Kaytee CritterTrail Quick Clean Habitat Assembly Instructions page 2

Examine each part and identify each component
using parts Identi cation list
Habitat Measures/Dimensions de l'habitat /El hábitat mide:
15.5"(39.37cm) L x 10.5"(26.67cm) W x 10.5"(26.67cm) H
B
D
F
E
H
J
C
G
I
A
G
QTY. KEY DESCRIPTION COLOR
1 A Scatter-less Base Green
1 B Roof Top Green
1 C Front Wire Panel w/ Door Silver
1 D Back Wire Panel Silver
1 E Bubble Wave Wheel Blue
1 F Wheel Connector Clip Blue
2 G Twist Lock Opening Cap Blue
1 H Water Bottle Blue
1 I Food Dish Blue
1 J Side Latch Blue
STEP 1
Fill Scatter-less Base with Bedding
Insert the provided Kaytee ® Bedding Tray (Product #100516386) into the Scatter-less Base
Peel away and dispose the top film layer of the Bedding Tray to expose bedding material.
A
STEP 2 Connect the Wire Panels
Place the Front Wire Panel w/ Door (C) so the spring
loaded door latch opens downward. Place the
Back Wire Panel (D) so that the opening for the
bottle nozzle is on the bottom. Connect the
Front Wire Panel w/ Door (C) to the
Back Wire Panel (D) by hooking the wire
into each other (as pictured).
C D
Door
opens
down.
D C
J
C
D
G
STEP 3
Attach Wire Panels
Place the assembled Front Wire Panel w/Door (C) and the assembled Back Wire Panel (D) on to
the Scatter-less Base (A). The Wire Panel Assembly should fit inside the tabs of the
Scatter-less Base (A). To secure, snap the two Side Latches (J) on the Scatter-less Base (A) to
the Wire Panel Assembly (C & D).
D
A
J
(A).
A
Unlocked
STEP 4 Bubble Wave Wheel Assembly
Insert the Wheel Connector Clip (F) into the center hole of the Bubble Wave Wheel (E). Attach the
Bubble Wave Wheel to the center of the Back Wire Panel (D) between the fifth and sixth bar up
from the bottom. Simply press the Wheel Connector Clip (F) through the Back Wire Panel (D) and
twist Connector half way to lock Wheel into place.
F
E
Tip: To keep your Bubble Wave Wheel silent, place a drop of vegetable oil directly on the spindle of
the Wheel Connector Clip.
Opening
for bottle
nozzle.
STEP 5
Roof Top Attachment
Place the Roof Top (B) onto the top of the assembled bottom portion of the habitat.
Line up the Roof Top (B) over the assembled Wire Panel Assembly (C & D) .
To secure, connect the two Side Latches (J) on the Roof Top (B) to the Wire Panel Assembly (C & D).
C
J
C
A
Locked
STEP 6
F
E
F
There are four unused access holes that will allow you unlimited expansion of your
pet's home with the use of CritterTrail
additional access holes until you are ready to expand your pet's home and have already
purchased your accessories! Access holes CANNOT be closed once opened.
To close an opened access hole on the Roof Top (
CritterTrail
STEP 7
B
To fill Water Bottle (H), remove the
twist off cap with rubber stopper.
Fill Bottle completely by placing it
J
under a light stream of running
water. Close the bottle by pushing
in the rubber stopper and twisting
the cap. Turn the bottle upright
and allow the vacuum to form. You
may experience a few initial drips.
Locate the attached wire bottle
holder and bottle sipper tube hole
D
location on the Back Wire Panel (D). Place the sipper tube into
the hole and pull the wire holder down to secure the bottle in
place. When refilling your Water Bottle, never squeeze it.
This may cause a fracture in the plastic and make it impossible for
the necessary vacuum to form.
Note: Temperature fluctuations and excessive cage vibrations
sometimes cause occasional dripping. Whenever you move your
CritterTrail Quick Clean Habitat always remove the Water
®
Bottle. Place a quality food mixture (not included) into your pet's
Food Dish (I). Place the Food Dish (I) into any corner of your
new CritterTrail
Water Bottle (H).
Accessory Attachment
Hint: Accessory Access Holes
® Add-on accessories. DO NOT punch out the
B
) you will need to use a
® 10" Funnel ® #100079222 with any of the CritterTrail ® Fun-nel ®
Tube accessories.
Two Twist Lock Opening Caps (G) are provided to cover the
expansion portals on Scatter-less Base (A).
G A
Using the Water Bottle and Food Dish
D
H
H
D
I
Habitat. Do not place Food Dish (I) under the
®
