C COPYRIGHTS 1998
REMACO TECHNOLOGIES PTE LTD
Installation Guide
433MHz
All controls support 230V/50Hz & 120V/60Hz
Circuit installation
230V / 50Hz or
120V / 60Hz according
to product nameplate
AVA-315-RF
1 Channel
Control Range
Motorized
Roller Shutter
AVA-361-Rx
L1
230AV / 50Hz
120AV / 60Hz
230V / 50Hz
(For AVA-361-RX)
AVA-361-Rx
Mini Box Receiver
Motorized
Roller Shutter
AVA-361-Rx
L 2
L1 Open
L2 Partition
Emission frequency
200m
35m
433 MHZ
200m
35m
Blue = Neutral
Black = Direction 1
Brown = Direction 2
Green / Yellow = Earth
120V / 60Hz
Website: www.remacotech.com
V: 2.0
AVA-361-RX
M
C
N
L
White = Neutral
Red = Direction 1
Black = Direction 2
Green = Earth
Advertisement
Related Manuals for Remaco AVA-361-RX
Summary of Contents for Remaco AVA-361-RX
-
Page 1: Installation Guide
