INSTALLATION GUIDE
Model #GB-250
100 GPM Grease Interceptor
For Indoor/Outdoor Use
Contents
Special Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
General Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Field Cut Riser Installation Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Anchor Kit Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Expanding Grease Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Application Specific Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Document #: 057-0780-05
Find these instructions online at: schierproducts.com/pages/gb-250
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Schier GB-250
Summary of Contents for Schier GB-250
-
Page 1: Table Of Contents
Application Specific Details ........6 Document #: 057-0780-05 Find these instructions online at: schierproducts.com/pages/gb-250... -
Page 2: Special Precautions
SPECIAL PRECAUTIONS For All Schier Grease Interceptor Installations - Failure to follow this guidance voids your warranty Installation Instructions High Temperature Kitchen Water installation Installation instructions and additional If water is entering the interceptor at excessive temperature (over 140º F), a... -
Page 3: General Installation Instructions
Schier grease interceptors are manufactured with an internal flow control system. They do not require an external flow control system or air intake vent. Schier grease interceptors are not to be installed in any other manner except as shown. Consult local codes for separate trapping requirements, cleanout locations and additional installation instructions. -
Page 4: Field Cut Riser Installation Guidelines
GB Unit (shown) Tilting before tightening clamps may ruin a perfect gasket seal. or Riser Schier recommends tilting only the adapter versus the entire riser assembly to make sure your riser height and proper tank access is maintained. Figure 2 - Insertion Depths 6. -
Page 5: Expanding Grease Capacity
Top View of 4 GB-250 Units Piped in Series GB-250 is certified to ASME A112.14.3 (Type C) and NOTE: When the flow control plate is required, it should CSA B481.1 and includes an internal flow control. -
Page 6: Application Specific Details
APPLICATION SPECIFIC DETAILS (Provided in kit) Valve optional Piping By Others Pumpout port kit (By Schier) Inside a Corroded Concrete Unit Basement Installation with Pumpout Port Kit Installation with Sampling Port SV24-L4 Serving an Apartment Complex Vent must terminate above the top rim of...
