- Page 1 Made in the USA since 1940 Esteam ® and J-Series OWNER’S MANUAL PRINTED IN THE USA FORM #5500B - REVISION 18 © Copyright 2016 Printed on Post-Consumer Recycled Paper...
-
Page 2: Table Of Contents
Table of Contents Made in the USA Since 1940 Safety Instructions ..............3 How to Steam................4 Esteam Hand Held Steamer ..........5-8 ® Jiffy Steamer Accessories ............9 Model J-1 & J-2 Jiffy Steamers ........10-15 ® Model J-2000 Jiffy Steamer ..........16-21 ® Model J-4000 Pro-Line Jiffy Steamer ......22-27... -
Page 3: Safety Instructions
Important Jiffy Steamer Safety Instructions ® When using your Jiffy Steamer, basic precautions should always ® be followed, including the following: 1. WARNING! Read all instructions prior to usage. 2. To reduce the risk of contact with hot water emitting from steam vents, check appliance before each use by holding it away from body and operating. -
Page 4: How To Steam
How to Steam As your dry cleaner knows, steam is the gentlest, safest, most efficient method to remove wrinkles. Not only is steaming five times faster than ironing, it is guaranteed not to scorch even the most delicate materials and fabrics. Our steamers will remove wrinkles from clothing, drapery, tablecloths...virtually any fabric. - Page 5 Never overfill. Never use water left overnight in steamer. Stale water causes foaming action and can create water droplets. If you start to see scale buildup in the water cup of your ESTEAM, it is time to clean it with our Jiffy Steamer Liquid Cleaner. Not doing so, could alter the performance of the unit.
- Page 6 Esteam Parts Diagram ®...
- Page 7 Liquid Cleaner - 3 Ten (10) Ounce Bottles per Package* 0899 *Not Available for Export. ESTEAM Steam Caps with Face Plates and Case Halves are Available in Black or Pink. Please specify color when ordering. If you donʼt see the part you need, please contact us.
-
Page 8: Esteam Hand Held Steamer
Esteam Cleaning Instructions ® Once you begin to see calcium scale collect in the bottom of your ESTEAM hand steamer, it is time ® to use the Jiffy Steamer Liquid ® Cleaner. It is important that you use our cleaner as it was specially formulated for our products. - Page 9 Keep your conventions. Never be without your Jiffy clothing and upholstery looking their best Steamer again! The Jiffy Steamer Travel Case with this handy brush. is constructed with the finest materials to Jiffy Steamer insure the protection of your steamer.
- Page 10 Jiffy J-1 and J-2 Model Steamer ® FEATURES • Cast aluminum housing for durability (Models J-1 and J-2) • Lightweight, flexible hose - Models J-2 (J-1 series utilizes a brass hat nozzle) • Shatterproof water bottle • Safety wiring feature temporarily turns the unit off if it accidentally runs dry •...
- Page 11 Jiffy J-1 and J-2 Model Steamer Directions ® 1. For J-2 models, attach hose firmly with included assembly wrench, which is magnetized and located on the bottom of the unit (figure #1). Assemble and attach hose hanger rod set. For J-1 models, the brass hat nozzle should already be attached.
-
Page 12: Jiffy Steamer Accessories
Steamer, you may ® purchase them separately. Use this handy diagram and parts list to identify any part you may need. Please include model and serial number when ordering. Jiffy Steamer Key# Part # Part Description Rod Set and Nut Complete with Metal Studs... - Page 13 0009 Screws for Bottom Plate (4 Screws Total) 0011 0010 “I” Kit - 5.5ʼ Hose with Four Attachments ACCESSORIES Jiffy Steamer Assembly Wrench 1026 Brass Hat Nozzle Attachment 1050 Metal Head/Wood Handle Hose Attachment Complete 0274 Metal Head / Wood Handle Only...
-
Page 14: Steamer
Jiffy J-1 and J-2 Wiring Diagram ® Caution: Insure that the power cord is Orange unplugged from the electrical White Yellow outlet before attempting to repair your Jiffy Steamer. ® Black from Cordset White Green L-290 Thermostat Yellow Wire Orange Fusible Link Brass Heating Unit... - Page 15 J-1 and J-2 Wiring Instructions ® Before attempting any repair on a Jiffy Steamer product, make sure that it is unplugged from the outlet. If you have any questions, please contact our repair department at 1-800-525-4339 between 7:30 AM - 4:00 PM Central Standard Time.
