DT Research SA3000P Basic Operation Manual

SA3000P/ SA3000T
SPECIFICATIONS
System
Processor
GPU
Memory (RAM)
Storage
Operating Systems
Display Resolution
Video Resolution
Network Interface
Expansion
Input/Output Ports
Power
AC/DC Adapter
Mechanical
Enclosure
Dimensions
(H x W x D)
Weight
Environmental
Regulatory
Temperature
Humidity
* Specifications subject to change without notice.
DT Research, Inc.
2000 Concourse Drive, San Jose, CA 95131
Copyright © 2012, DT Research, Inc.
All Rights Reserved. DT Research is a registered trademark of DT Research, Inc.
signage dtri com
BOG041112SA3000ENG
4
ENGLISH
SA3000P: Intel® Core™ 2 Duo, 2.26GHz
SA3000T: Intel® Celeron® T3100, 1.9GHz
Intel® GM45
2GB
8GB Flash, 250GB HDD, or 32GB to 64GB SSD
Microsoft® Windows® XP Embedded or Windows®
Embedded Standard 7
Up to 1920 x 1080
Full-HD
10/ 100/ 1000Mb BaseT LAN;
Wi-Fi 802.11a/b/g or Wi-Fi 802.11a/b/g/n (optional)
PCI Express; USB
1 VGA port; 1 HDMI port; 1 COM port; 18.5V DC-in jack; 2
Audio jacks (Microphone-in, Line-in, Headphone-Out jacks); 2
USB 2.0 ports; RJ45 connector for Ethernet;
Wi-Fi dipole antenna (optional)
Input: 100 – 240V AC; Output: 18.5V DC
Aluminum + steel
2.16 x 5.82 x 6.5 in/ 55 x 148 x 165.1 mm
2.9 lbs/ 1316 g
FCC Class B, CE, UL, C-Tick, RoHS compliant
Operation: 0°C - 40°C; Storage: -20°C - 60°C
0% - 90% non-condensing
http://www.dtresearch.com http://www.signage.dtri.com
Signage Appliance
SA3000P/ SA3000T
BASIC OPERATION GUIDE
ENGLISH
INTRODUCTION
Thank you for acquiring the SA3000P/
SA3000T, a Signage Appliance by DT Research.
The DT Research Signage Appliance facilitates
the creation of a unique and powerful communication medium that offers unparalleled
opportunities to capture an audience's attention at key decision-making locations. The SA3000P/
SA3000T enables efficient deployment for digital signage, featuring reliable, energy-efficient
hardware and intuitive server-based software. The Microsoft® Windows® based SA3000P/
SA3000T offers remote management of the hardware and the displayed content with the WebDT
Content Manager software. The SA3000P/ SA3000T together with the WebDT software, offers an
efficient solution for delivering and managing messages that target audiences in the right place,
at the right time.
1
2 3
Content Manager
Package Contents
1. One DT Research Signage Appliance
SA3000P/ SA3000T
2. Software and User Guide (including
WebDT Content Manager, and user
guides on Software Disk)
3. VESA-compliant Mounting Bracket
4. AC/DC Power Adapter
4
5. Basic Operation Guide
NOTE: The actual package contents may vary
depending on the configuration acquired.
