35 37 MAIN MACHINE COMPONENTS The main machine components are the following: Support hook for recovery tank drainage tube. Recovery tank drainage tube. Control handlebars. Support hook for spray gun. Dead man's lever. Solution tank level indicator. Control panel. Built-in battery charger. Reverse control button.
CONTENTS MAIN MACHINE COMPONENTS ..........3 CLEANING THE RECOVERY TANK...........22 CONTENTS .................4 EMPTYING THE SOLUTION TANK ............22 GENERAL SAFETY REGULATIONS .........5 CLEANING THE WATER SYSTEM FILTER ........22 CLEANING THE VACUUM TUBE ............22 RECHARGING THE BATTERIES ............5 CLEANING THE SOLUTION TANK ............23 USING THE MACHINE .................6 EXTRAORDINARY MAINTENANCE WORK ......23 DEACTIVATION OF THE MACHINE .............8...
GENERAL SAFETY REGULATIONS The following symbols are used to indicate any potentially hazardous situations. Always read this information carefully and take the necessary precautions to protect any people and/or objects that may be present. Operator cooperation is paramount for accident prevention. No accident prevention programme can be effective without the full cooperation of the person directly responsible for operating the machine.
• Before starting the charging operation, carefully read the user manual of the battery charger that you want to use. USING THE MACHINE DANGER: • In the event of danger, take prompt action by pressing the emergency button on the back of the machine (near the control handlebars).
Page 7
• The machine must only be powered with a voltage equal to that shown on the serial number plate. • Read the labels on the machine carefully. Do not cover them for any reason, and replace them immediately if they become damaged. •...
DEACTIVATION OF THE MACHINE WARNING: • Always protect the machine against sunlight, rain, and other atmospheric agents, both while it is stationary and while it is functioning. Store the machine in a dry, sheltered place: this machine is only designed for use under dry conditions, and must not be used or stored outdoors in humid conditions.
batteries; etc.), never exceed 2.49 mph. • If there are any machine operation anomalies, check they are not due to a lack of proper maintenance. Otherwise, request the intervention of authorised personnel or an authorised service centre. • If any parts need to be replaced, always request ORIGINAL spare parts from an authorised dealer or retailer.
TECHNICAL DESCRIPTION The TRIDENT T20SC PRO is a floor scrubbing machine that can work on various types of floor and dirt Information symbol: thanks to the mechanical action of a brush and the chemical action of a water-detergent solution. As Indicates additional information for the operator, to improve the use of the device.
13. TECHNICAL DATA TRIDENT TRIDENT TECHNICAL DATA TECHNICAL DATA T20 SC T20 SC Rated machine power 1075 Vacuum motor (voltage - nominal power rating) V - W 24 - 424 Working capacity up to 26802 Vacuum on vacuum head 1.75...
SYMBOLS USED ON THE MACHINE Daily care warning label: Applied to the machine to remind the operator of the necessary procedures to properly care for the machine itself. Symbol of maximum temperature for filling the solution tank: Located on the front of the solution tank, to indicate the maximum temperature of the water for filling the solution tank safely.
SYMBOLS ON THE CONTROL DISPLAY HOW TO UNPACK THE MACHINE The machine is shipped in specific packaging. To remove it, proceed as follows: Place the lower part of the outer packaging in contact with the floor. NB: use the pictograms printed on the box as a reference. Remove the outer package.
Lower the brush head body and press the “BRUSH HEAD CONTROL” button (4) on the control HOW TO MOVE THE MACHINE panel (Fig.4). To transport the machine safely, proceed as follows: NB: as soon as the button (4) on the control panel is pressed, the green LED (5) (“BRUSH HEAD BODY WORK POSITION”) will switch on (Fig.4).
ASSEMBLING THE BRUSH For packaging reasons, the brush is supplied disassembled from the device. To assemble it on the brush head body, proceed as follows: Make sure the electric brake is engaged, then rotate the lever (1) anti-clockwise. The lever is located on the rear right-hand side of the machine (Fig.1).
ASSEMBLING THE SQUEEGEE BODY DETERGENT SOLUTION (VERSIONS WITHOUT HDC) For packaging reasons, the squeegee body comes disassembled from the machine. In order to mount After filling the solution tank with clean water add the liquid detergent to the tank in the concentration it on the squeegee support, do the following: and manner indicated on the detergent manufacturer's label.
14. Make sure the vacuum tube (11) is correctly connected to the sleeve in the squeegee body. If it HOUR METER isn't, connect it (Fig.10). The device control panel contains the control display, which shows the total usage time. The numbers 15.
SCRUBBING WITH DRYING The drying without scrubbing operation should only be To perform a scrubbing and drying program, proceed as follows: carried out if the machine was previously used to carry out a scrubbing without drying operation. Make all the checks listed in “PREPARING TO WORK”.
VACUUM WAND KIT To use the vacuum kit, proceed as follows: Turn the main switch (1) to "0", making a quarter turn of the key in the direction of the arrow (Fig.1). Lower the squeegee body and turn the squeegee control lever (2) in the direction of the arrow (Fig.2).
11. Grip the handle (4) on the right-hand side of the recovery tank and turn the tank as far as it will go, EXTRA BRUSH HEAD PRESSURE until it reaches the work position (Fig.7). This machine can increase the pressure exerted on the brush during the work cycle. To do this: Make sure the brush head body is in contact with the floor.
Thoroughly clean the vacuum chamber of the squeegee body, first with a jet of water and then with a damp cloth. NB: the place designated for this operation must comply with current environmental protection regulations. Thoroughly clean the rear rubber blade of the squeegee body, first with a jet of water and then with a damp cloth.
13. Remove the vacuum motor filter (13), taking care not to lose the support tie (14) inside the NB: to adjust the solution jet from the tank cleaning accessory, turn the knob (9) on the recovery tank (Fig.13). accessory itself (Fig.9). 14.
Remove the vacuum tube (1) from the vacuum nozzle (2) on the squeegee body (Fig.1). REPLACING THE SQUEEGEE BODY RUBBER BLADES Grip the handle (3) on the right-hand side of the recovery tank (Fig.2) and turn the tank as far as it will go, until it reaches the maintenance position.
MACHINE CODE BRISTLE NOTES 404654 PPL 0.3 BLUE BRUSH 405631 PPL 0.6 WHITE BRUSH TRIDENT 404653 PPL 0.9 BLACK BRUSH T20SC PRO 405632 ABRASIVE BRUSH 405527 PAD HOLDER WITH CENTRE LOCK...
TROUBLESHOOTING This chapter lists the most common problems linked with the use of the machine. If you are unable to resolve the problems with the information given here, please contact your nearest assistance centre. PROBLEM POSSIBLE CAUSE SOLUTION The main switch is set to “0”. Make sure the main switch is on “I”.