- Page 16 Jiffy J-2000 Model Steamer ® FEATURES • Polymer outer housing unit for durability • Lightweight, flexible hose • Shatterproof water caddy • Safety wiring feature temporarily turns the unit off should it accidentally run dry • Comfortable, easy-to-grip handle • Removes wrinkles up to five times faster than conventional ironing •...
- Page 17 Jiffy J-2000 Directions ® 1. Attach hose firmly with included assembly wrench, which is magnetized and located on the bottom of the unit. Assemble and attach hose hanger rod set. Every Jiffy® Steamer has been factory tested and it is not uncommon for small amounts of water to be in the unit.
- Page 18 Jiffy J-2000 Parts Diagram ® Should you ever need replacement parts for your Jiffy Steamer, you may ® purchase them separately. Use this handy diagram and parts list to identify any part you may need. Please include model and serial number when ordering.
- Page 19 1120 Screws for Bottom Plate (4 Screws Total) 0011 1114 “I” Kit - 5.5ʼ Hose with Four Attachments ACCESSORIES Jiffy Steamer Assembly Wrench 1026 Metal Head/Wood Handle Hose Attachment Complete 1050 Metal Head / Wood Handle Only 0254 Replacement Wooden Handle (for Metal Steam Heads)
-
Page 20: Steamers
Jiffy J-2000 Wiring Diagram ® Orange Caution: White Insure that the power cord is Yellow unplugged from the electrical outlet before attempting to repair your Jiffy Steamer. ® Black from Cordset White Green L-290 Thermostat Orange Fusible Link Yellow Wire Blue Wire Brass Heating Unit... - Page 21 J-2000 Wiring Instructions ® Before attempting any repair on a Jiffy Steamer product, make sure that it is unplugged from the outlet. If you have any questions, please contact our repair department at 1-800-525-4339 between 7:30 AM - 4:00 PM Central Standard Time.
- Page 22 Jiffy J-4000 Pro-Line Model Steamer ® FEATURES • Built-in, easy-to-read sight gauge which indicates water level and sediment build-up. • Cast aluminum housing unit for durability • Corrosion-proof stainless steel boiler tank--no water lines to become clogged with hard water deposits •...
- Page 23 If so, straighten out the hose. If the escaping steam does not cease, please contact Jiffy Steamer at 731-885-6690. Plug into proper voltage outlet, turn switch to “STEAM”. It will take approximately 16 minutes for the unit to reach full steam.
- Page 24 Steamer, you may ® purchase them separately. Use this handy diagram and parts list to identify any part you may need. Please include model and serial number when ordering. Jiffy Steamer Key# Part # Part Description Rod Set and Nut Complete with Metal Studs...
- Page 25 “I” Kit - 5.5ʼ Hose with Four Interchangeable Steam HeadAttachments “I” Kit - 7.5ʼ Hose with Four Interchangeable Steam HeadAttachments 1026 1027 Jiffy Steamer Assembly Wrench Auto Hose Attachment with Dual Metal Heads 1050 Carpet Hose Attachment with 12” wide Metal Head 0259 7.5ʼ...
- Page 26 Jiffy J-4000 Wiring Diagram ® Caution: Insure that the power cord is unplugged from the electrical outlet before attempting to repair your Jiffy Steamer. ®...
- Page 27 Jiffy J-4000 Wiring Instructions ® Please note, the switch terminal numbers and the switch terminal letters are marked on the actual switch. 1. Positive black (1) (brown for 230 volt units) to A on switch. 2. Neutral white to (2) brown fuse wire (4) (blue for 230 volt units). 3.
- Page 28 Jiffy J-1, J-2 and J-2000 Cleaning Instructions. ® The cleaning procedure below is recommended as a regular maintenance measure to help your steamer maintain its maximum steaming performance. This maintenance should be performed on a basis of every 3-6 months depending on your water supply.
- Page 29 Jiffy J-4000 Cleaning Instructions ® The cleaning procedure below is recommended as a regular maintenance measure to help your steamer maintain its maximum steaming performance. This maintenance should be performed on a basis of every 3-6 months depending on your water supply. In most cases, a steamer that is severely clogged will require disassembly to properly clean and prolong the life span of the unit.
