- Page 1 Before beginning assembly, please read these instructions thoroughly. DIGITAL PROPORTIONAL SYSTEM DIGITAL PROPORTIONAL SYSTEM Instruction Manual *Specifications are subject to be changed without prior notice! THE FINEST RADIO CONTROL MODELS © Copyright 2015 KYOSHO CORPORATION / 禁無断転載複製 82030-T01...
-
Page 2: Table Of Contents
■ Table of Contents Title Title Page Page ■ Table of Contents ▶VR INFORMATION Volume information ■ For Safe Operation ▶KEYSPEED ■ Getting Started ▶OPERATIN ALARM ●Transmitter Assembly □■□STEERING MENU ●Transmitter Dismantling ●TRAVEL MENU ■ Names of Parts ▶ST TRAVEL Steering Travel ●ET Keys (1-3) and BT Button (1) ▶ST BALANCE L R Seering Balance L R ●Steering Adjustment... -
Page 3: For Safe Operation
Improper handling may lead to dangerous situations. Therefore please read the following information carefully in order to ensure safe operation. Please also understand that Kyosho is not responsible for any injuries or damage which result from noncompliance of these cautions and notices. - Page 4 ●When switching on, always turn on the transmitter first, followed by the MINI-Z. Follow the reverse order when switching off. ※If the wrong order is followed, it may lead to an uncontrollable model. ●Dismantling or modifying the RF Module (internalized in the case of the EX-6) is prohibited and is punishable by law.
-
Page 5: Getting Started
■ Getting Started ※ Depending on the model, expansion [Legend] :Point :Notice unit has been installed at the factory. ● Transmitter Assembly ● Transmitter Dismantling Insert the Grip Unit into the Master Unit, then attach Detach the Steering Unit, then detach the Master the Steering Unit. -
Page 6: Names Of Parts
■ Names of Parts 《Side View》 《Front View》 EXP Connector Cover Antenna （P.7） （P.7） （P.7） （P.7） （P.8） Power Switch Steering Unit Steering Unit （P.5） Release Button （P.5） Lock Lever （P.7） Colored Grip Throttle Trigger （P.7） ● ET Keys (1-3) and BT Button (1) Functions may be assigned to the ... -
Page 7: Et Keys (1-3) And Bt Button
● ET Keys (1-3) and BT Button (1) ● Throttle Trigger Position Adjustment Functions may be assigned to the keys/button. The position of the throttle trigger may be adjusted to match the user's hands. The possible functions which each key/button may be [How to Adjust] assigned to are different. -
Page 8: Unit Connector
● Unit Connector This product may be dismantled and therefore each unit features their respective connectors. Dirty or damaged connectors may result in malfunctions, so please handle them carefully. Do not touch the unit connectors with your fingers. If connectors become corroded due to grime, they may become inoperable. -
Page 9: Preparations
■ Preparations ● Battery Installation ● Battery Level Warning A warning will be displayed with the LED flashing and Press the tab on the bottom of the transmitter to open an alarm will sound when battery voltage is less 4v. battery box cover. -
Page 10: Initializing
● How to change the Modulation mode ● Initializing EX-6 When using the EX-6 for the first time, please carry EX-6 has two Modulation modes. out the following settings. ※ When attaching the Xpansion unit, this operation ※ EX-6 will not work normally if the initial is the same. -
Page 11: Pairing
● Pairing Case without the Xpansion unit Preparing the MINI-Z ※ Refer to p.21 pairing Operation in the case of ① Bring distance of EX-6 and MINI-Z close to about using the Xpansion unit. 10cm. In order for the MINI-Z to operate, it must store the 10cm transmitter's unique ID in its memory in a process called “pairing.”... -
Page 12: Procedures Prior To Operation
■ Procedures Prior to Operation 1.Switching On After ensuring that it is safe to do so, switch on the transmitter followed by the MINI-Z. 2.Model Confirmation Confirm the model which will be used. 3.Checking Movements With the model's wheels lifted off the ground, operate transmitter to check ... -
Page 13: Trim And Sub Trim Operation
● Trim and Sub Trim Operation The sub trim is a convenient feature but it could also complicate the setting process if used incorrectly. Use the sub trim in the correct manner while also referring to the sub trim operation instructions on p.39 and p.44. 《Purpose of the Trim》... -
Page 14: Operating Procedure
■ operating procedure ※ EX-6 can be used even to remove the expansion unit. ● STEERING ニュー ※ Other than the operation explanation of the ② Press and hold the ET1 lever to right, wait → steering wheel,the following function explanation is in about 1 second. -
Page 15: Throttle
● THROTTLE ■ Throttle travel ※ Other than the operation explanation of the trigger movement, the following function explanation in case We will adjust the operation amount of the front of not using the Xpansion unit. Refer to p.43 operation and rear of the throttle, respectively. -
Page 16: 3Ch 4Ch Operation
● 3CH operation ● 4CH operation Operating the ET3 lever, controls the 3ch When the button of BT1 is operated, it is servo. possible to operate the signal of 4CH. ※ The funtion explaination is in the case when not ※ The funtion explaination is in the case when not using the Xpansion unit. -
Page 17: Display And Control Method With The Xpansion Unit Attached
■ Display and Control Method with the Xpansion unit attached ● Basic Operations to Change Settings Controlling of the setting adjustments is done via the L(<) key, R(>)key, Operation ENTER(ENT) key, and BACK key. ENT Key: Selecting item to be modified; Confirming a change after a setting change. L（... -
Page 18: How To Attach Xpansion Unit
● Installation of expansion unit ※ Depending on the model, expansion unit has been installed at the factory. Xpansion unit can be mounted facing the ▼ B：when mounting sideways front or the side. The factory setting is ① Attach the monitor base at a right angle to mounted to the front.
