Cobra DC5200 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Digital Camera
DC5200
User's Manual
www.cobradigital.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DC5200 and is the answer not in the manual?

Questions and answers

Jovan Lopez
May 23, 2025

My dc5200 stays on the logo on the screen

0
1 comments:
Mr. Anderson
May 25, 2025

The Cobra DC5200 may stay on the logo screen due to issues such as low or improperly installed batteries, a corrupted memory card, or internal software problems. Make sure the batteries are fully charged and correctly inserted, and try removing or replacing the memory card. If the issue persists, it may require a reset or technical service.

This answer is automatically generated

0

Related Manuals for Cobra DC5200

Summary of Contents for Cobra DC5200

  • Page 1 Digital Camera DC5200 User’s Manual www.cobradigital.com...

  • Page 2: Table Of Contents

    Contents Chapter 1 Attention 1-1 Attention 1-2 Before using your camera 1-3 Copyright information 1-4 Caution when using the camera Chapter 2 Getting to know your camera 2-1 Functional parts of the camera 2-2 Monitor screen display Chapter 3 Preparing for use 3-1 Load batteries and Memory card 3-2 Turn on/off the camera 3-3 Set up...

  • Page 3: Chapter 1 Attention

    Chapter 1 Attention Please read this manual carefully before using the camera and follow its instructions closely to avoid causing any damage. 1-1 Important The software CD-ROM packaged with the camera is designed for a PC only. Playing this CD-ROM on a CD player may cause damage. This camera is a precision electronic device;...

  • Page 4: Copyright Information

    camera (such as costs of photography or any loss of benefit generated by the photography) is not the responsibility of the manufacturer and no compensation will be given for it. 1-3 Copyright information Unless agreed by the copyright owner, no pictures taken with this digital camera can be used in violation of copyright law.
  • Page 5 ● Avoid using or placing the camera in places which are: Damp and dusty; Exposed to direct sunlight or places subject to extremely high temperatures or heat; Violently turbulent environments; Locations full of smoke, oil fumes or steam; In raining or snowing environments.

  • Page 6: Chapter 2 Getting To Know Your Camera

    make contact with the camera to avoid scratching the lens, the LCD monitor or the viewfinder surface. Do not use any detergents or volatile solutions, which could affect the camera case and cause paint to dissolve or distort. Use a soft cloth only. Chapter 2 Getting to know your camera 2-1 Functional parts of the camera...

  • Page 7: Monitor Screen Display

    1. Flash light 11. Battery cover /Memory Card slot 2. Self-time LED 12. Up button 3. Lens 13. Right button 4. Viewfinder 14. Menu button 5. USB jack 15. Down button 6. Tripod socket 16. Flash button 7. Flash LED 17.

  • Page 8: Chapter 3 Preparing For Use

    Chapter 3 Preparing for use 3-1 Load batteries and Memory card Open the battery cover and insert three new AAA alkaline batteries into the battery compartment with the polarity correctly aligned as shown on the battery door. When the batteries are low, there will have a choice icon appear on the screen, you need to select what kind of battery you want to use, if you select alkaline battery, you should select...
  • Page 9 half , then you can not use the flash light, but your still can take picture until the icon display empty, if you choose rechargeable battery, you need to select 2, then battery capacity icon still display full, you still can take picture until the icon display empty.

