Page 1
Quick Guide You must read the Usage and Safety Precautions before use. The Operation Manual can be downloaded from the ZOOM website (https://www.zoom.jp/docs/ q2n-4k). This page has files in PDF and ePub formats. The PDF file format is suitable for printing on paper and reading on a computer.
Page 2
HINT • The dedicated AC adapter (ZOOM AD-17) can also be connected to the USB port to use AC power. • When connected to a computer, power can be supplied by USB. Press to turn the power on.
Page 3
Recording Using the Recording Screen The Recording Screen opens when the power is turned on. When recording: recording time Remaining battery charge In recording standby: available recording time VIDEO setting LO CUT setting FOV setting AUDIO setting SCENE setting AUTO GAIN setting Start recording Stop recording (press when recording)
Page 4
Adjusting the audio recording level • Adjusting manually: Turn Adjust so that the level meters are around High −12 dB with the loudest sounds. AUTO GAIN • Adjusting automatically: Turn Setting Explanation This disables automatic level ad- justment. Adjust the recording level manually.
Playing recordings Playing back videos Status indicator Playing : Remaining playback time Paused : Press on the Recording Screen. Remaining Stopped : battery charge The recorded file will start playing. Press to stop playback and re- open the Recording Screen. Playback operations Function Operation...
Setting item list From the Recording Screen, press to open the Setting Screen where you can use the following functions and settings. Page 1 Item Explanation NTSC/PAL This sets the standard recording frame rate used according to the re- gional video format. [NTSC (30 FPS)/PAL (25 FPS)] Beep Set the volume of the sound made when turned on or operated.
Note: card reader and USB mic functions support iOS devices Power 2 AA batteries : alkaline LR6 (1.5 V), nickel metal hydride HR6 (1.2 V) or lithium FR6 (1.5 V) AC adapter (ZOOM AD-17): DC 5 V/1 A Note: USB bus power supported Estimated continuous Video resolution Alkaline LR6 (1.5 V)
Page 8
ZOOM CORPORATION 4-4-3 Kanda-surugadai, Chiyoda-ku, Tokyo 101-0062 Japan http://www.zoom.co.jp Z2I-3395-02...
