I N S TALL ATI ON GU I D E
Wa l l - M ou n t e d I n s t a l l a t i o n
AeroVironment EV Solutions™ TurboDock™ Charging Station
Important: Installation should be completed by a licensed,
qualified electrician. Installation must comply with the
provisions of the National Electric Code (NEC) and all
local codes. In cases of conflict between local codes and
the NEC, local codes shall take precedence. Verify with
authority having jurisdiction.
Model TurboDock
NOTICE TO ELECTRICIAN: Leave this Installation Guide with the TurboDock