-
Page 30: Jiffy Steamer Maintenance
Jiffy Steamer Maintenance ® Clean and rinse your steamer regularly: All steamers need to be cleaned and rinsed on occasion to remove mineral deposits. We recommend our Jiffy Steamer Liquid Cleaner for cleaning internal parts. ® Never use additives: Additives such as salt, vinegar, bleach, perfumes and dyes should never be added to your steamer water. -
Page 31: Steamer Accessories
Steamer Accessories ® Esteam Converter & Adapter Plugs ® Take your Esteam worldwide and use it at 100% power. ® Our converter contains a 25 amp triac semiconductor for stable power output, large aluminum heat-sink to dissipate heat and a UL listed, flame retarding, non-conductive material used in the outer housing. -
Page 32: Jiffy
Jiffy Steamer Head Configurations ® Optional Steam Head Configurations Configuration #1 Standard Plastic Steam Head Available on the J-2 , J-2000 ® ® J-4000 and J-4000D Model ® ® steamers. Configuration #2 Metal Steam Head with Wooden Handle Available on the J-2M , J-2000M , J- ®... - Page 33 230V BS 546 230V PLUG #1 or 230V PLUG #3 PLUG #4 PLUG #2 Not available on the J-4000 ® Series. Not available on the ESTEAM Series. ® BS 1363 230V ETSA S/86 230V SI 32 230V 620-P 230V PLUG #5...
-
Page 34: Troubleshooting
Jiffy Steamer Troubleshooting ® Esteam ® PROBLEM POSSIBLE CAUSE SOLUTION The unit has sediment build-up and needs a thorough Use Jiffy Liquid Cleaner to clean off element. A ® cleaning. small brush may be needed to help scrub unit. Steamer works poorly or cycles ON and OFF while Replace thermostat on unit. - Page 35 Jiffy Steamer Troubleshooting ® J-4000 Model PROBLEM POSSIBLE CAUSE SOLUTION The heating element may be bad. Replace the heating element and reseal the tank assembly with high temperature silicone. The red indicator light Thermostat may be bad. Replace thermostat. remains ON for over 20 minutes, but no steam is Check water level.
- Page 36 Jiffy Steamer Matrix Chart ® INDEX A = upholstery B = steam brush 6" Metal Brush C = carpet Attachment Head Attachment fits onto the 9" Aluminum Bent Pipe Attachment Head) D = drapery 12" Carpet DM = metal steam Attachment Head head for drapery 9"...
- Page 37 12" Carpet Attachment Head 9" Aluminum Bent Pipe Hose with Attachment Head Wooden Handle and Brass Connection Fitting J-2M J-2W J-2000 J-2000B J-2000I J-2000M Esteam ® Steamboard • • • • • • • • • • • • •...
- Page 38 Jiffy Steamer Matrix Chart ® INDEX A = upholstery B = steam brush C = carpet D = drapery DM = metal steam head for drapery H = hat I = interchangeable steam head M = metal steam head with wooden Matrix Chart handle...
- Page 39 Use this helpful matrix chart to help you find the right Jiffy Steamer for your needs! ® 6" Metal Brush Attachment Head Attachment fits onto the 9" Aluminum Bent Pipe Attachment Head) 12" Carpet Attachment Head 9" Aluminum Bent Pipe Hose with Attachment Head Wooden Handle...
-
Page 40: Product Specifications
Jiffy Steamer ® PRODUCT SPECIFICATIONS Worldwide Leader in Steaming Equipment Since 1940 UL CSA, CE, TUV, UL CSA, CE, TUV, UL CSA, CE, TUV, UL CSA, CE, TUV, UL CSA, CE, TUV, UL CSA, CE, TUV, NOM, ANCE NOM, ANCE NOM, ANCE NOM, ANCE NOM, ANCE... - Page 41 Jiffy Steamer Warranty ® 3 YEAR LIMITED PRODUCT WARRANTY As the global leader of steaming equipment since 1940, we feel that our warranty should properly stand behind every product we craft. The Jiffy Steamer is precision built, tested and inspected before leaving our factory ®...
-
Page 42: Jiffy Jiffy
Jiffy Steamer Contact Information ® Contact Us Jiffy Steamer Company, LLC looks forward to serving your needs. ® If you have questions regarding our products, please do not hesitate to contact us. Jiffy ® Steamer Corporate Headquarters Information: 4462 Ken-Tenn Highway P.O.
