  • Page 1 Technical Manual for ZHOT101 - ZigBee Occupancy, Temperature & Light Sensor...
  • Page 2 Develco Products assumes no responsibility for any errors, which may appear in this manual. Furthermore, Develco Products reserves the right to alter the hardware, software, and/or specifications detailed herein at any time without notice, and Develco Products does not make any commitment to update the information contained herein.

  • Page 3: Table Of Contents

    Contents Cautionary Notes ................4 Features .................... 5 2.1 ZHOT101 - ZigBee Occupancy, Temperature & Light Sensor ......5 2.2 Key features..................5 Endpoints ................... 6 3.1 ZigBee Device Object (ZDO) .............. 6 3.2 Occupancy Sensor ................6 3.3 Temperatur Sensor ................6 3.4 Light Sensor ..................

  • Page 4: Cautionary Notes

    Develco Products A/S reserves the right to make changes to any product to improve reliability without further notice. Develco Products A/S does not assume any liability arising out of the application or use of any product or circuit described herein; neither does it convey any license under patent rights or...

  • Page 5: Features

    2 Features 2.1 ZHOT101 - ZigBee Occupancy, Temperature & Light Sensor The multi sensor enables you to detect movement and light as well as measuring temperature. The sensor is battery powered and can be mounted in four different ways: flat on the wall, flat on the ceiling, in the corner (using a 45°...

  • Page 6: Endpoints

    Application device Id 0x0001 • Private profile for internal Develco Products use only. • The DevUtil end point support a Develco products specified bootloader. New firmware can be downloaded to the device using the SmartAMM server + SmartAMM client tool. EFERENCE DOCUMENTS 053474r18ZB_CSG-ZigBee-Specification.pdf 075123r03ZB_AFG-ZigBee_Cluster_Library_Specification.pdf...

  • Page 7: Supported Clusters

    0-32 byte 4.1.1.1.2 PowerSource 8 bit Type range enum 4.1.1.1.1 ManufacturerName “Develco Products A/S” 4.1.1.1.2 ModelIdentifier “ZHOT101 - ZigBee Occupancy, Temperature & Light Sensor” 4.1.2 Identify – Cluster id 0x0003 4.1.2.1 Attribute Name type range Relevance and ref. /Opt 0x0000...

  • Page 8: Occupancy Sensor Device - Ep 0X22, Ep 0X28 And 0X29

    4.2 Occupancy Sensor Device – EP 0x22, EP 0x28 and 0x29 Each end point contains a logic module that can be configured to control the occupancy sensor signal base on the user defined settings for the temperature sensor input or the user defined settings for the light sensor input.
  • Page 9 4.2.2 Occupancy Sensor using temperature sensor input End point 0x22, 0x28 and 0x29 can be configured as a logic module that controls the occupancy sensor signal base on the user defined settings for the temperature sensor input. Temperature measure value Occupancy state Cluster ID 0x0402 Attribute ID 0x0000...
  • Page 10 4.2.3 Occupancy Sensor using illumination sensor input End point 0x22, 0x28 and 0x29 can be configured as a logic module that controls the occupancy sensor signal base on the user defined settings for the illumination sensor input. Illuminance measure value Cluster ID 0x0400 Occupancy state Attribute ID 0x0000...

  • Page 11: Temperature Sensor Device - Ep 0X26

    4.2.4 Binary Input Basic - Cluster id 0x000F Each occupancy sensor end points support a binary input basic cluster with is used for tamper indication and acknowledge of the tamper. The basic cluster is mapped to the same internal values for each end point.

  • Page 12: Light Sensor Device - Ep 0X27

    4.4 Light Sensor Device – EP 0x27 The ZCL “Measurement and Sensing” cluster in this section is implemented as a server cluster. Refer to ZigBee Cluster Library Specification. 4.4.1 Illuminance Measurement - Cluster id 0x0400 The illuminance measurement cluster is described in ZigBee Cluster Library Specification section 4.2 4.4.1.1 Attribute Name type...

  • Page 13: Mmi User Guide

    5 MMI user guide 5.1 Push Button Menu: Pushing the button on a device provides the user with several possibilities. A single short push has a specific meaning for the given device, for this sensor a single short push will toggle the occupancy status (occupied/unoccupied.).

  • Page 14: Action On Power On

    5.3 Action on Power On As a general rule, all end devices and routers that have not previously joined a network (or have been reset to factory default) will start up and search for a coordinator on the channels enabled for that device.

  • Page 15: General Network Behaviour

    6 General network behaviour 6.1 Installation When the device is virgin and powered for the first time it will start looking for a ZigBee PAN Coordinator or router to join. The device will scan each ZigBee channel starting from 11 to 24. The LED will flash once every second until it joins a device.

  • Page 16: Low Battery

    6.3 Low battery The current battery voltage can be read from the power configuration cluster described in section 4.3.1. The attribute “BatteryVoltage” is measuring the battery voltage, in units of 100mV. There is no led indication for low battery on the PIR sensor itself.

  • Page 17: Zigbee Home Automation Commissioning

    7 ZigBee Home Automation Commissioning ZigBee Home Automation specifies a common language which all ZigBee Home Automation devices must use to document commissioning of the device. Below is a table outlining the Develco ZigBee HA device MMI using this common language. ZigBee Action Availability...

  • Page 18: Specifications

    8 Specifications 8.1 Common • Dimensions: 106 x 61 x 54 mm • Colour: White • Battery: CR123, exchangeable • Battery life: up to 5 years, hourly reporting • Operation temperature: 0 to +50°C • Sensitivity: -94 dBm • Output power: +3 dBm •...

  • Page 19: Contact Information

    9 Contact Information Technical support: Please contact Develco Products for support. products@develcoproducts.com Sales: Please contact Develco Products for information on prices, availability, and lead time. info@develcoproducts.com...

  • Page 20: About Develco Products A/S

    10 About Develco Products A/S Energy efficiency, Savings & Comfort Develco Products provides communication systems for AMR, AMI and Smart Metering. Develco Products presents a complete solution facilitating the remote control of appliances via intelligent electricity meters or gateways also capable of communicating with other meters.
