Superwinch LT3000 Owner's Manual

Si el motor del guinche se atasca, no continue energizando
CAUTION
!
el motor.
SERVICIO INTERMITENTE
Un guinche electrico es similar a cualquier otra herramienta electrica, tal
como un taladro o una sierra. No debe permitirse que el motor se sobrecali-
ente. Tomanado precauciones normales se prolongara la vida util del motor.
Mantenaga la duracion de la traccion con el guinche lo mas corta posible
Si el motor se calienta hasta el punto en que esta demasiado cali-
ente al tacto, interrumpa el trabajo y deje que el moto se enfrie.
Para obtener mas informacion y datos de la garantia, conectese a
www.superwinch.com
LT4000 ATV LISTA DE REPUESTOS
10.
11.
12.
Reference número. Description
1 Cable
2 Motor
3 Tambor y barras de unión
4 Reductor de engranajes
5 Solenoide
6 Interruptor de manubrio
7 Control remoto
8 Interruptor
9 Gancho con reten
10 Dyneema® sintético europa
11 Guiacabos de rodillos
12 Aluminio Hawse
24
1. 7.
8.
2.
9.
3.
Numero de parte
1511F
. 87-24078
87-24075
87-24079
87-12893
87-12894
87-12895
87-22873-16
87-42615
87-24076
87-12911
87-24077
LT3000 ATV
CAUTION
!
5.
Superwinch, LLC.
359 Lake Road
Dayville, CT
06241 USA
tel: 1.800.323.2031
6.
fax: 1.860.963.0811
sales@superwinch.com
www.superwinch.com
Throughout this manual, you will find notations with the following headings:
DANGER
!
4.
WARNING
!
CAUTION
!
The following symbols on the product and in the Owner's manual are used:
Read Owner's
Manual
Note: Indicates additional information in the installation and operation procedures of your winch.
Correct installation of your winch is a requirement for proper operation.
Please Note: Winch is designed primarily for intermittent applications. This winch is not designed to
be used in industrial or hoisting applications and Superwinch does not warrant it to be suitable for
such use.
87-10994 Rev A 4/8/2014
OWNER'S GUIDE
3,000 lb (1361 kg)
LT4000 ATV
4,000 lb (1814 kg)
12 Volt DC Electric Winch
READ AND UNDERSTAND THIS GUIDE BEFORE
INSTALLATION AND OPERATION.
Indicates an imminently hazardous situation which, if not avoided,
will result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided,
may result in minor or moderate injury. This notation is also used
to alert against unsafe practices.
Always Use Keep clear of winch,
Handsaver wire rope and hook
while operating
Superwinch, LTD.
Union Mine Road
Pitts Cleave
Tavistock, Devon UK
PL19 0NS
tel: +44 (0) 1822 614101
fax: +44 (0) 1822 615204
sales@superwinch.net
www.superwinch.com
Never use winch Never use
to lift or move winch to hold
people loads in place
