- Page 1 Motion Sensor – MOSZB-130 Technical manual Revised 05.02.2018...
-
Page 2: Table Of Contents
Motion Sensor - MOSZB-130 – Technical manual Content Cautionary notes ............................................. 6 Features ................................................. 7 Motion Sensor – MOSZB-130 ...................................... 7 2.1.1 IAS Zone ............................................7 2.1.2 Occupancy ............................................ 7 2.1.3 Light ..............................................7 2.1.4 Temperature ..........................................7 Key features ............................................7 Endpoints.............................................. - Page 3 Motion Sensor - MOSZB-130 – Technical manual 4.2.3 Poll Control - Cluster id 0x0020 ................................... 14 4.2.3.1 Attribute ..........................................14 4.2.4 OTA Upgrade – Cluster id 0x0019 ................................14 4.2.4.1 Attributes ..........................................15 4.2.4.2 Commands ........................................... 15 4.2.4.3 OTA Upgrade Messages Diagram ............................... 16 4.2.5...
- Page 4 Motion Sensor - MOSZB-130 – Technical manual Normal – Keep alive ........................................25 6.2.1 Network lost ..........................................25 Low battery ............................................26 Specifications ............................................27 Contact Information ..........................................28 Develco Products A/S Olof Palmes Allé 40 http://develcoproducts.com DK-8200 Aarhus N...
- Page 5 Develco Products assumes no responsibility for any errors, which may appear in this manual. Furthermore, Develco Products reserves the right to alter the hardware, software, and/or specifications detailed herein at any time without notice, and Develco Products does not make any commitment to update the information contained herein.
-
Page 6: Cautionary Notes
Develco Products A/S reserves the right to make changes to any product to improve reliability without further notice. Develco Products A/S does not assume any liability arising out of the application or use of any product or circuit described herein; neither does it convey any license under patent rights or the rights of third parties. -
Page 7: Features
Motion Sensor - MOSZB-130 – Technical manual 2 Features Motion Sensor – MOSZB-130 The device enables you to detect movement and light as well as measuring temperature. The sensor is battery powered and can be mounted in four different ways: flat on the wall, flat on the ceiling, in the corner (using a 45°... -
Page 8: Endpoints
Motion Sensor - MOSZB-130 – Technical manual 3 Endpoints The device implements the following standard HA devices on different end points. ZigBee Device Object (ZDO) End point number 0x00 Application profile Id 0x0000 Application device Id 0x0000 ... - Page 9 Motion Sensor - MOSZB-130 – Technical manual Reference documents: 053474r18ZB_CSG-ZigBee-Specification.pdf 075123r03ZB_AFG-ZigBee_Cluster_Library_Specification.pdf 053520r27ZB_HA_PTG-Home-Automation-Profile.pdf 075356r15ZB_ZSE-ZSE-AMI_Profile_Specification.pdf They can all be downloaded from : http://www.zigbee.org/Products/DownloadZigBeeTechnicalDocuments.aspx Develco Products A/S Olof Palmes Allé 40 http://develcoproducts.com DK-8200 Aarhus N info@develcoproducts.com...
-
Page 10: Supported Clusters
The ZCL “General Function Domain” clusters in this section are implemented as server clusters. Refer to ZigBee Cluster Library Specification. http://www.zigbee.org/Specifications.aspx 4.1.1 Basic – Cluster id 0x0000 Only the first set has mandatory attributes, also the optional attributes that can be relevant to a Develco Product’s device are all in set 0x000. 4.1.1.1 Attribute Name... -
Page 11: Commands
Motion Sensor - MOSZB-130 – Technical manual 4.1.2.2 Commands The identify cluster has 2 commands as server. Name Payload Man/Opt Relevance and ref. 0x00 Identify Uint16 - Identify Time (seconds) 0x01 Identify Query none The identify cluster has 1 command as client. -
Page 12: Commands
Motion Sensor - MOSZB-130 – Technical manual The attribute value will change from not enrolled (0x00) to Enrolled (0x01) 4.2.1.1.2 IAS CIE Address Attribute specifies the address that commands generated by the server shall be sent to. To un-enroll the device the back end system has to write a new address into this attribute. Any value is valid. If the back end system writes an IEEE adr then it will try to enrol to this devices represented by the IEEE adr. -
Page 13: Note: How To Clear A Alarm In The "Zone Status
Motion Sensor - MOSZB-130 – Technical manual Bit0, Bit2: Note: How to clear a alarm in the “Zone status” The sensor requests ZCL Default Response on the Zone Status Change notification, if any new Alarm bit has been set. Until the IAS CIE has acknowledged the received alarm by sending the mandated Default Response, the Alarm bits are not cleared –... -
