Summary of Contents for Questyle Audio Super Hub SHB2
- Page 1 Super Hub SHB2 Super Hub SHB2 Master 用户手册 www.questyle.com...
-
Page 2: Table Of Contents
........... Getting System Started ..............5G Wireless Pairing ..............PC System Requirements ............Install Super Hub SHB2 Driver on Windows OS ......Core Audio Stream Introduction ........... Setup Core Audio Stream on JRiver Media Center ...... True DSD Technology .............. -
Page 3: About Super Hub Shb2
SHB2 Master. The SHB2 Master has a “MASTER” laser marking, and it features the ROGERS Ceramic PCB and selected components to ensure the Super Hub SHB2 is easy to use. It can match with various audio equipment and bring ultimate performance on sound quality and specifications. -
Page 4: Front View
If the indicator flashes quickly with red light, it means the system is in malfunction OLED display: and you need to power off the Super Hub SHB2 and restart it. If the problem is not OLED display solved, you have to contact your dealer or the After-Sales Support ③ Remote Control signal receiving zone... -
Page 5: Rear View
Rear View Bottom View ① Pre-amp right channel balanced output ② Pre-amp left channel unbalanced output ③ Pre-amp right channel unbalanced output ④ Pre-amp left channel balanced output ⑤ Left channel unbalanced input ⑥ Right channel unbalanced input ① 5G Wireless Pairing button: it is used to pair the SHB2 with a Questyle 5G ⑦ AES/EBU output ⑧ S/PDIF input wireless receiver. -
Page 6: How To Match With Super Hub Shb2
How to Match with Super Hub SHB2 1. Digital Input Super Hub SHB2 has OPT, S/PDIF, AES/EBU and USB inputs. Digital audio System and Volume Control Buttons signals from your PC, music server, CD or Blu-ray can be sent to the SHB2 via those interfaces. - Page 7 3. Used as a DAC/Pre-amplifier Super Hub SHB2 supports Linix system and Windows USB Audio Class 2.0 Super Hub SHB2 can be used as a DAC/Pre-amplifier to drive various active standard driver, it can be connected to music servers and used as a DAC.
-
Page 8: Getting System Started
Super Hub SHB2 can output digital signals. Just connect the digital output of SHB2 to the input of a DAC and it will work. When you power on the Super Hub SHB2, it starts with the Power indicator flashing quickly and the OLED display showing a startup picture. It completes the startup and starts to work when the Power indicator stays light on and the OLED display shows the volume, sample rate and input mode. -
Page 9: Pc System Requirements
“Super Hub SHB2 Driver/For Windows 7, 8, 8.1 and 10/” and then 3) File Format double click “Setup.exe”. File format is up to the media player on your PC. Super Hub SHB2 can decode any file format that the media player supports. 4) Requirements for PC Configuration At least one USB port is required. - Page 10 Installation is completed, click “Next” Click “Install” (Default install location is C drive) Click “Finish” to exit the installation Installation will take 3 or 5 minutes 5) Restart your PC and the CMA Twelve Driver is finished installation; 6) Installation on Win XP, Vista is similar to the above.
-
Page 11: Core Audio Stream Introduction
JRiver), you can't control the volume through system controller, the sound from the system or any other application will not be heard at the Super Hub SHB2 output, which is because the system has opened the Core Audio Stream channel for CMA Twelve and the audio data directly get to the DAC of Super Hub SHB2 with high-speed. - Page 12 2) Click “Add”-“Browse”, III JRiver Output Setup select the folder that 1) Click “Tools” and select “Options”; contains songs, and then click “OK”-“Finish”. 2) Select “Audio Device” under “Options”, and click ”Questyle ASIO Driver[ASIO]” and select “Default Audio Device”, and then click “OK”.
-
Page 13: Setup Dsd On Jriver Media Center
Nothing is better than the true. The True DSD technology is one of the core patent- ed technologies of Questyle Audio. It processes DSD signals without any PCM converting and provides True DSD, which is fundamentally different from DoP and Native DSD. - Page 14 7) Select “Custom” under “Bitstreaming: Yes(DSD) ” 6) Click “DSP & output format” under “Settings”. Make sure nothing on the left row is ticked. (To wit: without any processing to DSD data, ensuring original sound.) 8) Tick “DSD” and then click “OK”.
-
Page 15: Install Foobar2000
Save and exit. The setup is completed. You will get 5 files after the above download (as shown below): 9) With a song playing, put the mouse pointer at where the arrow is pointing to view current input and output. After the unzipping, you will see the following: Install Foobar2000 Foobar2000 is a free and multifunctional audio player as well as a powerful tool for... - Page 16 3. Select “Standard installation”. II Install Foobar2000 V1.3.9 4. Click “Next” to choose Foobar2000 install location. (Default install location is C drive) 1. Double click to install Foobar2000, and then click “Next”. 5. Click “Next”. 2. Click “I Agree”.
- Page 17 6. Click “Install”. (Default installation of all the components) 7. Click “Finish” and run Foobar2000. III Install Plugins 1. Install plugins according to the following steps highlighted from 1 to 8.
- Page 19 2. Restart Foobar2000 and go to the install location to confirm that the three plugins highlighted in the following figure are installed successfully. If so, you will see two more options on the left of the interface. (as shown in the figure below) These two plugins are needed for playing DSD files.
- Page 20 IV Setup the Software 2. In addition, installing plugins for Core Audio Stream channel requires copying the 1. Connect your CMA Twelve to a PC with a USB cable and finish the software “foo_out_ks.dll” (highlighted in the figure below) to “components” under installation setup according to the following steps highlighted from 1 to 9.
-
Page 21: Setup On Mac Osx
When you see the following interface after going to “System Prefer- With USB, S/PDIF, Optical or Analog signals input, or in ences”-“Sound”(as shown below), your Super Hub SHB2 is ready to work. Digital Source+5GHz Wireless Hub mode, it supports communicating with Questyle’s Transmission Mode 5G Wireless receivers via 5G Wireless Transmission. - Page 22 FCC STATEMENT 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
