TEK-MUHD44TP 4x4 HDBaseT Matrix 1. Description The TEK-MUHD44TP 79055 is a unique 4K 4x4 HDMI matrix switcher with HDBaseT outputs, RS232 and IR control of end-points, and EDID & HDCP management. Included in the unit are IR and RS-232 inserters for the HDBaseT connections, and audio de-embedders with both analog and digital outputs. -
Page 6: Front And Rear Panel Description
4. Front and Rear Panel Description 4.1 Front Panel Operation Name Description ① Firmware Micro USB port for update firmware. Power ② Keep light when power on. Indicator ③ IR Receiver Receive control signal from IR remote. ④ Real-time shows system status. Indicator Normal mode: Input buttons, ranging from "1"... -
Page 7: Rear Panel Operation
HDMI: HDMI output port, connect with HDMI displayers, deliver same input signals with HDBaseT ports, split HDMI output for local monitoring. e. HDBaseT: Works with HDBaseT receivers, such as TPHD402PR. It can extend AV, IR TEKVOX, INC. www.tekvox.com 830.460.9099... -
Page 8: Hdbaset Twisted Pair Cable Connection
and RS232 signal to 70m distance. Meanwhile, it can provide power for the receivers which support PoC. f. AUDIO: HDMI de-embedded stereo audio output Connect with extended IR receiver, ⑤ IR EYE remote control MUH44TPR2-N. ⑥ TCP/IP TCP/IP port for unit control Serial port for unit control, 9-pin ⑦... -
Page 9: System Diagram
TEK-MUHD44TP 4x4 HDBaseT Matrix 5. System Diagram TEKVOX, INC. www.tekvox.com 830.460.9099... -
Page 10: System Operation
6. System Operation 6.1 Front Panel Button Control Front Panel Button Control MUH44TPR2-N provides with convenient front panel button control. Here we make a brief introduction to the system operations. Switching I/O connection To convert one input to an output: Operation: “input”+“output”+“ENTER”... - Page 11 4th EDID data Note: If the conversion is successful, indicators of the pressed buttons will blink green for three times at normal speed; if the conversion failed, they will blink for three times quickly. TEKVOX, INC. www.tekvox.com 830.460.9099...
-
Page 12: Inquiry
Inquiry Check status Press and hold the button “ENTER” for 3 seconds, it will enter into system inquiry menu. Use Left and Right direction button to navigate checking the previous/next items. Function Example Description Items Check means connection corresponding port is status connected with input inputs... -
Page 13: Ir Control
5 embedded EDID data Note: With this IR remote, MUH44TPR2-N can be controlled by the built-in IR, the extended IR receiver connected to the “IR EYE”/”IR ALL IN” and the IR receiver on the far-end receiver. TEKVOX, INC. www.tekvox.com 830.460.9099... -
Page 14: Ir Operations
6.2.2 IR Operations Force Carrier Only if the IR receiver connected to HDBaseT receiver is with IR carrier, can the received IR signal be transferred to IR OUT port of the matrix. Only if the IR receiver connected to IR ALL IN port of the matrix is with IR carrier, can the received IR signal be transferred to IR OUT port of the matrix. -
Page 15: Control Local Device Remotely
Corresponding to the zone (receive IR signal from HDBaseT receiver with IR IN port connects with IR receiver) number of MUH44TPR2-N. Example: Send command “3R2.” to transfer IR signal received from zone 2 to IR OUT port 3. TEKVOX, INC. www.tekvox.com 830.460.9099... -
Page 16: Rs232 Control
RS232 Control Connection with RS232 Communication Port The MUH44TPR2-N can be controlled by far-end control system through the RS232 communication port. You cannot type in the commands using HyperTerminal or PuTTy. They must be entered using a program like Hercules, where the command is sent by the computer. This RS232 communication port is a female 9-pin D connector. -
Page 17: Installation/Uninstallation Of Rs232 Control Software
Control 3rd party device from remote Installation/uninstallation of RS232 Control Software Installation Copy the control software file to the computer connected with MUH44TPR2-N. Uninstallation Delete all the control software files in corresponding file path. TEKVOX, INC. www.tekvox.com 830.460.9099... -
Page 18: Rs-232 Control
6.3 RS-232 Control These same commands are used for IP communication. Communication protocol: Baud rate: 9600 Data bit: 8 Stop bit: 1 Parity bit: none Connector type: DB9 FM (Use Straight through cable) 6.3.1 Commands Command Function Feedback Example System Commands /*Type;... - Page 19 A & E are for port 1. B & F are for port 2. C & G are for port 3. D & H are for port 4. X is for baud rate, its value ranges from 1 to 7 (1--2400, 2-- TEKVOX, INC. www.tekvox.com 830.460.9099...
- Page 20 Command Function Feedback Example 4800, 3--9600, 4--19200, 5--38400, 6—57600, 7--115200) ***** is for data (max 48 Byte) Input port [y] learns the EDID from output port [x]. If the EDID data is available and the audio part EDIDH[x]B[y]. supports not only PCM mode, then force-set it to EDIDH[x]B[y] support PCM mode only.
- Page 21 2. In above commands, “[”and “]” are symbols for easy reading and do not need to be typed in actual operation. 3. Please remember to end the commands with the ending symbols “.” and “;”. 4. Commands are case-sensitive. TEKVOX, INC. www.tekvox.com 830.460.9099...
-
Page 22: Tcp/Ip Operation - Optional
6.4 TCP/IP Operation - Optional The optional network port of TEK-MUHD44TP is used for sending commands using TCP/IP control. These commands are sent the same as when using RS-232 control at TCP/IP port 4001. There is no Web based control for the unit. The Web interface is used for network configuration only. 6.5 IP Configuration To connect a computer to the network port you must use a crossover network cable or network switch. -
Page 23: Gui For Tcp/Ip Control
Users: Display or modify credential settings, front panel lock, and GUI version. If there is any modification, press Save to restore the settings, or press Cancel to withdraw. Interface: Set title bar label, LCD readout, and button labels, press Save to save the settings TEKVOX, INC. www.tekvox.com 830.460.9099... -
Page 24: Gui Update
Configuration: Set HDCP Compliance status for every input, and manage EDID. See the screenshot below: Network: Inquire and configure network settings including MAC address, IP address, subnet mask, and Gateway Note: Log in as user access main interface only. GUI Update GUI for MUH44TPR2-N supports online update in . -
Page 25: Firmware Updating
Connect a Micro USB, like the one for a Samsung Smartphone, to the front of the unit and cycle power. Click on Open and select the firmware file and then press Connect USB. If the USB connection is successful, press the update button. TEKVOX, INC. www.tekvox.com 830.460.9099... -
Page 26: Technical Specification
8. Technical Specification Video Input Video Output 2 HDMI Input 4 HDMI Output 4 HDBaseT Input Female Output Female HDMI Connector HDMI Connector Female RJ45(with LED indicators) T.M.D.S. Input Level Output Level T.M.D.S. 2.9V/3.3V 2.9V/3.3V Input 100Ω Output 100Ω (Differential) Impedance (Differential) Impedance... -
