- Page 1 2-Wire 2-Wire Video 2-Wire Video Video Interior Handset User Manual Outdoor Station User Manual EVD2-10IN English Read this manual carefully before using the product, and keep it well for future use.
- Page 2 User Manual EVD2- User Manual EVD2- User Manual EVD2-10IN...
-
Page 3: Parts And Functions
In standby mode, pick up handset, then press Call Call button/ button to activate the inner call; Unlock 2nd button During calling/talking state, press Unlock 2nd button to re- lease the second door. Speaker Send out voice from the visitor. User Manual EVD2-10IN... -
Page 4: Terminal Descriptions
Used to Slave Monitor Address or Extended Address setting. 3. Unit Mounting 1). Fix 2 screws to the wall at an appropriate height. 2). Connect the system correctly. 3). Attach the audio phone to the bracket. User Manual EVD2- User Manual EVD2- User Manual EVD2-10IN... -
Page 5: Setup Instructions
User Code. The DIP1 switches are used to configure the User Code for each Monitor. • Bit-1~5 of DIP1 are used to User Code setting. The value is from 1 to 32, which have 32 different codes for 32 apartments. • Bit-6 of DIP1 is used to video match. User Manual EVD2-10IN... - Page 6 • Bit-3 of DIP2 is used to monitor matched setting, When Bit-3 set to ON / OFF, there are different usages. 5.2.1 When Bit-3 of DIP2 set to OFF, the Bit-1~2 of DIP2 are used to master/slave address setting: User Manual EVD2- User Manual EVD2- User Manual EVD2-10IN...
- Page 7 5.2.2 When Bit-3 of DIP2 set to ON, the Bit-1~2 of DIP2 and Bit-1~5 of DIP1 are used to extended address setting: User Manual EVD2-10IN...
- Page 8 2). Pick up handset in standby mode, each time you press K4 to replace a group of ring tones. Four groups ring tones cycle: 3). Put down handset to exit the setting. User Manual EVD2- User Manual EVD2- User Manual EVD2-10IN...
-
Page 9: Specification
● Power Consumption: standby 2.1mA, working 75.9mA ● Wiring: 2 wires, non-polarity ● Dimension: 187(H)X97(W)X33(D)mm The design and specifications can be changed without notice to the user. Right to interpret and copyright of this manual are preserved. User Manual EVD2-10IN...
