R e s p i r a t o r F i t T e s t i n g Model 8095 N-95-Companion to the ® Plus ORTA OUNT Operation and Service Manual 1980308, Revision H August 2005...
Page 3
Model 8095 ™ N95-Companion to the ® ORTA OUNT Operation and Service Manual August 2005 P/N 1980308 Rev. H SHIP/MAIL TO: E-mail address: TSI Incorporated answers@tsi.com 500 Cardigan Road Shoreview, MN 55126-3996 Web site: http://www.tsi.com U.S. INTERNATIONAL Sales and Customer Service: Sales and Customer Service: (800) 874-2811/(651) 490-2811 (001 651) 490-2811...
CONTENTS Safety Information ................iii Chapters 1. Unpacking and Parts Identification ........... 1 Unpacking the N95-Companion Kit ..........1 Parts Identification for the N95-Companion ........2 Replacement Parts and Supplies..........6 2. Setting Up the Model 8095 N95-Companion......7 Introduction..................7 Selecting a Fit Testing Location ............
Page 6
Visit the TSI web site at www.tsi.com. Click on Find a Product by Product Group and select Respirator Fit Testers on the TSI homepage.
SAFETY INFORMATION Although the supply voltage to the Model 8095 N95-Companion is low- voltage, the instrument contains an internal high-voltage converter. To minimize the danger of shock, always unplug the instrument before removing the cover for maintenance or replacement of parts. Internal High Voltage Warning Label Warning Labels on bottom of N95-Companion...
Chapter 1 Unpacking and Parts Identification Unpacking the N95-Companion Kit Carefully unpack the Model 8095 N95-Companion and accessories from the carrying case. Use the tables and illustrations below to make certain that there are no missing components. Contact TSI immediately if anything is missing or damaged.
Parts Identification for the N95-Companion Figures 1-1 through 1-9 identify the parts of the Model 8095 N95-Companion. Please become familiar with these components before proceeding. ORTA OUNT Plus Neck Strap Sampling N95-Companion Pendant N95- Companion Interconnect Tube Water Trap Pendant Pendant Sample Tube Interconnect...
Page 11
Port to Port and ORTA OUNT Connector to Plus Sampling Pendant Figure 1-2 Model 8095 N95-Companion–Top Front View Particle Classifier Connector for Check Factory Use Button Only Connector to ORTA OUNT Figure 1-3: Model 8095 N95-Companion–Top Back View Unpacking and Parts Identification...
Page 12
Figure 1-4: Model 8095 N95-Companion–Bottom View Figure 1-5: Model 8026 Particle Generator Chapter 1...
Page 13
Figure 1-6: Sampling Pendant Probe Insertion Sampling Tools Probes Push Nuts Figure 1-7: N95 Probe Insertion Kit Unpacking and Parts Identification...
Pendant Interconnect Tube Pendant Sample Tube N95-Companion Interconnect Tube N95-Companion Interconnect Figure 1-8: Tubes and Cables Cable Figure 1-9: Salt Tablets Replacement Parts and Supplies The following items are sold by TSI as replacement parts and supplies for the Model 8095 N95-Companion. Table 1-2: Replacement Parts and Supplies Quantity Item Description...
Chapter 2 Setting Up the Model 8095 N95-Companion Introduction Before you can begin fit testing with the P Plus and ORTA OUNT N95-Companion, you must: • Select a fit testing location • Set up the particle generator • Set up the instrument •...
Setting up the Model 8026 Particle Generator The purpose of the particle generator is to supplement the naturally occurring particles in the room environment. The N95-Companion requires a minimum count of 70 particles/cc to operate. The target is 100 to 300 particles/cc for optimal performance.
You can save and reuse the solution if you wish. However, do not mix old solution with fresh solution. If you need to mix new solution, first discard whatever remains in the reservoir. If you wish to reuse solution, be sure to detach the reservoir from the generator, cover it tightly with the temporary cover, and store it in its designated space inside the carrying case.
Page 18
Pendant Sample Tube Pendant Interconnect Tube 3. Attach the pendant interconnect tube to the sampling pendant. 4. Attach the water trap, using the supplied short tubing, to the N95-Companion sampling port. This is the left-most barbed fitting on the front of the N95-Companion. 5.
Page 19
7. Connect the N95-Companion to P Plus interconnect tube ORTA OUNT between the N95-Companion output (the right-most barbed fitting on the front of the unit) and the P Plus sample input (marked ORTA OUNT "S" on the front of the P Plus).
Installing the Probe 1. Select the mask you wish to test. 2. Slide the sampling probe onto the piercing tool. As the pointed end of the piercing tool is very sharp, be extremely careful when handling it! Sampling Probe 3. Choose a location on the mask that is in front of the person's nose/mouth region.
Page 21
5. Push the sampling probe through the mask until the end of the tool point is visible from the outside of the mask. Leave a few millimeters of the tool point visible. 6. Place the push nut on the anvil tool with the "dished" side up. A magnet prevents the push nut from falling off.
Correctly Positioned Sampling Probe Note: Once you install a sampling probe into a disposable mask, the mask cannot be used for respiratory protection. Probed masks are to be used for quantitative fit testing only. Discard each probed disposable mask after a fit test is completed. Switching the Hardware Configuration from the N95-Companion to the P Plus...
Page 23
Note: If the P is turned on when the cable is disconnected, the ORTA OUNT screen will go blank for several seconds, and then turn ORTA OUNT back on. This is normal. The P detects that the N95- ORTA OUNT Companion is no longer connected and resets itself with new timing parameters.
