InstroTek SMART-MC Installation & Quick Start Manual

The following functions are available under the MENU key. Press
the Number Key which corresponds to the Menu Option you
MENU
wish to access.
1- Stat Test – Tests the electronic stability of the gauge.
2- Drift Test – Tests for electronic drift.
3- Recall – Allows the user to retrieve the most recent gauge test results.
4- Auto-Depth – Enable/Disable the Auto-Depth feature. Calibrate the
Auto-Depth feature.
5- O set – This mode provides three di erent o set functions, Moisture,
Density and Trench correction. Use this function to o set factory calibration
readings or correct for trench wall in uence in the eld. Use the DOWN for (-),
UP for (+).
6- Diagnostic Tests– Measure battery voltage, measure high voltage, measure
temperature, reset memory, clears all data from the gauge. This function is for
Advanced Technicians Only.
7- Review Standard Counts– View the last 30 STD Counts and date collected.
8- Language - Select English or Spanish.
9- Standard Mode – Select Average Standard Mode or Decay Mode.
10- Auto Scroll – Helps users during recording of data in the eld. The test
screens automatically scroll every 5 seconds.
11- Set Units – Allows the user to change units between lb/ft3, kg/m3, and
g/cc.
12- LCD light – Allows easy viewing of data and keypad during night work.
13- Serial Number – Allows entry of the gauge serial number.
14- Date/Time – Set the current date and time.
15- Buzzer / Alarm – Enable or disable the Buzzer alarm feature.
16- Special Calibration – Allows adjustment of calibration constants for local
or special materials.
17- Thinlayer Mode – Allows the gauge to be used on thin layer asphalt over
soil or aggregate bases. Use BS or AC depths for asphalt on asphalt overlays.
18- Calibration Constants – Allows entry and storage of calibration constants
used for determination of material density and moisture. This function is for
Authorized Users Only.
Note: When entering the MC1DRP moisture constants into
the SMART-MC, change the sign on moisture B value from negative to positive.