  • Page 10: Set Up

    operation LED lights, when the camera is on, press the ON/OFF button for 2 seconds will turn off the camera, the camera will turn off automatically after 30 seconds of inactivity if not connected to USB, the time can set by the AUTO POWER OFF function.
  • Page 11 1.2 Colour option Press the menu button will enter the capture select window, Press RIGHT button to enter colour menu. Press UP or DOWN button to select the Auto, then press menu button to confirm. Note: Using this function to make the items: exposure ,White balance and sharpness to default setting.
  • Page 12 Adjusting the exposure value: You can adjust the EV from -1.5 to 1.5 Press the menu button will enter the capture select window, Press RIGHT button to enter colour menu. Press UP or DOWN button to select Exposure, then press menu button to confirm. In the submenu press the UP or DOWN button to adjust the value.
  • Page 13 submenu. In the submenu press the UP or DOWN button to choose the item that you want, and then press the MENU button to confirm the setting. MENU Adjusting Sharpness option: Press the menu button will enter the capture select window, Press RIGHT button to enter colour menu.
  • Page 14 MENU 1.3 Resolution: Press the menu button will enter the capture select window, then press the RIGHT button twice to enter the Resolution window. Press UP or DOWN button to select the resolution and then press the MENU button to confirm the setting.
  • Page 15 select window, then press the RIGHT button until the Quality menu appears. Press the UP or DOWN button to select the item that you want, and then press the MENU button to confirm the setting. 1.5 Auto power off time: Press the menu button will enter the capture select window, then press the RIGHT button until the Auto Power Off menu appears.
  • Page 16 Auto Power Off Auto Power Off Cancel Cancel Auto Power Off Auto Power Off 1.6 Date and Time: Press the menu button will enter the capture select window, then press the RIGHT button until the Date& Time menu appears. Press the DOWN button to select “Set”, and press the menu button to enter the submenu of Date&...
  • Page 17 NO DISPLAY. Date Time Da te Time Menu DOWN Cancel Cancel Auto Power Off Auto Power Off LEFT/ RI GHT Menu 03:00 Menu 2002 2002 01 01 11:11:11 11:11:11 LEFT/RIGHT UP/DOWN UP/DOWN 1.7 Frequency: Set the anti-flicker frequency if you use Fluorescent light.
  • Page 18 Frequency Cancel 50Hz 60Hz 1.8 Language: Press the menu button will enter the capture select window, then press the RIGHT button until the window of Language appears. Press UP or DOWN button to select the language. And then press the MENU button to confirm the setting.
  • Page 19 playback mode, the latest recording file will be shown on the LCD .Press the RIGHT or LEFT button to view the previous or next file. In playback mode press the PLAYBACK button again to return to recording mode. 2.1 Erase: In playback mode press the MENU button to enter the Erase window.
  • Page 20 (erase all).Press the MENU button to confirm the setting. When you select “Format” the camera will format the memory card if you have inserted a memory card otherwise it will format the internal memory. Erase Cancel Format Protect Protect mode: If some file is important to you please use this function to keep the file from been deleted by accident.
  • Page 21 Erase Cancel Format Protect If you want to cancel the protecting function ,you can operate the camera as the following steps: Erase Cancel Format Unprotect 2.2 Auto power off time See the details on page 14. 2.3 Date and Time...
  • Page 22 See the details on page 15. 2.4 DPOF Press the menu button will enter the Erase select window, then press the RIGHT button until the window of DPOF appears. press DOWN button to select “Set”, and then press the MENU button to confirm the setting. You can press the RIGHT or LEFT button to choose the image to be printed, and you can press the UP or DOWN button to set the...
  • Page 23 2.6 Digital zoom In the still image preview mode, Press the menu button will enter the Erase select window, then press the RIGHT button until the window of ZOOM appears. Press the DOWN button to select “Pan”. If you want to activate the pan function you must enlarge the image firstly.

  • Page 24: Using Your Digital Camera

    enlarge the selected picture up to 4 times. * In Pan mode: Press the DOWN button to select “Pan” in zoom window, then press the MENU button to confirm the setting. Now press the UP/DOWN/LEFT/RIGHT buttons to adjust the zooming area to each part of the picture.
  • Page 25 to enter capture mode. Point the camera at the subject, use the monitor screen or the viewfinder to compose the image. While holding the camera still, gently press the Shutter button to take the picture. You will hear a beep sound indicating that the snapshot has been completed.
  • Page 26 get into Capture window, press the UP or DOWN button to select “Video 320x240” or “Video 192x144”, then press the MENU button to confirm. Press the Shutter button to make the video. Press the Shutter button again to stop recording. Note: The video resolutions are (192x144) and (320x240) Using the flash...
  • Page 27 time you take a picture, regardless of the lighting conditions. Using the digital zoom In the recording modes, you can use the digital zoom. Press the UP button to zoom in; press the DOWN button to zoom out. Previewing pictures The default setting of the Preview mode automatically displays one image or video file in the LCD screen.
  • Page 28 In the Preview setting mode, Set the camera to the Preview mode. Connect the camera to the computer with a USB cable. Turn on your camera. In Windows 2000 / ME, double click the “My Computer” icon on the desktop; the “My Computer”...
  • Page 29 driver automatically. After the driver is installed, the camera will be recognized as a Removable Disk. How to use the PC camera function Please install the camera driver first. Connect the camera to the computer with a USB cable, run the program Amcap under the folder <Sunplus Ca531a>...
  • Page 30 If you want to change the imaging size, select <Video Capture Pin> to change the Output Size.
  • Page 31 Chapter 4 How to install and use the application software Insert the installation CD into your CD-ROM drive; the installation CD menu should appear. If the menu does not appear, double-click the CD drive icon in <My Computer> or run D:\Autorun.exe to open the setup screen (assuming that your CD-ROM drive is in drive D:).
  • Page 32 Taking your computer system is WinXP for example: select “Win98/WinMe/Win2000/WinXP” then click “Install”.
  • Page 33 This picture will appear, click “Next”...
  • Page 34 When this picture appear, click “Next”. When this picture appear, click “Finish”. The installation of PC Camera drive is completed. A icon will appear on your computer which can link to the website: www.cobradigital.lifepics.com.

