Angle is ±45°. It can be replaced by ±70° scale as shown below. Basic Operation | IS40 PRO Operator Manual...
  • Page 9: Optional Data Pages

    If a data page has been shown for more than 5 seconds, first press on the Page key will show Rudder Angle page. ¼ Note: Two or more pages need to be enabled for the Page key to function. Basic Operation | IS40 PRO Operator Manual...
  • Page 10 Two line data display. Boat speed and Depth Refresh indicator Boat speed Depth Wind Apparent wind speed (AWS) Refresh indicator True wind speed (TWS) Apparent wind angle (digital) (AWA) Apparent wind angle (analog) True wind angle (TWA) Basic Operation | IS40 PRO Operator Manual...
  • Page 11 Course over ground (COG) Bearing to waypoint indicator Depth History Depth value Refresh indicator Depth graphic You can adjust the time period scale via the Arrow keys. ¼ Note: (Default = 10 min) Basic Operation | IS40 PRO Operator Manual...
  • Page 12 Position source. Highway Estimated time of arrival (ETA) Bearing to waypoint (BTW) Cross track distance (XTD) Distance to waypoint (DTW) Highway graphic Next waypoint Refresh indicator Waypoint name 10 | Basic Operation | IS40 PRO Operator Manual...
  • Page 13 Once selected a tick will appear in the check box. Auto scroll settings In the auto scroll settings menu you can start the auto scroll function and set the time interval between page changes. | 11 Basic Operation | IS40 PRO Operator Manual...
  • Page 14: Customizing A Page

    Analog items display Full screen analog display Four data items Highway graphic Nine data items Select Pages from the main menu. Select one of the predefined pages, then enable the page. 12 | Basic Operation | IS40 PRO Operator Manual...
  • Page 15 Pressing the Up Arrow key scrolls through the available analog scales from 0-5 m through to 0 -200 m. Pressing the Down Arrow key will decrease the analog scale. 0 - 5 m 0 - 200 m | 13 Basic Operation | IS40 PRO Operator Manual...
  • Page 16: Setup

    The operator will be noted when the auto select process is completed. ¼ Note: If more than one source is available on the network, you can chose your preferred source from the sources menu. See Manual source selection. 14 | Setup | IS40 PRO Operator Manual...
  • Page 17: Device List

    For devices of this type you can check the data information, configure and calibrate the device by selecting Options. | 15 Setup | IS40 PRO Operator Manual...
  • Page 18: Remote Displays

    Remote Displays When B&G HV displays are available on the network, they can be configured from the IS40 PRO. Follow the instructions on the screen to get the desired data. Calibration Sensors that can be calibrated are listed in the calibration menu.
  • Page 19 Bring the boat up to cruising speed (above 5 knots). Select Auto on the Boat speed calibration page. When the calibration is completed the Boat speed calibration scale will show the adjusted percentage value of the boat speed. | 17 Setup | IS40 PRO Operator Manual...
  • Page 20 To eliminate the effect of tidal conditions it is advisable to perform at least two runs, preferably three, along the measured course. Enter the desired distance in nautical miles that you would like to calculate the distance reference over. 18 | Setup | IS40 PRO Operator Manual...
  • Page 21 After the last run is completed and OK has been selected, a pop-up warning will ask you if you wish to replace the current calibration with the new one. Select Yes to complete. | 19 Setup | IS40 PRO Operator Manual...
  • Page 22 If a suitable temperature sensor is fitted, the system will monitor the current sea temperature. The offset value to be entered should adjust the temperature reading from the sensor to match a calibrated thermometer when submersed in the water. 20 | Setup | IS40 PRO Operator Manual...
  • Page 23: Time & Date

    From the time and date menu you can set your preferred time/date format and local time offset. ¼ Note: Local time is calculated based on UTC provided via a GPS unit connected to the network. | 21 Setup | IS40 PRO Operator Manual...
  • Page 24: Units

    It is possible to turn on or off background graphics for some pages. Example shown below. Background graphics off Background graphics on ¼ Note: Graphics cannot be individually set on or off for each page. 22 | Setup | IS40 PRO Operator Manual...
  • Page 25: Damping

    Software information Reveals the software you are currently running. See more information on “Software information and upgrade” on page 25. | 23 Setup | IS40 PRO Operator Manual...
  • Page 26: Diagnostics

    We recommend that you use this diagnostic tool as a basic overview of the network status. For more detailed information it is suggested that you check the individual source information via the device list. 24 | Setup | IS40 PRO Operator Manual...
  • Page 27: Maintenance

    Software information and upgrade To find out the latest version of software available for your display, go to the Simrad website pro.simrad-yachting.com To verify what software you are currently running, go to the software information page on your display.
  • Page 28: Specifications

    IEC 60945 protected (IPX5) Protection Safe distance to 0.2 m (0.6 ft) compass Temperature -25 to +55 ºC (-13 to +131 ºF) Dimensions 118 mm (4.65") 17 mm (0.67") 18.9 mm (0.74") 40mm (1.57") 26 | Specifications | IS40 PRO Operator Manual...
  • Page 29: Wiring

    (GPS) Auto scroll Start auto settings scroll (Highway) Scroll time Setup Display setup Lighting zone Select group Night mode Lighting level Standby Remote Displays [List] Calibration Rudder Feedback reference Distance reference [List] | 27 Specifications | IS40 PRO Operator Manual...
  • Page 30 Serial No. Diagnostics [List] Damping [List] Decimal places Speed Sea temp Use COG as heading Use SOG as boat speed Show Graphics Sounds Keypress sound System Network reset Reset to factory Software Information 28 | Specifications | IS40 PRO Operator Manual...