Page 14: Poll Control - Cluster Id 0X0020
Motion Sensor - MOSZB-130 – Technical manual The condition will also be shown on the MMI LED, see MMI description. Reportable. Default Min 12 hours, max 12 hours Note: The attribute “BatteryVoltage” is measuring the battery voltage, in units of 100mV. -
Page 15: Attributes
Motion Sensor - MOSZB-130 – Technical manual When the devices has joined a network it will automatically auto scan for a OTA upgrade server in the network. If it finds a server an auto bind is created and ones every 24 hour it will automatically send its “current file version” to the OTA upgrade server. -
Page 16: Ota Upgrade Messages Diagram
Motion Sensor - MOSZB-130 – Technical manual 4.2.4.3 OTA Upgrade Messages Diagram Develco Products A/S Olof Palmes Allé 40 http://develcoproducts.com DK-8200 Aarhus N info@develcoproducts.com... -
Page 17: Time - Cluster Id 0X000A
Motion Sensor - MOSZB-130 – Technical manual 4.2.5 Time – Cluster id 0x000A The Time cluster is a general cluster for time it is based on a UTC time in seconds since 0 hrs 0 mins 0 sec on 1st January 2000. -
Page 18: Occupancy Sensor Device - Ep 0X22, Ep 0X28 And 0X29
Motion Sensor - MOSZB-130 – Technical manual Bit1: Fault. If set, the source can be read in the Reliability attribute 0x006F StatusFlag Map8 0x00-0x0F Reportable. Default Min 1 sec, max 10 min Occupancy Sensor Device – EP 0x22, EP 0x28 and 0x29... -
Page 19: Manufacture Specific Attribute
Uint16 Write/read is supported 0xfffd ZCL header setting – Manufactor code for Develco Products is 0x1015 4.3.2 Occupancy Sensor using temperature sensor input End point 0x22, 0x28 and 0x29 can be configured as a logic module that controls the occupancy sensor signal base on the user defined settings for the temperature sensor input. -
Page 20: Occupancy Sensor Using Illumination Sensor Input
Motion Sensor - MOSZB-130 – Technical manual The ArmThreshold_MinTemperature attribute can be used in winter season where the air condition shall warm up the room. The MinTemperature attribute is configured to 20 degrees and when movements are detected in the room and the temperature is below MinTemperature the air condition is turned on heating the room. -
Page 21: Temperature Sensor Device - Ep 0X26
Motion Sensor - MOSZB-130 – Technical manual 4.4 Temperature Sensor Device – EP 0x26 4.4.1 Temperature Measurement – Cluster id 0x0402 The temperature measurement cluster is described in ZigBee Cluster Library Specification section 4.4 4.4.1.1 Attribute Name Type Range Man/Opt Relevance and ref. -
Page 22: Light Sensor Device - Ep 0X27
Motion Sensor - MOSZB-130 – Technical manual 4.4.1.1.3 MaxMeasuredValue The temperature sensor is NOT supporting temperature measurements above 50 degrees Celsius. 4.5 Light Sensor Device – EP 0x27 4.5.1 Illuminance Measurement - Cluster id 0x0400 The illuminance measurement cluster is described in ZigBee Cluster Library Specification section 4.2 4.5.1.1... -
Page 23: Mmi User Guide
Motion Sensor - MOSZB-130 – Technical manual 5 MMI user guide Push Button Menu Pushing the button on a device provides the user with several possibilities. Pushing the button for longer (push, hold for a few seconds, and release) allows the user to set the device into a desired mode. -
Page 24: Ez Mode - Target
Motion Sensor - MOSZB-130 – Technical manual Occupancy sensing cluster Illuminance Measurement cluster The EZ-mode time is hard coded to 3 minutes. This is the Minimum and recommended PermitJoin time broadcast for EZ-Mode Network Steering and minimum IdentifyTime set for EZ-Mode Finding and Binding. If the user enters the menu again another 3 minutes is started. -
Page 25: General Network Behaviour
Motion Sensor - MOSZB-130 – Technical manual 6 General network behaviour Installation When the device is virgin and powered for the first time it will start looking for a ZigBee PAN Coordinator or router to join. The device will scan each ZigBee channel starting from 11 to 24. The LED will flash once every second until it joins a device. -
Page 26: Low Battery
Motion Sensor - MOSZB-130 – Technical manual #Scan mode - 1 #Sleep mode #Scan mode - 2 #Sleep mode #Scan mode - 2 MCU is in sleep Scan current ch 3 MCU is in sleep Scan current ch 3 Scan current ch 3... -
Page 27: Specifications
Motion Sensor - MOSZB-130 – Technical manual 7 Specifications General Dimensions (Wx H x D) 82 x 82 x 28 mm Colour White Battery CR123, exchangeable 3 years, reporting every 2 minutes Battery life Battery level and low battery warning can be reported... -
Page 28: Contact Information
Motion Sensor - MOSZB-130 – Technical manual 8 Contact Information Technical support: Please contact Develco Products for support. products@develcoproducts.com Sales: Please contact Develco Products for information on prices, availability, and lead time. info@develcoproducts.com Develco Products A/S Olof Palmes Allé 40 http://develcoproducts.com DK-8200 Aarhus N info@develcoproducts.com...