  • Page 35: Installation Of The Application

    4-2 Installation of the application When you see the following screen, select <Install Photo Express> to install the < Photo Express 4.0> software. Follow the instructions on the screen to finish the installation.
  • Page 36 The <Language select> dialogue box will appear. You can select a language you want, such as <English> and then click <OK>.
  • Page 37 The "Welcome" message appears. Click "Next" to continue. The " License Agreement" dialogue box appears; click <Yes> to accept it.
  • Page 38 The "Choose Destination Location" message appears and according to the language instruction, choose an installation route (Optional). Click "Next".
  • Page 39 The interface changes into "Select Components"; click "Next".
  • Page 40 "Select Program Folder” window appears; click "Next" to install the driver.
  • Page 41 The “Setup Status” window appears , please wait a few minutes until the window “InstallShield Wizard Complete” appear, then click “Finish” to complete the installation. Installed software will automatically create an icon on the computer.

  • Page 43: Chapter 5 Specifications

    Chapter 5 Specifications 4-in-1 mode: Digital Still Camera mode: image capturing PC Camera mode: video capturing conferencing Camcorder mode: video clips U-disk Sensor: CMOS sensor, 3Mega pixel, 5Mega pixel via interpolation Lens: F=3.0 f=8.35 Focus range: 1.5M to infinity Illumination: 100-16000 (lux) Shutter speed: Electronic shutter 1/20-1/6000 s Image resolution:...
  • Page 44 (1280X1024) for image capturing VGA (640X480) / QVGA (320X240) for PC Camera mode QVGA (320X240) / QCIF(192X144) for Video Recording mode Memory: External - SD and MMC card compatible Self Timer: 10 sec. ZOOM: 4 x Digital zoom Colour LCD screen: 1.5 inch TFT display OSD languages: English, French, German, Spanish, Italian, Dutch,...
  • Page 45 PC requirements: CPU: Pentium III 800MHz and higher Windows 98SE/2000/ME/XP/VISTA Memory: 128MB and higher memory Disk space: at least 250MB free space on CD-ROM drive Chapter 6 FAQ’s (Frequently asked question) 6-1 The camera does not power on 1. The battery is not properly inserted --- Remove and re-insert the batteries.
  • Page 46 Note: Remove the batteries if the camera is not going to be used for some time. This will conserve battery life. 6-2 The flash does not fire 1. The flash is set to Off --- Set the flash to Auto or On. 2.
  • Page 47 1. The subject is out of focus --- Ensure that there is 1.5m (5ft) at least between the camera lens and the subject. 2. The camera moved --- After pressing the shutter button, keep your hand steady for 2 seconds to get the best result. When the flash is on, hold the camera steady until the flash has fired two times (the first flash is to reduce a red-eye phenomenon and to detect the...
  • Page 48 recorded image Incorrect frequency setting --- Select the correct anti-flicker frequency (50Hz or 60Hz) under fluorescent light setting. 6-6 Picture download problem 1. The computer does not recognize the camera --- For Windows 98SE, the camera driver needs to be installed first before downloading any pictures.
  • Page 49 under MSDC mode. It is always recommended that you disconnect your digital camera from the computer on the desktop using the safety unplug button, to ensure that the USB port is released for future interfaces. 2. The flash drive does not display recorded images --- The camera will load two Removable flash drives on your computer under MSDC mode.
  • Page 50 Right click [My Computer] > Manage > Disk Management. Right click blue bar of Removable disk which is on line > Change Drive Letter & Paths > Change > Assign the Following Drive Letter (assign an unused drive name) > OK. Open the new renamed Removable flash drive to download the recorded pictures.
