TABLE OF CONTENTS

INTRODUCTION .................................................................................................. 3
GENERAL TECHNICAL DESCRIPTION ............................................................ 4
CONTROLS AND FUNCTIONS .......................................................................... 6
BATTERY INSTALLATION ................................................................................... 8
OPERATING INSTRUCTIONS ............................................................................ 8
OPERATING NOTES ........................................................................................... 9
ADJUSTING THE TRANSMITTER FREQUENCY .............................................. 9
MICROPHONE CORD TERMINATION ............................................................. 10
5-PIN INPUT JACK WIRING ............................................................................. 11
A6U UHF ANTENNA .......................................................................................... 13
TROUBLESHOOTING ....................................................................................... 14
SPECIFICATIONS AND FEATURES ................................................................. 15
SERVICE AND REPAIR ..................................................................................... 16
RETURNING UNITS FOR REPAIR ................................................................... 16
WARRANTY ......................................................................................... Back cover
The UM200C transmitter is FCC type accepted under Part 74: 470-608MHz and 614-802MHz
2
