George Home Wooden light & sounds train set Assembly Manual

Wooden light & sounds train
Assembly Guide
IMPORTANT: RETAIN FOR FUTURE REFERENCE
WARNINGS:
• IMPORTANT SAFETY INSTRUCTIONS
• PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE
USE AND RETAIN FOR FUTURE REFERENCE.
• Adult assembly required.
• The hardware contains small screws with sharp points. Keep
unassembled parts out of the reach of small children.
• WARNING! Not suitable for children under the age of 36
months. Components of this product may break off into small
parts presenting a choking hazard.
• Choking hazard: Unassembled parts may be a choking hazard
to children 3 years and younger.
• To avoid the danger of suffocation, keep any bags or
packaging away from babies and children. Any packaging
or bags are not part of the toy and must be disposed of
immediately before assembling the toy.
You will need...
Cross head / Phillips
screwdrivers suitable
for use with the screws
and bolts provided.

Getting started...

1. Unpack the 2. Place the 3. After you have
components and components on assembled your
check against the a clean surface toy, dispose of all
list below. to prevent them packaging.
from being
damaged.
Wooden Train Station.indd 1
Using barrel nuts and long bolts
Unscrew the barrel nuts from the long bolts before beginning
assembly.
Slot the barrel nuts (C) into the larger holes in the panels (B & E),
ensure the slot in the top of the barrel nut is facing outwards so
you can rotate it with a screwdriver if needed.
Align the holes in all of the components then slot the bolts (D)
through the holes (2). Tighten the bolts into the barrel nuts using
a cross-head screwdriver.
1
You will have...
A x1 B x1
set
C x8
D x8
E x1 F x1
G x2 H x1
I x2 J x1
Step 1
A
Attach side (A) to
the base (B) using
D
two barrel nuts (C)
and four bolts (D).
Slot the barrel
nuts into the holes
in the base. Slot
the bolts through
the holes in the
2
side panel and
tighten into the
barrel nuts using a
screwdriver.
Step 2
Attach the front
panel (E) to the
attached side
panel using two
barrel nuts (C),
two bolts ( D) and
a screwdriver.
G
Step 3
Attach the handle
(F) to the side
panel using one of
the screws (G) and
a screwdriver.
Step 4
Attach the left side
panel (H) onto
the assembled
sections using four
barrel nuts (C) and
four bolts (D).
IMPORTANT: Do
not fully tighten
the bolts. Only half
tighten the bolts at
this stage.
H
C
Step 5
Slot the tabs
on the two roof
panels (I) into the
slots in the side
panels. Also insert
the tops of the
roof panels into
the grooves in the
I
handle.
B
Step 6
Fasten the handle
to the top of the
E
side panel using
the remaining
screw (G).
IMPORTANT:
Fully tight the four
bolts.
Using with the
train track
If you are going
F
to use the station
with the train
track, insert the
back panel (J) into
the slots in the
sides of the station
as shown. Push
the panel along
the slots until the
bottom edge is
against the front
panel.
J
Using the
station for
storage
Remove the back
panel (J) from the
station.
Place all of
the track and
accessories in the
station and slide
the back panel (J)
into the grooves in
the side panels as
shown.
I
G
