11 Order Codes

11.1 System

Type
SimStep

11.2 Motor Encoders

Frame size Type
Size 23 23HSX-206 CI 500L
23HSX-306 CI 500L
Size 34 34HSX-108 RI 500L
34HSX-208 RI 500L

11.3 Cables

Type
Motor – 1m
Motor – 2m
Motor – 3m
Motor – 5m
Motor – 10m
Encoder – 1m
Encoder – 2m
Encoder – 3m
Encoder – 5m
Encoder – 10m
Limits/Datum – 1m
Limits/Datum – 2m
Limits/Datum – 3m
Limits/Datum – 5m
Limits/Datum – 10m
Jog Link – 0.5m
I/O – 0.5m
I/O – 1m
I/O – 2m
I/O – 3m

11.4 Junction Boxes

Type
MSA889 – Motor & Limits/Datum
MSA891 – I/O Breakout
11.5 Jog Boxes & Joystick
Type
JC100 – Single Axis
JC200 – Dual Axis
JC809 – Multi-Axis
JC400 – Dual Axis Joystick

11.6 EMC Ferrites

Type
Cable Dia. 7 – 8.5mm
Cable Dia. 8.5 – 10.5mm
SimStep Manual - 3400 Iss. D
Order Code
508SMS09749
Order Code
301HSE00053
301HSE00054
301HSE00055
301HSE00056
Order Code
507MOC01892
507MOC02892
507MOC03892
507MOC05892
507MOC10892
507ENC01893
507ENC02893
507ENC03893
507ENC05893
507ENC10893
507LDC01894
507LDC02894
507LDC03894
507LDC05894
507LDC10894
507JDC05916
507IOC05895
507IOC01895
507IOC02895
507IOC03895
Order Code
506MSC00889
506MSC00891
Order Code
506JCT00100
506JCT00200
506JCT00809
506JCT00400
Order Code
114FER00003
114FER00004
th
7 June 2004 page 30
