4.1 Inserting plug-in card (AUX)

To access the plug-in card (AUX), cut the control panel cover as shown in the figure.
4.2 SOFA1-SOFA2 or GOPAVRS self-controlled safety edge
Command
SOFA1-SOFA2
GOPAV
1 6
1 8
EN
Function
SAFETY TEST
NC SAFETY STOP
NC CLOSING
SAFETY
DEVICE
UP
DOWN
ENTER
ESC
Description
Place the SOFA1-SOFA2 or GOPAVRS device into the
special housing for AUX plug-in cards.
If the test fails, an alarm message appears on the
display.
When selecting →
contact of the safety device to terminals
trol panel (in series with the photocell output contact,
if installed).
When selecting →
contact of the safety device to terminals 1-8 on the con-
trol panel (in series with the photocell output
if installed).
6
→ , connect the output
1-6 on the con-
→ , connect the output
contact,
