  • Page 1 REOVIB Control Equipment for the Vibratory Feeder Industry MFS 268 Frequency Converter for Vibratory Feeders Appendix: EtherNet-IP - Programming MFS_268_EtherNetIP_appendix_rev03.en 02.08.2016...

  • Page 2: Technical Safety Instructions For The User

    REOVIB MFS 268 Operating Instructions EtherNet/IP - Programming Technical safety instructions for the user This description contains the necessary information for the correct application of the product described below. It is intended for use by technically qualified personal. Qualified personnel are persons who, because of their training, experience and position as well as their...

  • Page 3: Table Of Contents

    REOVIB MFS 268 Operating Instructions EtherNet/IP - Programming Contents Technical safety instructions for the user ..................... 2 1.0 General ..............................4 2.0 Interface operation (EtherNet-IP ) ......................5 3.0 Activate interface ............................ 5 4.0 EDS-File ..............................5 5.0 Bus operating modes..........................5 5.1 Programming for the Bus operation ....................

  • Page 4: General

    REOVIB MFS 268 Operating Instructions EtherNet/IP - Programming 1.0 General The MFS 268 range of frequency converters for vibratory feeders can operate with an EtherNet-IP inter- face. In normal operation the set point, for the feeder throughput, can be sent from a PLC to the controller and the unit ready/fault status signals are fed back.

  • Page 5: Interface Operation (Ethernet-Ip )

    REOVIB MFS 268 Operating Instructions EtherNet/IP - Programming 2.0 Interface operation (EtherNet-IP ) Bus Power Supply 24 V, DC, 250 mA Bus connector 2 x RJ-45 Internal interface CAN-Bus Supported baud rates 1000 kBaud Communication Data consistency required Protocol EtherNet-IP 3.0 Activate interface...

  • Page 6: Programming For The Bus Operation

    REOVIB MFS 268 Operating Instructions EtherNet/IP - Programming 5.1 Programming for the Bus operation In normal operation the set point for Amplitude (throughout/feed rate) and the digital control signals, such as enable are set across the interface. The actual voltage/current values and unit status (ready or fault) are fed back.

  • Page 7: Parameter Operation

    REOVIB MFS 268 Operating Instructions EtherNet/IP - Programming 5.2 Parameter Operation In parameter operation, the specific unit parameters can be monitored and adjusted. A `write` enable must be transmitted before parameters can be altered. On closing, the `write` enable must be cancelled.

  • Page 8: Receive, Acknowledge Write Enable

    REOVIB MFS 268 Operating Instructions EtherNet/IP - Programming 5.2.3 Receive, Acknowledge Write Enable H-Byte L-Byte Word 1 xxxx H (undefined) H-Byte L-Byte Word 2 C0DE H H-Byte L-Byte Word 3 B5E7 H H-Byte L-Byte Word 4 C0DE H The parameters can be sent after receipt of the acknowledge 5.2.4 Send Parameter...

  • Page 9: Close Write Enable

    REOVIB MFS 268 Operating Instructions EtherNet/IP - Programming 5.2.5 Close write enable H-Byte L-Byte Wort d 0000 H H-Byte L-Byte Word 2 Write Enable Address = C0DE H H-Byte L-Byte Word 3 Enable Value 0000 H-Byte L-Byte Word 4 15 14 13 12 11 10 9...

  • Page 10: Parameter Table

    REOVIB MFS 268 Operating Instructions EtherNet/IP - Programming 6.0 Parameter Table Non listed addresses cannot be altered! Parameter: Adjustment Display- Factory Entry Parameter Value Code Setting: code address HEX (.bit) Vibratory feeder 0x0000...0xFFFF 0...100 % 000, 100C Amplitude (throughput) •...
  • Page 11 REOVIB MFS 268 Operating Instructions EtherNet/IP - Programming Parameter: Adjustment Display- Factory Entry Parameter Value Code Setting: code address HEX (.bit) Service limits 0x0000 / 0x FFFF 0 / I En.S. 0x5834 • Enable service menu 0x0000...0x8000 H 0x200A • Show output current (0... 100 %) 0x01F4...0x7530 H...

  • Page 12: Example Of Bus Communication With Frequency Controller

    REOVIB MFS 268 Operating Instructions EtherNet/IP - Programming 7.0 Example of bus communication with Frequency controller Variable values are shown in italics. 7.1 Normal mode (Set point to 70 %) Word Code send Code Received 0000 H 0000 H B332 H...
  • Page 13 REOVIB MFS 268 Operating Instructions EtherNet/IP - Programming Example of switch parameter change Enable invert send Received Word Code Code 0000 H 0000 H C0DE H Write Enable Address C0DE H Acknowledge B5E7 H Write Enable Value B5E7 H Acknowledge...

  • Page 14: Reset Controller

    REOVIB MFS 268 Operating Instructions EtherNet/IP - Programming 7.3 RESET Controller Word Code send Code received 0000 H 0000 H C0DE H Write Enable Address C0DE H Acknowledge B5C9 H Write Enable Value B5C9 H Acknowledge 8000 H + Set mode bit = 1...

  • Page 15: Methods For Adjusting The Ip-Address

    REOVIB MFS 268 Operating Instructions EtherNet/IP - Programming 8.0 Methods for adjusting the IP-address 1. Web server (Preferably) 2. DHCP Server Utility If you don’t have a browser, you can push a switch on the front of our device. If you push this switch shorter than five seconds, the device gets the IP-address 192.168.11.182.
  • Page 16 REOVIB MFS 268 Operating Instructions EtherNet/IP - Programming 5. Then you double-click on „Internet Protocol Version 4 (TCP/IPv4)“ 6. Then you set the subnet mask at 255.255.240.0. 7. You click on „OK“. 8. Then you open the web browser (e.g. the Internet-Explorer).

  • Page 17: Dhcp Server Utility (Example: „Bootp/Dhcp Server")

    REOVIB MFS 268 Operating Instructions EtherNet/IP - Programming 8.2 DHCP Server Utility (Example: „BOOTP/DHCP Server“) 1. Please download a DHCP Server software for example: „DHCP/BOOTP Utility“. Important: Before you start the DHCP-server, note the MAC-address which has the following form: 00-00-BC-14-55-35. The MAC-address stands on the front of the module.
  • Page 18 REOVIB MFS 268 Operating Instructions EtherNet/IP - Programming...
  • Page 19 REOVIB MFS 268 Operating Instructions EtherNet/IP - Programming...
  • Page 20 REO Shanghai Inductive Components Co., Ltd No. 536 ShangFeng Road · Pudong, 201201 Shanghai · China REO Vibratory Feeding and Power Electronics Division Tel.: +86 (0)21 5858 0686 · Fax: +86 (0)21 5858 0289 Brühler Straße 100 · D-42657 Solingen E-Mail: info@reo.cn ·...
