Westinghouse RTS Series Installation Quick Manual

STEP 1:
DOOR TEMPLATE
1. Fold the template and ensure
it is square to the door.
2. Bore two 3/8" holes through
the door at A.
STEP 3:
UNIT HANDLES
STEP 4:
MOUNTING OUTSIDE UNIT
Outside Outside unit
gasket for for Step 4
Step 4
STEP 2:
1. Using the parts from Bag A,
insert the latch into the hole on
the edge of the door and screw
into place. Make sure that the
center of the spindle hole is in
the center of the drilled 2
1. Align the marks on 2. Attach the outside
the hub as shown in
rubber gasket to the
top image. back of the outdoor
unit.
RTS Series
Installation Quick Guide
LATCH
hole.
1/8"
1. Using the screws from Bag B, install
the handles onto the inside unit and
outside unit based on your right/left
handed configuration.
2. Tighten the handle screw with
a screwdriver, so the handle is firmly
held in place.
3. Feed the outside unit cable
underneath the latch and align
the fixing posts with the two
corresponding holes in the latch.
2. Screw the included strike
plate into the doorjam.
