5.3 Battery Check; 5.4 Earthing The Measuring Instrument - Simco-Ion FMX-004 User Manual

5.3 Battery check

Switch the instrument on [POWER]
The battery indicator on the display shows the state of battery.
Battery fully charged Replace battery
Figure 2, battery condition

5.4 Earthing the measuring instrument

The case of the FMX-004 is made of a conductive plastic which provides an earth reference for
the measuring circuit. To ensure accurate measurement, the person performing the
measurement must be in good contact with earth, or the instrument must be earthed using the
supplied grounding lead.
36