Page 24
4. If desired, detach the P from the N95-Companion. Using ORTA OUNT your thumbs, pull outward on the two spring clips located on the base of the P , while gently lifting the P ORTA OUNT ORTA OUNT 5. Attach the standard P twin-tube assembly to the blue and ORTA OUNT...
Chapter 3 Fit Testing with the N95-Companion and the Plus ORTA OUNT Introduction Before you begin fit testing, during the time the particle generator is stabilizing the room environment, turn on the P Plus and allow ORTA OUNT it to warm up. Be sure to perform the daily checks! Refer to Chapter 4, Maintenance, for daily check instructions.
Page 26
3. Have the subject don the mask without assistance. Fit test results depend on the subject knowing how to properly don the mask. All subjects should be trained in proper mask-donning techniques before being fit tested. Do not allow the subject to adjust the mask during the exercises, as this invalidates previous results.
Page 27
5. Have the test subject follow the exercises one after another when prompted by the software. Each exercise takes approximately 90 seconds to complete. When the test is complete, the overall fit factor is displayed on the screen. 6. Review the results. If the fit test passed, issue that exact size and model respirator to the test subject.
Chapter 4 Maintenance Overview The N95-Companion and P Plus both require daily and periodic ORTA OUNT maintenance. Refer to the P Plus Operation and Service Manual ORTA OUNT for P Plus maintenance information. The N95-Companion ORTA OUNT maintenance information appears below. Daily Checks The daily checks are designed to determine if the instrument is working properly.
Page 30
Performing the Classifier Check After you perform the particle check with the P Plus ORTA OUNT still in the count mode, press and hold the classifier check button on the back of the N95-Companion for a minimum of 15 seconds. This disables power to the particle classifier.
Performing the Maximum Fit Factor Check Make sure all previous checks have been completed successfully before proceeding. Put the P into fit test mode. If the small HEPA filter ORTA OUNT supplied with the P is not already attached to the ORTA OUNT sample hose coming out of the sampling pendant, attach it now.
Page 32
Pendant Switching Valve To perform the purging procedure, you will need these tools and supplies: • Small dish or cup of warm water • TSI purge kit 1. Assembling the valve purge kit: • Remove the cover from the syringe tip. •...
Page 33
3. Preparing the fully assembled N95-Companion for the purge procedure: • Disconnect the main air sample tube. Disconnect 4. To purge the mask sample side (silver connector), do the following: • Connect the valve purge syringe to the (now available) sample connector.
Page 34
5. To purge the ambient side (blue connector), do the following: • Refill the valve purge syringe with warm water and reconnect it to the pendant as before. • Turn on the P and N95-Companion. ORTA OUNT • After the P has completed the initial ORTA OUNT...
Page 35
6. Clear the remaining moisture out of both sample sides with forced air: • The mask sample side can be done with the P ORTA OUNT and N95-Companion turned off. • The ambient side must be done in the same sequence as described in step 5 for purging the valve.
Page 36
The transparent cover on the water trap allows you to visually inspect the condition of the sponge and the trap's interior. If you wish to clean the interior or clean/replace the sponge: 1. Remove the two screws that hold the cover in place and remove the cover, along with the gasket.
Page 37
Note: The technician attempting this procedure must take special care to make certain that none of the internal tubes become pinched or blocked when the unit is reassembled. Pinched tubing is a common problem that will prevent the instrument from working properly after this procedure is completed. W A R N I N G Be sure to disconnect the power supply before beginning this procedure to avoid the risk of electric...
Page 38
4. Remove the silicone tubing from the top of the particle classifier. Silicone Tubing 5. With the clear tubing still attached, rotate the top housing up and out, to expose the inside of the particle classifier. Inside of the Particle Classifier Chapter 4...
Page 39
6. Using a damp (not wet) lint-free cloth, gently wipe off the interior surfaces of the classifier, removing the accumulated dust particles. Clean Both Surfaces 7. Make sure the O-ring is properly positioned in the lower housing groove. O-ring in Proper Position Maintenance...
Page 40
8. Rotate the upper housing back into position. Note the correct orientation below. Correct Position of Upper Housing 9. Replace the three thumbscrew clamps in the original locations. Do not overtighten! (See step #2 for picture.) 10. Continue to tighten the thumbscrews, in sequence, until they are finger-tight.
Chapter 5 Troubleshooting This chapter describes the symptoms, possible causes and recommended solutions for common problems encountered with the N95-Companion. Always perform the daily checks, described in Chapter 4, “Maintenance,” before you begin troubleshooting. This will help you to detect most problems quickly.
Page 42
Symptom Possible Cause Corrective Action Low particle The atomizer head on the Clean the atomizer head. counts particle generator is Refer to the maintenance (cont.) clogged. procedure in the Model 8026 Particle Generator Operation and Service Manual. ______________________ ______________________ The salt solution is mixed Refer to the mixing incorrectly.
Page 43
Symptom Possible Cause Corrective Action Leak in the flow system. If you recently cleaned the Zero count above 1.2 particles/cc particle classifier, verify that the O-ring is in place and the tubing is connected correctly. ______________________ ______________________ Leak in water trap. Tighten screw and fittings.
Appendix A Specifications The Model 8095 N95-Companion specifications, when it is used with the Model 8020 P Plus, are as follows. Specifications are subject to ORTA OUNT change without notice. Size 9.5 in. x 7.5 in. x 2.3 in. (24 cm x 19 cm x 6 cm) 2 lbs.
