Golight Stryker Instruction Manual

Instruction Guide
Congratulations
You are now the owner of one of the finest remote control
searchlights available today. Thank you for letting Golight®
assist you in your lighting application needs. We're proud of our
products and the technology that we've developed to ensure our
customers the most durable, versatile and powerful searchlights
in the lighting industry.
Please read these instructions before using your new Golight®
Stryker™ LED.
IMPORTANT SAFETY INFORMATION
 This symbol is to alert you to important operating or
servicing instructions that appear in your instructions.
Always follow basic safety precautions when using
this product to reduce the risk of injury, fire or electric
shock.
 This light is for off road and utility use only. It is not designed
for road use as a driving light.
 The Stryker™ complies with Part. 15.105 of the FCC Rules.
This equipment has been tested and found to comply with the
limits for a Class B digital device. These limits are designed
to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
 FCC RULE Part. 15.21 - Changes or modifications made by
the user not expressly approved by Golight, Inc. for compliance
could void the user's authority to operate the equipment.
For safe and efficient operation of your Golight® Stryker™,
observe these guidelines:
Your Golight® Stryker™ is a radio transmitter and receiver
operating at 433MHz. Whenever the light is on, the internally
mounted antenna sends out and receives radio frequency (RF)
energy.
The Stryker™ is a 2-Speed Searchlight with Directional Flexibility
which gives the operator a full 370° horizontal rotation and a 135°
vertical tilt with fingertip control. The Stryker™ provides superior
light penetration with the new LED/PVEX lens technology.
Stryker™ Hard Wired - Permanent Mount:
Stryker™ Searchlight
Wiring Harness
Permanent Mounting Gasket
Permanent Mounting Plate
Mounting Screws
Dash Control
Stryker™ Wireless - Permanent Mount:
Stryker™ Searchlight
Remote Control (Per Model Number)
2 - 23A 12V Batteries
Permanent Mounting Gasket
Permanent Mounting Plate
Mounting Screws
Stryker™ Wireless - Magnetic Mount:
Stryker™ Searchlight
Wireless Hand Held Remote Control
2 - 23A 12V Batteries
MOUNTING INSTRUCTIONS
Light Unit/Permanent Mount
Determine the location for the light on your vehicle or boat.
Remove the mounting plate from the light. Center the mounting
plate with the vise screw on the mounting plate to the back. Mark
the hole locations for the three mounting screws and drill a pilot
hole for each with 1/8 inch bit. Fasten the stainless steel mounting
plate with the 3 #10 – 16x3/4 type AB cross recessed pan head
tapping screws. Drill a 1/4" hole (wireless) or a 5/8" hole (hard-
wired) in the center of the mounting plate opening to accommodate
the power wire or wiring harness and connector. Attach the
connector that is affixed to the underside of the light to the
corresponding connector on the wiring harness (hard-wired).
Position the connection point beneath the mounting surface, and
apply silicone sealant around wire to seal the drilled opening.
Wet the mounting surface with a small amount of water or
lubricant for easier installation, then place the light over the
mounting plate by sliding the front of the light over the front of the
mounting plate, first pull the light backwards, then seat the back of
the light on to the mounting plate. Displace the back of the gasket
and install the vise screw (provided). Tighten the vise screw using a
Phillips head screwdriver. Replace the gasket.
