Summary of Contents for IEI Technology HTB-100-HM170
- Page 1 Fanless Medical Embedded System with Intel® Core™ i7-6822EQ/i5-6442EQ Processor, Isolated COM Ports, GbE LAN, HDMI, VGA, USB 3.0, Audio and RoHS Compliant HTB-100-HM170 Quick Installation Guide Version 1.00 ©2018 Copyright by IEI Integration Corp. All rights reserved.
-
Page 2: Intended Use
1.00 Initial release Intended Use The HTB-100-HM170 medical embedded system is intended to serve as a Medical Embedded System for integration with the hospital system. The Medical Embedded System is designed for general purpose for hospital environment. For data collection and process for reference, include Surgical, Radiology, LIS (Lab Information Systems) and Electronic Medical Record. - Page 3 All of the COM ports support 2.5 kV isolation that meets medical standard. The display interface options include VGA and HDMI with three audio jacks. The HTB-100-HM170 series systems are all capable of supporting one 2.5” SATA 6Gb/s solid-state drive (SSD) or an mSATA module.
- Page 4 Front Panel Rear Panel...
-
Page 5: System Specifications
System Specifications HTB-100-HM170 Intel® Core™ i7-6822EQ 2.0 GHz (up to 2.8 GHz, quad-core, 25W TDP) Intel® Core™ i5-6442EQ 1.9 GHz (up to 2.7 GHz, quad-core, 25W TDP) Chipset Intel® HM170 System Memory 2 x 260-pin DDR4 SO-DIMM slot (system max. 32 GB) Preinstalled one 4.0 GB DDR4 SDRAM SO-DIMM... - Page 6 Power Supply 150 W medical-grade power adapter Input: 90 V AC ~ 264 V AC, 47 Hz ~ 63 Hz, 2.0 A ~ 0.85 A Output: 150 W Max., 19 V 7.89 A Power Consumption 19 V @ 4.4 A (with Intel® Core™ i7-6822EQ processor and 4 GB DDR4 memory) Operating Shock Half-sine wave shock 5G;...
-
Page 7: Installation Precautions
Use the hand clamp on the other end of the grounding cable to clip on the Earth’s conductive surface. Mounting the System WARNING: The HTB-100-HM170 can only be placed on a desktop or other surface horizontally. Do not mount the HTB-100-HM170 onto a wall or other mounting apparatus. -
Page 8: Powering On The System
To avoid risk of electric shock, this equipment must only be connected to supply mains with protective earth. CAUTION: The power adapter came with the HTB-100-HM170 is a forming part of the medical device. CAUTION: Position the power cord so that people cannot step on it. Do not place anything over the power cord. -
Page 9: Troubleshooting
If the following situations happen, contact your distributor, sales representatives or IEI customer service center for technical support. The HDD is installed correctly, but the HTB-100-HM170 is unable to boot with AC power input after pressing the power button. - Page 10 Accessories The HTB-100-HM170 medical embedded system is shipped with the following components: Quantity Item Image medical embedded system Power cord Medical-grade power adapter (150 W, 19 V DC output) Grounding cable HDMI cable holder Screws (M3*4) for HDD installation Spare screw (M2*4) for M.2...
-
Page 11: Optional Items
Optional Items The following are optional components which may be separately purchased: Item and Part Number Image Cable cover Wi-Fi kit (P/N: EMB-WIFI-KIT02E-R10) -
Page 12: Declaration Of Conformity
DECLARATION OF CONFORMITY This equipment is in conformity with the following EU directives: EMC Directive (2004/108/EC, 2014/30/EU) Low-Voltage Directive (2006/95/EC, 2014/35/EU) RoHS II Directive (2011/65/EU, 2015/863/EU) Medical Device Directive 93/42/EEC: EN 60601-1 If the user modifies and/or install other devices in the equipment, the CE conformity declaration may no longer apply. -
Page 13: China Rohs
CHINA ROHS The label on the product indicates the estimated “Environmentally Friendly Use Period” (EFUP). This is an estimate of the number of years that these substances would “not leak out or undergo abrupt change.” This product may contain replaceable sub-assemblies/components which have a shorter EFUP such as batteries and lamps. -
Page 14: Safety Precautions
The equipment should be installed near an easily accessible outlet. For pluggable equipment, the power outlet must be installed near the equipment and must be easily accessible. Electric shocks can occur if the HTB-100-HM170 chassis is opened when the HTB-100-HM170 is running. To avoid risk of electric shock,... - Page 15 If considerable amounts of dust, water, or fluids enter the HTB-100-HM170, turn off the power supply immediately, unplug the power cord, and contact the HTB-100-HM170 vendor. Product Disposal CAUTION: Risk of explosion if battery is replaced by an incorrect type.
-
Page 16: Contact Information
Contact Information IEI Integration Corp. Address: No. 29, Zongxing Rd., Xizhi Dist., New Taipei City 221, Taiwan Phone: +886-2-8691-6798 Fax: +886-2-6616-0028 Web Site: www.ieiworld.com Sales Email: sales@ieiworld.com.tw...
