THE SA3000

SPECIFICATIONS

System
Processor
Intel
RAM
Minimum configuration: 2GB (DDR II SODIMM x 1)
Minimum configuration: 8GB Flash SATA
Storage
Optional upgrade: 120GB HDD, 16GB Flash SATA,
Display Resolution
Up to 1920 x 1080
Operating System
Microsoft
Network Interface
10/100 BaseT LAN/ WiFi 802.11a/b/g
1 HDMI ports, 2 Audio jacks, 2 USB 2.0 ports,
1 VGA port, 1 RJ45 connector for Ethernet,
I/O Ports
1 DC-in jack, 1 COM port
Optional: WiFi Dipole antenna
Expansion
1 Mini PCI Express card slot
Mechanical
AC/ DC Adaptor
External AC-DC 18.5V/ 3.5A/ 65W adaptor
Dimensions (H x W x D)
2.16 x 5.82 x 6.5 in/ 55 x 148 x 165.1 mm
Weight
2.9lbs/ 1.316kg (Flash); 3.12lbs/ 1.416kg (HDD)
Environmental
Regulatory
FCC Class B, CE, C-Tick, UL, RoHS compliant
Operating Temperature
0° – 40°C
Humidity
0% – 90% non-condensing
* Note: Specifications subject to change without notice
DT Research, Inc.
2000 Concourse Drive, San Jose, CA 95131
Copyright © 2008-2009, DT Research, Inc.
All Rights Reserved. DT Research, WebDT are registered trademarks of DT Research, Inc.
signage dtri com
BOG082709SA3000ENG
4
ENGLISH
Core
2 Duo processor, 2.26 GHz
®
TM
32GB SATA SSD or 64GB SATA SSD
Windows
XP Embedded
®
®
(optional)
http://www.dtresearch.com http://www.signage.dtri.com
Signage Appliance
SA3000
BASIC OPERATION GUIDE
ENGLISH

INTRODUCTION

Thank you for acquiring the SA3000,
a WebDT Signage Appliance by DT Research.
The WebDT Signage Appliance facilitates the
creation of a unique and powerful communication medium that offers unparalleled
opportunities to capture an audience's attention at key decision-making locations.
The SA3000 enables efficient deployment for digital signage, featuring reliable, energy-
efficient hardware and intuitive server-based software. The Microsoft
SA3000 offers remote management of the hardware and the displayed content
with the WebDT Content Manager software. The SA3000 together with the WebDT
software, offers an efficient solution for delivering and managing messages that target
audiences in the right place, at the right time.
1
2
3
Content Manager
Windows
based
®
®

Package Contents

1.
WebDT Signage Appliance SA3000
2.
Software and User Guide (including
WebDT Content Manager, and user
guides on Software Disk)
3.
VESA-compliant Mounting Bracket
4.
AC/DC Power Adapter
5.
Basic Operation Guide
4
NOTE: The actual package contents may
vary depending on the configuration
acquired.
