TROUBLESHOOTING
PROBLEM
Motor Not Running
Motor Not Running
SPECIFICATIONS
Motor 1/5 HP
Amps H 1.7 AMPS
Built in Power Outlet 9.5 AMPS
Max Air Volume 800 CFM
Speeds 3 / Positions 3: 0º, 45º, 90º
Certification C-ETL-US
Voltage 115 V
Cycle 60 HZ
Max Static Pressure 160 PA
Daisy Chain Yes / Stackable 5 units
Product Weight 10.8 Lbs / Boxed Weight 12.3 Lbs
Product Size (HxWxD) 13" x 11" x 11.4" / Boxed Size (HxWxD) 13.4" x 11.4" x 11.8"
Wheel Speed (RPM) L1090 / M1320 / H1570
Attached Cord 10' (FT) 14 AWG
Available Colors Blue
4
5
POSSIBLE CAUSE
a) Switch is OFF
b) Bad Outlet
c) Faulty Switch/Cord
a) Fan Blade Loose
3
13
SOLUTION
a) Turn Switch ON
b) Check Outlet / Change to
Another Outlet
c) Faulty Switch/Cord
a) Call Factory for
Replacement Advise
