- Page 1 Instruction Manual Anderson Instrument Co. Inc. 156 Auriesville Road Fultonville, NY 12072 1-800-833-0081 Fax 518-922-8997 Instrument Model Number Instrument Serial Number "LS" Capacitive Point Level Switch 30003 / 1.0 / 2015-05-06 / PW / NA...
-
Page 3: Table Of Contents
Table of Contents Section 1 - Application and Intended Use 1.1 - Application 1.2 - Intended Use Section 2 - Specifications Section 3 - Wiring Section 5 - Maintenance Section 6 - Dimensions Section 7 - Part Number Matrix Section 8 - Accessories Warranty and Return Statement... - Page 4 Safety Warnings Warning! This unit accepts DC voltage only, connection to AC voltage can cause failure of the sensor and/or risk of electrocution Warning! Do not remove this sensor from the process while it is operating. Removal while the process is operating can contaminate the process and could cause human injury.
-
Page 5: Section 1 - Application And Intended Use
Any modifications to the sensor that might have an influence on the function and the safety features of the sensor are only allowed to be carried out by authorized persons of Anderson Instrument Company. Possible misuse including any use in contradiction to the above-mentioned application is an indication of misuse of the measuring instrument! In such a case Anderson does not assume any responsibility for safety. -
Page 6: Section 3 - Wiring
Section 3 - Wiring Warning! This unit accepts DC voltage only, connection to AC voltage can cause failure of the sensor and/or risk of electrocution Figure 1.1 - Field Wireable Connector Assembly 4. Refer to pin detail. 4A - Wiring for full (immersed) indication: 1. - Page 7 Section 4 - Installation and Sensitivity Adjustment Warning! Do not subject this sensor to pressure that exceeds the specified upper range limit. Over-pressure may cause premature failure, incorrect output signal, or possible human injury. Caution: For proper mounting of this sensor, verify that the fitting connection type, size, gasket or seal, and holding ring or clamp match the process connection it is being mounted to.
-
Page 8: Section 5 - Maintenance
Section 5 - Maintenance Warning! Do not remove this sensor from the process while it is operating. Removal while the process is operating can contaminate the process and could cause human injury. Warning! Before removing for service or calibration, ensure that residual product has been flushed from the line and that internal pressure has returned to atmospheric pressure. -
Page 9: Section 6 - Dimensions
Section 6 - Dimensions 2.32” (59.8mm) 2.32” (59.8mm) 4.48” 4.48” (113.8mm) (113.8mm) 2 - 10” 2 - 10” (50 - 250mm) (50 - 250mm) 0.44” (11.2mm) 0.44” (11.2mm) VARIES WITH FITTING VARIES WITH FITTING Weight: 2” Tri-Clamp® 1.85 lbs. (.84kg) 1.5”... -
Page 10: Section 7 - Part Number Matrix
Section 7 - Part Number Matrix PROBE LENGTH OUTPUT TYPE Standard PNP - Sourcing 2” (50mm) NPN - Sinking (special order) 4” (100mm) 6” (150mm) FITTING STYLE 8” (200mm) 1-1/2” Tri-Clamp ® 10” (250mm) 2” Tri-Clamp ® G1/2” CLEAN Adapt DISPLAY WINDOW Typical Configuration: No window, Blank cover... -
Page 11: Warranty And Return Statement
These products are warranted to be free from functional defects in materials and workman- ship at the time the products leave the Anderson factory and to conform at that time to the specifications set forth in the relevant Anderson instruction manual or manuals, sheet or sheets, for such products for a period of two years. - Page 12 ANDERSON INSTRUMENT CO. LP • 400 BRITANNIA RD. EAST, UNIT 1 • MISSISSAUGA, ONTARIO L4Z 1X9 • CANADA • 905-603-4358 • FAX 905-568-1652 NEGELE MESSTECHNIK GmbH (A Division of Anderson) • RAIFFEISENWEG 7 • D-87743 EGG A. D. GÜNZ • GERMANY • +49 (0) 8333/9204-0 • FAX +49 (0) 8333/9204-49...
