User's
Manual
Quick, Easy Steps
IM 04L51B01-04Z1
4th Edition : Dec. 2015
Product user's manuals can be downloaded or viewed at the
following URL;
URL: www.smartdacplus.com/manual/en/
Manuals for reference
Connect an GX60
First Step Guide
(IM 04L51B01-02EN)
"Installation and Wiring"
Install modules.
First Step Guide
(IM 04L51B01-02EN)
"Installation and Wiring"
Connect I/O signals and power.
First Step Guide
(IM 04L51B01-02EN)
"Installation and Wiring"
First Step Guide
Turn on the power.
(IM 04L51B01-02EN)
"Basic Operations"
Make the GX/GP recognize the
First Step Guide
modules (GX/GP reconfiguration).
(IM 04L51B01-02EN)
"Reconfiguring the
GX/GP"
First Step Guide
Set the date and time.
(IM 04L51B01-02EN)
"Basic Operations"
First Step Guide
Configure signal inputs.
(IM 04L51B01-02EN)
"Basic Operations"
Paperless Recorder
Configure functions as
User' s Manual
necessary.
(IM 04L51B01-01EN)
First Step Guide
(IM 04L51B01-02EN)
Start measuring/recording.
"Basic Operations"
1
Install an expansion module (GX90EX) into the GX/GP.
9
To connect an GX60.
GX10/GP10: Up to 3 modules can be installed.
GX20/GP20: Up to 10 modules can be installed.
Not required
if preinstalled
To connect an GX60,
Modules (seven types)
install the modules in
the GX60.
Power inlet on
the GP10/GP20/GX60 (Power
Ex GX/GP
inret type)
Power switch
If preinstalled, modules are preconfigured.
If you rearrange the modules or connect an
GX60, reconfigure.
2
GX60 address setting
GX90EX
GX10/GP10 : Slot 2
GX20/GP20 : Slot 9
GX90EX
1
Modules not installed
Ex GX/GP
GX90XA
Analog input
module
GX60
M3 screw
Clamp
M3 screw
terminal
terminal
terminal
Set the date and time*.
GX60
Common menu tab
Start measuring/recording.
MENU key
To open, push the front door down and pull it toward you.
3
Connect the LAN cable bteween GX/GP and GX60.
Setting switch
(DIP switch)
2
Insert until a click is heard
and fasten with screws.*
Dummy covers are
attached to empty slots
(with screws).
* Recommended tightening
torque: 0.6 N•m
GX90XD
GX90YD
GX90XP
GX90WD
Digital input
Digital output
Pulse input
Digital input/
module
module
module
output module
Clamp
M3 screw
M3 screw
M3 screw
terminal
terminal
terminal
terminal
Configure input and functions.
* If you need to set the
time zone or DST (Daylight
Saving Time) or both, do
so before setting the date
and time.
Browse tab
Recording stopped
or
3
Modules installed
(10 modules)
To prevent electric shock when
wiring, make sure that the power
supply is turned off.
Clamp
terminal
Recording in progress
Alternates
Lit in blue
Lit in red
Running
Alarm activated
(No alarm)
Off: Power off
IM 04L51B01-04Z1 page 1/2
